R3D i FR150 Installation guide

Product Training
FR150 Bright Flip Phone
V1.4, November 14, 2022

R3DI – PRONOUNCED “RED EYE” IS WHAT HAPPENS WHEN
THE PASSION FOR “ADVENTURE” MEETS REAL LIFE
EXPERIENCES AND THE NEED TO BE SAFELY SECURED.
EMPOWERING USERS WITH PEACE OF MIND ALONG THEIR
JOURNEY, NO MATTER WHAT.
FOR THE SMART ADVENTURER.
OVERVIEW

FR150 Bright Flip Phone
4G LTE Flip Phone
For things that matter most
The Bright Flip Phone is a simple phone with a
dedicated security & tracking feature. It
includes all of the must have features and
great call clarity, plus the added options for
safety & convenience, along with Best-in-Class
specs.
HIGHLIGHTS
•Compatible with most US Wireless Networks
•Integrated Extra Bright LED Flashlight
•Integrated Security feature & Panic Button
•High volume loudspeaker mode *100dB
•Extended talk, large 1600mAh battery
•Solid construction and IP52 rating
•Large format keypad layout
•Large and Bright 2.8” QVGA-262K main
screen, 1.54” External display
•Hall sensor equipped for ease of use on the
dual LCD displays
•3.5mm American Standard headset jack
•HAC M4/T4, HD Voice, VoLTE

The FR150 Specifications
SOS Button
THE
BASICS
Qualcomm –4CProcessor KAI OS
2.5.4 –Operating System 512MB +
4GB Memory +32GBMicro SD slot,
4FF SIM Card Slot
NETWORK FDD LTE –
B2/B4/B5/B12/B13/B25/B26/B71/B66
TDD-LTE –B41
WCDMA –B2/B4/B5
CDMA –BC0/BC1/BC10
GSM –B2/B3/B5/B8
CONNECTIVITY WiFi: 802.11 b/g/n 2.4GHz with WIFI
Direct & Hotspot 2.0, BTv4.2
VoLTE Capable
BATTERY &
CHARGING
INFORMATION
Type: 1600 mAh, Removable Li-ion
Capacity: 5H Talk, 200H Standby
Quick charge –5VO.55A
Type A to Micro USB
CAMERA 2.0 MP Fixed Focus 1600x1200
resolution 720P Video capture
70 Lumens LED Flash
PHYSICAL Dimensions: 111x 55.6 x 19.1mm
Weight: 135g
IP52
DISPLAYS Main –2.8” LCD QVGA (240*320),
262K colors, TFT, 300 TYP Brightness,
PPI 143
External –1.54” LCD (240*240),
262K colors
MEDIA Video Format –3GP, MPEG-4
Image format –PNG, GIF, JPG, BMP
Video decode/encode –Decode:
H.265(HEVC) H.264(AVC), H.263, MPEG-
4, VP8; support for 720P Encode; H.264,
H.263, MPEG-4, AVC;
support for 480P
Audio format –MP3, OGG, AMR,
ACC, WAV, MIDI, M4A
FM Radio
Recorder
GPS, AGPS
Hall Sensor
THE BELLS &
WHISTLES
BEST IN CLASS
Built-in 70 Lumens Flashlight Extra loud
100dB speaker phone Panic Button &
Security feature Large format keypad
Slim line design for ease of carry
Voice Read-Out mode capable
APPROVALS
OR IN PROCESS
FCC, PTCRB, RoHS & Reach,
HAC M4/T3, TTY
*Data plan may be required. Coverage subject to network availability.
**Battery life may vary depending upon coverage and/or number of connecteddevices.

The FR150 Diagram
2.0 MP
CAMERA
70 LUMENS
FLASHLIGHT
EXTERNAL LCD
DISPLAY
SATIN FRONT
TOP COVER
BOLTED
TOGETHER
CHASSIS
CAMERA
& VOLUME KEYS
REMOVEABLE
BATTERY COVER +
REMOVEABLE XL
1600 mAh BATTERY
STOP
POSITION
Rubber Matt
4-WAY
NAVIKEY
XL MAIN SIMPLE
KEYPAD LAYOUT
XL RECEIVER
SPEAKER
MAIN 2.8” QVGA
LCD DISPLAY
XL LOUD
SPEAKER
SOS KEY
SECURITY
FEATURE-PANIC
BUTTON
POWER
KEY
3.5mm HEADSET JACK
MICRO USB 2.0 CHARGER
“OK”
BUTTON
In-Box Contents:
•FR150 Bright Flip Phone
•Micro USB Wall Charger
•Quick Start Guide
•Battery Pack (Li-Ion)
•Battery Door
Note: Additional accessories are
available at www.R3Di.com.

