1IQNet Server/Client Communication • Connection Module (CM) PE-Cable and/or Radio Secondary Communication
IQNet Server/Client
Communication Overview
Allows a single Server Satellite with IQ pri-
mary communication connection (Cellu-
lar, Ethernet, etc.) to be shared with up to
255 Client Satellites via Radio and/or Con-
nection Module (CM) PE-Cable secondary
communication.
a. Utilizes lower cost IQNCCRS RS-232
Cartridges for Client Satellites.
b. Reduces yearly reoccurring com-
munication costs for systems using
Cellular communication.
c. Provides Normally Closed Master
Valve or Pump Start sharing be-
tween Server and Client Satellites.
d. Provides Weather Sensor (not Flow
Sensor) sharing between Server
and Client Satellites.
Rain+Birdt IQNCCRS RS-232 Network Communication Cartridge -
IQNet Server/Client Installation & IQ-Cloud Configuration
For Additional Information
See IQ-NCC Cartridge Installation
and Operations Guide for IQ3G-
USA Cellular and IQNCCEN
Ethernet Cartridge Installation
and Configuration Instructions.
Go to www.RainBird.com/
for training, presentations,
product literature and
information for IQ-
Enterprise and IQ-Desktop.
IQ-Cloud Support
(800) 254-0692
www.RainBird.com/IQ
Rain Bird Global Service Plan (GSP)
(866) 477-9778
9Go to www.rainbird.com/iq
A
New users: Select IQ-Cloud Sign-up.
B
Existing users: Select IQ-Cloud Login.
10 Select Add Site
13 Add Client Satellites
A
Choose ESP-LX Controller Type.
B
Select Client IQNet Type.
14 Configure Client Satellites
A
Select Edit Configuration and Stations.
B
Enter the unique IQNet Network Address (2 to 56) that you selected in the
Setup Wizard for each Client Satellite.
15 Reverse Sync Data from each Satellite
A
Select Auto Configure.
B
Check All Options.
2018 Rain Bird Corporation
tRegistered trademark of Rain Bird Corporation
P/N: 690656-01 Rev. 6/18 D41261
3Attach IQ Cables to Cartridges in Server and
Client Satellites
C
Select the
Server Satellite
this Client is
connected to.
12 Configure Server Satellite
A
Select Edit Configuration and Stations.
B
Select IP Connection Type, enter the IP Address and Port Number for IQ-Cloud
to communicate to the Server Satellite.
11 Add Server Satellite
A
Choose ESP-LX Controller Type.
B
Select Server IQNet Type.
2Install IQ-NCC Cartridges 4Attach IQ Cables to Radio/CM Module
Attach Supplied Y-Cable to Radios or Straight-Cable to CM Modules
8Check IQNet Satellite Communication Status from
the Client Satellites
7Test Satellite Communication from the
Server Satellite
B
The Setup - Satellite Type
screen is displayed. Use +
or - to select Direct' press
Next.
NOTE: The IQ Port status
will allways show Disabled for
Client Satellites.
g Turn the controller dial to
ETM/IQ Settings
5Setup Wizard for Server Satellite
g Turn the controller dial to
ETM/IQ Settings
6Setup Wizard for Client Satellite
g Turn the controller dial to
ETM/IQ Settings
B
The Setup - Satellite Type screen is
displayed. Use + or - to select Client;
press Next.
C
The Setup – Satellite Address screen
is displayed. Use + or - to select a
unique address from 002-256 for
this satellite (press and HOLD but-
tons to accelerate settings); press
Next.
D
The Setup – Satellite Radio
Port screen is displayed. Use +
or - to select a radio port op-
tion (No Radio Installed, Radio
Installed); press Next.
E
The Setup – Satellite CM Port
screen is displayed. Use + or -
to select a CM Port option (No
Module, Module Installed);
press Next.
F
The Setup – CM Port
Termination screen is dis-
played. Use + or - to select a
CM Port Termination option
(On or Off).
