Racing RAC36CS-UK User manual

1
Instruction Manual
Cordless grass and shrub shears
RAC36CS-UK
Translation of Original Instructions
Read carefully this manual before any use. This manual contains important
recommendations concerning the safety.
32 rue aristide Bergès - ZI 31270 Cugnaux – France

2
Safety Instructions
Cordless Grass and Shrub Shears
Please read and save these instructions.
TOOL SAFETY WARNINGS
WARNING Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or serious
injury.
Save all warnings and instructions for future reference.
The term "power tool" in the warnings refers to your mains-
operated (corded) power tool or battery-operated (cordless)
power tool.
1) Work area safety
a) Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks which
may ignite the dust or fumes.
c) Keep children and bystanders away while operating

3
a power tool. Distractions can cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools. Unmodified
plugs and matching outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock
if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of electric
shock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool. Keep
cord away from heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase the risk of electric
shock.
e) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a cord

4
suitable for outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electric shock.
NOTE the term “residual current device (RCD)” may be
replaced by the term “ground fault circuit interrupter (GFCI)”
or “earth leakage circuit breaker (ELCB)”.
3) Personal safety
a) Stay alert, watch what you are doing and use
common sense when operating a power tool. Do not
use a power tool while you are tired or under the
influence of drugs, alcohol or medication. A moment of
inattention while operating power tools may result in
serious personal injury.
b) Use personal protective equipment. Always wear
eye protection. Protective equipment such as dust mask,
non-skid safety shoes, hard hat, or hearing protection used
for appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is

5
in the off-position connecting to power source and/or
battery pack, picking up or carrying the tool. Carrying
power tools with your finger on the switch or energizing
power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to a
rotating part of the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power tool
in unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or long hair
can be caught in moving parts.
g) If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection can
reduce dust-related hazards.
4) Power tool use and care
a) Do not force the power tool. Use the correct power

6
tool for your application. The correct power tool will do
the job better and safer at the rate for which it was
designed.
b) Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be controlled with
the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or
the battery pack from the power tool before making
any adjustments, changing accessories, or storing
power tools. Such preventive safety measures reduce the
risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and any
other condition that may affect the power tool’s
operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly
maintained power tools.

7
f) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are less
likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in
accordance with these instructions, taking into
account the working conditions and the work to be
performed. Use of the power tool for operations different
from those intended could result in a hazardous situation.
5) Battery tool use and care
a) Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type of
battery pack may create a risk of fire when used with
another battery pack.
b) Use power tools only with specifically designated
battery packs. Use of any other battery packs may create
a risk of injury and fire.
c) When battery pack is not in use, keep it away from
other metal objects, like paper lips, coins, keys, nails,
screws or other small metal objects, that can make a

8
connection from one terminal to another. Shorting the
battery terminals together may cause burns or a fire.
d) Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact accidentally
occurs, flush with water. If liquid contacts eyes,
additionally seek medical help. Liquid ejected from the
battery may cause irritation or burns.
6) Service
a) Have your power tool serviced by a qualified repair
person using only identical replacement parts. This will
ensure that the safety of the power tool is maintained.
Hedge trimmer safety warnings:
Keep all parts of the body away from the cutter
blade. Do not remove cut material or hold material
to be cut when blades are moving. Make sure the
switch is off when clearing jammed material. A
moment of inattention while operating the hedge
trimmer may result in serious personal injury.

9
Carry the hedge trimmer by the handle with the
cutter blade stopped. When transporting or storing
the hedge trimmer always fit the cutting device
cover. Proper handling of the hedge trimmer will reduce
possible personal injury from the cutter blades.
Keep cable away from cutting area. During operation
the cable may be hidden in shrubs and can be
accidentally cut by the blade
Instruction to hold the hedge trimmer properly, e.g. with
both hands if two handles are provided.
Never operate the machine while people, especially
children, or pets are nearby
Do not to overreach and to keep balance at all times, to
always be sure of footing on slopes and walk, never run
Do not to touch moving hazardous parts before the
machine is disconnected from the mains and the moving
hazardous parts have come to a complete stop.
Never to operate the machine with defective guards or
shields, or without safety devices,
Residual risks

10
Even if you use this product in compliance with all safety
requirements, the potential risks of injury and damage
remain. The following hazards may arise in the structure
and design of this product:
a. There are harmful health consequences resulting from
the emission of vibrations if the product is used for long
periods of time or not properly managed and properly
maintained.
b. Risk of injury to persons and property caused by flying
objects.
c. Prolonged use of this product exposes the operator to
vibration and can produce so-called "white finger"
disease. To reduce the risk, wear gloves and keep your
hands warm.
d. If any of the symptoms of "white finger syndrome"
occur, seek immediate medical attention. Symptoms of
the "white finger" include numbness, loss of sensitivity,
tingling, and pain, loss of strength, colour changes or skin
condition. These symptoms usually appear on the fingers,
hands or wrists. Risk increases at low temperatures.

