Ingco CS18528 User manual

Circular Saw
EN Circular Saw
ES Sierra Circular
CS18528 UCS18528
CS18528S CS18528-4
CS18528-6 CS18528-8
CS18528-6E
CS18568 UCS18568
CS18568S CS18568-6
CS18568-8
CS18528 UCS18528 CS18528S CS18528-4
CS18528-6
CS18528-8 CS18528-6E CS18568 UCS18568
CS18568S
CS18568-6 CS18568-8
ingcoglobal
INGCO GLOBAL
SCAN FOR VIDEO

2|English
The symbols in instruction manual and the label on the tool
Double insulated for additional protection.
Read the instruction manual before using.
CE conformity.
Wear safety glasses, hearing protection and dust mask.
Waste electrical products should not be disposed of with household waste.
Please recycle where facilities exist. Check with your Local Authority or
retailer for recycling advice.
Safety alert.
Please only use the accessories supported by the manufacture.

3|English
GENERAL POWER TOOL SAFETY WARNINGS
WARNING Read all safety warnings, instructions, illustrations and
specifications provided with this power tool. Failure to follow all instructions
listed below may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term "power tool" in the warnings refers to your mains-operated (corded)
power tool or battery-operated (cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit. Cluttered or dark areas invite
accidents.
b) Do not operate power tools in explosive atmospheres, such as in
the presence of flammable liquids, gases or dust. Power tools create
sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug in
any way. Do not use any adapter plugs with earthed (grounded)
power tools. Unmodified plugs and matching outlets will reduce risk of
electric shock.
b) Avoid body contact with earthed or grounded surfaces, such as
pipes, radiators, ranges and refrigerators. There is an increased risk
of electric shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water
entering a power tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling
or unplugging the power tool. Keep cord away from heat, oil, sharp
edges or moving parts. Damaged or entangled cords increase the risk
of electric shock.
e) When operating a power tool outdoors, use an extension cord

4|English
suitable for outdoor use. Use of a cord suitable for outdoor use
reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable, use a
residual current device (RCD) protected supply. Use of an RCD
reduces the risk of electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use common sense
when operating a power tool. Do not use a power tool while you are
tired or under the influence of drugs, alcohol or medication. A
moment of inattention while operating power tools may result in serious
personal injury.
b) Use personal protective equipment. Always wear eye protection.
Protective equipment such as a dust mask, non-skid safety shoes, hard
hat or hearing protection used for appropriate conditions will reduce
personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-
position before connecting to power source and/or battery pack,
picking up or carrying the tool. Carrying power tools with your finger
on the switch or energising power tools that have the switch on invites
accidents.
d) Remove any adjusting key or wrench before turning the power
tool on. A wrench or a key left attached to a rotating part of the power
tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all times.
This enables better control of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep
your hair and clothing away from moving parts. Loose clothes,
jewellery or long hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction and
collection facilities, ensure these are connected and properly used.
Use of dust collection can reduce dust-related hazards.
h) Do not let familiarity gained from frequent use of tools allow you
to become complacent and ignore tool safety principles. A careless
action can cause severe injury within a fraction of a second.

5|English
4) Power tool use and care
a) Do not force the power tool. Use the correct power tool for your
application. The correct power tool will do the job better and safer at the
rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and
off. Any power tool that cannot be controlled with the switch is
dangerous and must be repaired.
c) Disconnect the plug from the power source and/or remove the
battery pack, if detachable, from the power tool before making any
adjustments, changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting the power tool
accidentally.
d) Store idle power tools out of the reach of children and do not
allow persons unfamiliar with the power tool or these instructions
to operate the power tool. Power tools are dangerous in the hands of
untrained users.
e) Maintain power tools and accessories. Check for misalignment
or binding of moving parts, breakage of parts and any other
condition that may affect the power tool’s operation. If damaged,
have the power tool repaired before use. Many accidents are caused
by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting
tools with sharp cutting edges are less likely to bind and are easier to
control.
g) Use the power tool, accessories and tool bits etc. in accordance
with these instructions, taking into account the working conditions
and the work to be performed. Use of the power tool for operations
different from those intended could result in a hazardous situation.
h) Keep handles and grasping surfaces dry, clean and free from oil
and grease. Slippery handles and grasping surfaces do not allow for
safe handling and control of the tool in unexpected situations.