The FR150 Display Diagram
STATUS BAR
NOTICE
MENU/APP LIST
SHORTCUTS
Status Bar Notification Icons:

The FR150 Display Diagram
STATUS BAR
NOTICE
MENU/APP LIST
SHORTCUTS
Status Bar Notification Icons:

The FR150 Menu + Apps List

CONFIDENTIAL –For Use Under NDA Only
The FR150 Getting Started
Bright Flip Quick Start Guide
R3Di FR150
4G LTE Network Bands
B2/B4/B5/B12/B13/B25/B26/B41/B66/B71
About Your FR150 Bright Flip Phone
Phone Setup
1. Remove the back cover by gently pulling up on the
indentation on the bottom left of the cover.
2. Remove the battery by gently pulling up on the indentation
on the upper right of the battery.
3. Insert the 4FF SIM card by carefully sliding it into the “SIM”
slot on the right with the gold section facing down and the
slanted corner to the right.
4. If desired, you can insert a microSD card (not included) into
the ‘microSD’ slot on the right. Ensure that the gold section is
facing down, and the flat edge is facing the top. Reattach the
back cover of the phone. Please see illustrations to verify
correct card insertion orientation. To remove the SIM or
microSD card, push down on the plastic spring and pull the
SIM or microSD card out carefully.
WARNING: To avoid damage to the phone, only use a standard
nano-SIM card provided by your service provider.
Using Your Phone
Charging Your Phone
You should charge your phone fully before use. To do so, insert
the Micro USB cable to the device Micro USB port and plug the
other end into to the wall charger.
Note: Use only the charger USB cable supplied with the
phone. Use of incompatible chargers may cause damage to your
device and void the warranty.
Power On/Off Your Phone
To turn on your phone, long press the power key. You will see the
logo and wait for the phone to boot up and come to the home
page.
Note: You will need to complete the initial set-up steps when you
power on the phone the first time.
To turn off your phone, long press the power key, and navigate to
“Power off”.
Camera and Video
Take a Picture
1. Press the Camera key, or press the OK key to go into the
menu to select Camera , or use the Navigation ring
to press the right key to open the Camera .
2. Press the Right Soft key to display camera options
and settings.
3. Zoom in and out by tapping the Navigation ring up (+)
to zoom in, tap Navigation ring down (-) to zoom out.
4. Press the OK key to take a picture. After taking the picture,
press the Left Soft key to preview.
Take a Video
1. Press the Camera key or press the OK key from the Home
screen and select Camera .
2. Press the Navigation ring to scroll to the right until
the Camera is highlighted. Press the OK key to enter
Camera mode.
3. Use the Navigation ring to scroll to the right and
switch to Video mode.
4. Press the OK key to start and stop recording video.
View Pictures
1. From the Home screen, press the OK key to open the Main
Menu.
2. Use the Navigation ring to scroll down and to the
right until Gallery is highlighted. Press the OK key to
select Gallery .
3. Press the OK key to view the selected picture.
Send a Picture
1. In the Gallery, use the Navigation ring to scroll up or
down to select a picture to send.
2. Once your desired picture has been selected press the
Right Soft key to open the Options menu.
3. Use the Navigation ring to scroll down to Share and
press the OK key.
4. Use the Navigation ring to choose to send the picture
via E-mail, Facebook, Messages, WhatsApp or Bluetooth
then press the OK key to make your selection.
E-mail
Email Setup
1. From the Home screen, press the OK key.
2. Use the Navigation ring to scroll down until Email
is highlighted. Press the OK key to select Email .
3. Press the Right Soft key to navigate to the Next
menu to set up your email account.
4. Enter your email name, address, and password by scrolling
up or down using the Navigation ring . Once complete,
press the Right Soft key for Next to set up your
account.
Note: To set up a corporate email, contact your IT administrator
for instructions.
Create and Send an E-mail Message
1. From the Home screen, press the OK key.
2. Use the Navigation ring to scroll down until E-mail
is highlighted. Press the OK key to select E-mail .
3. Press the Left Soft key to compose a new email from
the Inbox screen.
4. Scroll down using the Navigation ring to enter a subject,
scroll down once more to enter an email message.
5. To attach files to the email message, press the Right Soft key
and make your selection.
6. To attach a file to your email message, press the Right Soft key
toentertheoptionsmenu.UsingtheNavigation ring
scrollupordowntoselect“AddAttachment”thenpress
the OK key to select the file type. Once your file type is
highlighted, press the OK key to select.
7. Using the Navigation ring, scroll up or down to select the file
you would like to attach to the email message, once
highlighted press the OK key. Press the Right Soft key
once more to attach the file to the email message.
SOS Message
An SOS message is a message that you can customize and store
in the phone. When you place an emergency call, the SOS
message will be sent to the pre-set SOS contacts automatically.
