Racaminetto TERRA User manual

PB 1
INSTRUCTIONS FOR USE
(EN)
TERRA Bistro Heating Table
(109cm, 2 x O. 7kW)
Before using the heater for the rst time, read these instructions
carefully and keep them for later use.

2 3
[email protected]
www.racaminetto.com

2 3
We are very pleased that you have purchased a Racaminetto Heating Table, and
we are sure you will be completely satised with this electric heater. Before using
this product for the rst time, please carefully read the instructions for use, which
include safety instructions and information on table top assembly and use and
maintenance of the heater.
The Racaminetto • Heating Table is a safe, high-quality, cost-efcient and very
effective electric heating device that can substantially reduce your energy
consumption while helping to protect the environment. The Racaminetto Heating
Table is an infrared radiation heater, which means that it heats objects directly,
without any energy loss or heating of the ambient air.
The heater has been approved for use in the countries of the European
Union and bears the CE (Conformite Europeenne) mark. Ali necessary
documentation is available from the manufacturer.
Please keep the instructions for use throughout the life of the product.
lnstructions for use in electronic form are available on our website www.
racaminetto.com
Racaminetto® TERRA Bistro Heating Table - Technical Specifications
Model name Terra Bistro Heating Table
Power source 230V-50Hz
Power of the heating tube 2x 0.7kW
Protection degree IP44
(Protected against splashing water and ingress of solid
foreign bodies with a diameter of 1mm and greater)
Operating temperature -10°c to +19°C
Operating humidity 30% to 90%
Storage temperature -20°c to +60°c
Storage humidity 10% to 90%
Height 109cm
Weight without table top 25.5kg
Warning
The technical parameters of the product may change over time. The instructions
for use of the product correspond to the technical condition as at the date of the
!ast update. We reserve the right to make changes to technical parameters or
properties and to printing errors.

45
Safety instructions
To reduce the risk of re, electric shock, or personal injury while
handling and using our product, please always observe the following
basic safety measures:
• Keep the product packaging out of the reach of children to avoid risk of
suffocation.
• Do not use the heater in a ammable environment (e.g. in premises where
petrol, paints, ammable liquids, gases or sprays are stored) to avoid risk of re
or explosion!
• Do not use the product without the table top to avoid risk of electric shock.
• Do not place the heater on soft objects such as high pile carpets, horsehair
mattresses or oor mats. Do not place the heater in the proximity of whirlpools,
wash basins, irrigation systems, showers, bathtubs, swimming pools or other
water bodies or sources of steam to avoid risk of electric shock.
• Always use the heater in sufcient distance from surrounding objects and do
not place any highly ammable or meltable objects (such as curtains, tablecloths
or plastic chairs) in its proximity. The productshould be positioned at least 80cm
from wallsand other objects.
• Do not place the heater immediately below or in front of electrical sockets.
• Do not tay the power cable in exposed areas (e.g. entry ways, corridors
or doors) or under the carpet and do not cover it with fabrics, runners, ete. lf
possible, use a cable cover to avoid stumbling over the cable, injury or product
damage.
• Do not use the product in the wilderness.
• Do not expose the product to high temperatures, especially to direct sunlight.
Due to a risk of overheating, the heater should not be used at an ambient
temperature exceeding 19°C.

