raditeq Pro Series User manual

Models:
www.raditeq.com
RPR4006R
RadiPower®
Product Manual
RF Power Meter

Page 1 of 16
Publish date: 08/08/2023
Version: 1
RadiPower® product manual
This product manual refers to the RadiPower® pro series.
Models: RPR4006R
Made by Raditeq B.V.
Carefully read the content of this manual before operating the product and make sure all the safety
instructions are strictly followed.
For your convenience, a Quick Start Guide has been added to this product. This Quick Start Guide
contains the basic start-up steps and main safety warnings.
Please keep the Quick Start Guide (and this regular manual) close at hand when you operate your new
Raditeq product(s).
Please contact your local reseller if you have any questions.
Supplier Information
Raditeq B.V.
Vijzelmolenlaan 3
3447 GX, Woerden
The Netherlands
Tel.: [phone]
Internet: www.raditeq.com
Email: [email protected]
All trademarks used in this manual are the property of their respective owners
RadiPower® Product Manual
RPR4006R
Page 1 of 16
This product manual is subject to change without notice
Copyright © 2008 - 2023 Raditeq B.V.

Page 2 of 16
Page 2 of 16
This product manual is subject to change without notice
Copyright © 2008 - 2023 Raditeq B.V.
RadiPower® Product Manual
RPR4006R
Table of contents
WARNINGS & PRECAUTIONS 3
Introduction 4
The RadiPower® 4000 Series 5
Theory of operation 5
RadiPower® Installation 6
Stand-alone Conguration 6
Software Conguration 7
Stand-alone command set 9
RPR4006R - RadiPower Status & Setting Commands 9
RPR4006R - RadiPower Status Commands - Continued 10
RPR4006R - Measurement Commands 11
RPR4006R - Measurement Commands - Continued 12
Specications RPR4000 Pro Series 13
Warranty Conditions 14

Page 3 of 16
RadiPower® Product Manual
RPR4006R
Page 3 of 16
This product manual is subject to change without notice
Copyright © 2008 - 2023 Raditeq B.V.
WARNINGS & PRECAUTIONS
Read the contents of this product manual carefully and become familiar with the safety markings, the product instructions
and the handling of the system. Please refer to the applicable product manual(s) for further information regarding the
operation and control of the product(s).
Only Raditeq qualied maintenance personnel is allowed to perform maintenance and/or repair service on the equipment.
This product® contains materials that can be recycled and reused to minimize material waste. At the ‘end-of-life’, specialized
companies can dismantle the discarded system to collect the reusable and recyclable materials. If your product is at its
‘end-of-life’, please return it to your local reseller or to Raditeq for recycling.
For cleaning, use a clean, dry cloth (or a damp cloth where needed) and wipe the surface of equipment.
This product contains no hazardous substances as described in the RoHS Directive (2011/65/EU).
This Product contains embedded software, which is (stand a lone) upgradeable using the RadiMation® Software.

Page 4 of 16
This product manual is subject to change without notice
Copyright © 2008 - 2023 Raditeq B.V.
RadiPower® Product Manual
RPR4006R
Introduction
This manual contains information about the RadiPower® RPR4000 Pro series range of RF power meters.
An accurate power meter is indispensable to perform reliable EMC measurements. The RadiPower® 4006R Pro
is a RF power meter especially designed for power measurements during EMC tests. The RadiPower® is an
aordable, accurate and fast power meter. It provides accurate RMS measurements over a wide frequency
range, which enables eective measurements in accordance with the latest EMC standards.
Each RadiPower® RF power meter has an USB port that allows direct connection and control from any Microsoft®
Windows PC.
Please read this manual carefully and make sure to pay special attention to the chapters regarding your new
product(s).
RadiMation® Software
RadiMation® is the brand independent EMC automation software from Raditeq.
RadiMation® places the EUT in the center. The software is designed to perform all
EMC tests required to certify an EUT. As a result, the test data of all dierent tests is
collected in one single software package, allowing fully automated report generation.
Our advanced report generation tool streamlines the process of creating test reports following EMC
(Electromagnetic Compatibility) tests. With its user-friendly interface and ecient functionality, generating a
comprehensive test report has never been easier. By simply pressing a single button, the tool automatically
compiles all the necessary data and formats them into a professional and organized report.
This automation signicantly reduces the time and eort traditionally required to manually compile and format
test reports. Our tool ensures consistency and accuracy in report generation, minimizing the risk of errors or
omissions.
Furthermore, the report generation tool supports the inclusion of all relevant graphs, charts, tables, and
explanatory notes to provide a comprehensive understanding of the test results.
By simplifying the report generation process, our tool empowers EMC test engineers to focus more on their
core tasks, such as analyzing results and implementing mitigation strategies if necessary. This improves overall
productivity and eciency in the testing workow, enabling faster turnaround times for delivering test reports
to clients or internal teams.
Device drivers for all main manufactures are freely made available or are made for free when required, as long
as the equipment is standard comercially available and still supported by the original manufacturer. This allows
you choose the best suited EMC test equipment for each specic application, instead of being locked in by a
vendor.
RadiMation