1. To edit the SOS message, select Settings >
Personalization > SOS Message.
2. Set the SOS contacts, you can set up to 5 contacts as SOS
contacts.
a. From the apps list, select “Contacts”.
b. Select a contact and select “Options”.
c. Select “Settings”.
d. Select “Set SOS Contacts”.
3. You can also personalize your SOS message from the SOS
message settings page.
How to Use the SOS Button:
1. Open the flip phone, long press the SOS
button on the back of phone, continue to
hold it down for 3 seconds while the phone
is vibrating.
2. A 911 call is initiated.
Note that:
1. The phone must be opened, and the SOS key must be long
pressed while vibrating to initiate a 911 call.
2. As long as you are in an area covered by wireless service,
the emergency call is placed.
3. When you call emergency numbers, the SOS message will
automatically be sent to any SOS contacts you’ve
programed.
4. More on SOS Key operations:
SOS Key Short-Pressed (less
than 3 seconds)
SOS Key Long-Pressed (3
seconds or longer)
Flip Opened E911 will not be dialed. E911 call will be dialed.
Flip Closed E911 will not be dialed. E911 will not be dialed.
Personalize Your Device
You can change the settings in the Personalization menu for
various interfaces, such as Sound, Display, and Search. For
example, you can set your wallpaper in Display menu.
Set Wallpaper
1. From the Home screen press the OK key.
2. Use the Navigation ring to scroll down and to the right
until Settings is highlighted. Press the OK key to select
Settings .
3. Scroll right to the Personalization menu, and then scroll
down to “Display” and press the OK key to select.
4. Press the OK key once more and then scroll to select
Wallpaper picture location. Press the OK key to select from
Camera, Wallpaper or Gallery.
5. Use the Navigation ring to scroll though photos.
When you have found the one you like, press the Right soft
key to save it to your Home screen.
Bright Flip Quick Start Guide
R3Di FR150
4G LTE Network Bands
B2/B4/B5/B12/B13/B25/B26/B41/B66/B71
About Your FR150 Bright Flip Phone Phone Setup
1. Remove the back cover by gently pulling up on the
indentation on the bottom left of the cover.
2. Remove the battery by gently pulling up on the indentation
on the upper right of the battery.
3. Insert the 4FF SIM card by carefully sliding it into the “SIM”
slot on the right with the gold section facing down and the
slanted corner to the right.
4. If desired, you can insert a microSD card (not included) into
the ‘microSD’ slot on the right. Ensure that the gold section is
facing down, and the flat edge is facing the top. Reattach the
back cover of the phone. Please see illustrations to verify
correct card insertion orientation. To remove the SIM or
microSD card, push down on the plastic spring and pull the
SIM or microSD card out carefully.
WARNING: To avoid damage to the phone, only use a standard
nano-SIM card provided by your service provider.
Using Your Phone
Charging Your Phone
You should charge your phone fully before use. To do so, insert
the Micro USB cable to the device Micro USB port and plug the
other end into to the wall charger.
Note: Use only the charger USB cable supplied with the
phone. Use of incompatible chargers may cause damage to your
device and void the warranty.
Power On/Off Your Phone
To turn on your phone, long press the power key. You will see the
logo and wait for the phone to boot up and come to the home
page.
Note: You will need to complete the initial set-up steps when you
power on the phone the first time.
To turn off your phone, long press the power key, and navigate to
“Power off”.
Camera and Video
Take a Picture
1. Press the Camera key, or press the OK key to go into the
menu to select Camera , or use the Navigation ring
to press the right key to open the Camera .
2. Press the Right Soft key to display camera options
and settings.
3. Zoom in and out by tapping the Navigation ring up (+)
to zoom in, tap Navigation ring down (-) to zoom out.
4. Press the OK key to take a picture. After taking the picture,
press the Left Soft key to preview.
Take a Video
1. Press the Camera key or press the OK key from the Home
screen and select Camera .
2. Press the Navigation ring to scroll to the right until
the Camera is highlighted. Press the OK key to enter
Camera mode.
3. Use the Navigation ring to scroll to the right and
switch to Video mode.
4. Press the OK key to start and stop recording video.
View Pictures
1. From the Home screen, press the OK key to open the Main
Menu.
2. Use the Navigation ring to scroll down and to the
right until Gallery is highlighted. Press the OK key to
select Gallery .
3. Press the OK key to view the selected picture.
Send a Picture
1. In the Gallery, use the Navigation ring to scroll up or
down to select a picture to send.
2. Once your desired picture has been selected press the
Right Soft key to open the Options menu.
3. Use the Navigation ring to scroll down to Share and
press the OK key.
4. Use the Navigation ring to choose to send the picture
via E-mail, Facebook, Messages, WhatsApp or Bluetooth
then press the OK key to make your selection.
E-mail
Email Setup