NOTE: CM Port
termination is only
required if this satellite is
at the end of an IQNet PE
Communication Cable path.
If you are not sure, consult
with the system designer.
A
The IQ Settings main menu is
displayed. Use the UP or DOWN
arrows to select Setup Wizard;
press Next.
B
The Setup - Satellite Type
screen is displayed. Use + or -
to select Server; press Next.
C
The Setup – Satellite Address
screen is displayed. Server
Satellites always have an ad-
dress of 001; press Next.
D
The Setup – Satellite IQ Port
screen is displayed; press Next.
E
The Setup – Satellite Radio
Port screen is displayed. Use +
or - to select a radio port op-
tion (No Radio Installed, Radio
Installed); press Next.
F
The Setup – Satellite CM Port
screen is displayed. Use + or
- to select a CM Port option
(No Module Installed, Module
Installed); press Next.
g Turn the controller dial to
ETM/IQ Settings
A
The IQ Settings main menu is dis-
played. Use the UP or DOWN ar-
rows to select Status; press Next.
B
The Satellite Status screen is
displayed. Current status of IQ,
Radio, and CM ports are shown.
Press Signal to display 3G signal
strength.
C
The Signal Strength is displayed.
The signal strength between the
satellite and the 3G Cellular net-
work is indicated on a scale of
1-10.
D
The Satellite Status screen is dis-
played. Current status of IQ, Radio,
and CM ports are shown. Press
Ping to check the communication
status with selected Clients.
E
The IQNet Ping screen is displayed.
Use the + and - buttons to select
any Client address. Press Ping to
check the communication status.
The LCD will display Response-Yes
if the ping is successful, or No for
an unsuccessful ping.
A
The IQ Settings main menu is dis-
played. Use the UP or DOWN arrows
to select Setup Wizard; press Next.
A
The IQ Settings main menu is dis-
played. Use the UP or DOWN arrows
to select Status; press Next.
Install IQ3G-USA Cellular or
IQNCCEN Ethernet Cartridge
in Server Satellite
Install IQNCCRS RS-232 Cartridges
in the Client Satellites
NOTE: Refer to IQ3G-USA Cellular and
IQNCCEN Ethernet Cartridge Installation
Posters for full Installation instructions.
NOTE: Use Y-Cable for satellites that
have both a CM Module and Radio.
What’s NewIQ-Cloud Sign Up IQ-Cloud Login EN
IQ-Cloud Login
Login
Configure this computer
Rain Bird IQ Central Control System
TM
User Name
Password
I forgot my password
Log On Cancel
What’s New
Show Quick Start
C
Select Configure this computer
for first time IQ-Cloud connection
on a new computer.
D
Enter User Name & Password to
Logon to IQ-Cloud.
3G Cellular
Antenna
Backplane
Connect DB9 Cable
end to Radio port
Connect 2-pin cable
end to CM Module
ESP-LX Controller
Server Satellite
IQ3G-USA or
IQNCCEN Cartridge
Supplied IQ-Y and Straight Cables
Connect Cartridges to CM's and Radios
IQFSCMLXME Flow Smart Connection Modules
for ESP-LXME Controllers and IQCMLXD
Connection Modules for LXD Controllers
To Internet
and IQ-Cloud
To Additional
Connection
Module Client
Satellites
To Additional
Radio or
Connection
Module Client
Satellites
IQNCCRS Cartridge
ESP-LX Controller
ESP-LX Controller
IQNCCRS Cartridge
19-Gauge PE
Cable, Twisted Pair,
Shielded, Gel Filled
Communication
Cable (Max 18K feet)
IQSSRADIO or RB-
SS-TN9B Radios
(separate antenna
and Radio Site
Survey required)
Attach IQ-Y Cable to Radio
IQ NCC Cartridges
Attach Straight-Cable for
Connection Modules (CM)
Client Satellite
