WIRELESS COLOR WEATHER STATION
WITH TEMPERATURE ALERTS
For the start-up of this device:
Main unit by AC adaptor (included) and 1x CR2032 (included)
Sensor by 2 x AA batteries (not included)
We thank you for your purchase of Baldr wireless color weather
station with temperature alerts. It has been designed and con-
structed using innovative components and techniques to enable
the perfect display. Please read the instructions carefully to
become familiar with the properties and functions before you use
the unit.

Weather forecast for next 12-24 selectable
1. Weather forecast
2. Calendar display
3. Weekdays in 7 languages
4. Current time
PRODUCT OVERVIEW
MAIN UNIT
15
16
17
18
19
20
14
22
21
23
1
10
13 11 9
5
7
6
8
12
2
3
4
Weather forecast for next 12-24 hours
2
ENEN EN

19. “ ALERTS ” button
21. Stand bracket
22. Hanging hole
23. Battery compartment
5. Indoor temperature and humidity
6. Outdoor temperature and humidity
7. Max/min record of indoor temperature and humidity
8. Max/min record of outdoor temperature and humidity
9. Low battery indication
10. High/ low outdoor temperature warning
11. Channel indication
12. Channel scan
13. Frost-point warning
15. “ SET ” button
16. “▲/ CH ” button
17. “ ▼/RCC ” button
14. “ ” button
18. “ ” button
Clear sensors data and re-registration
or increase the data
Check or enter into temperature alerts
setting
RCC function or decrease the data
Enter into time setting or switch C/F
Check or enter into alarm setting
Check or clear Max/min record
20. “ MEM ” button
3
EN

4
1.
WARNING:
Notes:
Pick out
Positive
pole
The default year is 2020, if the weekday display is incorrect .
Please confirm year was set correctly. (for manual setting only)
THIS PRODUCT CONTAINS A BUTTON-CELL BATTERY. IF
SWALLOWED, IT COULD CAUSE SEVERE INJURY OR DEATH
IN JUST 2 HOURS.SEEK MEDICAL ATTENTION IMMEDIATELY
IF INGESTED.
2.
The CR2032 cell battery is for memory function (included).
Please do not used as power supply. If you need to replace the
cell battery, please take out the part device as shown in the
figure below, load new battery matching the polarity(+and-).
ENEN EN

5
1. Signal light 2. Hanging hole
3. Battery compartment 4. Channel 1-2-3 switch
OUTDOOR SENSOR
12
3
4
FEATURES
●
●
●
●
●
●
●
●
Up to 3 RF channels for outdoor sensors (only one sensor included)
Calendar, alarm and snooze function
Time display in 12/24H
Frost-point warning indication
Temperature tendency display in arrows
Outdoor high/ low temperature warning
●
Key tone on or off selectable
Weekdays in 7 languages: GER (German), ENG (English),
FRE (French),ITA(Italian),SPA(Spanish), DUT(Dutch),DAN(Danish)
WWVB atomic time
EN

6
● Weather forecast for next 12-24 hours with barometer
Measures indoor/outdoor humidity and temperature (℉/℃)
Max/min record of indoor /outdoor temperature & humidity
Indoor temperature range: 14 ℉~122℉(-10℃~50℃)
Outdoor temperature range:-40℉~140℉(-40℃~60℃)
In/outdoor humidity range: 1%-99%
White backlight with dimmer
PACKAGE CONTENT
Following contents are included in the package:
1 x WeatherStation Main Unit
1 x Remote Sensor
1x
AC Adaptor
1 x
CR2032 Cell Battery1 x
1 x User Manual
GETTING START
MAIN UNIT INSTALLATION
●
●
●
●
●
●
BALDR recommends high quality alkaline or lithium
batteries for the best product performance. Heavy duty
or rechargeable batteries are not recommended.
Remove the cell battery’ s Insulating strip ,then plug the adaptor to
a powered outlet.
SENSOR INSTALLATION
1. Remove the battery compartment cover;
ENEN EN

