Racing RACSBE2652 User manual

ORIGINAL INSTRUCTIONS
ELECTRIC LOG SAW
RACSBE2652
RACING
32, rue Aristide Bergès - ZI 31270 Cugnaux – France

DESCRIPTION OF THE SYMBOLS
The use of symbols in this manual is intended to draw your attention to
possible risks. The safety symbols and the explanations that accompany them
must be perfectly understood. The warnings in themselves do not remove the
risks and cannot replace correct actions for preventing accidents.
Read the operator’s manual.
Before any use, refer to the corresponding paragraph in the present manual.
This symbol, before a safety comment, indicates a precaution, a warning or a
danger. Ignoring this warning can lead to an accident for yourself or for others.
To limit the risk of injury, fire, or electrocution always apply the
recommendations indicated.
Risk of electric shock! Risk of personal injury by electric shock.
Wear ear protection, eye protection, helmet, mask, non-skid footwear, gloves
and face protection
Saw blade for cutting wood.
Do not use for face grinding.

Do not use in the rain or leave outdoors while it’s raining.
Keep your hands away from blade and cracks which open in the log;
Always switch off the appliance, disconnect the power and wait till the machine
comes to a standstill prior to maintenance, cleaning or repair work!
Keep children away.
The unit must be always operated by one person only. Other people should
keep a safe distance from the work area, especially when the log saw is under
operations. Never use another people to help you with freeing jammed log.
Conforms to European standards.
The crossed-out wheeled bin symbol indicates that the item should be
disposed of separately from household waste. The item should be handed in
for recycling in accordance with local environmental regulations for waste
disposal. By separating a marked item from household waste, you will help
reduce the volume of waste sent to incinerators or land-fill and minimize any
potential negative impact on human health and the environment.
SPECIAL SAFETY WARNINGS
Observe the permissible dimensions of logs to be cut (see “Technical
Specifications”).

Never cut several workpieces at the same time – and also no bundles
containing several individual pieces. Risk of personal injury if individual pieces
are caught by the saw blade uncontrolled. Never cut log containing the
following:
-ropes
-cords
-cables
-wires
Do not overload machine – use it only within the performance range it was
designed for (see “Technical specifications”).
Use this machine outdoor only.
GENERAL SAFETY WARNINGS
When using this machine observe the following safety instructions, to exclude
the risk of personal injury or material damage.
Please also observe the special safety instructions in the respective chapters;
where applicable, follow the legal directives or regulations for the prevention of
accidents pertaining to the use of circular saw.
General hazards!
1. Be alert. Know what you are doing. Set out to work with reason. Do not
operate machine while under the influence of drugs, alcohol or medication.
2. Keep your work area tidy – a messy work area invites accidents.
3. Regularly clear the work area of the cut logs.
4. Prevent adverse body positions. Ensure firm footing and keep your balance
at all times.
5. Consider environmental effects:
Provide proper lighting.
Do not operate machine near inflammable liquids or gases.
This machine shall only be started and operated by a person familiar with
circular saw and who is at all times aware of the dangers associated with the
use of such machine.
Keep bystanders, particularly children, our of the danger zone. Persons under
18 years of age shall use this machine only in the course of their vocational
training, under the supervision of an instructor.
Do not permit other persons to touch the machine or power cable while it is
running.
6. During operation the machine is standing on level, horizontal ground and
that the floor area around the machine is level, well maintained and free from
loose material e.g. chips and off-cuts.
7. Stock and finished workpieces to be located close to the operators normal
working position.