6|English
5) Service
a) Have your power tool serviced by a qualified repair person using
only identical replacement parts.
power tool is maintained.
Additional Safety Warnings
Safety instructions for all saws
Cutting procedures
a) DANGER: Keep hands away from cutting area and the blade. Keep
your second hand on auxiliary handle, or motor housing. If both hands are
holding the saw, they cannot be cut by the blade.
b) Do not reach underneath the workpiece. The guard cannot protect you
from the blade below the workpiece.
c) Adjust the cutting depth to the thickness of the workpiece. Less than a
full tooth of the blade teeth should be visible below the workpiece.
d) Never hold the workpiece in your hands or across your leg while
cutting. Secure the workpiece to a stable platform. It is important to support
the work properly to minimize body exposure, blade binding, or loss of control.
e) Hold the power tool by insulated gripping surfaces, when performing
an operation where the cutting tool may contact hidden wiring or its own
cord. Contact with a "live" wire will also make exposed metal parts of the
power tool "live" and could give the operator an electric shock.
f) When ripping, always use a rip fence or straight edge guide. This
improves the accuracy of cut and reduces the chance of blade binding.
g) Always use blades with correct size and shape (diamond versus
round) of arbour holes. Blades that do not match the mounting hardware of
the saw will run off-centre, causing loss of control.
h) Never use damaged or incorrect blade washers or bolt. The blade
washers and bolt were specially designed for your saw, for optimum
performance and safety of operation.

7|English
c) When restarting a saw in the workpiece, centre the saw blade in the
kerf so that the saw teeth are not engaged into the material. If a saw blade
binds, it may walk up or kickback from the workpiece as the saw is restarted.
d) Support large panels to minimise the risk of blade pinching and
kickback. Large panels tend to sag under their own weight. Supports must be
placed under the panel on both sides, near the line of cut and near the edge of
the panel.
e) Do not use dull or damaged blades. Unsharpened or improperly set
blades produce narrow kerf causing excessive friction, blade binding and
kickback.
f) Blade depth and bevel adjusting locking levers must be tight and
secure before making the cut. If blade adjustment shifts while cutting, it may
cause binding and kickback.
g) Use extra caution when sawing into existing walls or other blind areas.
The protruding blade may cut objects that can cause kickback.
Safety instructions for saws with pendulum guard and saws with tow
guard
Lower guard function
a) Check the lower guard for proper closing before each use. Do not
operate the saw if the lower guard does not move freely and close
instantly. Never clamp or tie the lower guard into the open position. If the
saw is accidentally dropped, the lower guard may be bent. Raise the lower
guard with the retracting handle and make sure it moves freely and does not
touch the blade or any other part, in all angles and depths of cut.
b) Check the operation of the lower guard spring. If the guard and the
spring are not operating properly, they must be serviced before use.
Lower guard may operate sluggishly due to damaged parts, gummy deposits,
or a build-up of debris.
c) The lower guard may be retracted manually only for special cuts such
as "plunge cuts" and "compound cuts". Raise the lower guard by the
retracting handle and as soon as the blade enters the material, the lower
guard must be released. For all other sawing, the lower guard should operate
automatically.
d) Always observe that the lower guard is covering the blade before
placing the saw down on bench or floor. An unprotected, coasting blade will
cause the saw to walk backwards, cutting whatever is in its path. Be aware of
the time it takes for the blade to stop after switch is released.

8|English
Residual risks
Even when the power tool is used as prescribed it is not possible to
eliminate all residual risk factors. The following hazards may arise in
connection with the power tool’s construction and design:
a) Health defects resulting from vibration emission if the power tool is being
used over longer period of time or not adequately managed and properly
maintained.
b) Injuries and damage to property to due to broken accessories that are
suddenly dashed.
Warning! This power tool produces an electromagnetic field during
operation. This field may under some circumstances interfere with active or
passive medical implants. To reduce the risk of serious or fatal injury, we
recommend persons with medical implants to consult their physician and the
medical implant manufacturer before operating this power tool.