When power on or reset, LCD will full display for 3 seconds with
“BI” sound. Then display Indoor temperature and humidity with
100% backlight brightness.
(+and-);
7
Switch the Channel 1-2-3 of the senor to any channel you want.
For example, you can set to Channel 1 for the sensor. But please
ensure the main unit are set to the same channel before synchro-
nization. Special note: Press “▲/ CH” button on the main unit to
set the channel. The setting order is CH1--CH2--CH3-- Channel
scan(from CH1 to CH2 to CH3, 10 seconds intervals),you must
select the same number choices for both the sensor and the main
unit in order to synchronize.
Main unit will auto receive outdoor signal after power on, the
receiving status will last for max 3 minutes. The receiving anten-
na signal will flash. If no signal received in 3 minutes, it will stop
receiving outdoor signal.
If the main unit is out of 3 minutes’ signal receiving window, you
need to press and hold the “▲/ CH ” button to enter signal
receiving again.
Notes:
3. Replace the battery cover.
SENSOR SETUP
●
●
1.
2.
Power the main unit prior to load the battery of sensor.
● Press the “SET” button to switch between Celsius and Fahrenheit.
MAIN UNIT SETUP
2. Insert 2 x AA batteries in each sensor matching the polarity
EN

8
After power on, It will start receiving outdoor sensors’ signal for 3
minutes. If all 3 channels signal received within 3 minutes or
receiving window ends, it will enter into WWVB Signal Receiving
window.
After RF signal receiving, it will start searching radio signal for 7
minutes with the antenna symbol “ ” flashing on screen. Mean-
while, the backlight brightness will automatically turn to OFF
(default brightness: 100%),you can press top button to light the
backlight with 100% brightness for 5 seconds.
Once signal received, the main unit will display the received
time/month/date/weekday with symbol “ ” displaying on
screen.
RF Signal Receiving
WWVB Signal Receiving
ENG ON M/D
12:00 AM
(12H format)
Weekday
Language Display Time Date FormatBeep
Display Date
Jan 1st.2020 ℉ON
6:30
Alarm OFF Sunny To Cloudy-5 (EST)
Temperature
Unit
Zone Weather
RCC Function
Alarm Time
The default value is :
1.
2.
ENEN EN

9
Manual Settings
*Tips: press and hold “▲/ CH ” or “ ▼/RCC ” button will quickly
change the value by 8 steps.
* RCC symbol display:
a. When receiving signal , RCC symbol “ ” will be flashing by“1HZ”.
b. When signal successfully received, LCD will display complete RCC
symbol “ ” and exit RCC receiving.
c. If no signal is received, the RCC symbol will disappear.
1.
. 2
3.
.
.
Daily RCC signal receiving: there are regular radio signal
receiving at UTC 7:00AM,8:00AM, 9:00AM, 10:00AM, 11:00AM
each day. It starts receiving signal at UTC 7:00AMeveryday. For
each day, once signal received at any one receiving time, it will
stop receiving signal that day.
4Manual receiving: press and hold “ ▼/RCC ” button to enter
RCC signal receiving.
5During receiving,you can press “ ▼/RCC ” button to exit RCC
receiving.
After signal received, if there is no need for other settings, you
can just finish reading here. If there is other setting require-
ments. Please check the following steps. Or if there is no signal
received, you can follow bellow steps for Manual Setting.
Press and hold “ SET ” button to enter into setting, press “
SET ” button to skip setting steps or go to the next setting
option.
EN

Zone Atlantic Eastern Central Mountain Pacific Alaskan Hawaiian
Time AST EST CST MST PST AKT HKT
10
Press “ SET ” to select Weekday Language. Default setting :GER.
Press the “▲/ CH ” or “ ▼/RCC ” button to select languages: ENG
、GER、ITA、FRE、DUT、SPA、DAN optional . (English/Ger-
man/Italian/French/Dutch/Spanish/ Danish)
3.
Press “ SET ” to select Beep ON/OFF .Default setting :ON.
Press the “▲/ CH ” or “ ▼/RCC ” button to select ON/OFF.
4.
Press “ SET ” to select Temperature Unit.Default setting : ℉
Press the “▲/ CH ” or “ ▼/RCC ” button to select ℃/℉.
5.
6.Press “ SET ” to select the RCC. Default setting : ON. Press
the “▲/ CH ” or “ ▼/RCC ” button to select OFF or ON.
6.
Press “ SET ” to select DST ON/OFF. Default setting : ON. Press
“▲/ CH ” or “ ▼/RCC ” button to select DST ON if you do observe
Daylight Saving Time.
7.
Press “ SET ” to select Time Zone. Default setting : -5(EST). Press
“▲/ CH ” or “ ▼/RCC ” button to select time zone: AST(-4),EST
(-5),CST(-6),MST(-7),PST(-8),AKT(-9),HAT(-10) optional.
8.
Press “ SET ” to select Year. Setting range: 2000-2099.Press
“▲/ CH ” or “ ▼/RCC ” button to adjust the value.
9.
DST symbol display:
a. Select "DST ALWAYS " means dst function is always on all the
year round
b. Select "DST",means dst function will be on during daylight saving time
c. Select "DST OFF",means dst function is off.
ENEN EN

