Mode 1: PWM output (factory setting by default, NO gyro)
When the Green indicator is on, Channel 1 to Channel 7 output standard PWM. Short press ID SET once
to change Mode 1 to Mode 2 and three times within 1 second to Mode 3.
Mode 2: PWM+PPM+SBUS output (NO gyro)
When the Blue indicator is on, Channel 1 to Channel 5 output standard PWM while Channel 6 outputs
PPM and Channel 7 outputs SBUS. Short press ID SET once to change Mode 2 to Mode 1 and three
times within 1 second to Mode 4.
Mode 3: PWM output + Gyro
When the Red indicator is on, Channel 1 to Channel 7 output standard PWM. Meanwhile, the Gyro
function is also on, stabilizing the direction, keeping car from slipping and ensuring safer turning to
preventing drifting from fast speed. Short press ID SET once to change Mode 3 to Mode 4 and three
times within 1 second to Mode 1. Short press ID SET twice in 1 second to change the gyro phase.
Mode 4: PWM+PPM+SBUS output + Gyro
When both the Red and the Blue indicators are on (Purple), Channel 1 to Channel 5 output standard
PWM while Channel 6 outputs PPM and Channel 7 outputs SBUS. Meanwhile, gyro function is also on,
stabilizing the direction, keeping car from slipping and ensuring safer turning to preventing drifting from
fast speed. Short press ID SET once to change Mode 4 to Mode 3 and three times within 1 second to
Mode 2. Short press ID SET twice in 1 second to change the gyro phase.
5. Gyro Introduction
5.1 Gyro Function
The R7FG integrated gyro for professional car drifting can be enabled and disabled. When it’s enabled,
the turning stability can be maximized during competition. When there is false position, gyro function
keeps the car straight forward and turn precisely.
5.2 Gyro Enabled
Factory setting is gyro function OFF by default.
Short press ID SET three times with interval less than 1 second, the RED indicator flashes three times.
Red LED on/off indicates the gyro function is on/off.
5.3 Gyro Phase
When the gyro forward is enabled, try to turn the model car to check if the gyro is correcting the wheels.
Normally, the wheels should turn right to correct when the car is turned left while the wheels should turn
left to correct when the car is turned right. If the gyro phase is reversed, short press the binding button (ID
SET) twice in 1 second in mode 3 and mode 4. The indicator flashes once means the gyro phase setting
is complete.
5.4 Transmitter Sensitivity Adjustment
Gyro sensitivity setting is CH3 by default (factory setting) and can be adjusted by the VR rotary switch.
Percentage is displayed when sensitivity is adjusted while the bigger percentage means higher sensitivity.
If the VR rotary switch/CH3 is set with other function, MODE can be changed to STD in GYRO setting of
the menu to adjust gyro sensitivity with buttons Dec(-) and Inc(-).