9|English
1
1
12
6
11
10
7 8 9
2 3
12 2 3
A
B
11
9
4 5

10lEnglish

11|English
Model
No.
CS18528
CS18528
-4
(IRAM Plug)
CS18528
-6
(ISRAEL Plug)
CS18528
-8
(BS Plug)
CS18528S
Voltage
220-240V~50/60Hz
Power rating
1400 W
Idle speed
4800/min
Cutting depth at 45°
45 mm
Cutting depth at 90°
65 mm
Saw blade
185 mm
Totally insulated
II/
Model
No.
CS18568
CS18568-6
(ISRAEL Plug)
CS18568-8
(BS Plug)
CS18568
(SAA Plug)
Voltage
220-240V~50/60Hz
Power rating
1600 W
Idle speed
5000/min
Cutting depth at 45°
45 mm
Cutting depth at 90°
65 mm
Saw blade
185 mm
Totally insulated
II/
1. Description(Fig.1+Fig.2)
1. Handle
2. On/Off switch
3. Interlock button for On/Off switch
4. Locking lever for cutting depth setting
5. Power cable
6. Hinged guard hood
7 . Flange
8 . Saw blade
9 . Parallel stop
10. Lock screw for the parallel stop
11. Lock screw for mitre cuts
12. Additional handle
Please read these instructions carefully and pay
particular attention to the safety regulations. Keep
the instructions together with the circular saw.
2. Technical data
(SAA Plug)
Model
No. CS18528-6E UCS18528
Voltage
220-240V~50/60Hz
110-120V~50/60Hz
Power rating
1400 W
1400 W
Idle speed
4800/min
4800/min
Cutting depth at 45°
45 mm
45mm(1-3/4 ″ )
Cutting depth at 90°
65 mm
65mm(2-9/16 ″ )
Saw blade
185 mm
185mm(7-1/4 ″ )
Totally insulated
II/
II/
S
Model
No. UCS18568
Voltage
110-120V~50/60Hz
Power rating
1600 W
Idle speed
5000/min
Cutting depth at 45°
45mm(1-3/4 ″ )
Cutting depth at 90°
65mm(2-9/16 ″ )
Saw blade
185mm(7-1/4 ″ )
Totally insulated
II/
3. Applications
The hand-held circular saw is designed for sawing
straight cuts in wood, in materials similar to wood,
and in plastics.
4. Safety regulations
The corresponding safety information can be found
in the enclosed booklet.
5. Working with the hand-held
circular saw
Always hold the circular saw firmly.
The hinged guard hood will be pushed back
automatically by the workpiece.
Never apply force! Advance the circular saw
gently and steadily.
The off-cut piece should be to the right of the
circular saw so that the wide part of the base
plate is supported over its entire surface.
When sawing along a marked line, guide the
circular saw along the corresponding groove.
Clamp small pieces of wood securely before
sawing. Never hold them in your hand.
Always observe the safety regulations! Wear
goggles!
Do not use defective saw blades or blades with
cracks or flaws.
Do not use flanges or flange nuts with a hole
which is larger or smaller than that of the saw
blade used.
Do not try to stop the saw blade with your hand
or by applying pressure to the side of the blade.
The hinged guard must not jam and must return
to its original position once work is completed.
Before plugging in the circular saw, check that
the hinged guard is functioning properly.
Before each use, always check that the safety
devices - the hinged guard, splitter, flanges and
adjustment devices - are functioning properly and
have been adjusted and secured correctly.
You can connect a suitable dust extractor to the
guard hood. Check that the dust extractor is fitted
securely and properly.
The hinged guard hood is not to be wedged in
the retracted guard hood when sawing.

