TUG PLATE VIEW
INSTALLATION GUIDE
PARTS LIST
•Knob
•Swivel Mount
•Knob Screw
•Base Mount Screw
•Swivel Screw
•Base Mount
TOOL LIST
•3mm Allen Wrench
•5/8” Wrench
GoPro Knob Swivel Mount
Base MountBase Mount Screws Swivel Screw
Knob Screw
INSTALLATION GUIDE
1 Use a 3mm allen wrench to remove the Base Mount Screws from the Base Mount.
2 Align the 2 holes in the Base Mount with the holes in the top of the Tug Plate. Use the Base Mount Screws and a
3mm allen wrench to mount the Tug Plate View onto the backside of the Tug Plate
3 Remove the Knob and Knob Screw from the Swivel Mount.
4 Pass the ears of the GoPro case into the Swivel Mount. Put the Knob Screw through the holes in the Swivel
Mount and thread the Knob onto the Knob Screw.
5 Adjust the GoPro’s vertical camera angle and tighten the Knob with a 5/8” wrench.
6 Adjust the GoPro’s horizontal camera angle by loosening the Swivel Screw with a 3mm allen wrench. Pivot the
Swivel Mount and tighten the Swivel Mount Screw.
7 Double check all the mounting hardware to make sure it is tight.
8 Enjoy your new Tug Plate View footage!
