Features
ˆ
Features
Your Public Address Amplifier gives you the
versatility and power you need in a profes-
sional sound system. Its wide frequency re-
sponse easily handles amplification of voice
and music. Use it in meeting halls and audi-
toriums, at sports events, in schools, and in
the office for paging systems — anywhere
you need to deliver special announcements
with excellent sound.
The amplifier (if bridged) produces up to 350
watts of clean, powerful sound with minimum
distortion.
Your amplifier includes these features:
10–50000 Hz Frequency Response
Built-In Cooling Fan — helps protect the
amplifier by reducing its internal tempera-
ture.
Two Mounting Options — you can mount
the amplifier in a standard-sized audio equip-
ment rack or on a desk, shelf, or table.
2 Lighted VU Meters — measure the ampli-
fier’s output for each channel in decibels.
Left and Right Output Level Gain Controls
— let you adjust the overall sound level on
the left and right channels.
Clipping Indicator — lights if a sound
source signal overdrives the amplifier.
Phones Jack — lets you connect head-
phones so you can listen privately.
Bridging Capability — you can combine the
amplifier’s two channels and use the amplifi-
er with only one channel, producing a total of
350 watts.
Meter Range Select Switch — lets you con-
trol the meter’s sensitivity.
Input Jacks —let you connect a variety of
audio input sources for music and special ef-
fects.
A/B SPEAKER Switches — let you select the
speakers you want to use with the amplifier.
STEREO/MONO Switch — lets you select the
output type; stereo or mono (bridged).
Binding Post Terminals — let you easily
connect wires directly to the amplifier.
Switched AC Outlet — lets you power other
devices by plugging them into the back of the
amplifier.
This symbol is intended to alert you to
the presence of uninsulated danger-
ous voltage within the product’s enclo-
sure that might be of sufficient
magnitude to constitute a risk of elec-
tric shock. Do not open the product’s
case.
This symbol is intended to inform you
that important operating and mainte-
nance instructions are included in the
literature accompanying this product.
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN.
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE
COVER OR BACK. NO USER-SERVICE-
ABLE PARTS INSIDE. REFER SERVICING
TO QUALIFIED PERSONNEL.
WARNING: To reduce the risk of fire or
shock hazard, do not expose this product
to rain or moisture.
!
!

4Preparation
ˆ
Preparation
PRESETTING THE
CONTROLS
Before you begin making connections or us-
ing your amplifier, preset the audio input
source’s and the amplifier’s controls to avoid
overdriving a channel or producing sudden
unexpected loud sounds.
Warning: To prevent possible hearing loss,
set the audio input device’s and amplifier’s
controls as indicated in the following sec-
tions. After you turn on the amplifier or
change the program source, adjust the con-
trols to a comfortable listening level.
Presetting Audio Input Devices
Always set the power control for an audio
mixer or preamplifier you connect to the am-
plifier to OFF.
Presetting the Amplifier
Set the amplifier’s controls as follows:
MOUNTING THE AMPLIFIER
You can mount the amplifier in a standard-
sized audio equipment rack or on a desk,
shelf, or table. Before you use your amplifier,
be sure you place it in a location with ade-
quate ventilation. Do not put it on thick car-
peting (which can restrict air flow) or near a
heat source such as a heat vent or radiator
(which can cause it to overheat).
To mount the amplifier on a standard-sized
audio equipment rack, drive and tightly se-
cure mounting screws (not supplied) through
the mounting holes.
PLACING THE SPEAKERS
Speaker placement depends on your room’s
size and arrangement. We recommend you
play a wide-range recording and experiment
with speaker placement until you find the lo-
cations that result in the best sound. For the
best results, point the speakers toward the
audience (especially if the speakers are far
apart) so the coverage areas overlap to pre-
vent dead spots (areas not covered by the
speakers’ sound). Position the speakers
slightly above the level of the listeners’
heads (see “Connecting Speakers” on
Page 6).
Control Setting
POWER Out
SPEAKER A/B Out
LEFT and RIGHT MIN
METER RANGE Out

