Racing RAC3000EB User manual

ORIGINAL INSTRUCTIONS >EN
ELECTRIC BLOWER VACUUM SHREDDER
RAC3000EB
USER GUIDE
WARNING: Read thoroughly the instruction manual before using.

CONTENTS
1. SAFETY INSTRUCTIONS.....................................................................................................................3
2. YOUR PRODUCT.................................................................................................................................14
3. ASSEMBLY........................................................................................................................................... 15
4. OPERATION......................................................................................................................................... 16
5. MAINTENANCE AND STORAGE..................................................................................................... 18
6. DISPOSAL.............................................................................................................................................18
7. DECLARATION OF CONFORMITY................................................................................................. 19
8. WARRANTY..........................................................................................................................................20
9. PRODUCT FAILURE........................................................................................................................... 21
10. WARRANTY EXCLUSIONS.............................................................................................................22
02

1. SAFETY INSTRUCTIONS
Safe operating practices for hand-held mains-
operated electrical garden vacuums, and garden
blower/vacuums with or without shredding means
and garden blowers
Training
a) Read the instructions carefully. Be familiar with the
controls and the correct use of the machine.
b) Never allow children or people unfamiliar with these
instructions to use the machine. Local regulations can
restrict the age of the operator
c) Keep in mind, that the operator or user is responsible
for accidents or hazards occurring to other people or
their property.
Preparation
a) Obtain ear protection and safety glasses. Wear
them at all times while operating the machine.
b) While operating the machine always wear
substantial footwear and long trousers. Do not
operate the machine when barefoot or wearing open
sandals. Avoid wearing clothing that is loose fitting or
that has hanging cords or ties.
c)Do not wear loose clothing or jewellery that can be
drawn into the air inlet. Keep long hair away from the
air inlets.
d) Operate the machine in a recommended position
and only on a firm, level surface.
e) Do not operate the machine on a paved or gravel
surface where ejected material could cause injury.
f) Before using, always visually inspect to see, that the
shredding means,shredding means bolts and other
03

fasteners are secure, the housing is undamaged and
that guards and screens are in place. Replace worn
or damaged components in sets to preserve balance.
Replace damaged or unreadable labels.
g) Before use, check the supply and extension cord for
signs of damage or aging. If the cord becomes
damaged during use, disconnect the cord from the
supply immediately. DO NOT TOUCH THE CORD
BEFORE DISCONNECTING THE SUPPLY. Do not
use the machine if the cord is damaged or worn.
h) Never operate the machine while people, especially
children, or pets are nearby.
Operation
a) Before starting the machine, make certain that the
feeding chamber is empty.
b) Keep your face and body away from the feed intake
opening.
c)Do not allow hands or any other part of the body or
clothing inside the feeding chamber, discharge chute,
or near any moving part.
d) Keep proper balance and footing at all times. Do not
overreach. Never stand at a higher level than the
base of the machine when feeding material into it.
e) Always stand clear of the discharge zone when
operating this machine.
f) When feeding material into the machine be extremely
careful that pieces of metal, rocks, bottles, cans or
other foreign objects are not included.
g) If the cutting mechanism strikes any foreign objects
or if the machine should start making any unusual
noise or vibration, immediately shut off the power
04

source and allow the machine to stop. Disconnect the
machine from the supply and take the following steps
before restarting and operating the machine:
inspect for damage;
replace or repair any damaged parts;
Check for and tighten any loose parts.
h) Do not allow processed material to build up in the
discharge zone; this may prevent proper discharge
and can result in kickback of material through the
intake opening.
i) If the machine becomes clogged, shut-off the power
source and disconnect the machine from supply
before cleaning debris.
j) Never operate the machine with defective guards or
shields, or without safety devices, for example debris
collector in place.
k)Keep the power source clean of debris and other
accumulations to prevent damage to the power
source or possible fire.
l) Do not transport this machine while the power source
is running.
m) Stop the machine, and remove plug from the socket.
Make sure that all moving parts have come to a
complete stop
whenever you leave the machine,
before clearing blockages or unclogging chute,
Before checking, cleaning or working on the
machine.
n) Do not tilt the machine while the power source is
running.
05

