Raddy WF-60C User manual

WEATHER STATION
USER MANUAL
Please read the instruction before using the product and keep it for future
reference.
Any questions, please feel free to contact [e-mail] or visit
https://iraddy.com/
WF-60C

READ BEFORE USE
IMPORTANT PLACEMENT GUIDELINES
PACKAGE CONTENTS
INSTALLATION
INITIALIZATION
OVERVIEW
FEATURES
BAROMETER CALIBRATION
REMOTE SENSOR RECONNECTION
RCC SIGNAL RECEPTION
SETTING MODE
LANGUAGES SELECTION
KEY TONE
ADJUST BACKLIGHT
AUTO DIM
ALARM CLOCK SETTING
SNOOZE FUNCTION
MAX AND MIN RECORD
LOW BATTERY INDICATORS
TEMPERATURE
HUMIDITY
WEATHER FORECAST
MOON PHASE
PLACEMENT INSTRUCTION
IF YOU HAVE PROBLEMS, PLEASE TRY AS FOLLOWING
TIPS
SPECIFICATION
01
01
02
02
03
04
06
07
08
08
09
10
11
11
12
13
13
14
14
15
15
16
17
17
18
19
19
WF-60C WEATHER STATION
CONTENTS

Do not clean any part of the product with benzene, thinner or other solvent
chemicals. If necessary, clean it with a soft cloth.
Do not dismantle or modify the product in any way.
Never immerse the product in water, It will damage the product.
Do not tamper with the internal components. Do not use new and used
batteries.
Do not use different types of batteries alkaline, standard or rechargeable
batteries with this product.
Remove the batteries if storing this product for a long period of time,
otherwise the battery might damage the product.
Do not dispose of this product as unsorted municipal waste, it’s
necessary to separately collect it for special treatment.
Do not place the base station in rain or moisture.
The transmit range depends on the type of obstacles located between the
transmitter and the receiver (e.g. a concrete wall will interfere with the
signal much more than a plasterboard wall).
Be sure the sensor is mounted vertically, to allow moisture to drain out
properly.
Place out of direct sunlight & ensure the sensor is well-ventilated.
The distance between base station and sensors should be at least
5~ 6.5 feet (1.5~2 meters) away from any interfering sources such as
computer monitors or TV sets.
The base station stay away from the metal window frames.
Please do not use other electrical products such as headphones or
microphone operating on the same signal frequency. (433.92MHz),
neighbors using electrical devices operating on the same signal frequency
WF-60C WEATHER STATION
1.
2.
3.
READ BEFORE USE
IMPORTANT PLACEMENT GUIDELINES
01

1 x Weather Station
3 x Remote Sensor
1 x User Manual
1 x DC Adapter
*Alkaline batteries are not included
SENSOR SET UP
Base station supports up to 3 sensors connection, the sensor switch is
located inside the battery compartment. It can be switched between 1,2,3,
matching the info of Channel 1, Channel 2, Channel 3 that synchronize on
the OUTDOOR Dashboard. Install 2 alkaline AA batteries to activate the
sensor.
can also cause interference.
Place the base station in a dry area, free of dirt and dust. To ensure
accurate temperature measurement, place out of direct sunlight and away
from heat sources or vents.
4.
WF-60C WEATHER STATION
PACKAGE CONTENTS
INSTALLATION
321
02

BASE STATION SET UP
Remove the protective film that is applied to the LCD screen before using
the product.
Plugged in with power adapter and the base station will start to work.
Battery power is optional but it helps keep the settings when plugged out.
Since previous settings will be reset when plugged out, we recommend
installing the batteries for the base station.
Base station can stand upright on the table or mount on the wall.
1.
2.
Open the battery compartment cover at the back of the base station,
insert 3 x AA batteries or plug in the power adapter to power up the base
station.
After power-on, all icons on the LCD will light up in 3 seconds, and you
will hear a beep tone. At the mean time it will start to detect the indoor
temperature and humidity.
Then it will start to detect the air pressure for 10 seconds, and the
pressure reading will keep flashing during this process.
Next, it will start to make connections to the remote sensors. Now open
the remote sensor battery compartment, set channels of the 3 remote
1.
2.
3.
4.
3.
WF-60C WEATHER STATION
INITIALIZATION
03