8. The wear of suitable personal protective equipment when necessary; This
may include:
•Hearing protection to reduce the risk of induced hearing loss;
•Respiratory protection to reduce the risk of inhalation of harmful dust;
•Gloves for handling saw blades (saw blades should be carried in a holder
wherever practicable).
9. Stop the machine running whilst unattended.
10.Report faults in the machine, including guards or saw blades, as soon as
they are discovered.
11.Adopt safe procedures for cleaning, maintenance and remove chips and
dust regularly to avoid the risk of fire.
12.Follow manufacturer’s instructions for use, adjustment and repair of saw
blades.
13.Observe the maximum speed marked on the saw blade.
14.To use correctly sharpened saw blades.
15.Refrain from removing any off-cut or other part of the workpiece from the
cutting area whilst the machine is running except by using a push stick.
16.Use the saw blades designed to reduce the emitted noise.
17.Ensure that guards and other safety devices necessary for machine
operation are in position, in good working order and properly maintained.
18.The saw blade made in conformity to EN847-1: 2013 shall be used on the
machine.
19.Never dismantle the machineʼs safety devices or render them inoperative.
20.To rectify faults or remove jammed pieces of wood, always switch off the
machine first. Pull the power plug!
21.Refit all guards and safety devices immediately after you have completed
any repairs or maintenance work.
22.The circular saw has to be connected to a 230 V socket with a 16 A fuse.
23.Make sure you stand squarely and keep your balance at all times.
24.Each time before re-using the tool, carefully check that the guards or parts
are working as intended.
25.Check that the moving parts are in good working order, that they do not jam,
and that no parts are damaged. Make sure that all parts are fitted correctly and
that all other operating conditions are properly fulfilled.
26.Have damaged switches replaced by a customer service workshop.
27.Use only the transport devices to move the machine. Never use the guards
for handling and moving the machine.
28.All operators must receive proper training in the use, adjustment and
operation of the machine.
29.Make sure that the flanges used are as specified by the manufacturer ,
suitable for the intended use .
30.Make sure you include that necessary for operating the machine guards
and other safety devices are fitted, they are in good operating condition and
properly maintained.

31.Do not use circular saw blades made of high-alloy high-speed steel
Danger! Risk of electric shock!
To ensure the machine remains weatherproof, before any use check to see
that the switch, power cable or plug are not damaged (no cracks, etc.)
Do not use the power cable for any purpose it is not intended for.
Risk of personal injury and crushing by moving parts!
Do not operate the machine without installed guard.
Keep sufficient distance to driven components when operating the machine.
Ensure the machine is disconnected from power supply before servicing.
Ensure that when switching on (e.g. after servicing) no tools or loose parts are
left on or in the machine.
Turn power off if the machine is not used.
Hazard generated by modification of the machine or use of parts
not tested and approved by the equipment manufacturer!
Use only parts approved by the equipment manufacturer. This applies
particularly to :
-Saw blade (see “Technical specifications”)
-ON/OFF switch (type: KOA7)
-Motor (type: YY90-2-1)
Do not change any parts.
Hazard generated by machine defects!
Keep machine and accessories in good repair. Observe the maintenance
instructions.
Before any use check machine for possible damage: before operating the
machine all safety devices, protective guards or slightly damaged parts need
to be checked for proper function as specified. Checked to see that all moving
parts work properly and do not jam. All parts must be correctly installed and
meet all conditions necessary for the proper operation of the machine.
Damaged protection devices or parts must be repaired or replaced by a
qualified specialist. Have damaged switches replaced by a service center. Do
not use this machine if the switch can not be turned ON or OFF.
Keep handles free of oil, grease and resin.
Hazard generated by dust
Pay attention to the factors that influence exposure to dust, this includes:
-Type of material being machined
-Importance of local extraction (capture at source)
-Proper adjustment of hood / baffles / chutes

A The machine should be checked whether inner and outer blade cover、left
and right side table moving cover、inner and outer flange of blade and blade
are proper before operation.
B Pushing the moving worktable forward and check whether left and right table
moving cover and inner and outer blade touch each other so as to avoid
unnecessary damage, while the log saw is working after turning-on the power.
C Please turn off the power supply after using, cleaning the machine, save at
dry airiness place.
Remove plug from mains before maintenance or if cord is damaged
WARNING! Electricity - Risk of electric shock.
Warning symbol
Use a protection for face
SAFE WORKING PRACTICE
It is essential all operators are:
-Adequately trained in the use, adjustment and operation of the machine;
-Instructed in factors that influence exposure to noise e.g.:
saw blade designed to reduce the emitted noise;
saw blade and machine maintenance.
-Informed of factors that influence exposure to dust e.g.:
type of material being machined;
importance of local extraction(capture at source);
proper adjustment of hoods/baffles/chutes;
where provided, dust extraction equipment to be switched on before
commencing machining.
It is important that:
-During operation the machine is standing on level, horizontal ground and
that the floor area around the machine is level, well maintained and free
from loose material e.g. chips and off-cuts;
-Adequate general or localized lighting is provided;
-Stock and finished workpieces are located close to the operator’s normal
working position.
It is essential for the operator to:
-Use a push block or push stick to avoid working with the hands close to the
saw blade when using a dual purpose circular sawing machine for
firewood/circular saw bench in the saw bench mode;