Maintenance and storage
a) When the machine is stopped for servicing,
inspection, or storage, or to change an accessory,
shut off the power source, disconnect the machine
from the supply and make sure that all moving parts
are come to a complete stop. Allow the machine to
cool before making any inspections, adjustments, etc.
Maintain the machine with care and keep it clean.
b) Store the machine in a dry place out of the reach of
children.
c)Always allow the machine to cool before storing.
d) When servicing the shredding means be aware that,
even though the power source is switched off due to
the interlock feature of the guard, the shredding
means can still be moved
e) Replace worn or damaged parts for safety. Use only
genuine replacement parts and accessorises.
f) Never attempt to override the interlocked feature of
the guard.
Additional safety instructions for units with bagging
attachments
Switch-off the machine before attaching or removing the
bag.
Recommendation
The machine should be supplied via a residual current
device (RCD) with a tripping current of not more than 30
mA.
Additional instructions
This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and
06

knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
Children should be supervised to ensure that they do
not play with the appliance.
Never allow children, persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge or people unfamiliar with these
instructions to use the machine, local regulations may
restrict the age of the operator.
Never use the machine when people, especially
children, or pets are nearby.
Remember that the operator or user is responsible for
accidents or hazards occurring to persons or their
belongings.
Before connecting, check:
oWhether the tool and cable are not damaged. If
damaged, do not use the machine and bring it back
to your dealer for inspection and repair.
oThat the voltage on the rating plate of the tool
matches with your electrical installation.
Do not use accessories other than those
recommended by the manufacturer; Non-
recommended accessories can damage the unit
and/or cause injuries.
Do not disassemble the tool yourself. Disassembly,
repair or inspection must be made exclusively by
qualified personnel.
Use the tool fully assembled and secure. Before using,
check if the protections and safety devices are in
place.
07

During the operation of the machine, always wear
protective equipment, including protective masks,
visors or goggles, ear protection, helmet, gloves, non-
slip footwear and protective clothing.
Always carry the machine by its handle; never use the
cord or any other part of the machine.
Do not use the machine when you are tired, under the
influence of alcohol or drugs or sick.
Use the tool to suck and blow leaves and similar
materials. Do not blow flammable materials, cigarette
butts and materials that can damage the device.
Do not use the appliance to suck water or wet debris.
Always use the machine with the collection bag.
Avoid using the machine in bad weather, especially
when there is a risk of thunderstorms and lightning.
In case of accident, immediately stop using the
machine. Turn off and unplug it and check the
problem. Do not use the machine while the machine is
damaged.
Do not use the tool if you are drunk, tired, under the
influence of drugs or ill. Do not use the tool if you are
not in an adequate physical condition
Do not use the tool during bad weather conditions
(lighting, rain, storm, big winds, etc.)
Do not use the tool in an area where ventilation is
poor. Gas emissions can cause injury.
Do not use the tool in damp locations.
Do not use the tool in the presence of flammable
liquids or gases.
Do not operate the product with damaged guards or
shields not in place.
08

Do not lean. Keep a good balance at all times.
Keep handles dry, clean and free from oil and grease.
Use and handle the machine carefully.
Do not put your body, clothes or shoes close to the air
opening
Do not lift up the tool when it is in operation.
Do not point the tool in front of people; this can lead to
accidents and injuries.
Do not put any objects inside the tube and inside the
tool.
Before using the product and after any shock, please
check it for signs of wear or damage.
Please carry out repairs if necessary.
Inspect and regularly service the product. Repairs
should be carried out only by an authorized service
center or a similarly qualified specialist.
Children should not play with plastic bags, sheets and
small parts! Keep them out of the reach of children.
There is a danger of swallowing and suffocation!
Do not use the product on a slippery surface.
Do not use the product on steep, slippery slopes. If
you need to work on slopes, use an extreme care and
be careful about your footing. Please wear non
slippery footwear.
When planning your work schedule, allow enough
time for rest. Limit continuous use of the device, e.g.
use 30 ~ 40 minutes per session, and take 10 ~ 20
minutes of rest between work sessions. Work a
maximum of two hours per day.
Do not connect a damaged cord to supply or touch a
damaged cord before it is disconnected from the
09

