Radioddity AVRT7 Plus User manual

BH7NOR&BG6QBV Firmwareandsoftwaredownloads：http://avrx.cn
- 1 -
AVRT7 Plus User Manual
V1.6 (for reference only, updated)
list
1. Introduction …………………………………………………………………………………… 2
2. AVRTx Selection table …………………………………………………………………… 3
3. AVRT7 Plus Mainboard illstration ………………………………………………………… 4
4. Setup & Usage: Single gateway mode ……………………………………………………… 6
5. Setup & Usage: real-time 2-channels decoding …………………………………………………… 14
6. AVRT7 Plus’ accessories & Usage …………………………………………………………… 16
7. Application of external radio………………………………………………………………….. 18
8. AVRT7 Plus’Installation & Usage of its software …………………………………………… 20
9. AVRT7 Plus’illustration of its firmware updating …………………………………………………… 21
10. Cautions of Usage ………………………………………………………………….. 22
11. AVRT7 PLUS Serial data printout help …………………………………….. 25

BH7NOR&BG6QBV Firmwareandsoftwaredownloads：http://avrx.cn
- 2 -
Introduction
The full name of APRS is Automatic Packet Reporting System. More than
10 years ago, there was the APRS in China’s domestic market, but it was
expensive and hard to use because of its poor integration so that it was not
popular at that time. BI7NOR ＆ BG6QBV designed and produced the low
price AVRTx serious special device, which help more HAM radio ameture to enjoy
the fun of APRS by lower cost and simpler operation.
The modification and improvement has been done to AVRT7 Plus by
combining old model’s advantage and users’feedback. AVRT7 Plus can achieve
the APRS iGate (rate : 1200bps). It compatible the regular amaturish and
commercial APRS device and many kinds of APRS Digi repeater station and
iGate， and it is the first network iGate multifunctional APRS device in China‘s
domestic market that with the internal radio module and individual 2-channel ’
s real-time decoder and it can upload the data to the network server in the
meanwhile.

BH7NOR&BG6QBV Firmwareandsoftwaredownloads：http://avrx.cn
- 3 -
APRS system illustration
model AVRTNC‐Digi AVRT5 AVRT11 AVRT7Plus
PurposeAPRSrepeater
conectingboard
Hand‐held
APRS 
TNC
CARAPRS
TNCAPRSgateway
Features
 Itcanprovidethe
APRSrepeter
functionthrough
themotolora16
pinssocketafterthe
radiofrequency
dataissetup. 
Hand‐held
APRS,
Maximum RF
power:1watt.
RF+GPRS
2tracks
uploading/APRS
gateway

WithinternalRFreceving
module，extendedsocket
decodingfunction，theAPRS
gatewaycoulduploadthedatato
aserverafterthereal‐time
individual2waydecoding.
GPSpositioning
function Yes

Yes  
Mapbluetooth
connectivity

Optionalfunction 
Yes 

Yes  Optionalfunction 
LCDdisplay  
Yes  Optionalfunction
Extensionsocket
forradio Yes  Yes Yes
Extensionsocket
forother
function
Reserved  Reserved Yes 
APRSgateway   Yes Yes

APRSrepeater   Yes Yes Yes
Internal
transmitting
module
Yes  
Internal
receivingmodule  Yes Yes
Ambient
tempreture
detection

Optionalfunction Yes Yes Reserved
Ambient
pressure
detection
 Yes Reserved
Buzzingalert  Yes Yes 
Statusindicator Yes Yes Yes Yes
TTLserialport Yes Yes Yes Yes

BH7NOR&BG6QBV Firmwareandsoftwaredownloads：http://avrx.cn
- 4 -
upgrading/setup
/mapconnecting
function
Internalbattery Yes  
ExternalDC
(12v)socket  Yes Yes 
GPRStracksdata
uploading  Yes 
remarks    
InternalWIFImodule
Necessary
conditionfor
usage
Viaaradio GSMcard/ 
Radio LAN  orWIFIconnection
AVRT7 Plus Motherboard function
1. receiving antena base
2.extenalradiosocket（thesocketcoulbeconnectedviathe6pinscabletoFT8800RIC2720H，etc.）