45
• Unsupervised children under the age of 3 should be prevented from accessing
the device.
• Be extra careful when using the heater in the proximity of children. Do not
allow children to play with the heater.
• Persons under the age of 15 must not use or operate the heater, put the plug in
the socket, regulate or clean the device or perform any user maintenance.
• Do not operate the heater using a special programme, timer, remote control
system or any other component that switches the heater on automatically since
there is a risk of re if the heater is covered or placed incorrectly.
• Only use sockets with a grounding pin. To ensure IP44 protection, use
corresponding sockets with IP44 protection. Failure to use an appropriate socket
may pose a risk of electric shock.
• Do not disconnect the heater from the socket by tugging at the power cable;
disconnect the device by pulling the plug out from the socket to avoid any
damage to the power cable.
• Do not use the product if the power cable is damaged or if the device
has stopped working properly after a drop or damage. The product must be
inspected solely by an authorised service centre or by the manufacturer. A
damaged power cable can be replaced only by an authorised service centre or by
the manufacturer.
• Do not touch the surface of the heater when it is hot, as there is a risk of burns.
• To avoid overheating, do not cover the product and do not restrict air inow
and outow.
• Protect the product from strong shocks, drops, and rain.
• Do not insert any foreign bodies into the heater holes as they may cause an
electric shock, re or product damage.
• Do not use the heater to light cigarettes or ignite other objects.

67
• The protective grid covers the heating tube, but no protective grid completely
prevents access to the tube. Never use the heater without the protective grid ta
avoid risk of burns.
• /fa heating tube breaks, switch off the heater immediately and disconnect it
from the socket. Be careful when handling the tube, as there is a risk onjury
From the shards. Always wear protective gloves when handling the tube.
• Do not leave the heater unattended when it is switched on ar when it is
plugged into an electrical socket.
• This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the
appliance.
• This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved.
• Children shall not play with the appliance.
• Cleaning and user maintenance shall not be made by children without
supervision.
• Children of less than 3 years should be kept away unless continuously
supervised.
• Children aged from 3 years and less than 8 years shall only switch on/
off the appliance provided that it has been placed or installed in its intended
normal operating position and they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved. Children aged from 3 years and less than 8 years shall not plug in,
regulate and clean the appliance or perform user maintenance.

67
Caution
The heater is not equipped with room temperature control. Do not use the heater
in small rooms if they are occupied by people who are unable to leave the room
on their own, unless they are continually supervised.
Some parts of this product can become very hot and cause burns. Particular
attention has to be given where children and vulnerable people are present.
Table top assembly
lf you purchased our heater without the table top installed and you would like to
assemble the device on your own, please follow the procedure specied below.
Assembly instructions:
1. Place the table top on a at, smooth surface.
2. Place the heater on the table top upside down.
3. Put the heater in the centre of the table top and ensure that the edges of
the top part are parallel to the edges of the table top ar that they are situated
in the centre of the circular table top.
4. Using self-drilling screws, attach the top part of the heater to the table top.
5. Turn the heater with the attached table top over and place it on the plastic
adjustable legs.
6. lf necessary, use the plastic adjustable legs to balance and stabilise the
heater so that it does not jiggle back and forth.
Recommended table tops: Form-pressed laminate table tops (Werzalit). For more
information about table tops, see: http:www.racaminetto.com

89
Warning
• The heater must not be used without a properly attached table top due ta the
risk of injury From electric shock.
• The table top must be made of durable, non-ammable and non-meltable
material. Do not use rattan or reeds as there is a risk of combustion!
• The minimum size ofa square table top is 70cm x 70cm and the minimum
diameter of a round table top is 70cm. These table top sizes were used as the
minimum safe distance in tests where the table was placed in a corner adjacent ta
the walls.
• The maximum allowance weight ofa table top is 9kg.
• The table top must completely cover the top part of the heater and must be
attached using the screws located in the designated openings in the top part.
• Use self-drilling screws to attach the table top. Select a suitable table top
thickness to prevent screw damage to the table top.
The appliance manufacturer is not liable for table top assembly by the user or for
any health or property damage incurred.
Use
The product is designed ta provide heat to people in either interior or exterior
settings.
• The product was not designed for purposes other than that specied in these
instruc tions for use. Any inappropriate use of the product may be dangerous.
The heater may only be used in a vertical position. The product is not designed to
be attached to a wa[[ or cei[ing.
Before using the product for the rst time, remove all packaging material
and unwind the power cable before connecting it to a power socket. The
packaging material is recyclable. in the interest of environmental protection,
dispose of the packaging in a recycling bin.
• Place the heater on a rm, straight surface.
• Follow the instructions provided in this guide to attach the heater to an
appropriate table top.
• Before turning the heater on, make sure the heating tube and power cable have
not been damaged and that neither the socket nar the heater are wet or damp.
• Only connect the product to an AC voltage power source with the
corresponding voltage range (230V). Connect the heater to the power grid via a
socket that has all the power contacts as well as
a protective grounding pin.