supply; damaged cords can lead to contact with live
parts.
Keep extension cords away from moving hazardous
parts to avoid damages to the cords which can lead to
contact with live parts.
When a cable is damaged or entangled, please stop
immediately to use the tool. Switch off the tool, let it
cool and unplug it in a secure way.
When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of electric
shock.
Use extra care when using on stairs.
In dusty conditions, slightly dampen surfaces or use
mister attachment if available
Use the full blower nozzle extension so the air stream
can work closer to the ground
Never use the appliance for spreading chemicals,
fertilizer, or any other substances that may contain
toxic materials. Do not use appliance as a sprayer of
flammable liquids.
Keep all the air intakes and the blower tube free of
dust, lint, hair and other material that may cause a
reduction in air flow.
Do not switch on the tool in enclosed or poorly
ventilated spaces or in the presence of inflammable
and/or explosive substances such as liquids, gasses,
and powders.)
Disconnect electrical supply before opening inlet
cover or installing pick up tubes. Never operate unit
without inlet cover secured or pick-up tubes in place.
10

Always inspect the area before starting the appliance
to remove debris and hard or sharp objects that can
be blown or cause damaged during operation
Never operate this appliance when you are tired, ill or
under the influence of alcohol, drugs or medication.
Always run the appliance with the blower tubes
attached to the unit.
Always work moving away from solid objects such as
walls, large stones, automobiles and fences.
Clean spaces with corners by starting in corners and
moving outward to straight areas to prevent an
accumulation of debris, which could fly into face.
Be careful when working near valuable plants. The
force of air could damage tender plants.
Uses for your blowers: sweeping debris or grass
clippings from driveways, sidewalks, patios, parks,
parking lots, barns, etc. Gathering grass clippings,
straw or leaves into piles. Removing debris from
corners, around joints and between bricks.
Stay alert. Watch what you are doing and use
common sense when operating a power tool. Do not
operate tool when you are tired or under the influence
of drugs, alcohol or medication. A moment of
inattention while operating power tools may result in
serious personal injury.
Residual risks
Even if you use this product in compliance with all
safety requirements, the potential risks of injury and
damage remain. The following hazards may arise in the
structure and design of this product:
11

a. There are harmful health consequences resulting
from the emission of vibrations if the product is used for
long periods of time or not properly managed and
properly maintained.
b. Risk of injury to persons and property caused by
flying objects.
c. Prolonged use of this product exposes the operator to
vibration and can produce so-called "white finger"
disease. To reduce the risk, wear gloves and keep your
hands warm.
d. If any of the symptoms of "white finger syndrome"
occur, seek immediate medical attention. Symptoms of
the "white finger" include numbness, loss of sensitivity,
tingling, and pain, loss of strength, colour changes or
skin condition. These symptoms usually appear on the
fingers, hands or wrists. Risk increases at low
temperatures.
e. Inhalation of particles of material blown/vacuumed
f. Unattended projections
g. Contact with foreign objects
h. Contact with the tool in operation
i. Hearing loss in the absence of correct hearing
protection
Explanation of symbol
Denotes risk of personal injury, loss of life, or damage to the tool in case of non-
observance.
Conforms to all relevant EC Directives.
Read instruction manual before operating or attempting any maintenance work.
12

This product is double insulated electrically.
SWITCH OFF: Remove plug from mains before cleaning or maintenance.
Do not use in the rain or leave outdoors while it is raining.
Wear eye protection, ear muffles.
Warning. Moving blades. Keep hands and feet away when the machine is
operated.
Keep bystanders away.
Guarantee sound power level.
Remove plug from the mains immediately if the cable is damaged or cut.
Intended use
This vacuum blower is intended to be used for the vacuuming and the blowing of leaves, dust, and
similar little materials. It must not to be used for vacuuming and blowing water, chemical products,
flammable material, metal or wood and others dangerous objects.
This product is intended for private domestic use only. It must be used outdoors.
This product is not intended to be used in a closed room or in places where exhausted gas and
flames can be present.
The use of this product in case of rain or humid environment is prohibited.
Use this vacuum blower only as described in this manual and only for the intended use as
described above.
Any other use might lead to damage of the appliance, property or personal injury.
No liability will be accepted for damage resulting from improper use or non-compliance with
this manual.
13