BH7NOR&BG6QBV Firmwareandsoftwaredownloads：http://avrx.cn
- 5 -
3.LANnetworksocket（568A/568Bselfadaptable，DHCPIPaddressautomaticallyobtaining）
4.USBTTLsocket
5.LCDscreensocket(aLCDscreenisavailableforit)
6.powersupplyinput(DCIN:712V)
7.masterchip
8. high efficiency DC-DC power supply circuit
9. status indicator
10. bluetooth module (optional parts)
11. internet controlling chip
12. wifi module
13. individual 2-channels’real-time decoder
14. VHF RF receiving module
The major function of AVRT7 Plus is to achive the APRS iGate (rate 1200bps) with the full
programme including VHF receiving module and 2 individual TNC Codec. It works (with the
right data setting) when the network cable is plugged in and the WIFI account and password
is set up. It compatible the regular amaturish and commercial APRS device and many kinds
of APRS Digi repeater station and iGate.
1. With the internal RF + extension radio it can achive the 2 channel real-time decoding : with
internal RF receiving module, and with the extension radio socket, the data could be
uploaded to the server while decoding to achive the real-time APRS iGate network gateway
function;
2. With the optional LCD screen : the user can see the real-time data received without cell
phone, computer or Garmin navigator ;
3. With the optional BPM180,18B20, the extension meteorological function could be
activated : ( the new function module could be ordered such as tempreture, humidity, wind
direction or speed, etc. )

BH7NOR&BG6QBV Firmwareandsoftwaredownloads：http://avrx.cn
- 6 -
AVRT7 Plus’setup and usage
With the user’s feedback according to their previous genarations products, the AVRT7
Plus software could be installed and set up simply. User just need a network cable and set up
few simple data.
Before it is switched on, all parts should be connected to AVRT7 Plus. Boot the AVRT7
Plus and it would work automatically to avoid users’tedious operation.
Connecting illustration with single router （ network cable
connection）：
connect the power supply
connect the AVRT7 plus to a router

BH7NOR&BG6QBV Firmwareandsoftwaredownloads：http://avrx.cn
- 7 -
connect the AVRT7 plus to a external antenna
DC IN (7~12V)
LCD screen socket ( optional LCD screen)
USB-TTL socket
RJ45 network socket ( 568A/568B self-adaptable, DHCP IP address automatically obtaining.)
External radio socket ( 6 pins cable could be connected such as FT8800R, IC2720H,etc.)
External RF antenna base.
connecting illastration with single router (wifi connection)
connect the power supply
via wifi (WLAN)
connect the AVRT7 plus to a external antenna
DC IN (7~12V)
LCD screen socket ( optional LCD screen)
USB-TTL socket
RJ45 network socket ( 568A/568B self-adaptable, DHCP IP address automatically obtaining.)
External radio socket ( 6 pins cable could be connected such as FT8800R, IC2720H,etc.)
External RF antenna base.

BH7NOR&BG6QBV Firmwareandsoftwaredownloads：http://avrx.cn
- 8 -
gateway setting :
basic setting:
1. callsign : user’s own callsign, SSID default : -10;
2. login password: please use Users’APRS verify code,。
user could get the further guidance through the QQ group(30531489).
APRS Passcode Generator Website： http://apps.magicbug.co.uk/passcode/index.php
3. coodinate data: base on user’s physical gateway position, the relevented definition
refer to the following pictures:
* coodinate format ( please comply with the ARPS coodinate format otherwise the data could be denied by
the server) :

BH7NOR&BG6QBV Firmwareandsoftwaredownloads：http://avrx.cn
- 9 -
icon，gateway default “&”
icon, default/, could be amended by user.
latitude first and then longitude, N: north latitude, E: east longitude
coodinate data , format: degree-minute.second
beacon type, default “!”, do not change it.
4. VHF RF receiving module ‘s frequency should be base on user’s local frequency , the
format is : 144.6400 .
5. status text
6. APRS server selection
7. APRS gateway information upload interval time, unit: second, for example, "60 seconds",
fill in "0060".
8. Beacon filtering
9. External display backlight on time selection. ON = long bright, the display continues to
display; 30 seconds = beacon decoding is complete, the backlight is off after 30 seconds,
restore the black screen waiting state.
10. External display shows the distance unit selection: KM/MI
11. ctcss feature is not enabled
12. External radio DIGI function, select DIGI = APRS relay function to use. The APRS DIGI
function is used and the beacon received is uploaded to the APRS server. In addition, it will
be re-encoded, using an external radio transmitter beacons, radio transmitter will not receive
beacon decoding! ! !

