R-Biopharm Lumitester PD-20 Reference guide

Equipment / Software / Accessories
10/2009
R-Biopharm AG
An der neuen Bergstraße 17, 64297 Darmstadt, Germany
Phone: [phone] - 81 02-0, Fax: [phone] - 81 02-40
E-mail: [e-mail], www.r-biopharm.com
• Use a new Lucipac Pen for each measurement.
• With Lumitester PD-20 up to 2,000 measurements can be
performed which will be saved as separate data sets within
the data memory of the device.
• By connecting Lumitester PD-20 to a computer the data can
be uploaded and saved.
• To transfer the data to Microsoft Excel open the programme
first and click on “Data” in the menu bar, then click on
“Import Data”. The assistant for import of data will guide you
through converting the data into the table form desired.
R-Biopharm – for reliable analysis.
Flowchart
AMP/ATP measurement with LuciPac Pen and
Lumitester PD-20
Brief information
• Prior to performance of the first test with
LuciPac Pen and Lumitester PD-20 read the
instructions for preparation of the device and
follow the steps for installation which are
described within the instruction manual.
• The manual can be found on the CD which is included
in the package. The manual also contains a detailed
description of the handling of the device.
• Please note that the control software has to be
installed first before connecting the Lumitester PD-20
to a computer.
• The driver software will be installed after the
connection has been made.
• Instructions for installation are included in
the instruction manual for the control
software.
Data transfer
From Lumitester PD-20

8
Equipment / Software / Accessories
6
7
9
8
10
Put the swab back into the tube and
push it downwards until the holder is
completely inserted into the tube.
Shake the LuciPac Pen repeatedly in
direction of arrow (horizontal) so that
the liquid in the capsule falls into the
reaction tube and dissolves the regent.
Insert the LuciPac Pen into the measuring
chamber of the Lumitester PD-20 and
close the chamber cover.
Press ENTER to start the measurement.
The result will be displayed after a
countdown from 10 to 0.
Keep instrument steady in an upright
position during the measurement.
Remove LuciPac Pen from the chamber
after measurement.
1
2
4
3
5
Take LuciPac Pen tubes out of the
refrigerator 20 min prior to use and
bring them to room temperature.
Do not use cold Lucipac Pen test tubes.
Turn on Lumitester PD-20 by pressing
POWER button.
Remove swab stick (orange holder)
from the test tube.
Moisten swab with tap water.
Swab the surface which you want to test.
20
min.
