Package Contents and Product Views
Open the package and you should find the following:
1. Computers or servers with SATA I & SATA II & SATA III.
2. Hard drive with SATA I & SATA II & SATA III.
3. You are strongly advised to set the storage mode (the default is the Independent
mode) before using the iR2321.
4. The product needs to be restarted after adding or changing the RAID mode, and
the update is guaranteed to be the new RAID mode.
5. The product allows the user to simultaneously utilize two hard drives manu
factured by different companies. However, if the user expects better efficiency,
we strongly recommend the users to use hard drives manufactured by the
same manufacturer.
6. Please make sure that the two hard drives are free from bad blocks or defects
prior to installation in order to avoid system crashes or data loss.
7. The actual storage capacity of iR2320 recognized by the system may differ from
the total capacity stated on the hard drives combined once the drives have been
formatted.
8. It is highly recommended for users to back up important data contained within
the iR2321 on a regular basis or whenever the user feels necessary to a remote
or a separate storage device. Stardom will not be responsible for any lost of data
caused during the use of the unit or the recovery of the data lost.
9. For initial setup, it is advisable to utilize two fresh hard drives that are identical inbrand
and model. In the event that a hard drive is not brand new and is not detected during
the RAIDbox boot process, please connect the hard drive to the computer individually.
Proceed to clear its sectors through the operating system and reformat it (for specific
steps, consult the operating system's instructions) before reintroducing it into the
RAIDbox for use.
Hardware Requirements and Precautions
Hardware Installation
Please check the product and accessories for any defect or missing parts.
If you have any questions, please contact your product supplier.
Please visit the official website (www.raidon.com.tw) to download user
manuals, drivers and other related resources.
Raidon
RAIDON is one brand under RAIDON TECHNOLOGY, INC.
Thank you for choosing RAIDON’s product.
The information provided in this manual was checked before publication, but the actual product
specifications may have changed before shipping; Latest product specifications and updates
can be found at www.RAIDON.com.tw or through your sales representative. No separate
notifications will be provided by our company.
If you have any questions about RAIDON products or would like to receive the latest product
assistance.
All product-related content in this manual are copyrighted by RAIDON TECHNOLOGY, INC.
Please follow the instructions below to complete the hardware installation.
Properly connect SATA cable and power cable from your system to the device.
Power on your system after hardware installation is completed, and your
operating system will automatically detect the hard drives from booting.
Then follow the steps from your operating system to partition and format
the drives when necessary, device will be ready to use once the format
is completed.
5.
6.
V0.1(SEP. 2023)
2.5”HDD Tray
A
Fail status indicator LED
2.5”Tray Key Lock & Push Open Button
B
Mute Switch
C
D
E
HDD status indicator LED
Fan Port
F
Cooling Fan
G
7+15 Pin SATA Connector X2
H
45cm SATA Cable
Power Supply Connector
Power Supply
Mother board
SATA Port
iR2321
Internal Case
SATA Port
45cm SATA Cable
LED Instruction
4.
IR2321 Device
x1
Contents of Product Package
Internal SATA Cable x2
RAID Mode
Buzzer
Raid Switch
J
Lock Unlock
For the 2.5" HDD tray, please use the key included in the accessory kit
to unlock the 2.5" HDD tray key lock and push the HDD eject button to
the right, the 2.5" HDD tray handle will pop up to remove the tray.
nstall the 2.5-inch hard disk and secure it with the small screws
included in the 4 parts package.
3.When the HDD/SSD installation has been completed, insert the hard
drive tray into the system horizontally and secure the latch into place.
Front view
Rear view
A
I
C
G
B
A
D
E
HDD 1
HDD 2
MUTE
FAIL
HDD 1HDD 2
MUTE
FAIL
HDD Idle
HDD Fail or Adsent
HDD Access
Rebuilding(Source)
Rebuilding(Target)
Light On
─ ─
Light On
Light On
─ ─
Blue LED
─ ─
Light On
Blinking
─ ─
Blinking
─ ─
On
─ ─
─ ─
─ ─
Red LED Buzzer
Status
F
I