BH7NOR&BG6QBV Firmwareandsoftwaredownloads：http://avrx.cn
- 10 -
Gateway use does not need to enable APRS relay function! ! !
Note：DIGI function : The AVRT7 plus could and olny could transfer data when there is a
external radio and after the DIGI is selected.
13.DIGI PATH
14. DIGI Beacon transmit audio modulation selection,
15. DIGI alias
16. WIFI SSID
17. WIFI PASS
18. Write account and password to the WIFI module (see WIFI settings operation)
19. LAN Port IP Assignment Selection, Custom IP or Router Auto Assignment (DHCP)
20.21.22.23. Custom IP value
24. Serial port selection (install USB serial port driver, see hardware manager COM)
25. Connect the PC and AVRT7PLUS using a USB serial cable, select COM (24). AVRT7PLUS
data value can be read out by activation
26. Load saved data
27. Restore the default data value
28. Write the current data value
29. Save the current data value
30. Display configuration software version
31. After reading the data value (25), the AVRT7PLUS firmware version is displayed
32. Select AVRT7PLUS firmware
33. Update AVRT7PLUS firmware
34. Operation status display
35. Firmware update blue band prompt completion percentage. The blue band reaches to the
right and the firmware update is completed
36. AVRT7 reboots
2.4G-WIFI setting : (use the router’s WIFI login ID and password)
Note 1, WIFI would be disabled when the network cable is plugged in, and the WIFI
setting only could be set up without the network cable.
Note 2, the power to stop, re-insert the power and USB serial cable boot. WIFI data
SSID and PASS, directly activate the "APPLY" write, the operation is prohibited
"read data (25)"
Note 3, the DC power supply must be plugged in when inputting the WIFI data.

BH7NOR&BG6QBV Firmwareandsoftwaredownloads：http://avrx.cn
- 11 -
16. SSID : please use your WIFI login account; (default : bi7nor)
17. PASS : please use your WIFI login password; (default : abcd1023)
18. Please click “Apply”and input the WIFI setting data into the AVRT7 plus after the
red LED (from wifi module) on the left side is on. And the AVRT7 plus would reboot
after the wifi setting is finished and it would connect to the wifi automatically. (English
alphabet and number could be only accepted.)
-------------------------------------------------------------------------------
In case there is a system prompt as follow, that means the invalid WIFI setting and you
need to apply again until success.
WIFI Write Fail
--------------------------------------------------------------------------------------------
In case there is a system prompt as follow, that menas WIFI account and password
both are correct and the system would reboot and then work normally.
WIFI Write complete
Note 4: The default wifi account is : bi7nor, the password is: abcd1023
in case fail to input the right wifi data, user could also amend their
router’s wifi account and password.
Note 5: It could be the outer RF interference that lead to the router’s
mulfunction so that AVRT7 plus fail to connect the router via wifi.
Please make sure the router’s wifi channel is on one of the
following channels : CH1, CH6, CH11, CH13.

BH7NOR&BG6QBV Firmwareandsoftwaredownloads：http://avrx.cn
- 12 -
Router WIFI settings reference (2.4GHz)
Wireless - General：
AVRT7 Plus –WIFI Only supports 2.4GHz !!!
Authentication Method: WPA2
WPA Encryption: AES
Radio channels : CH1, CH6, CH11, CH13. (china Region )

BH7NOR&BG6QBV Firmwareandsoftwaredownloads：http://avrx.cn
- 13 -
mobile phone WIFI sharing settings reference :
Encryption type: WPA2 PSK
AP Band: 2.4G
Broadcast channel: 11 (china
Region 1、6、11、13)

BH7NOR&BG6QBV Firmwareandsoftwaredownloads：http://avrx.cn
- 14 -
※ two channels real-time dual decodding diagram:
In this mode : AVRT7 plus could decode the beacon from VHF module inside and from extension
radio at the same time, and AVRT7 plus would upload the valid beacon to the APRS-IS server
without mutual interference.
So the V+V and the V+U dual frequency gateway could be easily established to achieve the
function of dual standing by and dual communication.
connect the power supply
connect the AVRT7 plus to a router