sensors to 1, 2, 3 and install the batteries respectively. The base station
will detect the RF signals from the remote sensors for a maximum of 3
minutes, and the signal icons on the outdoor channel dashboard will
keep flashing during detection until it connects with the sensor.
Finally, it will enter the RCC (Radio Control Clock) reception mode for 7
minutes. Once the signal is received, the LCD will display the received
time/month/date/weekday.
5.
WF-60C WEATHER STATION
MAIN UNIT
1. Temperature and Humidity of Channel 1
2. Max/Min Record of Outdoor Channels
3. Low Battery Indicator for Base Unit
4. Max/Min Record of Base Unit
5. Indoor Temperature and Humidity
6. Trends Indicator for Indoor Temperature and Humidity
7. Barometer Air Pressure
OVERVIEW
1
2
3
4
5 6 7 8 9 10 11 12
13
14
15
16
17
18
19
2021
04

WF-60C WEATHER STATION
8. Barometer Air Pressure Trends
9. Weather Forecast
10. Alarm Icon
11. Time in 12/24 Hours Format
12. Snooze Icon
13. Auto Dim
14. Calendar in Date And Month
15. Moon Phase
16. Rcc Icon and Dst
17. Weekday
18. Trends Indicator for 3 Channels’ Temperature and Humidity
19. Temperature and Humidity of Channel 3
20. Temperature and Humidity of Channel 2
21. Low Battery Indicator for 3 Sensors
22. Hanging Hole
23. Battery Compartment Cover
24. Stand Bracket
25. DC Jack
26. 7 Buttons: ALARM, MEM, CH, SNOOZE/LIGHT, +/RCC, -, SET
22
23
24
25
26
ALARM MEM CH SET
SNOOZE/LIGHT -
/ RCC
+
05

WF-60C WEATHER STATION
REMOTE SENSOR
Time and Calendar (Day/Month)
12/24 hours format switchable
Alarm with snooze function
Weather forecast with 5 variables: sunny, partly cloudy, cloudy, rainy,
and snowy
Indoor temperature and humidity
Outdoor temperature and humidity
Support up to 3 sensors
FEATURES
1. LED Indicator
2. Battery Compartment Cover
3. Hang Hole for Wall Mounting
4. Channel Switch
5. Hole for Hanging Strip
1
2
3
4
5
321
WEATHER ICON
Description Sunny Partly Cloudy Cloudy Rainy Snowy
06

WF-60C WEATHER STATION
Max/Min memory records for all indoor/outdoor temperature and humidity
Trend index
C/F(Celsius/Fahrenheit) switchable
Comfort dashboard
Low battery indicator
Key tone on/off
Transmission range: up to 100 meters/330 feet in open area
3-mode brightness: Bright/Dim/Off
Support desk standing or wall hanging
After powering on, the pressure reading will be flashing for 10 seconds.
If there is no need for calibration, press【SNOOZE/LIGHT】button to exit
setting. If calibration is required, you can press【+/RCC】or【-】
buttons to adjust data. Press and hold【+/RCC】and【-】buttons will
quickly change the value by 8 steps.
If no operation within 10 seconds, it will automatically save and exit
setting.
Barometer range: 850-1050hPa/mb (600-832mmHg, 23.62-32.75inHg).
Arrow indication for humidity changes:
will display when the reading increase by 2mb, within one hour or
compared with last reading.
will display when the reading decrease by 2mb, within one hour or
compared with last reading.
will display when the reading changes less than 2mb, within one
hour or compared with last reading.
1.
2.
3.
4.
BAROMETER CALIBRATION
07