5
Connections
The following drawings show recommended
speaker placements for typical, narrow, and
wide sound coverage.
ˆ
Connections
CONNECTING AN INPUT
SOURCE
You can connect a component such as an
audio mixer or preamplifier to the inputs on
the back of your amplifier. Each input (la-
beled INPUT and INPUT MONO) has a bal-
anced and unbalanced jack. You need a
shielded cable with a 1/4-inch (6.35-mm)
phono plug to connect to an unbalanced jack
or a cable with a phono-type plug to connect
to a balanced jack. To prevent hum and oth-
er noise, use low-capacitance shielded ca-
ble. Your local RadioShack store carries a
wide selection of audio components, parts,
and cables.
Note: If you are using the MIC level inputs,
you must connect an audio mixer or pre-am-
plifier to this amplifier.
Cautions:
• You can connect audio mixers or pream-
plifiers to either the balanced
or
unbal-
anced jacks. Do not connect input
sources to both jacks at the same time.
• Before you make any connections, be
sure POWER on the front of the amplifier
is off and the AC power cord is not
plugged in.
Unbridged Connection
If you are connecting more than one speaker
on the same channel (unbridged connec-
tion), connect your audio mixer’s or preampli-
fier’s left and right output jacks to the INPUT
R and INPUT L jacks on the back of the ampli-
fier. Then, make sure STEREO/MONO on the
back of the amplifier is set to STEREO.
Bridged Connection
If you are connecting high-power speakers
that can handle a power output of 350 watts
(bridged connection), connect your audio
mixer’s or preamplifier’s output jack to the IN-
PUT MONO or INPUT L jack on the back of the
Typical Coverage
(two speakers)(single speaker) Wide Area CoverageNarrow Coverage

6Connections
amplifier. Then, make sure STEREO/MONO
on the back of the amplifier is set to MONO.
GROUNDING THE INPUT
SOURCE
To avoid a low frequency hum, connect your
audio mixer’s or preamplifier’s ground wire
(usually black or green) to the GND terminal
on the back of the amplifier.
CONNECTING SPEAKERS
You can connect one or more 4-, 8-, or 16-
ohm speakers to the amplifier. You can also
bridge the amplifier’s channels.
The amplifier has two channels: Aand B. If
you connect two pairs of speakers, follow
these guidelines:
• Speakers connected to the same chan-
nel (Aor B) are part of a pair and must
be of the same impedance.
• Speakers connected to different chan-
nels (Aor B) are not part of a pair and
can be different impedances.
Most speaker terminals are color-coded or
have a mark that indicates the terminal’s po-
larity. Usually, terminals with positive polarity
are red or have a plus symbol (+), and termi-
nals with negative polarity are black or have
a minus symbol (–). Phasing is correct when
you connect + to + and – to –.
Preparing the Speaker Wires
Use the shortest length of wire possible to
connect the speakers. After placing the
speakers, use this table to determine the
wire length and choose the appropriate
gauge.
To prepare the speaker wire, remove about 1
inch of insulation from the end of the speaker
wire you are connecting to the amplifier.
Then twist the exposed wire to secure all of
the wire strands.
Unbridged Connection
Use this connection if you are connecting
more than one speaker on the same channel
or if you do not have high-power speakers.
1. Connect the speaker
wires to the corre-
sponding left and right
speaker’s positive (+)
and negative (–) ter-
minals.
2. Connect the other end of the left and
right speaker’s positive (+) and negative
(–) wires to the amplifier’s correspond-
ing SPEAKERS LEFT and SPEAKERS
Wire Length Wire Gauge
25 feet or less 18 gauge
Over 25 feet 16 gauge
Wire Strands
Split strands
about 4”
1"

7
Connections
RIGHT terminals for each channel (as
shown here).
To connect the
speaker wires to
the amplifier, turn
the knob on the
terminal counter-
clockwise until it
stops, insert the bare wire inside the
space between the knob and the ampli-
fier, then turn the knob clockwise until it
stops to secure it.
3. Make sure STEREO/MONO is set to STE-
REO.
Bridged Connection
Use this connection only if you have high-
power speakers that can handle a power out-
put of 350 watts.
Important: For a bridged connection, do not
connect any speaker wires to the black
SPEAKERS terminals.
1. Connect the speaker wires to the
speaker’s positive (+) and negative (–)
terminals.
2. Connect the other end of the speaker’s
positive (+) and negative (–) wires to the
amplifier’s red SPEAKERS LEFT and
SPEAKERS RIGHT terminals (as shown
here).
Note: SPEAKERS RIGHT (+) on the
amplfier is used as a negative (–) termi-
nal for a bridged connection.
3. Make sure STEREO/MONO is set to
MONO.
USING THE SWITCHED AC
OUTLET
The amplifier’s switched AC outlet provides a
source of 120 V, 60 Hz power for audio
equipment you connect to it. POWER on the
amplifier turns both the amplifier and the au-
dio equipment connected to this outlet on or
off.
CONNECTING POWER
To connect the amplifier to power, plug the
attached power cord into a standard AC out-
let.
Your amplifier’s fuse (located on the amplifi-
er’s back panel) protects the amplifier from
voltage surges. If the amplifier does not work
when you press POWER, check the fuse. If it
is blown, see “Replacing the Fuse” on
Page 9 to replace it.