2. YOUR PRODUCT
a. Description
1. Supply cable
2. Main handle
3. On/off switch
4. Front handle
5. Blower tube
6. Motor housing
7. Function switch (blower/vacuum)
8. Collection bag
9. Wheel
10.Attachment for shoulder harness
11.Speed control roller
b. Technical specifications
Model
RAC3000EB
Rated input power
3000W
Rated no-load speed
15000/min
Rated Voltage
230-240V~50Hz
Blower velocity
250 km/h
Maximum blower air output
10.7m3/min
Collecting bag capacity
40L
Weight
2.78Kg
Sound pressure level
LpA: 90.8dB(A) K=3 dB(A)
Sound power level
LwA,m: max.103.7dB(A) K=3 dB(A)
Guarantee sound power level
LwA: 107dB(A)
Vibration
Front handle: 4.21m/s²K= 1,5m/s²
Rear handle: 3.78m/s²K= 1,5m/s²
14

3. ASSEMBLY
a. Tube assembly
-Slide the upper tube into the motor housing, then tighten the screws and make sure the
tube is firmly fixed with motor housing.
-Insert the 2 lower tubes (one into upper tube and the smaller below) and push them until
they are connected firmly together. Use the provided plate and two screws to fix the tubes
together.
-Assemble the wheels to the lower tube. Add one wheel on each side of the hole situated on
smaller lower tube. Fix the wheels together with the screw and the nut. Then fix the
provided two plates and screws to fix the tubes together.
15

Caution: In the interests of safety the tubes should not be dismantled after they have been
assembled.
-Attach the collect bag to the hook on upper tube and the outlet on the bottom of motor
housing.
4. OPERATION
Before starting the machine, make sure that collect bag is fitted and the shoulder harness is
adjusted to a suitable working position.
a. Extension cable
The tool must be connected to an extension cable. Plug the cable of the tool into extension
cable. Then, attach the extension to the cable holder to hold it.
The extension cable shall not be lighter than the standardised code H05 RN-F/H05 VV-F. See
your retailer or manufacturer for more advice.
b. Switching on and off the tool
Before start the tool, be sure that the speed control knob is on the position 1 (lower position).
-To switch on, press the ON/OFF switch (fig 2a).
-To stop the tool, release the ON/OFF switch (fig 2b).
2a 2b
c. Speed Control
You can adjust the power of the air flow with the control knob. The power goes to 1 to 6 (from
the lower to the highest power).
Turn the knob to adjust the power of the airflow, according the work performed.
When stop to use the machine, put the knob to the position 1.
16

d. Blowing mode
Blowing mode can be used for cleaning corners, fences, walls, wooden areas or beneath cars.
Be careful what you point the jet of air as it could move heavy material and cause injury or
damage.
- Inspect the work area before starting. Remove any debris or objects that could be thrown or
those that can get caught or obstruct the device.
- Put the shoulder strap.
- Push down the lever to choose the blowing mode.
- Hold the machine by the handle. Walk and hold the tube just above the ground and blow
the debris.
-Switch on the tool by pushing and holding the ON/OFF switch.
- Work in order to gather the debris in one or more lots. Use the vacuum mode to collect the
heap. You can also pick up the pile of debris with a broom (or rake) and a shovel.
- When the operation is finished, release the ON/OFF switch.
- Throw away the debris in a trash bin.
e. Vacuum mode
- Inspect the work area before starting. Remove any debris or objects that could be thrown or
those that can get caught or obstruct the device.
- Put the shoulder strap.
- Push up the lever to choose the vacuum mode.
- Make sure that the collect bag is fitted properly.
- Switch on the tool by pushing and holding the ON/OFF switch.
- Put the tube to the ground without putting it in the debris. Move while sucking debris
- When the collection bag is filled, stop working and empty the bag.
17

