R&S TSMA6B User manual

R&S®TSMA6B
Autonomous Mobile Network Scanner
User Manual
4901402602
Version 01
(a1XJ2)

This manual describes the following R&S®TSMA6B models:
●R&S®TSMA6B (4900.8005.K20)
© 2021 Rohde & Schwarz GmbH & Co. KG
Mühldorfstr. 15, 81671 München, Germany
Phone: [phone] - 0
Email: [email protected]
Internet: www.rohde-schwarz.com
Subject to change – data without tolerance limits is not binding.
R&S® is a registered trademark of Rohde & Schwarz GmbH & Co. KG.
Trade names are trademarks of the owners.
4901.4026.02 | Version 01 | R&S®TSMA6B
Throughout this manual, products from Rohde & Schwarz are indicated without the ® symbol, e.g. R&S®TSMA6B is indicated as
R&S TSMA6B.

Contents
R&S®TSMA6B
3User Manual 4901.4026.02 ─ 01
Contents
1 Preface.................................................................................................... 9
1.1 Documentation Overview............................................................................................. 9
1.1.1 Getting Started Manual................................................................................................... 9
1.1.2 User Manuals and Help...................................................................................................9
1.1.3 Basic Safety Instructions.................................................................................................9
1.1.4 Data Sheets and Brochures............................................................................................ 9
1.1.5 Release Notes and Open Source Acknowledgment (OSA)............................................ 9
1.2 Safety and Regulatory Information........................................................................... 10
2 Key Features.........................................................................................11
3 Instrument tour.....................................................................................12
3.1 Front panel view..........................................................................................................12
3.2 Rear panel view........................................................................................................... 12
3.3 Removable SSD option (R&S TSMA6B-BEB)........................................................... 15
3.4 Status LEDs................................................................................................................. 16
4 Option concept.....................................................................................18
4.1 Software options (scanner)........................................................................................18
4.1.1 Technology options....................................................................................................... 18
4.1.2 Band options................................................................................................................. 19
4.2 Software options (applications).................................................................................19
4.2.1 R&S SmartONE Expert (ROMES) options....................................................................19
5 Preparing for use................................................................................. 21
5.1 Unpacking the instrument..........................................................................................21
5.2 Connecting external devices..................................................................................... 22
5.3 Connecting power supply.......................................................................................... 23
5.3.1 Connecting to a vehicle DC power supply.................................................................... 23
5.3.2 Connecting an AC power supply...................................................................................24
5.3.3 Connecting the R&S TSMA6B-BP................................................................................ 25
5.4 Switching on R&S TSMA6B....................................................................................... 28
5.5 Connecting with R&S TSMA6B WLAN access point............................................... 28
5.6 Connecting USB to LAN adapter TSPC-U2L2 / TSPC-USL......................................31

Contents
R&S®TSMA6B
4User Manual 4901.4026.02 ─ 01
5.7 Connecting test mobile phones.................................................................................32
5.8 Calibrating GPS for dead reckoning......................................................................... 32
5.9 Using external SSD option (R&S TSMA6B-BEB)..................................................... 33
6 Configuring the R&S TSMA6B............................................................ 35
6.1 Changing IP adresses.................................................................................................35
6.2 Accessing the R&S TSMA6B..................................................................................... 35
6.2.1 Using the R&S TSMA6B web GUI................................................................................ 35
6.2.2 Using a remote desktop connection..............................................................................37
6.3 Selecting measurement mode................................................................................... 39
6.3.1 Measurement modes.................................................................................................... 39
6.3.1.1 PC mode....................................................................................................................... 40
6.3.1.2 Remote ViCom server mode.........................................................................................40
6.3.1.3 QualiPoc mode..............................................................................................................41
6.3.1.4 NESTOR and NESTOR probe mode............................................................................ 43
6.3.1.5 SmartONE mode...........................................................................................................45
6.3.1.6 Scanner mode...............................................................................................................46
6.4 Importing workspace files (NESTOR, ROMES)........................................................ 48
6.5 Pairing Bluetooth® devices........................................................................................ 48
6.6 Changing keyboard language....................................................................................50
6.7 Verify virtual memory settings...................................................................................51
7 Connecting multiple TSMx devices....................................................56
7.1 Connecting R&S TSMA6B with R&S TSME6............................................................ 56
7.2 Connecting R&S TSMA6B with R&S TSMExxDC..................................................... 58
7.3 Connecting R&S TSMA6B with R&S TSMExxDC + R&S TSME6............................ 59
8 Update and restore.............................................................................. 60
8.1 Downloading setup file...............................................................................................60
8.2 Updating firmware/software/tools - general instructions........................................60
8.2.1 Calling R&S TSMA6B web GUI.................................................................................... 60
8.2.2 Checking mode of operation......................................................................................... 60
8.2.3 Local execution of the setup file....................................................................................62
8.2.4 Remote installation of the setup file.............................................................................. 65
8.2.5 Local installation using a USB stick.............................................................................. 68