-Wear suitable personal protective equipment when necessary; this could
include;
hearing protection to reduce the risk of induced hearing loss;
respiratory protection to reduce the risk of inhalation of harmful dust;
gloves for handling saw blades (saw blades should be carried in a
holder wherever practicable);
-Refrain from cross cutting logs on a machine in the saw bench mode;
-Stop the machine running whilst unattended;
-report faults in the machine, including guards or saw blades, as soon as
they are discovered;
-Adopt safe procedures for cleaning, maintenance and remove chips and
dust regularly to avoid the risk of fire;
-follow manufacturers instruction for use, adjustment and repair of saw
blades;
-Select the correct riving knife, depending on the saw blade thickness, when
using a dual purpose circular sawing machine for firewood/circular saw
bench in the saw bench mode;
-Observe the maximum speed marked on the saw blades;
-Use correctly sharpened saw blades;
-Ensure that any spacers and spindle rings used are suitable for the
purpose as stated by the manufacturer;
-refrain from removing any off-cut or other part of the workpiece from the
cutting area whilst the machine is running except by using a push stick;
-Ensure that guards and other safety devices necessary machine operation
are in position, in good working order and properly maintained.
RESIDUAL RISK
The following risks are inherent to the use of these machines:
■ Injuries caused by touching the rotating parts
■ Injuries caused by disruption of the cutting blade
These risks are most evident:
■ Within the range of operation
■ Within the range of the rotating machine parts
In spite of the application of the relevant safety regulations and the
implementation of safety devices, certain residual risks cannot be avoided.
These are:
■ Impairment of hearing.
■ Risk of accidents caused by the uncovered parts of the rotating cutting
blade.
■ Risk of injury when changing the blade.
■ Risk of squeezing fingers when opening the guards.
- Braking should be verified every before use, running the machine, switch off
then check the stopping time.

- Only saw blades made in conformity to EN 847-1:1997 shall be used on the
machine;
- The machine during indoor use shall be connected to an external chip and
dust extraction system;
- A Residual Current Device (RCD) should be used
INTENDED USE
This machine is only intended for cutting firewood as detailed in these
instructions. Unspecified use, modifications to the machine, or use of parts not
tested and approved by the equipment manufacturer may cause
unforeseeable damage!
This machine is intended for operation by ONE person. Other persons shall
keep a sufficient distance to the machine.
TECHNICAL SPECIFICATIONS
Voltage
230V~ 50Hz
Protection class
IP54
Power input
2600W (S6, 40%)
Rated speed
2800 min-1
Saw blade
Ø505 × Ø30 × 3.6mm x 40T
Cutter Capacity
Ø30-170mm
Machine weight
76kg
Sound pressure level LpA:
91 dB(A) K=2 dB(A)
Sound power level LwA:
105 dB(A) K=2 dB(A)
Measured sound values determined according to EN ISO 3744
The noise figures quoted are emission levels and are not necessarily safe
working levels. Whilst there is a correlation between the emission and
exposure levels, this cannot be used reliably to determine whether or not
further precautions are required. Factors that influence the actual level of
exposure of work-force include the characteristics of the work room, the other
sources of noise, etc. i.e. the number of machines and other adjacent
processes, and the length of time for which an operator is exposed to the noise.
Also the permissible exposure level can vary from country. This information,
however, will enable the user of the machine to make a better evaluation of the
hazard and risk.
Wear hearing protection!
Pay attention to the factors that influence exposure to noise, this includes:
-Use saws blades designed to reduce the emitted noise
-Maintain saw blade and the machine properly
1. Open package and take out all parts. (see picture 1)

Picture 1
1. Main machine 2. Wheel parts 3. operating handle 4.ruler bar
5. wood supporter 6. cover for working table
7.weight balancer 8. connect plate for working table
9. working table
2. Disassemble the spring pipe（see picture 2）to put it into the right fixer,
screw it with M18 anti-loose nut (see picture 4).
Picture 2 Picture 3

Picture 4
3. Assemble the wheel parts. Firstly disassemble all screws and nuts on it.
Then connect it with the frame and tighten all screws and nuts (see picture 5
and picture 6).
Picture 5 picture 6
4. Assemble the vice working table. Firstly use four M8X15 large
semicircular head square neck bolts to assemble the connect plate for vice
working table on main working table , secondly use four M8X15 large
semicircular head square neck bolts to assemble vice working table on
connect plate (see picture 7 and picture 8).