RadiPower® Product Manual
RPR4006R
Page 5 of 16
This product manual is subject to change without notice
Copyright © 2008 - 2023 Raditeq B.V.
Shielded USB cable
Model: USB A male to Mini USB
Used to connect the RF power sensor with the PC.
The RadiPower® 4000 Series
The RadiPower® RF power sensor
Model: RPR4006R
True RMS Power Meter for measurements of (non) sinusoidal
singals.
Standard delivered with USB stick containing the following documents:
• The user manual and Quick Start Guide.
• The installation of RadiMation® Free software and drivers.
• Optional - The calibration certicate for the power meter (if a calibration was requested).
Theory of operation
The RadiPower® RPR4006R incorporates a hardware RMS detector, enabling direct measurement of (non)-sinusoidal
signals with exceptional accuracy. This advanced feature eliminates the need for additional signal processing or
waveform assumptions, making it a versatile device for a wide range of applications.

RadiPower® Product Manual
RPR4006R
Page 6 of 16
This product manual is subject to change without notice
Copyright © 2008 - 2023 Raditeq B.V.
Connect the RadiPower® sensor to a Windows computer with a USB port for ‘stand-alone’ use. Use the supplied
USB cable to connect the sensor to your computer. Windows will prompt that new hardware has been found. The
USB-driver for the RadiPower® is Windows certied and will be loaded automatically from the Windows update.
If the drivers are not loaded automatically, these can be installed manually from the supplied USB-key. Follow
the normal instructions from Windows to install the drivers manually.
Once the drivers are loaded successfully, the RadiPower® will be shown in the device list.
RadiPower® Installation
Stand-alone Conguration
Connect the RadiPower® sensor to a Windows computer with a USB 2.0 (USB 3.0 preferred). Use the supplied USB
cable to connect the RadiPower® sensor. The hardware installation for the RadiPower® sensor is now complete.

Page 7 of 16
This product manual is subject to change without notice
Copyright © 2008 - 2023 Raditeq B.V.
RadiPower® Product Manual
RPR4006R
In order to control the RadiPower® from a computer, the RadiMation® EMC software package can be used.
RadiMation® from Raditeq is sold separately. A free-ware version of RadiMation® is available on: https://www.
raditeq.com/automated-emc-software/radimation-free/. If the RadiPower® is operated manually, this chapter
can be skipped.
RadiMation comes after version 2022.2 with an Auto Detect feature. This makes it possible to automatically
detect Raditeq (and other hardware) and congure it.
The Auto detect start when you rst download and install RadiMation. Or click Devices -> Auto-detect.
Software Conguration
Select the correct interfaces used by your
device. In the case of a RadiPower®, USB.

RadiPower® Product Manual
RPR4006R
Page 8 of 16
This product manual is subject to change without notice
Copyright © 2008 - 2023 Raditeq B.V.
After Click the all setting on and press continue till the auto detect wizard completes and select (all) Devices to
be added to your conguration. For more information and a instructional video go to:
https://www.raditeq.com/radimation-auto-detect-feature/

RadiPower® Product Manual
RPR4006R
Page 9 of 16
This product manual is subject to change without notice
Copyright © 2008 - 2023 Raditeq B.V.
Stand-alone command set
The RadiPower® sensor can also be directly connected to a PC.
Communication with the RadiPower® sensor is possible using a virtual COM-port (VCP)
RPR4006R - RadiPower Status & Setting Commands
Command Descritption Power meter Reply
*IDN? Returns the ID of the RadiPower Raditeq, RPR4006R, 4.2.0
ID_NUMBER? Returns unique identier number. For example: "1.58.95.146.21.0.0.124"
VERSION_SW? Returns the software version For example: "4.0.3"
VERSION_HW? Returns the hardware version For example: "4"
STATUS? Check wheter an error is raised OK or error code
REBOOT SYSTEM Restart the RadiPower embedded
software
OK
CLEAR Error messages are cleared (if the error is
still present after clear, the error is raised
again)
OK
LOCAL Return to local mode OK
RESET Reset the module. The following things
are reset:
• Frequency: 1.3 GHz
• ACQ Speed: 1 MS/sec
• Filter: 12
• Auto store: O
• Power oset: 0.00 dB
• Power units: dB
*After resetting the user parameter, the
em-bedded software is restarted.
OK