Contents
R&S®TSMA6B
5User Manual 4901.4026.02 ─ 01
8.3 Firmware update - details...........................................................................................71
8.4 Software update - details............................................................................................72
8.4.1 Remote ViCom Server software....................................................................................72
8.4.1.1 Preparation....................................................................................................................73
8.4.1.2 ViCom server local installation...................................................................................... 73
8.4.1.3 ViCom server remote installation.................................................................................. 74
8.4.1.4 ViCom server installation using a USB stick................................................................. 75
8.4.2 R&S NESTOR software................................................................................................ 76
8.4.2.1 Preparation....................................................................................................................76
8.4.2.2 NESTOR local installation.............................................................................................76
8.4.2.3 NESTOR remote installation......................................................................................... 77
8.4.2.4 NESTOR installation using a USB stick........................................................................ 78
8.4.3 R&S SmartONE setup (SmartBenchmarker, ROMES, QualiPoc).................................79
8.4.3.1 Preparation....................................................................................................................80
8.4.3.2 SmartONE local installation.......................................................................................... 80
8.4.3.3 Initial software start / measurement mode selection..................................................... 80
8.5 TsmeTools update.......................................................................................................84
8.5.1 Preparation....................................................................................................................84
8.5.2 TsmeTools local installation...........................................................................................84
8.5.3 TsmeTools remote installation....................................................................................... 85
8.5.4 TsmeTools installation using a USB stick...................................................................... 85
8.6 Options (NESTOR, TSMA6B, SmartONE Expert)..................................................... 86
8.6.1 Installation of NESTOR options.....................................................................................86
8.6.2 Installation of TSMA6B options..................................................................................... 87
8.6.3 Installation of SmartONE Expert (ROMES) options...................................................... 87
8.7 User backup and restore............................................................................................ 88
8.7.1 Backup.......................................................................................................................... 88
8.7.2 Restore..........................................................................................................................89
8.7.3 Restore factory backup................................................................................................. 89
8.8 Usage of the R&S TSMA6B Image Stick................................................................... 90
8.8.1 Create a R&S TSMA6B Image Stick.............................................................................90
8.8.2 Boot from the R&S TSMA6B Image Stick..................................................................... 91
8.8.3 Capture an Image from a R&S TSMA6B...................................................................... 91

Contents
R&S®TSMA6B
6User Manual 4901.4026.02 ─ 01
8.8.4 Apply an Image to a R&S TSMA6B.............................................................................. 93
9 Troubleshooting................................................................................... 96
9.1 LED indicated errors...................................................................................................96
9.2 Evaluate selftest file....................................................................................................97
9.3 Verify scanner link / recall device info using TsmeDeviceManager....................... 97
9.3.1 Obtaining device information - "Device Info".................................................................98
9.3.2 Device analysis output.................................................................................................. 99
9.3.3 Verify installed license keys........................................................................................ 100
9.4 R&S TSMA6B automatically switches off after power on..................................... 101
9.5 Scanner is not found from software (R&S ROMES, R&S NESTOR).....................102
9.6 Verify scanner connection LAN settings................................................................ 105
9.7 No RF / GPS data.......................................................................................................106
9.8 No remote access via LAN port............................................................................... 108
9.9 WLAN access point not detected by external PC, mobile or tablet......................111
9.10 Web GUI not accessible via WLAN..........................................................................114
9.11 Web GUI locally not accessible................................................................................115
9.12 Slow/Instable WLAN connection............................................................................. 117
9.13 Bluetooth® device not detected by R&S TSMA6B..................................................119
9.14 Contacting Customer Support.................................................................................121
Annex.................................................................................................. 122
A Usage of the Web GUI........................................................................122
A.1 Home.......................................................................................................................... 122
A.1.1 Overview..................................................................................................................... 122
A.1.2 IP Settings...................................................................................................................124
A.1.3 HW Info....................................................................................................................... 124
A.2 Configuration.............................................................................................................126
A.2.1 System........................................................................................................................ 126
A.2.1.1 Mode........................................................................................................................... 127
A.2.1.2 Power.......................................................................................................................... 127
A.2.1.3 Speaker.......................................................................................................................128
A.2.1.4 RF Band...................................................................................................................... 128
A.2.1.5 Password.................................................................................................................... 128