WF-60C WEATHER STATION
Press and hold the【CH】button to clear all sensors data and re-search
for RF signal from the remote sensors again. While the unit is searching
for signal, the signal icons on the outdoor channel dashboard will keep
flashing.
If you want to change the channel of the remote sensor, remove the
batteries from the sensor, toggle the channel selection on the sensor,
install the batteries, and then repeat step 1 on the main unit.
Note: If the unit is in searching for RCC signal, long press the【+/RCC】
button to exit the RCC Receiving Mode first. Otherwise, the unit won’t
respond to the【CH】button.
1.
2.
REMOTE SENSOR RECONNECTION
Every day at 1:00 AM, 2:00 AM, 3:00 AM, 4:00 AM, and 5:00 AM, the
clock will automatically carries out the synchronization procedure to
correct any deviations to the exact time if the Daily RCC Reception is
enabled. The signal searching lasts 7 minutes once a time. If the signal is
received successfully once, the remaining RCC signals on that day will be
ignored. If no signal is received in the scheduled time, the signal searching
will be stopped for today.
Press and hold the【SET】button to enter the Setting Mode, the
language display flashes.
Short press the【SET】button 6 times and use the【+/RCC】or【-】
button to select “ON”/”OFF” for the Daily RCC Reception.
Short press the【SET】button to save and go to the next item setting.
If you choose “OFF”, the unit will go to the Calendar Year Setting. If you
choose “ON”, the unit will go to the RCC Time Zone Calibration.
Use the【+/RCC】and【-】button to select the time zone deviation
1. Turn On/Off the Daily Auto RCC Reception:
RCC SIGNAL RECEPTION
①
②
③
④
08

WF-60C WEATHER STATION
Press and hold the【SET】button to enter the Setting Mode. Once in
Setting Mode, the item you are currently setting will flash on the screen.
Press【+/RCC】and【-】buttons to select for the currently flashing
item. Press and hold the【+/RCC】and【-】buttons will quickly
change the number value by 8 steps.
1.
2.
SETTING MODE
value. Then short press the【SET】button to save.
*The RCC (DCF) signal is transmitted from Germany. Germany is in UTC-1
Zone, countries that are in the same time zone as Germany (for example,
France, Italy, Spain, Denmark, Netherlands), the time zone selection is 0.
Countries not in UTC-1 time zone need to add or subtract the time zones,
for example, Portugal with UTC-0 time zone, the time zone selection is -1.
Note: While the main unit is searching for RCC signal, it won’t respond to
any button command. If you need to use other functions with the buttons,
please exit the Manual RCC Signal Receiving Mode first.
Press and hold the【+/RCC】button to enter the Manual RCC Signal
Receiving Mode. The RCC icon will flash and the unit will search for the
RCC signal. (It won’t search for signal automatically every day.)
Once the signal is received, the LCD will update and display the
received time/month/date/weekday. And the unit will display DST on the
LCD. If no DST signal is received, DST icon will not display.
During the signal searching, press and hold the【+/RCC】button again
can exit the Manual RCC Signal Receiving Mode.
2. Manual Receiving:
①
When searching for signal, RCC icon will be flashing.
When signal is successfully received, LCD will display the complete
RCC icon and exit RCC receiving.
If no signal is received, the RCC icon will disappear.
3. RCC Icon Display:
①
②
③
②
③
09

WF-60C WEATHER STATION
3.
Languages Selection
1. LANGUAGE SELECTION
2. KEY TONE ON/OFF
3. AUTO DIM ON/OFF TIME SETTING
4. RCC ON/OFF
5. (RCC-ON →DST-TIME ZONE DEVIATION VALUE SELECTION)
6. CALENDAR YEAR
7. CALENDAR DATE FORMAT (MONTH-DAY or DAY-MONTH)
8. CALENDAR MONTH
9. CALENDAR DATE
10. TIME FORMAT 12/24H
11. CLOCK HOUR
12. CLOCK MINUTE
13. AIR PRESSURE UNIT SELECTION
14. WEATHER PATTERN
The order of setting items is as follows:
Press and hold the【SET】button to enter the Setting Mode. Once in Setting
Mode, the language display will flash and you can use the【+/RCC】and
【-】buttons to select the language. Press the【SET】button to save.
Short press the【SET】button can save the setting and go to the next
setting item. The setting will also be automatically saved and exit if
there is no valid operation within 10 seconds.
10