Page 10 of 16
This product manual is subject to change without notice
Copyright © 2008 - 2023 Raditeq B.V.
RadiPower® Product Manual
RPR4006R
Command Descritption Power meter Reply
STORE The following parameters are stored by
this command:
• Frequency
• ACQ Speed
• Filter
• Power oset
• Power units
OK
AUTO_STORE<space><store> Sets the auto store setting, with <store>:
0 = settings will not be automatically
stored
1 = settings will be stored in ash after
each change of the settings.
*Be aware, the ash will degrade much
faster when activated!
OK
AUTO_STORE? Query the auto store setting.
0 = settings will not be automatically
stored
1 = settings will be stored in ash after
each change of the settings.
*Be aware, the ash will degrade much
faster when activated!
For example: “1”
RPR4006R - RadiPower Status Commands - Continued

RadiPower® Product Manual
RPR4006R
Page 11 of 16
This product manual is subject to change without notice
Copyright © 2008 - 2023 Raditeq B.V.
RPR4006R - Measurement Commands
Command Descritption Power meter Reply
POWER? Returns the measured power in dBm or
Watt
For example: "-38,81"
POWER_UNIT<space><unit> Set in which unit the reply on the "POWER?"
command must be. <unit> can be:
0 = dBm
1 = Watt
OK
POWER_UNIT? Replies the used unit
0 = dBm
1 = Watt
For example: “0”
POWER_OFFSET<space><oset> Sets the power oset in dB. <oset> can
be set from -100.00 to +100.00 dB.
OK
POWER_OFFSET? Replies the power oset. See the command:
"POWER_OFFSET<space><oset>" for
the explanation of <oset>.
<oset> For example: "15.23"
FILTER<space><lter> Set the lter of the power meter where
<l-ter> can be set from "1" till "12".
OK
FILTER? Get the current used lter by the power
me-ter
For example: "12"
FILTER_BW? Returns the lter bandwidth <BW> in Hz.
Filter bandwith is calculated by
ACQ_speed dvidided by averaging
For example: “1000”
FREQUENCY?<space>MIN Get the minimum frequency of the power
meter
"4000"
FREQUENCY?<space>MAX Get the maximum frequency of the power
meter
"6000000000"
FREQUENCY
<space><frequency>
Set the frequency of the power meter
where, <frequency> is in Hertz.
OK
FREQUENCY? Get the current used frequency by the
power meter
For example: "1300000000"
GET_DATA? Returns power, frequency, and lter in a
single reply.
For example:
“-6858;50000000;12” =
-68.85dBm, 50MHz, lter 12

Page 12 of 16
This product manual is subject to change without notice
Copyright © 2008 - 2023 Raditeq B.V.
RadiPower® Product Manual
RPR4006R
Command Descritption Power meter Reply
GD? Returns power, frequency, and lter in a
single reply.
For example:
“-6858;50000000;12” =
-68.85dBm, 50MHz, lter 12
ACQ_SPEED<space><speed> Set the ADC sample speed in kSps.
<speed> can be:
• 1000
• 5000 (*)
*Not supported in ranging mode
OK
ACQ_SPEED? Get the set current used ACQ_Speed
used by the power meter
<speed> For example: "1000"
RPR4006R - Measurement Commands - Continued

RadiPower® Product Manual
RPR4006R
Page 13 of 16
This product manual is subject to change without notice
Copyright © 2008 - 2023 Raditeq B.V.
Specications RPR4000 Pro Series
Model RPR4006R
Measuring function RMS power
Measurement speed 1 MS/s | 5 MS/s
Resolution 0,01 dB
Measuring units dBm or Watt
Zero adjustment Not required
Input damage level > +20 dBm
Measurement range & accuracy
Frequency range 4 kHz to 6 GHz
Power measuring range Frequency
4 kHz - 100 MHz
100 MHz - 1,5 GHz
1,5 GHz - 3,5 GHz
3 ,5 GHz - 4,5 GHz
4,5 GHz - 6 GHz
MAX dBm
+10
+10
+10
+10
+10
MIN dBm
-70
-65
-60
-55
-50
Frequency response accuracy (at 23º C ± 2º C) +/- 0,2 dB
Linearity error 0,05 dB + 0,005 dB/dB
Temperature eect 0,15 dB max over full temperature range
Deviation from CW for signals with high crest factor < 0,2 dB
VSWR
Max SWR: < 100 MHz 1,05
100 MHz to 6 GHz 1,10
Connections & Dimensions
Dimensions of measuring device (LxWxH) 125,2 * 44.5 * 32 mm
RF input connector N type precision
Data connector (power head side) Mini USB
Power Consumption
Supply voltage +5Vdc from USB port (4,75 V to 5,25 V)
Current consumption (USB) Max. 500 mA
Environmental conditions
Temperature range (operating) 0° to 30° Celsius
Temperature range (storage) -10 to 50º C
Relative humidity 10 – 90% (non-condensing)
Compliance
EMC EN 61326
Low Voltage N/A
Warranty 3 year (1)
(1) Three years warranty will be granted only after you register the product at www.raditeq.com. Without registration, a 1 year warranty period applies.
• All specications are measured after 30 minutes warm-up time and 0dBm unless specied otherwise.
• Typical specications indicate that the measured values are met on at least 80% of the points.