Contents
R&S®TSMA6B
7User Manual 4901.4026.02 ─ 01
A.2.2 Connectivity.................................................................................................................129
A.2.2.1 Bluetooth..................................................................................................................... 129
A.2.2.2 WLAN..........................................................................................................................129
A.2.2.3 WLAN AP.................................................................................................................... 130
A.2.2.4 LAN............................................................................................................................. 131
A.2.2.5 LAN EXT1................................................................................................................... 132
A.3 File Transfer...............................................................................................................132
A.4 Options.......................................................................................................................133
A.4.1 Available......................................................................................................................133
A.4.2 Install...........................................................................................................................134
A.5 Update........................................................................................................................ 135
A.6 Backup....................................................................................................................... 136
A.7 Restart........................................................................................................................136
A.8 Help............................................................................................................................ 137
B Introduction to Remote ViCom Sample App................................... 138
B.1 Overview.................................................................................................................... 138
B.2 Requirements............................................................................................................ 138
B.2.1 General Requirements................................................................................................ 138
B.2.2 Preparation..................................................................................................................138
B.3 Usage......................................................................................................................... 139
B.3.1 Connection Establishment.......................................................................................... 139
B.3.1.1 Connection Type Selection......................................................................................... 139
B.3.1.2 Server Discovery.........................................................................................................139
B.3.2 GSM RSSI Scan......................................................................................................... 141
B.3.2.1 GSM Preferences........................................................................................................141
B.3.2.2 GSM Scan Results......................................................................................................141
B.3.3 WCDMA Top-N Pilot Scan.......................................................................................... 142
B.3.3.1 WCDMA Top-N Pilot Preferences............................................................................... 142
B.3.3.2 WCDMA Top-N Pilot Scan Results............................................................................. 143
B.3.4 LTE Top Signal Scan...................................................................................................144
B.3.4.1 LTE Top Signal Preferences........................................................................................144
B.3.4.2 LTE Top Signal Scan Results......................................................................................145
B.3.5 Throughput Test Case.................................................................................................145

Contents
R&S®TSMA6B
8User Manual 4901.4026.02 ─ 01
B.3.5.1 Throughput Preferences............................................................................................. 145
B.3.5.2 Throughput Results.....................................................................................................146
B.3.6 RF Power Scan........................................................................................................... 147
B.3.6.1 RF Power Scan References........................................................................................147
B.3.6.2 RF Power Scan Results.............................................................................................. 147
C Managing Scanner Device with R&S TsmeDeviceManger............. 149
C.1 Installing and Managing Software License Keys - "Options"...............................149
C.2 Configuring Measurement Bands - "Band Configuration"................................... 151
C.3 Obtaining Firmware and Correction Data Updates - "Updates"........................... 153
C.4 Aligning R&S TSMA6B Manually - "Self Alignment"............................................. 154
C.5 Configuring Downconverter R&S TSME30DC/TSME44DC - "Downconverter Con-
figuration"..................................................................................................................155
Index....................................................................................................157

