RadioLink R6DSM User manual

R6DSM
(FHSS and DSSS spread spectrum)
Radiolink R6DSM, 2.4G 10 channels receiver, DSSS and FHSS spread spectrum working
synchronously, 1 gram weight, SUBS signal, use for Radiolink transmitters AT9, AT9S，AT10 and
AT10II, is the best choice for racing drone.

Two signal working mode:
Red LED always, SBUS signal , 10 channels totally.
How to match code with transmitter:
1. Place the transmitter and the receiver close to each other within 1 meters.
2. Turn on the transmitter, then power on the R6DSM.
3. Connect CH3 of R6DSM to ESC.
4. There is a black button on the R6DSM, press the binding button twice in two seconds and
release, receiver light start blinking, after about 8 times blinking, match code success when
receiver signal LED always on!
Specification:
1) Channels:
10 channels: output 10 channels signal, support SBUS signal, with red LED.
2) Working voltage: 4.8-10V
3) Working current: 38-45mA（input voltage: 5V）
4) Size: 15*13 MM
5) Weight: 1g
6) Detachable antenna
7) 4096 section precision, 0.25us per section, servo anti-shake rudder.
8) Control distance: about 600 meters, actually control distance depends on the environment.

Installment of receiver antenna：
1. The antenna must be kept as straight as possible. Otherwise it will reduce the effective range.
2. Large model aircraft may of some metal part interfering signal; in this case the antennas
should be placed at both sides of the model. Then the best RF signal condition is obtained at any
flying attitude.
3. The antennas must be kept away from conductive materials, such as metal and carbon by at
least a half inch. The coaxial part of the antennas does not need to follow these guidelines, but do
not bend it in a small radius.
4. Keep the antennas away from the motor, ESC, and other noise sources as much as possible.
5. Press and hold the Easy Link (ID SET) one second, now the receiver starts work.
6. After all of the above steps finished, the LED indicator will turn and keep in red.
7. The receiver can be packed by sponge or foam for shocking proof when it is installed to the
model.
After all of the above steps finished, turn off the transmitter and then power it on, now the
program functions to assure it under control of transmitter with a right connection.