Page 14 of 16
This product manual is subject to change without notice
Copyright © 2008 - 2023 Raditeq B.V.
RadiPower® Product Manual
RPR4006R
Warranty Conditions
Raditeq B.V. oers a standard warranty term of three (3) years on their products, calculated from the shipping date, under the
condition that the product is registered on www.raditeq.com. For registration of the product, the customer should provide the
product model, serial number and the responsible reseller (if applicable). If the product is not registered, a limited warranty
term of one (1) year will be applicable.
Return Material Authorization (RMA) & Warranty repair
If a defect occurs to our product within the warranty term, a Return Material Authorization (RMA) ‘Warranty Repair’ request
can be issued using the RMA link at www.raditeq.com/support. Upon receipt of the request, an RMA number will be provided.
Please do not send the product without this RMA number! The defective product should be shipped to our service department
at the following address:
Raditeq B.V. – Service Department
Vijzelmolenlaan 3
3447GX WOERDEN
The Netherlands
There will be no charge for repair services (materials or labour) within the (extended) warranty term.
These warranty terms are not applicable to:
• Normal wear and tear
• Fibre optic cables
• Products that have been improperly used
• Products that have been used outside their specied range
• Products that have been improperly installed and/or maintained
• Products that have been modied without approval of Raditeq
• Calibration and/or re-calibration of the product
Repair services on products that are not covered by the Raditeq warranty will be charged to the customer.
Repairs outside warranty
If a defect is not covered under warranty, an RMA xed-repair can be ordered on the RMA link: www.raditeq.com/support If
a re-calibration is needed after repair, this calibration should be ordered separately. The calibration will be performed at the
ISO17025 accredited calibration laboratories of DARE!! Calibrations, based on the applicable service code / prices.
Warranty after repair
For repairs outside the original warranty period, a limited warranty of six months is applicable on the performed repair.
Shipping conditions are the same as with repairs that are covered within the original warranty period.
Shipping
The customer will need to arrange shipping and cover for the costs (like e.g. transportation costs, duties, taxes) for sending
the defect product the service department of Raditeq in The Netherlands. Raditeq will arrange the courier and cover for the
costs for the return shipment after repair.

RadiPower® Product Manual
RPR4006R
Page 15 of 16
This product manual is subject to change without notice
Copyright © 2008 - 2023 Raditeq B.V.
EU Declaration of Conformity
We
Raditeq B.V.
of
Vijzelmolenlaan 3
NL-3447GX Woerden
The Netherlands
declare under our sole responsibility that the
Product: RadiPower® Series
models: RPR4006R
are in accordance with the European directives:
EMC Directive 2014/30/EU
Low Voltage Directive 2015/35/EU
RoHS Directive: 2015/863/EU
per the provisions of the applicable requirements of the following harmonized standards:
Emission: EN 61326-1:2013, Class A1
Electrical equipment for measurement, control and laboratory use.
Immunity: EN 61326-1:2013, Industrial level, performance criteria A
Electrical equipment for measurement, control and laboratory use.
Safety: EN 61010-1:2010, Safety requirements for electrical equipment
for measurement, control, and laboratory use
The technical construction les are maintained at the adress specied above.
Date of issue: Publish date: 08/08/2023
Place of issue: Woerden, The Netherlands
Authorized by: P.W.J. Dijkstra
Title of authority: Director

Raditeq B.V. | Vijzelmolenlaan 3 | 3447GX Woerden | The NetherlandsRaditeq B.V. | Vijzelmolenlaan 3 | 3447GX Woerden | The Netherlands
www.raditeq.com | T:[phone]www.raditeq.com | T:[phone]