8Using Your Amplifier
ˆ
Using Your Amplifier
1. Start the input sound source.
2. Make sure LEFT and RIGHT on the front
of the amplifier are set to MIN.
3. Press POWER to turn on the amplifier.
4. One at a time, adjust LEFT and RIGHT to
the desired volume level.
Turn LEFT and RIGHT clockwise to
increase or counterclockwise to
decrease the corresponding left and
right output power. To get the best per-
formance with the least sound distortion,
always adjust LEFT and RIGHT so the
meter’s pointer does not continuously
swing to the extreme right.
5. When you finish, press POWER to turn
off the amplifier.
USING THE METERS/METER
RANGE
The position of the pointers on both of the
amplifier’s meters indicate the output power.
Built-in lamps light to make the meters easy
to see in dark areas.
METER RANGE controls the sensitivity of both
meters. When output power is too strong, a
meter’s needle might continuously swing to
the extreme right and damage or reduce the
accuracy of the meter.
If the meter’s needle continuously swings to
the extreme right, press METER RANGE to
the out position to maintain a 0 dB gain for
the meter. Or, press METER RANGE to the in
position to allow a 20 dB gain.
CLIP INDICATOR
The CLIP indicator on the front of the amplifi-
er lights steadily when a sound source’s sig-
nal exceeds the output power level you set
using LEFT and RIGHT, warning you of possi-
ble damage to the amplifier. If this happens,
reduce the output level of the connected
sound source or LEFT and RIGHT until the in-
dicator flickers only at peak volume levels.
USING SPEAKER A/B
Press in SPEAKER A or SPEAKER B on the
front of the amplifier for the channel you want
to listen to. Or, press in SPEAKER A and
SPEAKER B to listen to all connected speak-
ers.
Caution: If you connected 4 ohm speakers
to the amplifier, to avoid damage do not set
both SPEAKER A and SPEAKER B to the in
position.
MONITORING THE SOUND
SOURCES
To monitor the sound sources directly from
the amplifier, connect a pair of mono or ste-
reo headphones with a 1/4-inch (6.35-mm)
plug into the PHONES jack on the front of the
amplifier. Using headphones lets you easily
check and adjust the sound source’s bal-
ance.
Note: Your local RadioShack store carries a
wide selection of headphones.

9
Care
Listening Safely
To protect your hearing, follow these guide-
lines when you use headphones.
• Set the volume to the lowest setting
before you begin listening. After you
begin listening, adjust the volume to a
comfortable level.
• Do not listen at extremely high volume
levels. Extended high-volume listening
can lead to permanent hearing loss.
• Once you set the volume, do not
increase it. Over time, your ears adapt
to the volume level, so a volume level
that does not cause discomfort might
still damage your hearing.
ˆ
Care
To enjoy your PA Amplifier for a long time:
• Keep the PA Amplifier dry. If it gets wet,
wipe it dry immediately.
• Use and store the PA Amplifier only in
normal temperature environments.
• Handle the PA Amplifier gently and
carefully. Do not drop it.
• Keep the PA Amplifier away from dust
and dirt.
• Wipe the PA Amplifier with a damp cloth
occasionally to keep it looking new.
Modifying or tampering with the PA Amplifi-
er’s internal components can cause a mal-
function and might invalidate its warranty. If
your PA Amplifier is not performing as it
should, take it to your local RadioShack store
for assistance.
REPLACING THE FUSE
If the amplifier does not operate, you might
need to replace the fuse on the back of the
amplifier with another 7-amp, 250-volt fuse.
Important: Let the amplifier cool down and
see if it starts again before you assume a
fuse needs to be replaced.
Caution: Do not use a fuse with ratings other
than those specified. Doing so might damage
your amplifier.
1. Unplug the amplifier from the AC outlet.
2. Turn the fuse holder cap on the back of
the amplifier in the direction of the arrow,
then pull out the cap to remove the fuse.
3. If the fuse is blown, replace it. Use only
an identical fuse with the proper rating.
The fuse must be 7 amps.
Insert the fuse into the fuse holder’s socket,
press the fuse holder back into the amplifier,
then turn the fuse holder’s cap clockwise to
tighten it.

