Radio Shack Telephone Listener User manual

Cat. No. 43-231B
OWNER’S MANUAL
Please read before using this equipment.
Telephone Listener
43-231b.fm Page 1 Thursday, August 12, 1999 4:15 PM

2
FEATURES
Your RadioShack Telephone Listener amplifies your calls through its built-in
speaker so everyone in the room can hear. The Listener’s features include:
•Suction Cup Pickup Coil — makes attachment to the telephone easy and
convenient. The coil is designed so you can attach it (depending on the
type of phone you use) to just about anywhere on the phone.
•Volume Control — lets you adjust the Listener’s volume to a comfortable
listening level.
•Two Power Sources — let you power your Listener from an internal bat-
tery or standard AC power (with an optional AC adapter).
•Mounting Options — you can place the Listener on a desktop or table, or
mount it directly on the wall.
©1994, 1998 Tandy Corporation.
All Rights Reserved.
RadioShack is a registered trademark used by Tandy Corporation.
43-231b.fm Page 2 Thursday, August 12, 1999 4:15 PM

3
PREPARATION
CONNECTING TO POWER
You can power your Listener from either an internal battery or AC power.
Using Battery Power
To power the Listener from an internal battery, you need one 9-volt battery (not
supplied). For the best performance and longest life, we recommend an alkaline
battery, such as RadioShack Cat. No. 23-553.
Caution: Always use a fresh battery of the required size and recommended
type.
43-231b.fm Page 3 Thursday, August 12, 1999 4:15 PM

4
1. Insert a coin into the slot between the front and back halves of the case,
and twist it slightly to separate the halves, then lift off the front case.
2. Snap the battery connector over the battery’s terminals.
3. Place the battery on top of the foam cushion inside the front case, then
place the back case over the front case and snap it closed.
When the Listener’s volume drops or the sound
distorts, replace the 9-volt battery.
Illus showing opening
the case with a coin
and installing the
battery
43-231b.fm Page 4 Thursday, August 12, 1999 4:15 PM

5
Cautions:
• If you do not plan to use the Listener for a week or more, or if you plan to
use only an AC adapter, remove the battery. Batteries can leak chemicals
that can destroy electronic parts.
• Dispose of old batteries promptly and properly. Do not burn or bury them.
Using AC Power
To power the Listener from a standard AC outlet, you need an AC adapter such
as Cat. No. 273-1431.
43-231b.fm Page 5 Thursday, August 12, 1999 4:15 PM

6
Cautions:
• You must use an AC adapter that supplies at least 7.5 volts DC power and
delivers at least 300 milliamps. Its center tip must be set to positive, and its
barrel plug must properly fit the Listener’s 9V DC jack. The recommended
adapter meets these requirements. Using an adapter that does not meet
these requirements could damage the Listener or the adapter.
• To prevent damage to the Listener or the adapter, be sure you connect the
adapter to the Listener before you plug it into the AC outlet, and unplug the
adapter from the AC outlet before you unplug it from the Listener.
Insert the adapter’s barrel plug into the Listen-
er’s 9V DC jack, then plug the adapter into a
standard AC outlet.
Illus. showing inserting
the barrel plug into
the 9V DC jack
43-231b.fm Page 6 Thursday, August 12, 1999 4:15 PM

7
Note: Connecting the AC adapter automatically disconnects the internal bat-
tery.
MOUNTING
You can place the Listener on a flat surface, such as a shelf or desk top, or
mount it directly on the wall.
To mount the Listener on the wall, you need two flat-head screws (not supplied)
with heads that fit into the keyhole slots on the back of the Listener.
Drill two holes 215/16 inches (75 mm) apart.
Then thread a screw into each hole, letting
the heads extend about 1/4inch (6 mm) from
the wall.
Illus showing the distance
between the two screws in
wall and the distance they
extend from the wall.
43-231b.fm Page 7 Thursday, August 12, 1999 4:15 PM

8
Align the keyhole slots with the mounting
screws and slide the Listener downward to se-
cure it.
CONNECTING AND TESTING THE LISTENER
1. Insert the plug from the suction cup pickup
coil into TEL PICK-UP.
Illus showing
alignment of screws
with keyhole slots
and an arrow to
indicate sliding the
Listener downward
Illus showing insertin
the suction cup plug
into TEL PICK-UP.
43-231b.fm Page 8 Thursday, August 12, 1999 4:15 PM