1. From the Home screen, press the OK key.
2. Use the Navigation ring to scroll down until Email
is highlighted. Press the OK key to select Email .
3. Press the Right Soft key to navigate to the Next
menu to set up your email account.
4. Enter your email name, address, and password by scrolling
up or down using the Navigation ring . Once complete,
press the Right Soft key for Next to set up your
account.
Note: To set up a corporate email, contact your IT administrator
for instructions.
Create and Send an E-mail Message
1. From the Home screen, press the OK key.
2. Use the Navigation ring to scroll down until E-mail
is highlighted. Press the OK key to select E-mail .
3. Press the Left Soft key to compose a new email from
the Inbox screen.
4. Scroll down using the Navigation ring to enter a subject,
scroll down once more to enter an email message.
5. To attach files to the email message, press the Right Soft key
and make your selection.
6. To attach a file to your email message, press the Right Soft key
toentertheoptionsmenu.UsingtheNavigation ring
scrollupordowntoselect“AddAttachment”thenpress
the OK key to select the file type. Once your file type is
highlighted, press the OK key to select.
7. Using the Navigation ring, scroll up or down to select the file
you would like to attach to the email message, once
highlighted press the OK key. Press the Right Soft key
once more to attach the file to the email message.
SOS Message
An SOS message is a message that you can customize and store
in the phone. When you place an emergency call, the SOS
message will be sent to the pre-set SOS contacts automatically.
1. To edit the SOS message, select Settings >
Personalization > SOS Message.
2. Set the SOS contacts, you can set up to 5 contacts as SOS
contacts.
a. From the apps list, select “Contacts”.
b. Select a contact and select “Options”.
c. Select “Settings”.
d. Select “Set SOS Contacts”.
3. You can also personalize your SOS message from the SOS
message settings page.
How to Use the SOS Button:
1. Open the flip phone, long press the SOS
button on the back of phone, continue to
hold it down for 3 seconds while the phone
is vibrating.
2. A 911 call is initiated.
Note that:
1. The phone must be opened, and the SOS key must be long
pressed while vibrating to initiate a 911 call.
2. As long as you are in an area covered by wireless service,
the emergency call is placed.
3. When you call emergency numbers, the SOS message will
automatically be sent to any SOS contacts you’ve
programed.
4. More on SOS Key operations:
SOS Key Short-Pressed (less
than 3 seconds)
SOS Key Long-Pressed (3
seconds or longer)
Flip Opened E911 will not be dialed. E911 call will be dialed.
Flip Closed E911 will not be dialed. E911 will not be dialed.
Personalize Your Device
You can change the settings in the Personalization menu for
various interfaces, such as Sound, Display, and Search. For
example, you can set your wallpaper in Display menu.
Set Wallpaper
1. From the Home screen press the OK key.
2. Use the Navigation ring to scroll down and to the right
until Settings is highlighted. Press the OK key to select
Settings .
3. Scroll right to the Personalization menu, and then scroll
down to “Display” and press the OK key to select.
4. Press the OK key once more and then scroll to select
Wallpaper picture location. Press the OK key to select from
Camera, Wallpaper or Gallery.
5. Use the Navigation ring to scroll though photos.
When you have found the one you like, press the Right soft
key to save it to your Home screen.
Bright Flip Quick Start Guide
R3Di FR150
4G LTE Network Bands
B2/B4/B5/B12/B13/B25/B26/B41/B66/B71
About Your FR150 Bright Flip Phone Phone Setup
1. Remove the back cover by gently pulling up on the
indentation on the bottom left of the cover.
2. Remove the battery by gently pulling up on the indentation
on the upper right of the battery.
3. Insert the 4FF SIM card by carefully sliding it into the “SIM”
slot on the right with the gold section facing down and the
slanted corner to the right.
4. If desired, you can insert a microSD card (not included) into
the ‘microSD’ slot on the right. Ensure that the gold section is
facing down, and the flat edge is facing the top. Reattach the
back cover of the phone. Please see illustrations to verify
correct card insertion orientation. To remove the SIM or
microSD card, push down on the plastic spring and pull the
SIM or microSD card out carefully.
WARNING: To avoid damage to the phone, only use a standard
nano-SIM card provided by your service provider.
Using Your Phone
Charging Your Phone
You should charge your phone fully before use. To do so, insert
the Micro USB cable to the device Micro USB port and plug the
other end into to the wall charger.
Note: Use only the charger USB cable supplied with the
phone. Use of incompatible chargers may cause damage to your
device and void the warranty.
Power On/Off Your Phone
To turn on your phone, long press the power key. You will see the
logo and wait for the phone to boot up and come to the home
page.
Note: You will need to complete the initial set-up steps when you
power on the phone the first time.