12|English
Parallel cuts (Fig. 3)
Important! Wear ear muffs and
goggles.
1. Release the lock screw 11.
2. For 90° cuts, adjust the parallel stop 9 using
the scale on groove A, for 45° cuts adjust the
parallel stop 9 using the scale on groove B.
Observe the saw blade width.
3. Tighten the lock screw.
Important!
First make a trial cut. Adjustment of
the cutting depth (Fig. 4)
1. Release the locking lever 4.
2. Swing the shoe downwards.
3. Adjust the cutting depth using the scale.
The saw teeth must project approx. 2 mm out
of
the
wood.
4. Push the locking lever down
Adjustment of the cutting angle (Fig. 5)
1. Release the lock screw 11
2. Adjust the cutting angle to the desired
angle between 0 and 45°.
3. Tighten the lock screw 11.
Changing the saw blade (Fig. 6)
Important! Pull out the plug before making
any changes to the circular saw!
1. Open the hinged guard hood 6 and hold.
2. Press the lock button.
3. Undo the screw
4. Remove the flange 7 and the saw blade
by dropping down and out.
5. Clean the flange and insert a new blade. Note
the direction of rotation (see arrow on the guard
hood).
6. Tighten the screw and check for concentricity.
Switching on
Before pressing the On/Off switch, check that the
saw blade is properly fitted, that the moving parts
run smoothly and that the clamping screws are
tight.
Switching on and off (Fig. 7)
To switch on: Press the interlock button 2
and the switch 3
simultaneously.
To switch off: Release the interlock button
and the switch.
6. Maintenance
Keep the cooling vents on the motor housing clean
and unobstructed at all times. Blow out any dust
and dirt at regular intervals.
Have a specialist workshop check the carbon
brushes in the event of excessive sparking.
Worn carbon brushes are to be replaced only by a
specialist workshop or by our Customer Service
Centre.
Keep the machine clean at all times.
Never use any caustic agents to clean the plastic
parts.
If ever you discover any damage, consult the
exploded drawing and parts list to determine
exactly which replacement parts you need to order
from our Customer Service Centre.

15
10
CS18528,UCS18528,CS18528S,CS18528-4,CS18528-6,CS18528-8,
CS18528-6E,CS18568,UCS18568,CS18568S,CS18568-6,CS18568-8
61
60
59
58
57
51
50
56
48
49
55 47
54
53
43
52
42
41
40
39
38
45
46
44
37
36
35
30
29
28
27
26
25
24
23
34
22
33
21
20
32
19 31
18
17
16
11
15 12
13
7
14
2
7
10
8 47
62
63
9
1 2 3 4 5 6 7 8

6
CS18528,UCS18528,CS18528S,CS18528-4,CS18528-6,CS18528-8,
CS18528-6E,CS18568,UCS18568,CS18568S,CS18568-6,CS18568-8
No.
Part Description
Qty
No.
Part Description
Qty
1
base
1
33
Elastic cylindrical pin
1
2
rivet
2
34
bearing 607
1
3
spring
1
35
Head
1
4
screw M6x12
1
36
self-locking spring
1
5
screw φ6x40
1
37
Self-locking
1
6
angle bracket
1
38
bearing 6001RS
1
7
washer φ16xφ6.5x1.5
3
39
rotor
1
8
Nut M6
2
40
bearing 608
1
9
Nut M5
1
41
bearings spacer
1
10
screw M6x16
1
42
Wind fence
1
11
screw M6x14
1
43
screw st5x65
2
12
Deep locking lever
1
44
stator
1
13
Nut M6x20
1
45
Extension spring
2
14
depth bracket
1
46
brush holder
2
15
screw M8x16
1
47
carbon brush
2
16
outer flange
1
48
brush cover
2
17
clamping flange
1
49
motor cover
1
18
screw M4×10
3
50
screw M5x40
3
19
cover flange
1
51
screw M5x8
3
20
screw M4×10
1
52
right grip
1
21
Spanner
1
53
switch
1
22
blade cover
1
54
capacitor(Option)
2
23
front cover
1
55
left grip
1
24
Compression spring
1
56
screw ST4X22
1
25
screw M5x12
4
57
screw ST4X16
5
26
bearing 6002RS
1
58
screw ST4X14
2
27
front cover
1
59
cord clip
1
28
spindle
1
60
cord protector
1
29
Woodruff key 4×13
1
61
Electric cable
1
30
Big gear
4
62
spanner
1
31
screw M5x20
1
63
Parallel stop
1
32
ring
1

INGCO TOOLS
CO.,LIMITED
www.ingco.com
MADE IN CHINA
0419.V07
CS18528 UCS18528 CS18528S CS18528-4
CS18528-6
CS18528-8 CS18528-6E CS18568 UCS18568
CS18568S
CS18568-6 CS18568-8
