RAILBLAZA C-TUG User manual

Caring For Your C-TUG®Cart
Thanks for purchasing a Quality, New Zealand Made C-TUG Cart
The C-TUG is designed for the movement of watercraft. It is specically not designed for
the movement of people either directly on the cart, or in or on watercraft or other objects
placed on the cart.
Due to the harsh and abusive environment where this product may be used, we suggest
the following steps be taken to extend the life of your C-TUG;
• After using your C-TUG in salt water, or sandy/dusty conditions remove the wheels,
disassemble the chassis and hose down with fresh water. Wash the axle area
thoroughly
• Do not clean with solvents or solvent based products, and avoid commercial
cleaning products, fresh water is best for cleaning C-TUG components
• When portaging in hot, dry or dusty conditions it is recommended that you spray
axles with water regularly to avoid overheating in the axle area
• Each time you t the wheels to your C-TUG ensure the axle is clean and free of sand
or debris
• Do not leave your C-TUG cart in strong sunlight for extended periods. Your C-TUG
is designed for use outdoors but both rubber and thermoplastics will degrade if
left in strong sunlight for long periods.
Your C-TUG Cart is a robust, quality product designed to take the hard work out of getting
your watercraft to and from the water. With reasonable care you can expect it to serve
you well for many years. There is a 2 year warranty against manufacturing defects on the
SandTrakz wheels, and a 5 year warranty against manufacturing defects on standard Kiwi
Wheels and all other parts. Please refer to our website www.c-tug.com for more details
and information on how to make a warranty claim.
NOTE: Load should not be stored for long periods on SandTrakz wheels.
Wheels must be washed to remove sand from axle area after each use.
C-TUG encourages users of C-TUG products to observe safe practice procedures when
using products in marine environments.
CT-1073.C
1. Thread ladder lock onto strap
2. Thread strap through C-TUG Rails
3. Feed strap back through ladder lock
Part List:
• 2 x Crossbeams
• 2 x C-TUG Rails
• 2 x C-TUG Rail Bases
• 2 x Wheels
• 1 x Kickstand
• 1 x Strap Kit (includes)
1 x 1.2 m Webbing
2 x Ladder Lock
1 x 1.6 m Webbing (with sewn on metal buckle )
• 1 x Fastener pack (includes)
4 x Green D-Washer
4 x Hex Bolts
4 x Hex Nuts
www.ctug.com
Disclaimer: C-TUG is not responsible for injury or damage to
persons or property resulting from the misuse of this product.
© 2022 RAILBLAZA LIMITED, Auckland NZ, and RAILBLAZA USA (Railblaza)
All rights reserved. International Design & Util Pats Pending.
MADE IN NEW ZEALAND
Direction of Pull
Place the Kickstand at the back of the kayak to ensure
it folds away if it hits an object.
Scan for C-TUG videos
Use Kickstand opposite to pull direction


CROSSBEAM
KICKSTAND
Slip the bottom of the kickstand into the inside
of one of the crossbeams.

Pull kickstand completely through and ensure
the pins in the kick stand base insert into the
indentions on the inside of the Crossbeam.

Bring the other side of the crossbeam to meet up
against the kickstand side.

Compress both sides of the crossbeam and
you should feel a click as the cross beam pins
t into the opposite side.

Swivel the
Hull Rail into
the hook.

Install straps as shown on back of instructions and
you are ready to use your C-TUG R.

Continue to swivel the rails until they are at.
Position the Rails of your C-Tug to match
your kayak hull and tighten bolts.

CLICK TO
LOCK
Slip the wheel over the axle and push down on
axle pin till it clicks into the lock position.
Assembled C-Tug rails
1. Insert nuts into hex
recess through the
C-TUG Rails
2. Add green D-washers
over bolt, at edge
against bracket
3. Tighten by hand
4. Press on green pads.