To turn off your phone, long press the power key, and navigate to
“Power off”.
Camera and Video
Take a Picture
1. Press the Camera key, or press the OK key to go into the
menu to select Camera , or use the Navigation ring
to press the right key to open the Camera .
2. Press the Right Soft key to display camera options
and settings.
3. Zoom in and out by tapping the Navigation ring up (+)
to zoom in, tap Navigation ring down (-) to zoom out.
4. Press the OK key to take a picture. After taking the picture,
press the Left Soft key to preview.
Take a Video
1. Press the Camera key or press the OK key from the Home
screen and select Camera .
2. Press the Navigation ring to scroll to the right until
the Camera is highlighted. Press the OK key to enter
Camera mode.
3. Use the Navigation ring to scroll to the right and
switch to Video mode.
4. Press the OK key to start and stop recording video.
View Pictures
1. From the Home screen, press the OK key to open the Main
Menu.
2. Use the Navigation ring to scroll down and to the
right until Gallery is highlighted. Press the OK key to
select Gallery .
3. Press the OK key to view the selected picture.
Send a Picture
1. In the Gallery, use the Navigation ring to scroll up or
down to select a picture to send.
2. Once your desired picture has been selected press the
Right Soft key to open the Options menu.
3. Use the Navigation ring to scroll down to Share and
press the OK key.
4. Use the Navigation ring to choose to send the picture
via E-mail, Facebook, Messages, WhatsApp or Bluetooth
then press the OK key to make your selection.
E-mail
Email Setup
1. From the Home screen, press the OK key.
2. Use the Navigation ring to scroll down until Email
is highlighted. Press the OK key to select Email .
3. Press the Right Soft key to navigate to the Next
menu to set up your email account.
4. Enter your email name, address, and password by scrolling
up or down using the Navigation ring . Once complete,
press the Right Soft key for Next to set up your
account.
Note: To set up a corporate email, contact your IT administrator
for instructions.
Create and Send an E-mail Message
1. From the Home screen, press the OK key.
2. Use the Navigation ring to scroll down until E-mail
is highlighted. Press the OK key to select E-mail .
3. Press the Left Soft key to compose a new email from
the Inbox screen.
4. Scroll down using the Navigation ring to enter a subject,
scroll down once more to enter an email message.
5. To attach files to the email message, press the Right Soft key
and make your selection.
6. To attach a file to your email message, press the Right Soft key
toentertheoptionsmenu.UsingtheNavigation ring
scrollupordowntoselect“AddAttachment”thenpress
the OK key to select the file type. Once your file type is
highlighted, press the OK key to select.
7. Using the Navigation ring, scroll up or down to select the file
you would like to attach to the email message, once
highlighted press the OK key. Press the Right Soft key
once more to attach the file to the email message.
SOS Message
An SOS message is a message that you can customize and store
in the phone. When you place an emergency call, the SOS
message will be sent to the pre-set SOS contacts automatically.
1. To edit the SOS message, select Settings >
Personalization > SOS Message.
2. Set the SOS contacts, you can set up to 5 contacts as SOS
contacts.
a. From the apps list, select “Contacts”.
b. Select a contact and select “Options”.
c. Select “Settings”.
d. Select “Set SOS Contacts”.
3. You can also personalize your SOS message from the SOS
message settings page.
How to Use the SOS Button:
1. Open the flip phone, long press the SOS
button on the back of phone, continue to
hold it down for 3 seconds while the phone
is vibrating.
2. A 911 call is initiated.
Note that:
1. The phone must be opened, and the SOS key must be long
pressed while vibrating to initiate a 911 call.
2. As long as you are in an area covered by wireless service,
the emergency call is placed.
3. When you call emergency numbers, the SOS message will
automatically be sent to any SOS contacts you’ve
programed.
4. More on SOS Key operations:
SOS Key Short-Pressed (less
than 3 seconds)
SOS Key Long-Pressed (3
seconds or longer)
Flip Opened E911 will not be dialed. E911 call will be dialed.
Flip Closed E911 will not be dialed. E911 will not be dialed.
Personalize Your Device
You can change the settings in the Personalization menu for
various interfaces, such as Sound, Display, and Search. For
example, you can set your wallpaper in Display menu.
Set Wallpaper
1. From the Home screen press the OK key.
2. Use the Navigation ring to scroll down and to the right
until Settings is highlighted. Press the OK key to select
Settings .
3. Scroll right to the Personalization menu, and then scroll
down to “Display” and press the OK key to select.
4. Press the OK key once more and then scroll to select
Wallpaper picture location. Press the OK key to select from
Camera, Wallpaper or Gallery.
5. Use the Navigation ring to scroll though photos.
When you have found the one you like, press the Right soft
key to save it to your Home screen.