Press “ SET ” to select Weather. Default setting : Sunny To
Cloudy. Press “▲/ CH ” or “ ▼/RCC ” to select weather : Sunny,
Sunny To Cloudy, Cloudy, Rainy or Snow optional.
16.
Press “ SET ” to select Month & Date display format. Default
setting : M/D. Press the “▲/ CH ” or “ ▼/RCC ” button to select
M/D or D/M format. (M: Month ,D: Date)
10.
Press “ SET ” to select the Month. Press “▲/ CH ” or “
▼/RCC ” button to adjust the value.
11.
Press “ SET ” to select the Date. Press “▲/ CH ” or “ ▼/RCC ”
button to adjust the value.
12.
Press “ SET ” to select 12/24H Time Format. Default setting :12
H. Press the “▲/ CH ” or “ ▼/RCC ” button to select 12H or
24H.
13.
Press “ SET ” to select Hours. Press “▲/ CH ” or “ ▼/RCC ”
button to adjust the value.
14.
Press “ SET ” to select Minutes. Press “▲/ CH ” or “ ▼/RCC ”
button to adjust the value.
15.
11
Press “ SET ” to confirm and exit.
17.
During setting, touch top button to save and exit setting.
Press and hold “ ” button to enter into alarm time setting.
18.
During setting, if no operation for 20 seconds, it will automati-
cally save and exit setting.
19.
ALARM FUNCTION
1.
Press “▲/ CH ” or “ ▼/RCC ” button to adjust data; press and
hold “▲/ CH ” or “ ▼/RCC ” button will quickly change the value
by 8 steps.
2.
The setting order is: Hour → Minute→ Exit.
3.
During setting, touch top button to save and exit setting.
4.
Alarm Time Setting
EN

During setting, if no operation for 20 seconds, it will automati-
cally save and exit setting.
5.
The alarm is default ON after setting the alarm time. Alarm
symbol will display on screen.
6.
When in time display mode, press “ ” button to check alarm
time. Press “▲/ CH ” or “ ▼/RCC ” button to turn ON/OFF alarm
by the ON/OFF of symbol .
1.
When in alarm time display mode, Press “▲/ CH ” or “ ▼/RCC ”
button to turn on/off the alarm by the ON/OFF of symbol .
2.
Alarm ON/OFF Setting
When the alarm is ringing, press any other button except top
button to stop the alarm. And the alarm will restart next day.
1.
SNOOZE FUNCTION
12
Or when alarm is ringing, press the top button to activate snooze
function. The alarm will ring again in 5 minutes snooze interval.
And the “ ” symbol will be flashing on screen to indicate the
snooze mode. Press any other button except top button to exit the
snooze mode. And the alarm will restart next day.
2.
When alarm rings, the ascending “Bibi” alarm sound will last for
2 minutes if no operation.
3.
Press “MEM” button to check outdoor and indoor max/min tem-
perature and humidity.
1.
The checking order is : Max Record→Min Record→Exit. The
value will display for 5 seconds.
2.
Press and hold the “MEM” button to clear the max and min
record.
3.
MAX AND MIN RECORD
OPERATION GUIDELINES
ENEN EN

Normally, the Max and Min record will update every 24 hours
at 0:00.
4.
If no operation for 5 seconds, it will automatically exit .
5.
After power on ,the indoor temperature will display automatical-
ly, it will update reading each 30 seconds and start to receive
outdoor signal which lasts for max 3 minutes.
1.
Indoor temperature display range:14℉~ 122℉(-10℃~ 50.0℃);
for temperature lower than 14℉,the reading will be : “LL.L” ; for
temperature higher than 122℉,the reading will be : “HH.H”.
2.
Outdoor temperature display range :-40℉~140℉(-40℃~60℃);
for temperature lower than -40℉,the reading will be : “LL.L” ; for
temperature higher than 140℉,the reading will be : “HH.H”.
3.
TEMPERATURE
13
Arrow indication for temperature changes:
will display when temperature changes less than 1.8℉within
one hour or compared with last reading;
will display when the reading increase by 1.8℉within one
hour or compared with last reading.
will display when the reading decrease by 1.8℉within one
hour or compared with last reading.
4.
When in time display mode, press “ALERTS ” button to turn on/off
outdoor temperature alerts.Temperature alerts symbol will
display on screen after alerts turned on.
1.
OUTDOOR TEMPERATURE ALERTS
Accuracy: For temperature between 32℉~122℉,the accuracy is
±1.8℉,if out of this range the accuracy will be ±3.6℉; Tem-
perature resolution is 0.1℉(0.1℃).
5.
Press “SET ” button to select the temperature unit ℃/℉(Refer to
Manual Settings point 5).
6.
EN