WF-60C WEATHER STATION
Press and hold the【SET】button to enter the Setting Mode.
Short press the【SET】button again to go to the key tone setting. The
option ON or OFF will flash.
Use the【+/RCC】and【-】buttons to select.
Press the【SET】button to save. The setting will also be automatically
saved and exit if there is no valid operation within 10 seconds.
1.
When Using Battery Power: Press【SNOOZE/LIGHT】for once，the
screen lights up for 20 seconds, and then goes back to Dim.
When Using A/C Power: Press【SNOOZE/LIGHT】to adjust the backlight
brightness, BRIGHT-DIM-OFF. It defaults as Bright level.
1.
2.
2.
3.
4.
KEY TONE
Language selection order: GE→IT→SP→DA→DU→EN→FR
Languages
abbreviation
Sunday
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
English French German Italian Spanish Danish Dutch
EN
SU
MO
TU
WE
TH
FR
SA
FR
DI
LU
MA
ME
JE
VE
SA
GE
SO
MO
DI
MI
DO
FR
SA
IT
DO
LU
MA
ME
GI
VE
SA
SP
DO
LU
MA
MI
JU
VI
SA
DA
SO
MA
TI
ON
TO
FR
LO
DU
ZO
MA
DI
WO
DO
VR
ZA
The key tone can be enabled/disabled in the setting.
ADJUST BACKLIGHT
11

RCC
WF-60C WEATHER STATION
Press and hold the【SET】button to enter Setting Mode, then short
press the【SET】button twice, the auto dim icon will appear and the
Hour starts to flash.
Use the【+/RCC】and【-】buttons to set the correct hour for the
start time. Press and hold the【+/RCC】and【-】buttons will quickly
change the value by 8 steps.
Press the【SET】button to save your setting, the Minute starts to
flash. Use the【+/RCC】and【-】buttons to set the correct minute
for the start time.
Press the【SET】button to save your setting, the Hour starts to flash.
Use the【+/RCC】and【-】buttons to set the correct hour for the
end time.
Press the【SET】button to save your setting, the Minute starts to
flash. Use the【+/RCC】and【-】buttons to set the correct minute
for the end time.
Press the【SET】button again to save your setting and go to the next
item setting, or you can leave it alone. The unit will save your setting in
10 seconds and exit the Setting Mode if there’s no valid operation.
AUTO DIM
In Auto Dim Mode, the auto dim icon will show up and the backlight
brightness will be adjusted to 3% automatically. Backlight brightness will
be back to bright mode when out of auto dim period.
1. Set Time Period for Auto Dim Mode:
2.
3.
①
In Auto Dim Mode, short press the【SNOOZE/LIGHT】button, the
backlight will light up for 10 seconds, and then back to dim.
Turn On/Off Auto Dim: During the set auto dim time period, press and
hold the【SNOOZE/LIGHT】button to enable/disable the Auto Dim Mode.
This operation will be saved and will take effect on the next following
days until you turn it off/on next time during the set auto dim time period.
②
③
④
⑤
⑥
⑦
12