CONFIDENTIAL –For Use Under NDA Only
The FR150 SOS Messages
Bright Flip Quick Start Guide
R3Di FR150
4G LTE Network Bands
B2/B4/B5/B12/B13/B25/B26/B41/B66/B71
About Your FR150 Bright Flip Phone Phone Setup
1. Remove the back cover by gently pulling up on the
indentation on the bottom left of the cover.
2. Remove the battery by gently pulling up on the indentation
on the upper right of the battery.
3. Insert the 4FF SIM card by carefully sliding it into the “SIM”
slot on the right with the gold section facing down and the
slanted corner to the right.
4. If desired, you can insert a microSD card (not included) into
the ‘microSD’ slot on the right. Ensure that the gold section is
facing down, and the flat edge is facing the top. Reattach the
back cover of the phone. Please see illustrations to verify
correct card insertion orientation. To remove the SIM or
microSD card, push down on the plastic spring and pull the
SIM or microSD card out carefully.
WARNING: To avoid damage to the phone, only use a standard
nano-SIM card provided by your service provider.
Using Your Phone
Charging Your Phone
You should charge your phone fully before use. To do so, insert
the Micro USB cable to the device Micro USB port and plug the
other end into to the wall charger.
Note: Use only the charger USB cable supplied with the
phone. Use of incompatible chargers may cause damage to your
device and void the warranty.
Power On/Off Your Phone
To turn on your phone, long press the power key. You will see the
logo and wait for the phone to boot up and come to the home
page.
Note: You will need to complete the initial set-up steps when you
power on the phone the first time.
To turn off your phone, long press the power key, and navigate to
“Power off”.
Camera and Video
Take a Picture
1. Press the Camera key, or press the OK key to go into the
menu to select Camera , or use the Navigation ring
to press the right key to open the Camera .
2. Press the Right Soft key to display camera options
and settings.
3. Zoom in and out by tapping the Navigation ring up (+)
to zoom in, tap Navigation ring down (-) to zoom out.
4. Press the OK key to take a picture. After taking the picture,
press the Left Soft key to preview.
Take a Video
1. Press the Camera key or press the OK key from the Home
screen and select Camera .
2. Press the Navigation ring to scroll to the right until
the Camera is highlighted. Press the OK key to enter
Camera mode.
3. Use the Navigation ring to scroll to the right and
switch to Video mode.
4. Press the OK key to start and stop recording video.
View Pictures
1. From the Home screen, press the OK key to open the Main
Menu.
2. Use the Navigation ring to scroll down and to the
right until Gallery is highlighted. Press the OK key to
select Gallery .
3. Press the OK key to view the selected picture.
Send a Picture
1. In the Gallery, use the Navigation ring to scroll up or
down to select a picture to send.
2. Once your desired picture has been selected press the
Right Soft key to open the Options menu.
3. Use the Navigation ring to scroll down to Share and
press the OK key.
4. Use the Navigation ring to choose to send the picture
via E-mail, Facebook, Messages, WhatsApp or Bluetooth
then press the OK key to make your selection.
E-mail
Email Setup
1. From the Home screen, press the OK key.
2. Use the Navigation ring to scroll down until Email
is highlighted. Press the OK key to select Email .
3. Press the Right Soft key to navigate to the Next
menu to set up your email account.
4. Enter your email name, address, and password by scrolling
up or down using the Navigation ring . Once complete,
press the Right Soft key for Next to set up your
account.
Note: To set up a corporate email, contact your IT administrator
for instructions.
Create and Send an E-mail Message
1. From the Home screen, press the OK key.
2. Use the Navigation ring to scroll down until E-mail
is highlighted. Press the OK key to select E-mail .
3. Press the Left Soft key to compose a new email from
the Inbox screen.
4. Scroll down using the Navigation ring to enter a subject,
scroll down once more to enter an email message.
5. To attach files to the email message, press the Right Soft key
and make your selection.
6. To attach a file to your email message, press the Right Soft key
toentertheoptionsmenu.UsingtheNavigation ring
scrollupordowntoselect“AddAttachment”thenpress
the OK key to select the file type. Once your file type is
highlighted, press the OK key to select.
7. Using the Navigation ring, scroll up or down to select the file
you would like to attach to the email message, once
highlighted press the OK key. Press the Right Soft key
once more to attach the file to the email message.
SOS Message
An SOS message is a message that you can customize and store
in the phone. When you place an emergency call, the SOS
message will be sent to the pre-set SOS contacts automatically.
1. To edit the SOS message, select Settings >
Personalization > SOS Message.
2. Set the SOS contacts, you can set up to 5 contacts as SOS
contacts.
a. From the apps list, select “Contacts”.
b. Select a contact and select “Options”.
c. Select “Settings”.
d. Select “Set SOS Contacts”.
3. You can also personalize your SOS message from the SOS
message settings page.
How to Use the SOS Button:
1. Open the flip phone, long press the SOS
button on the back of phone, continue to
hold it down for 3 seconds while the phone
is vibrating.
2. A 911 call is initiated.
Note that:
1. The phone must be opened, and the SOS key must be long
pressed while vibrating to initiate a 911 call.
2. As long as you are in an area covered by wireless service,
the emergency call is placed.
3. When you call emergency numbers, the SOS message will
automatically be sent to any SOS contacts you’ve
programed.
4. More on SOS Key operations:
SOS Key Short-Pressed (less
than 3 seconds)
SOS Key Long-Pressed (3
seconds or longer)
Flip Opened
E911 will not be dialed.
E911 call will be dialed.
Flip Closed
E911 will not be dialed.
E911 will not be dialed.
Personalize Your Device
You can change the settings in the Personalization menu for
various interfaces, such as Sound, Display, and Search. For
example, you can set your wallpaper in Display menu.
Set Wallpaper
1. From the Home screen press the OK key.
2. Use the Navigation ring to scroll down and to the right
until Settings is highlighted. Press the OK key to select
Settings .
3. Scroll right to the Personalization menu, and then scroll
down to “Display” and press the OK key to select.
4. Press the OK key once more and then scroll to select
Wallpaper picture location. Press the OK key to select from
Camera, Wallpaper or Gallery.
5. Use the Navigation ring to scroll though photos.
When you have found the one you like, press the Right soft
key to save it to your Home screen.