14
After power on ,the indoor humidity will display automatically, it
will update reading each 30 seconds and start to receive
outdoor signal which lasts for max 3 minutes.
1.
HUMIDITY
During setting, if no operation for 20 seconds, it will automatical-
ly save and exit setting.
7.
Humidity display range: 1%-99%;for humidity lower than 1%,the
reading will be “1%” ;for humidity higher than 99%,the reading
will be “99%”.
2.
Accuracy: when the humidity is between 30-80%,the accuracy
is ± 5%,if out of this range the accuracy will be ±7%.
3.
Press and hold “ALERTS ” button to enter temperature alerts
setting. The temperature alert value will be flashing.
Default setting : High Temperature Alert:95℉(35℃),Low Tem-
perature Alert: 41℉(5℃).
2.
Alerts setting order: Outdoor High Temperature Alert→ Outdoor
Low Temperature Alert→ Exit.
3.
Press “ALERTS” button to confirm and move to next alert
setting.Press “▲/ CH ” or “ ▼/RCC ” button to adjust the value.
Hold to adjust quickly.
4.
After turn on the alerts function, when the outdoor temperature
is higher or lower than the upper and lower temperature alarm
setting value,the corresponding high temperature alert
symbol " " or low temperature alert symbol " " with the
outdoor real-time temperature value will keep flashing ,Mean-
while with "BiBiBiBi" sound every 1 minute.
5.
Press any button to stop the alert sound when alert rings.
6.
ENEN EN

Tips: The reading will be more accurate if it is placed at the same posi-
tion for half an hour after power on.
The weather forecast icon will show after power on. There are 5
kinds of weather modes: Sunny, Sunny To Cloudy, Cloudy,
Rainy, Snow. The weather icon displays are based on the hourly
calculation of indoor/outdoor temperature & humidity and
barometer data. The forecast is for next 12 hours with 70%-75%
accuracy after 48 hours of data accumulation .
●
WEATHER FORECAST
Humidity resolution:1% .
5.
Arrow indication for humidity changes:
will display when humidity changes less than 5% RH within
one hour or compared with last reading;
will display when the reading increase by 5% RH within one
hour or compared with last reading.
will display when the reading decrease by 5% RH within one
hour or compared with last reading.
4.
15
When current outdoor channel’ s temperature is in the range of
32℉~37.22℉(0℃~ 2.9℃),the alert symbol “ ” will be flashing
until the temperature reading is higher than 37.22℉; the symbol
will keep displaying on screen if temperature is lower than 32℉.
•
FROST-POINT ALERT
After powering on, touch “ ” button to adjust the bright-
ness of the backlight.
•
Backlight brightness can be selected from 50%,100% and off.
•
ADJUSTABLE BACKLIGHT
!
Sunny Sunny To Cloudy Cloudy Rainy Sonw
EN

16
No outdoor
sensor reception
Make sure the CH 1-2-3 switch on both
units match.
2.
Reload the batteries of both outdoor sensor
and main unit. Please refer to the SENSOR
SETUP section.
1.
Relocate the main unit and/or the outdoor
sensor. The units must be within 328ft
(100m) of each other.
2.
Reload batteries in outdoor sensor.
3.
Reload batteries in main unit.
4.
Let both units sit within a couple feet of
each other for a few minutes to gain a
strong connection before taking sensor to
outdoor area.
5.
About Outdoor Sensor: When battery indicator shows next to the
outdoor temperature, replace batteries in your outdoor sensor.
Flashing of the outdoor reading is generally an
indication of wireless interference.
Bring the sensor and main unit indoors, side
by side and remove batteries from each.
•
About Cell Battery in Main Unit: The CR2032 cell battery is only
for memorizing the setting during sudden power outage. When
battery indicator shows next to your Indoor Temperature, replace
battery.
•
LOW BATTERY INDICATORS
TROUBLE SHOOTING
Problem
Outdoor reading
is flashing or
showing dashes
Possible Solution
1.
ENEN EN