When the collect bag is full, the vacuum power will be greatly reduced. When this happens,
turn the switch to position “1” and disconnect the plug from the electricity supply. Wait
until the suction fan has stopped completely before operation. Open the zip fastener inside
the bag; spread out the opening and empty it completely. If you have collected only leaves
or vegetable matter, they will already have been shredded and will be ready for composting.
Zip up the bag and resume work.
Note: Before re-fitting the bag, clean the inside of the exhaust opening, removing any
shredded deposits. Pay special attention to the cleaning of the supporting edges of the air
flow deviator on the inside of the tube.
5. MAINTENANCE AND STORAGE
WARNING! Do not use products that can damage the device (abrasive, corrosive, alcohols,
steam cleaners, abrasive cloths, scrapers, etc.).
Do not install the appliance in a dishwasher for cleaning!
The unit must be completely switched off, unplugged, and cool before cleaning.
a. Care
After each use:
- Remove the collection bag and empty its contents into a dustbin.
- Use a brush to remove debris from fan and inside the tube.
- If necessary, you can clean the body of the tool with a soft dry cloth.
b. Maintenance
After each use:
- Check all nuts, bolts and screws are tight and that the safety devices are properly
positioned.
- Check if the machine has not suffered damage. If the machine is damaged, you will need to
hire a qualified technician to inspect the machine and makes repairs.
c. Storage
- Always clean the tool before storage.
- The tool, tube and collector bag must be stored in a well-ventilated place, stable and plane.
- The tool must be out of the reach of children.
6. DISPOSAL
Electrical products should not be discarded with household products. According to the
European Directive 2012/19/EC on waste electrical and electronic equipment and its
implementation into national law, electrical products used must be collected separately
and disposed of at collection points provided for this purpose. Talk with your local
authorities or dealer for advice on recycling.
18

7. DECLARATION OF CONFORMITY
BUILDER SAS
ZI, 32 rue, Aristide Bergès – 31270 Cugnaux - France
Tel: [phone] Fax: [phone]
States that the designated below machine:
ELECTRIC BLOWER VACUUM SHREDDER
RAC3000EB
Serial number: 20230704531-20230705030
Developed, designed and manufactured in accordance with the requirements of directives:
Machinery Directive 2006/42/EC
EMC Directive 2014/30/EC
ROHS Directive (EU)2015/863 amending 2011/65/EU
Directive Noise 2000/14/EC Annex V and 2005/88/EC
Sound power level: max 103.7dB(A) K=3 dB(A)
Guarantee sound power level: 107dB(A)
Also meets the following standards
EN 60335-1:2012/A2:2019
EN50636-2-100:2014
EN62233:2008
EN IEC55014-1:2021
EN IEC55014-2:2021
EN IEC61000-3-2:2019/A1:2021
EN 61000-3-3:2013/A2:2021
Philippe MARIE/PDG
Cugnaux, 25/05/2023
Responsible of the technical file: Mr Olivier PATRIARCA
19

WARRANTY
The manufacturer guarantees the product against defects in material and workmanship for a period of 2
years from the date of the original purchase. The warranty only applies if the product is for household use.
The warranty does not cover breakdowns due to normal wear and tear.
The manufacturer agrees to replace parts identied as defective by the designated distributor. The
manufacturer does not accept responsibility for the replacement of the machine, in whole or in part , and/or
ensuing damage.
The warranty does not cover breakdowns due to:
• insu󰀩cient maintenance.
• abnormal assembly, adjustment or operations of the product.
• parts subject to normal wear and tear.
The warranty does not extend to:
• shipping and packaging costs.
• using the tool for a purpose other than that for which it was designed.
• the use and maintenance of the machine done in a manner not described in the user manual.
Due to our policy of continuous product improvement, we reserve the right to alter or change specications
without notice. Consequently, the product may be di󰀨erent from the information contained therein, but a
modication will be undertaken without notice if it is recognized as an improvement of the preceding
characteristic.
READ THE MANUAL CAREFULLY BEFORE USING THE MACHINE.
When ordering spare parts, please indicate the part number or code, you can nd this in the spare parts list
in this manual. Keep the purchase receipt; without it, the warranty is invalid. To help you with your product,
we invite you to contact us by phone or via our website:
• +33 (0)9.70.75.30.30
• https://services.swap-europe.com/contact
You must create a "ticket" via the web platform.
• Register or create your account.
• Indicate the reference of the tool.
• Choose the subject of your request.
• Describe your problem.
• Attach these les: invoice or sales receipt, photo
of the identication plate (serial number), photo
of the part you need (for example: pins on the
transformer plug which are broken).
8. WARRANTY
20