CONFIDENTIAL –For Use Under NDA Only
The FR150 FAQ’s
Problem 1: Phone freezes/operation is unstable
Answer: Power cycle your phone by turning it off and on again. If you are unable to turn the phone off, remove and replace the Battery, and then turn the phone
on again. Data that was being edited is erased after your phone is powered on again.
Problem 2: Cannot use phone, mail, or Internet.
Answer: Try the following:
•Check to make sure the device is not in Airplane mode. To check, go to Settings > Network & Connectivity > Airplane Mode.
•Check to make sure the data communication is enabled. To check, go to Settings > Network & Connectivity > Mobile network & Data > Data Connection.
•Move to a location with strong wireless signal (the more signal bars, the stronger the signal).
•Turning off and on your device.
•Check with your carrier to verify your sim status, provisioning plan, and service coverage area.
Problem 3: Battery level goes down quickly.
Answer: If you were in a weak signal area or have been out of service area for a long period, your phone battery might be depleted at a faster pace as it is trying to
connect to the network.
Problem 4: Cannot unlock screen.
Answer: Power the phone on again. If you are unable to turn the phone off, remove and replace the Battery, and then power the phone on again. Data that was
being edited is erased after the phone is powered on again.
Problem 5: Forgot my unlock passcode.
Answer: If you’ve forgotten your unlock passcode you will need to restore your device to factory default settings. We recommend that you keep your passcode
somewhere safe so that it is not lost. To reset your device, go to “Settings” > “Device Information” > “Reset” > “Reset Phone”. Please note that if you perform a factory
reset, all device data may be lost.
Problem 6: I can’t access my voicemail.
Answer 1: Contact your service provider for the “Voicemail number” and verify it’s entered correctly in the “Voicemail number” box, which can be found by going to
Contacts > Voicemail.
Answer 2: Try later if the network is busy.