Make sure both the main unit and sensor are
placed out of direct sunlight and away from
any heat sources or vents.
Problem
No outdoor
sensor reception
Inaccurate
temperature/
humidity
Possible Solution
Make sure both units are placed at least 3 ft
(0.9 m) away from electronics that may
interfere with the wireless communication
(such as TVs, microwaves, computers, etc).
3.
Use standard alkaline batteries. Do not use
heavy duty or rechargeable batteries.
NOTE: It may take a few minutes for main
unit and sensor to synchronize after batter-
ies are reloaded.
4.
17
If your BALDR product does not operate properly after trying the
troubleshooting steps, please contact the seller on your order page
or shoot an email to: [email protected].
BALDR sensors are sensitive to surrounding environmental condi-
tions. Proper placement of both the main unit and outdoor sensor
are critical to the accuracy and performance of this product.
“HH.H/LL.L”
display in indoor
and/or outdoor
temperature
If the temperature is higher than the detection
range, “HH.H” will display on screen for indi-
cation; if lower than the detection range,
“LL.L” will display on screen for indication.
PLACEMENT INSTRUCTION
EN

Place main unit in a dry area free of dirt and dust. To help ensure
an accurate indoor temperature measurement, be sure to place
the Main unit away from heat sources or vents.
Main Unit Placement
Sensor must be placed outside to observe outdoor conditions.
Sensor is water resistant for water splashes and is designed for
general outdoor use, however, to extend its life place the sensor in
an area protected from direct weather elements. The best location
is 4 to 8 feet (1.2 to 2.4 meters) above the ground with permanent
shade and plenty of fresh air to circulate around the sensor.
Outdoor Sensor Placement
• The distance between main unit and transmitter should be at least
5~6.5 feet (1.5~2 meters) away from any interfering sources such
as computer monitors or TV sets.
Important Placement Guidelines
• To maximize wireless range, place units away from large metallic
items, thick walls, metal surfaces, or other objects that may limit
wireless communication.
• Please do not use other electrical products such as headphones
or speakers operating on the same signal frequency.
• Neighbors using electrical devices operating on the same signal
frequency can also cause interference.
• Do not clean any part of the product with benzene, thinner or
other solvent chemicals. When necessary, clean it with a soft
cloth.
• Never immerse the product in water. This can cause electrical
shock and damage the product.
PRECAUTIONS
18
ENEN EN

BALDR provides a 1-year limited warranty on this product against
manufacturing defects in materials and workmanship.
• Do not subject the product to extreme force, shock, or fluctuations
in temperature or humidity.
• Do not mix new and old batteries or batteries of different types.
• Do not mix alkaline, standard or rechargeable batteries with this
product.Remove the batteries if storing this product for a long
period of time.
• Do not dispose of this product as unsorted municipal waste. Col-
lection of such waste separately for special treatment is neces-
sary.
• Do not tamper With the internal components.
WARRANTY
19
Warranty service can only be performed by our authorized service
center. The original dated bill of sale must be presented upon request
as proof of purchase to us, or our authorized service center.
The warranty covers all defects in material and workmanship with
the following specified exceptions:(1) damage caused by accident,
unreasonable use or neglect (including the lack or reasonable and
necessary maintenance); (2) damage occurring during shipment
(claims must be presented to the carrier); (3) damage to, or deteri-
oration of any accessory or decorative surface;(4) damage result-
ing from failure to follow instructions contained in your owner’ s
manual.
This warranty covers only actual defects within the product itself,
and does not cover the cost of installation or removal from a fixed
installation, normal set-up or adjustments, claims based on mis-
representation by the seller or performance variations resulting
from installation-related circumstances.
To receive warranty service, the purchaser must contact with
BALDR nominated service center for the problem determination
and service procedure.
Thank you for your choice of BALDR products!
EN

STATION MÉTÉO COULEUR SANS FIL AVEC
ALERTES DE TEMPÉRATURE
Pour la mise en service de cet appareil :
Unité principale par adaptateur CA (inclus) et 1x CR2032 (inclus)
Capteur par 2 x piles AA (non incluses)
Nous vous remercions pour votre achat de la station
météorologique couleur sans fil Baldr avec alertes de temp é
rature. Elle a été conçue et construite en utilisant des composants
et des techniques innovants pour permettre un affichage parfait.
Veuillez lire attentivement les instructions afin de vous familiariser
avec les propriétés et les fonctions avant d'utiliser l'appareil.
20
MANUEL D'UTILISATION MODÈLE:B0359WST2H2R
(VERSION US)
ENEN FR