WF-60C WEATHER STATION
Check the Set Alarm Time: In standard mode, short press the
【ALARM】button to check the set alarm time. It will return to normal
time display mode if no operation in 5 seconds.
Turn On/Off the Alarm Clock: In standard mode, short press the
【ALARM】button and the LCD will display the set alarm time. If there’s
an alarm icon beside the alarm time, the alarm is on. If there’s no alarm
icon, the alarm is off. Press the【ALARM】button again can turn on/off
the alarm. It will save your setting and return to normal time display
mode if no operation in 5 seconds.
Set Daily Alarm Clock:
1.
2.
3.
ALARM CLOCK SETTING
When the alarm is ringing, press any button except the【SNOOZE/
LIGHT】button can stop the alarm for the day. And the alarm will restart
the next day. The alarm sound will last for 2 minutes if no button is
pressed.
1.
SNOOZE FUNCTION
Press and hold the【ALARM】button to enter the Alarm Clock
Setting Mode. The Hour starts to flash. Use the【+/RCC】and【-】
buttons to set the correct hour.
Short press the【ALARM】button, the Hour will be saved and the
Minute starts to flash. Use the【+/RCC】and【-】buttons to set
the correct minute.
Short press the【ALARM】button again, the alarm clock will be
saved.
*Press and hold【+/RCC】and【-】buttons will quickly change the
value by 8 steps.
*If the alarm clock can’t be set, check if the base station is in RCC
Receiving Mode and exit back to standard mode by long pressing the
【+/RCC】button.
①
②
③
13

WF-60C WEATHER STATION
When alarm is ringing, press the【SNOOZE/ LIGHT】button to activate
the snooze mode. The alarm will ring again after 5 minutes, and the
“ZZ” icon will be flashing on screen to indicate the snooze mode. The
Snooze mode can be repeated if you press the【SNOOZE/ LIGHT】
button again next time when the alarm rings.
The Alarm will make sound as follow:
0-10 seconds: Beep per second
11-20 seconds: Beep x2 per second
21-30 seconds: Beep x4 per second
31-120 seconds: Keep Beeping
2.
3.
In standard mode, press the【MEM】button to check maximum
temperature and humidity record, the value will display for 5 seconds.
Press the【MEM】button a second time to check the minimum
temperature and humidity record, the value will display for 5 seconds.
Press the【MEM】button a third time will return to standard mode.
Press and hold the【MEM】button will clear the max and min record
and reactivate the memory.
Normally, the Max and Min record will update every 24 hours at 00:00 AM.
1.
2.
3.
4.
5.
MAX AND MIN RECORD
About Remote Sensor: When the battery indicator icon appears next to
the outdoor temperature, replace the batteries for the corresponding
remote sensor.
About Cell Battery in Main Unit: The cell battery is only for memorizing
the setting during a sudden power outage. When battery indicator icon
appears next to the indoor temperature, replace the batteries for the main
unit.
1.
2.
LOW BATTERY INDICATORS
14

WF-60C WEATHER STATION
After power on, the indoor temperature will display automatically, it will
update reading every 30 seconds and the base station will start to
receive signals from the remote sensor which lasts for a maximum of
3 minutes.
Indoor temperature display range: -10℃~ 50.0℃(14℉~ 122℉)
For temperature lower than -10℃, the reading will be: “LL.L”.
For temperature higher than 50.0℃, the reading will be: ”HH.H”.
Outdoor temperature display range :-40℃~ 60℃(-40℉~140℉)
For temperature lower than -40℃, the reading will be: “LL.L”.
For temperature higher than 60℃, the reading will be: “HH.H”.
Arrow indication for temperature changes:
will display when the reading increase by 1℃(1.8℉) within one
hour or compared with last reading.
will display when the reading decrease by 1℃(1.8℉) within one
hour or compared with last reading.
Accuracy: ±1℃(±2℉). Temperature resolution is 0.1℉(0.1℃).
In standard mode, press the【SET】button to select °C or °F units.
1.
2.
3.
4.
5.
6.
TEMPERATURE
After power on ,the indoor humidity will display automatically, it will
update the reading every 30 seconds and the base station will start to
receive signals from the remote sensor which lasts for a maximum of 3
minutes.
Humidity display range: 1%-99%.
For humidity lower than 1%, the reading will be “1%”.
For humidity higher than 99%, the reading will be “99%”.
Accuracy: when the temperature is between 68℉~78.8℉(20℃~26
℃) and the humidity is between 40-80%, the accuracy is ±5%. The
accuracy will be ±8% if out of this range.
1.
2.
3.
HUMIDITY
15