CONFIDENTIAL –For Use Under NDA Only
The FR150 FAQ’s
Problem 7: I can’t send MMS.
Answer: Depending on your service provider (wireless carrier) you may have a limit on the MMS file size. Contact your carrier for details on the maximum file size
allotted.
Problem 8: Difficulty hearing during call.
Answer 1: Check your wireless signal to make sure you are in a strong signal area.
Answer 2: Adjust you call volume if using the speaker phone.
Answer 3: If you are using hearing aids, confirm they are compatible with this FR150 Flip Phone. Note that this device is M4/T3 rated.
Problem 9: I am hearing a popping sound momentarily during a call.
Answer: If you are moving or traveling from one location to another, the popping sound might indicate a network change.
Problem 10: Call does not connect.
Answer 1: Ensure the number dialed included the area code. If not, try re-dialing using the full 10-digit number (including the area code).
Answer 2: Are you in an area with poor wireless coverage? Try calling again from an area with stronger wireless signal.
Problem 11: I pressed the SOS button accidentally and called E9-1-1.
Answer: Don’t panic and don’t hang up. Explain to the emergency call dispatcher that you are safe, and the call was made by mistake.
Problem 12: Can I change the SOS emergency call number to an emergency service outside of the U.S.?
Answer: Currently, the emergency number function only works within the U.S. for 911 services. ATEL USA and R3Di are not responsible for misplaced emergency
calls to 911 or any other emergency services.

CONFIDENTIAL –For Use Under NDA Only
For Additional Information + Support:
@R3DiOfficial @R3Di_Official
R3Di Warranty Support R3Di Device Support FR150 User Manual FR150 Quick Start Guide

CONFIDENTIAL –For Use Under NDA Only
For Kai Information + Support:
This device is equipped with the Kai Operating System (OS), version number 2.5.4. Scan the QR code below to learn more about the features and benefits:

THANK YOU
Passion for Innovation