11
e. Inhalation of particles
f. Unattended projections
g. Contact with foreign objects
h. Contact with the tool in operation
i. Hearing loss in the absence of correct hearing
protection
General safety regulations for electric tools
This equipment is not designed to be used by people (including children) with limited physical,
sensory or mental capacities or those with no experience and/or knowledge unless they are
supervised by a person who is responsible for their safety or they have received instructions
from such a person in how to use the equipment safely. Children must always be supervised in
order to ensure that they do not play with the equipment.
Additional safety instructions
• The battery pack supplied with your cordless tool is not charged. The battery pack has to be
charged before you use the tool for the first time.
• The battery pack does not reach its maximum capacitance until it has been charged and
discharged approximately five times.
• Battery packs lose their charge even when they are not being used. Regular charging is
therefore recommended.
• Please check the data marked on the rating plate of the battery charger. Be sure to connect
the battery charger to a power supply with the voltage marked on the rating plate. Never
connect it to a different mains voltage.
• Keep the battery charger and the cordless tool out of children’s reach.

12
• Wear suitable work clothes. Wear safety goggles.
• Never open the battery pack. Avoid contact with a leaking battery pack. In case of accidental
contact, wash the affected area of skin with soap and water. If battery acids gets in your eye,
rinse out the eye with clear water for at least 10 minutes and seek a doctor’s advice
immediately. Neutralize other affected areas with a mild acid such as lemon juice or vinegar.
• Protect the battery charger and its cable from damage and sharp edges. Have damaged
cables repaired without delay by a qualified electrician.
• Make sure that the contacts of the battery pack do not come into contact with other metallic
objects such as nails or screws. There is a risk of short-circuiting!
• Use only battery chargers that are intended for the battery pack in question.
• Do not use damaged battery chargers.
• Leave repairs strictly to the appointed service center or authorized dealers.
• Do not use the supplied battery charger to charge other cordless tools.
• Never allow the battery pack to become fully discharged. This will cause it to develop a
defect.
• Timely recharging of the battery pack will help it serve you well for a long time. You must
recharge the battery pack when you notice that the power of the cordless tool drops.
• In heavy use the battery pack will become warm. Allow the battery pack to cool to room
tempera ture before commencing with the charging.
• Protect your cordless tool and the battery charger from moisture and rain.
• Do not use the cordless tool or the battery charger near vapors and inflammable liquids.
• Do not throw battery packs into an open fire. There is a risk of explosion!
• Use the battery charger only in dry conditions and an ambient temperature of 10-40°C.
• Do not keep the battery charger in places where the temperature is liable to reach 50°C. In
particular, do not leave the battery charger in a car that is parked in the sunshine.
• Do not ignite the battery pack or expose it to fire.
Do not lose these safety instructions.

13
Rechargeable batteries and cordless electric machines and tools contain materials that are
potentially harmful to the environment. Never place any cordless electric machines or tools in
your household refuse. When cordless electric machines or tools become defective or worn,
remove the rechargeable batteries and return them to iSC GmbH Eschenstrasse 6, D-94405,
Germany. If the rechargeable batteries cannot be removed, return the complete cordless
machine or tool. You can then be sure that the equipment will be correctly disposed of by the
manufacturer.
Safety instructions for grass shears
• Before you begin your work, examine the material you want to cut. Remove any foreign
bodies. Keep a continuous watch out for foreign bodies while you are working. If you come
across any foreign bodies while cutting, turn off the device (release the ON button) and
remove the items in question.
• Keep the device at a suitable distance from your body while working. Only switch on the
device when all parts of the body are well out of the way.
• Make sure that no people or animals ever come within the working or swiveling range of the
device.
• Only use the device in broad daylight or make sure that you provide adequate artificial light.
• Important! The cutting tools continue running on after the device has been switched off.
• When the device is not in use, make sure that it is stored in such a way that there is no risk
of hands coming into contact with the cutting blades.
• If the cutting blades get jammed while cutting, turn off the device (release the ON button)
and remove the object in question (thick branch, foreign body) with a suitable blunt aid.

14
Never remove any such objects with your fingers as the pre-tensioned blade can cause
serious injuries through cutting.
• Keep the air vents clean.
• Keep the charging cable away from the blades. Never use the device with the charging
cable plugged in.
• We recommend that you use a socket with a residual current device with maximum 30mA
tripping current for the charger.
• Never attempt to remove the cuttings with the motor running or to hold material you wish to
cut. Always switch off the device before attempting to remove any jammed cuttings.
• Make sure you keep all parts of your body away from the blade. Never attempt to remove
the cuttings with the blade running or to hold the material you wish to cut. Always switch off
the equipment before attempting to remove any jammed cuttings. A single moment of
carelessness when using the hedge trimmer can result in serious injuries.
• Carry the hedge trimmer by its handle with the blades at a standstill. Always fit the protective
cover when transporting the hedge trimmer or putting it into storage. Careful handling of the
equipment reduces the likelihood of injury by the blade.
• Keep the cable out of the cutting zone. During operation the cable may be hidden by the
hedge and be cut through by accident.
• Hold the equipment correctly, for example with both hands if the equipment is fitted with two
handles.
• Familiarize yourself with the operator controls and proper operation of the machine.
• Local regulations may set minimum age requirements for the user.
• Always keep in mind that the operator or user of the equipment is responsible for accidents
or risks involving other persons or their property.
• Never use the machine with safety devices which are damaged or fitted in the wrong
position.
• Beware of injuries to your feet and hands by the cutting mechanism.
• Use only spare parts and accessories which are recommended by the manufacturer.
• Do not switch on the motor until your hands and feet are a safe distance from the cutting
mechanism.
• Switch off the machine:
- whenever it is left unattended;