89
• Only use electrical sockets with grounding pins and secure residual current
circuit breakers (30mA).
• A maximum of one heater with two heating tubes (2 x 0.7kW) may be attached
to a 16A/B circuit breaker
• Turn on the heater by turning the switch to the “on” position (shown with a
line) and turn off the heater by turning the switch to the “ofF’ position (shown
with a circle). The tube will heat up completely within 10-15 seconds. You may
turn on either one of the heating tubes or both.
• The heater is hot while in use. To avoid burns, do not touch hot surfaces. Do
not touch the heater with wet hands. Always let the heater cool down before
relocating it to a new site.
• Do not move or lift the heater while it is in use. Always unplug the heater from
the power socket before handling it.
• Unplug the heater when it is not in use. Store the heater in a vertical position
with the power cable wound up to prevent damage. Regularly check the technical
condition of the product. When storing the heater far a longer period of time,
store it in its original packaging in a dry and well ventilated place.
• Replacement of heating tubes is handled by the manufacturer or authorised
service centre.
Warning
Some parts of this product can become very hot and cause burns. Special care
must be taken in the presence of children and the disabled.
The heater must not be used without a table top as there is a risk of injury due to
electric shock and burns.

10 11
Cleaning and maintenance
Clean the heater regularly to prevent corrosion and product damage. Avoid
chloride contamination (e.g. de-icing salt} which could cause a chemical reaction
or corrosion.
Before cleaning the product, turn it off, unplug it and let it cool down. Only clean
the outer surface of the product and use a soft cloth moistened with a light
application of soap or detergent. After cleaning, always wipe the product with a
dry cloth to ensure all moisture has been removed. The heater must not be used
while damp or wet. Do not use any abrasive or aggressive cleaning solutions or
materials. Never submerge the product in water. The heating tube is very fragile.
Do not clean the inside of the heater. Do not apply a stream of water to the heater
or clean it with strong pressure.
Warranty
The product has a 2-year warranty period from the date of sale of the product
written in the warranty. The warranty expires after this period. The manufacturer
or authorised service centre handle warranty and post-warranty repairs. The
warranty includes replacement or repair of the product for defects caused by
defective parts of the product or by its manufacture. The warranty does not apply
to defects caused by regular wear. The warranty does not apply to defects to
infrared heating tubes caused by mishandling or misuse of the product.
The manufacturer and importer are not liable for claims or compensation of dam.
ıges caused during product use in the event of product misuse or intentional
product damage.
Customers forfeit the right to a warranty if:
• The product is used in a manner incompliant with the enclosed instructions for
use
• The product is mechanically damaged
• The product has been disassembled or repaired by an unauthorised individual
• Damage occurred due to amateur assembly of the table top
• The power cable or another component of the product has been removed or
replaced
• The warranty list has not been Filled out by the res.ponsible party

10 11
Disposal:
in the interest of environmental protection, the product must not be disposed of
in household waste containers after expiry of its product life. The product must
be disposed of in an appropriate waste collection centre. Please adhere to loca!
material disposal regulations.
Dispose of the product in compliance with Directive 2002/96/EC-WEEE
(Waste Electrical and Electronic Equipment).

12 PB
Manufacturer and contact information:
Manufactured in the Turkey.
Racaminetto
OSB. 18. Cadde No:27
[email protected]
www.racaminetto.com
©Copyright 2019 - Racaminetto Ali rights reserved.
Racaminetto® is a registered trademark of Racaminetto
Date of last revision: 08/11/2019
When this paper instruction booklet is no lenger needed, please recycle it.
