Racking Solutions KCCB001 User manual
Chrome Kitchen Cart
KCCB001
PACKAGE CONTENTS
Please inspect box contents to ensure you have received all components.
Note: the black circular plastic tops in between the shelves are used only for
packaging purposes. They are NOT NEEDED. Please discard responsibly &
EX24+2 FX4
AX1 BX1 CX1
DX1
GX4 HX1 IX4
Bottom Pole (with threaded
insert pre-installed)
Shelf
extra Slip sleeve
HELP LINE
01977 555007
ASSEMBLY INSTRUCTIONS
TOOLS REQUIRED
Never climb or stand on the shelves.
Informaon
if in doubt contact the supplier
Allow adequate working space and be
aware of others working around you
Inspect all packages for damage and
check that all components have been
supplied
Cauon
During Assembly
!
Warning
Rules for safe use of shelving
!
ENSURE THAT THE MAXIMUM LOAD
CARRYING CAPACITIES ARE NOT
EXCEEDED
Dispose of packaging materials
responsibly
Wear appropriate clothing -protecve
gloves and footwear are
recommended
Make sure the floor is level
Take care when handling heavy items
parcularly when liing or stretching
Please read these instrucons
throughly before commencing
assembly.
Assembly should be undertaken by
at least two people
Not suitable for use in damp or wet
environments.
Shelves must be loaded evenly, and load
heavier items on the boom shelves
Rubber Mallet
Total weight capacity of kitchen cart is 225 kg on casters.
Basket
Bamboo Cutting Board
Cart Handle Top Pole (with end cap and
pole connector pre-installed)
Sidebar w/4 Hooks Casters (2 locking;
2 non - locking)
keep away from small children.
ASSEMBLY INSTRUCTIONS
STEP 1: ASSEMBLING THE CASTERS
Screw each Caster (I) into the bottom of each Bottom Pole (G). Turn
clock-wise to screw in place. Screw in tightly.
G
I
STEP 2: SLIP SLEEVES
On the Bottom Pole (G), place 1 pair of slip sleeves (E) at the desired
Please make sure the arrow faces up and that the word “top”
is right side up. Do this for each Bottom Pole (G) and make sure that
the heights are identical for Bottom Pole (G).
Slide the pair of Slip Sleeves (E) until you hear a click to confirm the
pair is locked onto the Bottom Pole (G).Do not place more than one
pair on each Pole (G) at a time.
*For safety and stability, the lowest SHELF (A) should be lower than
the 3rd notch from the bottom.
**Note: There will be a very small gap in-between the Slip Sleeves
(E)-this is normal.
G
E
STEP 3 : INSTALLING THE SHELF
Place The Shelf (A) on its side and slide the Bottom Pole (G) through
the holes in the Shelf (A). Make sure that the shelf (A) corner
cylinders are positioned over the Slip sleeves (E).
Stand the unit upright.
level.
A
*Note : The level side of the Shelf (A) is the Top side (the logo on the
corner cylinders should be right - side up.)
**Use a rubber mallet, if needed, to secure the Shelf (A).
STEP 4 INSTALLING TOP POLES
Screw the Top Pole (F) into the Bottom Pole (G). The tops of these
poles are indicated by the black end up.
G
F
STEP 5: INSTALLING THE BASKET,CART
HANDLE AND SIDEBAR
Repeat Step 2 for the Basket (B), the Cart Handle (D) and the
Sidebar with 4 Hooks (H). And Slide each piece onto the Slip
Sleeves (E). Only do ONE piece at a time. Adjust to desired
height.
B
STEP 6: PLACE THE BAMBOO CUTTING
BOARD
Place the Bamboo Cutting Board (C) on top of the Poles. The
grooves on the bottom of the Bamboo Cutting Board (C) will fit
exactly on the Top Poles (F). Remove board to clean thoroughly.
STEP 7: FINISH AND ENJOY YOUR QUALITY
RACKING SOLUTION PRODUCT
C
H
D
