R.T. LARGE MRTL263 FUSO User manual

Installation and aftercare instructions:
Before you start it is recommended that the mirror is secured to a suitably reinforced wall to ensure stability. Wall plugs
are only suitable for solid stone/brick walls. For plasterboard walls use specialist wall plugs (not supplied).
Wear suitable eye protection when drilling. Take care when using power tools near water -the use of a residual current
device (RCD) is recommended. Beware of hidden pipes or cables. Take care when drilling tiled surfaces as the drill might
slip. Use a piece of masking tape to prevent the drill from wandering.
Unit 2 Bluebell Industrial Estate, Dublin 12
Tel: [phone] Email: [e-mail]
www.rtlarge.ie
460MM
145MM
45MM
Features:
High density LED technology
IR Motion sensor switch
SQ Class ultra-clear flat glass surface
Copper free silver mirror with Valspar Anti-Oxidation coating
LED lifespan over 100,000 hours
Compliant with CE, EMC, LVD, IP44, RoHS
MRTL263 FUSO
(DL-03D-W)
700MM
550MM

Installation Procedure
IMPORTANT: ALLWAYS SWITCH OFF THE ELECTRICAL SUPPLY AT THE MAINS DURING INSTALLATION AND MAINTENANCE.
1. Before installation. Decide on a desired location for the mirror. Be mindful of hidden water pipes or electrical cables
behind the wall. It is recommended that infrared sensor (if applied) is kept a minimum distance of 150mm from the
adjacent wall.
2. Drill the holes in the wall for the screw plugs supplied in the fixing kit. Ensure the holes are horizontal using a spirit level.
Fasten the screws into the plugs leaving the screw head protruding about 10 - 8mm from the wall.
3. Unscrew the lid of the plastic box at the back of the mirror. Use the electrical connections found inside the box to
connect the mirror to the main supply in accordance with the current IEE regulations. Once the connection is made, screw
the lid back on the plastic box. Hang the mirror on the wall and switch on the electrical supply.
Unit 2 Bluebell Industrial Estate, Dublin 12
Tel: [phone] Email: [e-mail]
www.rtlarge.ie
Colour coding:
L - Live = Brown
N - Neutral = Blue
E - Earth = Green & Yellow

[e-mail]
be left on for prolonged periods of time.
abrasive cloth when turned off. Never use cleaning agents
tact with the electrical
ery hot or very cold items against or in close
Operating Instructions
Lighting is turned on/off using the IR motion sensor switch on the lower right of the mirror, to operate, cover the
sensor zone by moving your finger over it, please note there is 10~15cm distance required from the sensor to the
wall in order to make it work.
Electrical Safety Instructions
All fittings must be installed by a competent person, in accordance with current IEE wiring regulations. If in doubt please
consult a qualified electrician.
Safety, Care and Cleaning
DO NOT strike glass components with hard or pointed items. DO NOT place v
proximity to glass surfaces unless an adequately thick insulation material is used to prevent such items coming in contact
with the glass.
The nominal thickness of the mirror glass used in this product is 5mm. If the glass becomes chipped or broken replace
immediately.
This product should not be positioned near curtains and/or other fabrics. Never cover the mirror. This product maybe
become heated, we recommend that it is turned off after use and should never
It is recommended that the unit is cleaned with a soft, dry, non
or abrasive materials on any type of surface finish. Do not allow moisture to come into con
components.
Customer Care:
Fur further information please call: [phone]