10 The FCC Wants You to Know
ˆ
The FCC Wants You to Know
Your amplifier might cause TV or radio inter-
ference even when it is operating properly.
To determine whether your amplifier is caus-
ing the interference, turn off your amplifier. If
the interference goes away, your amplifier is
causing it. Try to eliminate the interference
by:
• moving your amplifier away from the
receiver
• contacting your local RadioShack store
for help

11
Specifications
ˆ
Specifications
Input Impedance..........................................................................................................20 kOhms
Continuous Output Power
Stereo at 1 kHz .............................................................................. 125 Watts ×2 (8 ohms)
Stereo at 1 kHz .............................................................................. 175 Watts ×2 (4 ohms)
Bridged at 20 Hz to 20 kHz .................................................................. 250 Watts (8 ohms)
Bridged at 1 kHz .................................................................................. 350 Watts (8 ohms)
Total Harmonic Distortion ................................................................................ 0.1% at 80 Watts
Frequency Response (10 Hz – 50 kHz) ............................................................................ ±3 dB
Input Sensitivity .............................................................................................................. 0.775 V
Signal-to-Noise Ratio ................................................................................... 90 dB (A-weighted)
Speaker Impedance ....................................................................................... A, B(4–16 ohms)
A+B(8–16 ohms)
Bridged (8–16 ohms)
Power Requirement ........................................................................................... 120V AC 60 Hz
Dimensions (HWD) ............................................................................... 55/6×19 ×141/4Inches
(11.4 ×48.2 ×30.5 cm)
Weight .......................................................................................................................... 27.53 lbs
(12.5 kg)
Specifications are typical; individual units might vary. Specifications are subject to change and
improvement without notice.

32-2004
04A00
Printed in China
RadioShack
A Division of Tandy Corporation
Fort Worth, Texas 76102
Limited One-Year Warranty
This product is warranted by RadioShack against manufacturing defects in material and workman-
ship under normal use for one (1) year from the date of purchase from RadioShack company-owned
stores and authorized RadioShack franchisees and dealers. EXCEPT AS PROVIDED HEREIN, Ra-
dioShack MAKES NO EXPRESS WARRANTIES AND ANY IMPLIED WARRANTIES, INCLUDING
THOSE OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED
IN DURATION TO THE DURATION OF THE WRITTEN LIMITED WARRANTIES CONTAINED
HEREIN. EXCEPT AS PROVIDED HEREIN, RadioShack SHALL HAVE NO LIABILITY OR RE-
SPONSIBILITY TO CUSTOMER OR ANY OTHER PERSON OR ENTITY WITH RESPECT TO ANY
LIABILITY, LOSS OR DAMAGE CAUSED DIRECTLY OR INDIRECTLY BY USE OR PERFOR-
MANCE OF THE PRODUCT OR ARISING OUT OF ANY BREACH OF THIS WARRANTY, IN-
CLUDING, BUT NOT LIMITED TO, ANY DAMAGES RESULTING FROM INCONVENIENCE, LOSS
OF TIME, DATA, PROPERTY, REVENUE, OR PROFIT OR ANY INDIRECT, SPECIAL, INCIDEN-
TAL, OR CONSEQUENTIAL DAMAGES, EVEN IF RadioShack HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES.
Some states do not allow limitations on how long an implied warranty lasts or the exclusion or limita-
tion of incidental or consequential damages, so the above limitations or exclusions may not apply to
you.
In the event of a product defect during the warranty period, take the product and the RadioShack
sales receipt as proof of purchase date to any RadioShack store. RadioShack will, at its option, un-
less otherwise provided by law: (a) correct the defect by product repair without charge for parts and
labor; (b) replace the product with one of the same or similar design; or (c) refund the purchase
price. All replaced parts and products, and products on which a refund is made, become the prop-
erty of RadioShack. New or reconditioned parts and products may be used in the performance of
warranty service. Repaired or replaced parts and products are warranted for the remainder of the
original warranty period. You will be charged for repair or replacement of the product made after the
expiration of the warranty period.
This warranty does not cover: (a) damage or failure caused by or attributable to acts of God, abuse,
accident, misuse, improper or abnormal usage, failure to follow instructions, improper installation or
maintenance, alteration, lightning or other incidence of excess voltage or current; (b) any repairs
other than those provided by a RadioShack Authorized Service Facility; (c) consumables such as
fuses or batteries; (d) cosmetic damage; (e) transportation, shipping or insurance costs; or (f) costs
of product removal, installation, set-up service adjustment or reinstallation.
This warranty gives you specific legal rights, and you may also have other rights which vary from
state to state.
RadioShack Customer Relations, 200 Taylor Street, 6th Floor, Fort Worth, TX 76102
We Service What We Sell
12/99