Picture 7 Picture 8
5. Assemble the working table cover. Insert the rotating block on cover into
the corresponding fixing block on working table and fix it with M4x8 cross
countersunk head screw (see picture 9).
Picture 9
6. Assemble the operating handle. Put it into the right holes on working table
and tighten the rotary knobs after get a comfortable height (see picture 10) .

Picture 10
7. Assemble the wood supporter and ruler bar ，put them into
corresponding holes（see picture 11 and picture 12）.
Picture 11 picture 12

Sawing
1. Turn on the machine.
2. Wait until the saw blade has reached full speed.
3. Put the wood on the rocker.
4. Take hold of handle bar of the rocker with both hands and lead it evenly to
the saw blade; thus the saw blade is revealed.
5. Push the rocker evenly to ensure the engine speed does not drop.
6. Remove the sawn wood from the rocker before putting on the next piece.
Safe removal of possible blocking
Unplug the machine.
Check it and localize the blocking.
Remove the blocking while considering all safety instructions.
Check the machine visually and make sure it is not damaged. In particular, the
saw blade must not show any sign of damage.
MAINTENANCE
-Warning: Turn off the machine and disconnect from the power supply
before conducting maintenance work or settings.
-Wear goggles when cleaning the machine.
-Handle your device carefully and out of reach of the children.
-Have your tool repaired by a qualified person. This power tool complies
with the applicable safety standards. Repairs should be performed only by
qualified persons using original spare parts, otherwise this may make the use
extremely dangerous.
-Use only the blade recommended by the manufacturer for this model. If a
blade is damaged, it must only be repaired by the manufacturer or qualified
persons.
-Use only well-sharpened, crack-free and not distorted blades.
-Use only blades that comply with the European standard EN 847-1.
-Ensure that there are no tools or other materials on or in the machine
before putting it into operation.
-Exchange immediately rocker that run out.
Before and after each use
-Check the blade
-Make the air vents are never obstructed by debris or accumulation of other
objects, as this may damage the engine or cause a fire risk.
-Clean your tool, using a damp cloth and a soft brush. Never clean the
product with water and never immerse it in liquid. Never use solvents or
detergents as this may damage the plastic parts of the product.
-Check all safety
-Remove possible sawdust blockages at the discharge.

Every 50 hours of operation
-Check all screwed connections, tighten if necessary (Rocker and rocker
stop must remain movable)
STORAGE
-Store the manual close to the machine.
-Always wait the appliance cool down before storage.
-Always store the log saw in a dry area.
-Wipe the log saw clean with a brush. Apply a thin layer of oil using an oily
cloth to protect the machine from rust, before storage.
TROUBLESHOOTING TABLE
Warning: In the interests of operational safety, always switch off the saw
and remove the mains plug before carrying out maintenance work.
Problem
Possible Cause
Help
Saw blade gets loose
after turning off the motor
Fastening nut tightened
insufficiently
Tighten fastening nut,
M20 left-handed thread
Motor does not start
a) Failure mains fuse
b) Extension cable
defect
c) Connections on the
motor or switch defect
d) Motor or switch defect
a) Check the mains fuse.
b) Replace extension
cord
c) Have a mechanic
check by a professional
d) Have a mechanic by a
professional
No motor output turns off
automatically
Overload by dull saw
blade, thermo protection
is triggered
Insert a sharpened saw
blade; motor can be
turned on again after the
cooling period
Burns on the cutting
surface
a) Fastening nut
tightened insufficiently
b) Wrong saw blade
a) Insert a sharpened
saw blade
b) Insert saw blade with
20 or 28 teeth for
longitudinal cuts

EC Conformity declaration
RACING
ZI, 32 rue Aristide Bergès – 31270 Cugnaux - France
Tel: [phone] Fax: [phone]
The undersigned, hereby certifies that the units described below
ELECTRIC LOG SAW
Model: RACSBE2652
S/N:
is in compliance with the provisions of the following European directives:
2014/30/EU " Electromagnetic Compatibility "
2006/42/EC "Machinery"
2011/65/EU "ROHS"
And to the following standards:
EN55014-1: 2017
EN55014-2:2015
EN61000-3-2: 2014
EN61000-3-11: 2000
EN 1870-6: 2017
EN 60204-1: 2006/A1: 2009
EC-type certificate number:
Notified Body: No 0123
The people name holding the technical file：Mr. Olivier Patriarca
Cugnaux, 24/05/2019
Philippe MARIE / PDG
