Rack LCD Net LMK1L20 Series User manual

• Attach the left and right mounting bracket to 19” rack
mounting rails
• Adjust the rear mounting bracket to fit your rack
• M6 screw and cup washer x 6pcs included
• Remember to lea e the screws slightly loose until you
complete the installations
• Pick up the LCD keyboard drawer
• Insert the LCD keyboard drawer into the mounting
bracket
• Pull and hold the left & right black arrow buttons on
the rails
• Return the LCD keyboard drawer to park position
• Attach front left and right mounting ears of the LCD
keyboard drawer to ertical mounting rails
• M6 screw and cup washer x 2 pcs included
• Tighten all 8 pcs of M6 screw to complete the installa-
tion
To Install the Mounting Brackets and LCD Keyboard Drawer
Website: www.RackLCDNet.com Email: [email protected] Tel: [phone] Fax: [phone]
LMK1L20 Series - Installation and User Guide

To Use the Slides
• A black arrow button is located on the out-
side of each side
• Pull and hold the black arrow button on ei-
ther side of the LCD keyboard drawer to
unlock
• Push the LCD keyboard drawer into the rack.
(keep your fingers away from the slide stop)
To Open the LCD Keyboard Drawer
• Press the carry handle button. Gently pull the
LCD keyboard drawer out when the carry han-
dle button is pressed
• Flip up the LCD
• Drawer is now ready to operate