9
2. Rotate the volume control to about its
middle position (3).
3. Set ON/OFF to ON.
Note: To prevent feedback, do not place
the suction cup pickup coil near the Lis-
tener’s speaker.
4. Because telephone designs vary greatly,
you might need to try attaching the
pickup coil at different locations on your
telephone. Start by pressing the suction
cup against the back of the handset,
opposite the receiver’s earpiece. Then
lift the telephone handset off the cradle.
Illus showing power
switch set to ON and
volume control set to
3
Illus showing the
suction cup pressed
against the back of
the handset, opposite
the receiver’s earpiece
43-231b.fm Page 9 Thursday, August 12, 1999 4:15 PM

10
5. While listening to the dial tone through the Listener’s speaker, move the
suction cup to different locations on the phone. Try the left rear corner of
the phone’s base, as well as around the receiver’s earpiece. Keep moving
the suction cup pickup coil until you find the position that provides the best
sound quality and volume.
6. When you finish, leave the suction cup attached to the telephone and set
ON/OFF to OFF.
43-231b.fm Page 10 Thursday, August 12, 1999 4:15 PM

11
OPERATION
To use the Listener, simply place or answer a call on the phone you attached it
to, then set ON/OFF to ON. Adjust the Listener’s volume control to a comfortable
level.
When the call is over, hang up the phone then set ON/OFF to OFF.
43-231b.fm Page 11 Thursday, August 12, 1999 4:15 PM

12
CARE
To enjoy your Listener for a long time:
• Keep the Listener dry. If it gets wet, wipe it dry immediately.
• Use and store the Listener only in normal temperature environments.
• Handle the Listener gently and carefully. Don’t drop it.
• Keep the Listener away from dust and dirt.
• Wipe the Listener with a damp cloth occasionally to keep it looking new.
Modifying or tampering with the Listener’s internal components can cause a
malfunction and invalidate its warranty. If your Listener is not performing as it
should, take it to your local RadioShack store for assistance.
43-231b.fm Page 12 Thursday, August 12, 1999 4:15 PM

13
NOTES
43-231b.fm Page 13 Thursday, August 12, 1999 4:15 PM

14
43-231b.fm Page 14 Thursday, August 12, 1999 4:15 PM

15
Limited One-Year Warranty
This product is warranted by RadioShack against manufacturing defects in material and workmanship
under normal use for one (1) year from the date of purchase from RadioShack company-owned stores
and authorized RadioShack franchisees and dealers. EXCEPT AS PROVIDED HEREIN, RadioShack
MAKES NO EXPRESS WARRANTIES AND ANY IMPLIED WARRANTIES, INCLUDING THOSE OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN DURATION
TO THE DURATION OF THE WRITTEN LIMITED WARRANTIES CONTAINED HEREIN. EXCEPT AS
PROVIDED HEREIN, RadioShack SHALL HAVE NO LIABILITY OR RESPONSIBILITY TO CUS-
TOMER OR ANY OTHER PERSON OR ENTITY WITH RESPECT TO ANY LIABILITY, LOSS OR
DAMAGE CAUSED DIRECTLY OR INDIRECTLY BY USE OR PERFORMANCE OF THE PRODUCT
OR ARISING OUT OF ANY BREACH OF THIS WARRANTY, INCLUDING, BUT NOT LIMITED TO,
ANY DAMAGES RESULTING FROM INCONVENIENCE, LOSS OF TIME, DATA, PROPERTY, REVE-
NUE, OR PROFIT OR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES,
EVEN IF RadioShack HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
Some states do not allow the limitations on how long an implied warranty lasts or the exclusion of inci-
dental or consequential damages, so the above limitations or exclusions may not apply to you.
In the event of a product defect during the warranty period, take the product and the RadioShack sales
receipt as proof of purchase date to any RadioShack store. RadioShack will, at its option, unless other-
wise provided by law: (a) correct the defect by product repair without charge for parts and labor; (b) re-
place the product with one of the same or similar design; or (c) refund the purchase price. All replaced
parts and products, and products on which a refund is made, become the property of RadioShack.
New or reconditioned parts and products may be used in the performance of warranty service. Re-
paired or replaced parts and products are warranted for the remainder of the original warranty period.
You will be charged for repair or replacement of the product made after the expiration of the warranty
period.
(Continued)
43-231b.fm Page 15 Thursday, August 12, 1999 4:15 PM

RadioShack
A Division of Tandy Corporation
Fort Worth, Texas 76102 8110H0010D
4A8 Printed in Hong Kong