BH7NOR&BG6QBV Firmwareandsoftwaredownloads：http://avrx.cn
- 15 -
connect the AVRT7 plus to a external antenna
DC IN (7~12V)
LCD screen socket ( optional LCD screen)
USB-TTL socket
RJ45 network socket ( 568A/568B self-adaptable, DHCP IP
address automatically obtaining.)
External radio socket ( 6 pins cable could be connected such as
FT8800R, IC2720H,etc.)
External RF antenna base.
BLUE LED： handheld radio in
RED LED : External RF in

BH7NOR&BG6QBV Firmwareandsoftwaredownloads：http://avrx.cn
- 16 -
AVRT7 Plus’ accessories & Usage
the connection of the LCD display :
connect the power supply
connect the AVRT7 plus to a router

BH7NOR&BG6QBV Firmwareandsoftwaredownloads：http://avrx.cn
- 17 -
connect the AVRT7 plus to a external antenna
DC IN (7~12V)
LCD screen socket ( optional LCD screen)
USB-TTL socket
RJ45 network socket ( 568A/568B self-adaptable, DHCP IP address
automatically obtaining.)
External radio socket ( 6 pins cable could be connected such as FT8800R,
IC2720H,etc.)
External RF antenna base.
(screen cable)： 8 pins newwork cable is available
1. The LCD must be connected to the system only before AVRT7 plus is
turnned on, then reboot it.
2. The ordinary 1:1, 8 pins RJ45 network cable is available for the system
screen. A shielded cable is recommended to avoid the outer
interference.
3, LCD screen for the built-in and external radio beacon are displayed,
such as receiving beacons at the same time the external radio priority
display.

BH7NOR&BG6QBV Firmwareandsoftwaredownloads：http://avrx.cn
- 18 -
interface definition for external radio :
1. an external radio could be connectted to AVRT7 plus via this
socket.
DC IN (7~12V)
LCD screen socket ( optional LCD screen)
USB-TTL socket
RJ45 network socket ( 568A/568B self-adaptable, DHCP IP address
automatically obtaining.)
External radio socket ( 6 pins cable could be connected such as
FT7800R、FTT8800、 IC2720H、IC208H、D710、V71A，etc.)
DIY can also be connected to Motorola Radio, GM300, SM50, SM120,
GM338, GM398, GM3688.950I，
All any radio can be DIY connection
External RF antenna base.

BH7NOR&BG6QBV Firmwareandsoftwaredownloads：http://avrx.cn
- 19 -
diagram for LED status indicator :
Position
of LED
Power
on
Network
connectting
Server
connected
Server(netwok)
disconnected
Beacon
decoded
by
external
radio
Becon
decoded
by
internnal
radio
B Flashed
fast
C
Flash in
middle
speed
Constant
light Flash slow Constant light Flashed fast -
LED A : internal wifi LED, the internal wifi module is available when it remains lit.
LED C : connected to router via wifi

BH7NOR&BG6QBV Firmwareandsoftwaredownloads：http://avrx.cn
- 20 -
AVRT7 Plus Configuration program download and driver installation
1, All file download :
http://avrtx.cn/
2, software download
a, Download the manual and software
http://avrtx.cn/index.php?folder=QVZSVDcgUExVUw==
b, Download USB serial port driver
http://avrtx.cn/download/USB%20driver/CH340/CH340%20DRIVER.ZIP
c, Download the Microsoft VB/VC Runtime Library file
http://avrtx.cn/download/ocx%20libraries/all%20ocx%20libraries.zip
d、solution for the “MSComm32.ocx”
Install the Microsoft VB/VC Runtime Library file (right mouse button, select: install in
administrator mode)
* * * * * * * * * * * *
3、AVRT7 Plus Configuration program value read and write：
a. To install the CH340 driver first, connect the USB cable between your PC and AVRT7 Plus.
b. Start the software and choose the right COM port (you may find it in the computer device
manager), and click the button; there is a prompt would be shown in the
lower right corner (if fail you may click and then reboot the AVRT7 Plus)
c. click to achieve the default data setting, User could amend the data base on
the dafault version.
d. After the amendment, click to save data and reboot AVRT7 Plus.