WF-60C WEATHER STATION
WEATHER ICON
Description Sunny Partly Cloudy Cloudy Rainy Snowy
4.
5.
The weather symbol will show after power on. There are 5 kinds of
weather modes: Sunny, PartlyCloudy, Cloudy, Rainy, Snowy. The weather
symbol displays are based on the hourly calculation of indoor/outdoor
temperature & humidity and barometer data. The forecast is for the next
12 hours with 70%-75% accuracy.
WEATHER FORECAST
Arrow indication for humidity changes:
will display when the reading increase by 3% RH within one hour or
compared with last reading.
will display when the reading decrease by 3% RH within one hour or
compared with last reading.
Humidity resolution: 1%.
UNIT TEMPERATURE RANGE
-9.9℃～50℃(14℉～122℉)
-40℃～60℃(-40℉～140℉)
Show HH.H
> 50℃(122℉) for base station
or > 60℃(140℉) for remote
sensors
1%RH～99%RH
1%RH～99%RH
HUMIDITY RANGE
BASE STATION
REMOTE
SENSORS
OUT OF RANGE
Show HH.H
< -9.9℃(14℉) for base station
or < -40℃(-40℉) for remote
sensors
Show HH > 99%RH
Show LL < 1%RH
16

WF-60C WEATHER STATION
Press and hold the【SET】button to enter the Setting Mode, the
language display starts to flash.
Then press the【SET】button 16 times (15 times if the RCC is off) to
enter the Weather Forecast Calibration Mode, the weather symbol
begins to flash.
Use the【+/RCC】and【-】to select the correct weather icon.
Press the【SET】button to save. The unit will also save your setting in
10 seconds and exit the Setting Mode if there’s no valid operation.
Note: The Snowy symbol is not in the setting options. It will show up
automatically when the remote sensor of channel #1 is placed outdoor and
the data predicts that it will snow in the next 12 hours.
Place the main unit in a dry dust-free place. To ensure an accurate indoor
temperature measurement, be sure to place the main unit away from heat
sources or vents.
Weather Forecast Calibration
①
②
③
④
Moon Phase is changed according to Calendar automatically. There are 12
moon phases in loop.
MOON PHASE
Full Moon New Moon
Main Unit
For a more accurate reading and weather forecast, please place the sensor
at a proper place:
1. Avoid exposing to direct rain, sunlight or other heat/cold source.
Outdoor Sensor
PLACEMENT INSTRUCTION
17

WF-60C WEATHER STATION
Make sure there is enough air flow around the sensor to reflect the
changes of environment (Well-ventilated).
Make sure there’s not a thick wall or strong interference source using
same signal frequency (433.92MHz) between the weather station and the
sensor.
Place the sensor vertically at the height about 1.5m-3m / 4.9ft-9.8ft.
When the sensor is used for the first time or relocated, let it stand for
around one hour or more before having accurate measuring of
temperature and humidity.
You can place the sensor in multiple ways: hang from the back hole
using a nail, place on a stable surface, or lift with a rope. No matter
which way, make sure at least one side of the air vent (back or bottom)
is not blocked.
2.
3.
4.
5.
6.
1.
2.
3.
4.
Turn off any other existing wireless equipment to check whether this is
the cause of the problem.
Move any other existing wireless equipment. Shorten the distance
between the sending and receiving devices and reduce the number of
obstacles(walls, furniture,etc.) between them.
Try to remove and reassemble batteries, if the batteries are old, try new
ones.
If the buttons are not function correctly, make sure the RCC Receiving
Mode is turned off.
IF YOU HAVE PROBLEMS, PLEASE TRY AS FOLLOWING
18