15
- before inspecting or cleaning the machine and before carrying out any work on it;
- if it begins to vibrate excessively.
• Hold the power tool by the insulated handles because the blade may strike concealed power
cables. Contact between the blade and a live cable can make the metal parts of the
equipment live and will cause an electric shock.
• It is recommended to search the hedge for hidden objects such as wire fencing.
4
3
2
1
8
5
6

16
Fig. 1
Fig.2
Fig. 3 Fig. 4
Fig. 5
A
6
1
2
2
1

17
Fig. 6
Important!
When using the equipment, a few safety precautions must be observed to avoid injuries and
damage. Please read the complete operating instructions and safety regulations with due care.
Keep this manual in a safe place, so that the information is available at all times. If you give the
equipment to any other person, hand over these operating instructions and safety regulations
as well. We cannot accept any liability for damage or accidents which arise due to a failure to
follow these instructions and the safety instructions.
1. Safety regulations
The corresponding safety information can be found in the enclosed booklet.
Caution!
Read all safety regulations and instructions.
Any errors made in following the safety regulations and instructions may result in an electric
shock, fire and/or serious injury.
Keep all safety regulations and instructions in a safe place for future use.
Explanation of the warning signs on the machine (Figure 6)
1. Important! Read the operating instructions and follow the warnings and safety instructions
2. Keep all other persons away from the danger zone.
3. Caution! The cutter blades continue to run after the motor is switched off . Wait for the
blades to come to a standstill.

18
Risk of injury!
4. Dispose of batteries correctly!
5. Protect the tool from the damp and never expose it to rain.
6. Guaranteed sound power level: 87dB
2. Layout and items supplied
2.1 Layout (Fig. 1)
1 Grass cutter blade
2 Blade release mechanism
3 Safety lock-off
4 ON button
5 Blade guard
6 Battery charger
2.2 Items supplied
• Open the packaging and take out the equipment with care.
• Remove the packaging material and any packaging and/or transportation braces (if available).
• Check to see if all items are supplied.
• Inspect the equipment and accessories for transport damage.
• If possible, please keep the packaging until the end of the guarantee period.
Important!
The equipment and packaging material are not toys. Do not let children play with plastic
bags, foils or small parts. There is a danger of swallowing or
suffocating!
• Original operating instructions

19
• Safety instructions
3. Proper use
The equipment is designed for cutting the edges of lawns and small areas of grass in private
and hobby gardens.
Tools for private and hobby gardens are not suitable for use in public facilities, parks and sport
centers, along roadways, on farms or in the forestry sector. For the tool to be used properly it is
imperative to follow the instructions set out in the manufacturer’s directions for use.
Important! It is prohibited to use the tool to chop material for composting because of the
potential danger to persons and property.
The machine is to be used only for its prescribed purpose. Any other use is deemed to be a case
of misuse. The user / operator and not the manufacturer will be liable for any damage or injuries
of any kind caused as a result of this.
Please note that our equipment has not been designed for use in commercial, trade or industrial
applications. Our warranty will be voided if the machine is used in commercial, trade or industrial
businesses or for equivalent purposes.
4. Technical data
Speed n0: .......................................................... 1000 rpm
Cutting width of the grass cutter: .......................... 70 mm
Cutting thickness of the shrub shears .....................8 mm
Running time max.: .............................................. 40 min
Battery pack: ...........................Li-Ion / 3.6 V d. c. / 1.3Ah
Charging time: .........................................................3~5h
Protection class: ........................................................... III

20
LpA sound pressure level: ...................................... 73 dB
LWA sound power level: .......................................... 84 dB
Kuncertainty ........................................................... 3 dB
Vibration ahV: ...................................................... 2.5 m/s2
Kuncertainty ...................................................... 1,5 m/s2
Weight: ................................................................ 583g
Battery charger
Mains voltage...........................100-240V AC ~ 50-60 Hz
Output
Rated voltage ..................................................... 5V DC
Rated current: .................................................... 1000 mA
• The vibration emission level has been measured in accordance with a set of standardized
criteria and can be used to compare one power tool with another.
• The specified emission level can also be used to make an initial assessment of the exposure
to vibrations.
• The vibration emission level may vary from the level specified during actual use, depending on
the way in which the power tool is used.
• Try to keep the impact from vibrations as low as possible. Exposure to vibrations can be
reduced by wearing gloves when using the tool, for example, and by limiting the amount of
operating time. This includes the full cycle of operation (e.g. times when the power tool is
switched off and times when the tool is switched on but no working load is applied).
5. Before starting the equipment