Preface
R&S®TSMA6B
9User Manual 4901.4026.02 ─ 01
1 Preface
1.1 Documentation Overview
This section provides an overview of the R&S TSMA6B user documentation. Unless
specified otherwise, you find the documents on the R&S TSMA6B product page at:
www.rohde-schwarz.com/manual/tsmx
1.1.1 Getting Started Manual
Introduces the R&S TSMA6B and describes how to set up and start working with the
product. Includes basic operations, typical measurement examples, and general infor-
mation, e.g. safety instructions, etc. A printed version is delivered with the instrument.
1.1.2 User Manuals and Help
Contains the description of all instrument modes and functions. Includes the contents
of the getting started manual .
1.1.3 Basic Safety Instructions
Contains safety instructions, operating conditions and further important information.
The printed document is delivered with the instrument.
1.1.4 Data Sheets and Brochures
The data sheet contains the technical specifications of the R&S TSMA6B. It also lists
the firmware applications and their order numbers, and optional accessories.
The brochure provides an overview of the instrument and deals with the specific char-
acteristics.
See www.rohde-schwarz.com/brochure-datasheet/tsmx
1.1.5 Release Notes and Open Source Acknowledgment (OSA)
The release notes list new features, improvements and known issues of the current
firmware version, and describe the firmware installation.
The open-source acknowledgment document provides verbatim license texts of the
used open source software.
See www.rohde-schwarz.com/firmware/tsmx
Documentation Overview

Preface
R&S®TSMA6B
10User Manual 4901.4026.02 ─ 01
1.2 Safety and Regulatory Information
The product documentation helps you use the R&S TSMA6B safely and efficiently. Fol-
low the instructions provided here and in the printed "Basic Safety Instructions". Keep
the product documentation nearby and offer it to other users.
Intended use
The R&S TSMA6B is intended for the development, production and verification of elec-
tronic components and devices in industrial, administrative, and laboratory environ-
ments. Use the R&S TSMA6B only for its designated purpose. Observe the operating
conditions and performance limits stated in the data sheet.
Where do I find safety information?
Safety information is part of the product documentation. It warns you about the poten-
tial dangers and gives instructions how to prevent personal injuries or damage caused
by dangerous situations. Safety information is provided as follows:
●The printed "Basic Safety Instructions" provide safety information in many lan-
guages and are delivered with the R&S TSMA6B.
●Throughout the documentation, safety instructions are provided when you need to
take care during setup or operation.
Safety and Regulatory Information

Key Features
R&S®TSMA6B
11User Manual 4901.4026.02 ─ 01
2 Key Features
As in-building traffic in cellular networks grows, there is an increased need for indoor
measurements. While traditional drive test systems consist of a laptop with test mobile
phones and scanners, there are also walk-test solutions that use tablets and smart-
phones.
The R&S TSMA6B enhances such solutions, providing the user with accurate insight
into the RF environment.
The R&S TSMA6B combines the technology of the R&S TSME6 ultra-compact drive
test scanner with a high-performance Intel processor. The scanner can run PC-based
drive test software, and smartphones can be connected via USB.
With its ultra-broadband front end, the integrated scanner measures all supported tech-
nologies 350 to 6000 MHz simultaneously. The future-proof architecture and the in-field
upgradability for both, hardware and software, allow up to 4x4 MIMO measurements
and pave the way for the upcoming 5G technology.
Key Features
●No limitation in 3GPP (LTE, WCDMA, GSM, NB-IoT…) frequency bands up to 6
GHz incl. a Multi-GNSS receiver for uninterrupted location tracking
●More than 10 technologies simultaneously in one system
●Future-proof for upcoming 5G related measurements
●Compact and lightweight design with customized mechanical concept for cascad-
ing multiple scanner hardware
●Maximum connectivity supporting additional scanner hardware, Windows-based
PC, Android-based UEs or tablets using wireless and wired connections
●Integrated 8th generation Intel quad-core processing unit

Instrument tour
R&S®TSMA6B
12User Manual 4901.4026.02 ─ 01
3 Instrument tour
3.1 Front panel view
The front panel of the R&S TSMA6B does not provide any connectors or control ele-
ments for operation.
Figure 3-1: R&S TSMA6B - Front Panel
3.2 Rear panel view
The following figure provides an overview of the control elements and the connectors
on the rear panel of the instrument.
Figure 3-2: R&S TSMA6B - Rear Panel
1 = WLAN/Bluetooth ON/OFF
2 = SCAN port - Gbit LAN IF- 2nd scanner (TSME4/6)
3 = CPU ON/OFF
4 = AUX connector (SMA) - synchronization
5 = USB 3.0 (4x)
6 = DC IN connector
7 = Docking connector R&S TSMA6B-BP
8 = Restore button
9 = Status LEDs - Mode, Meas
10 = POWER ON/OFF
11 = USB-C (1x)
12 = HDMI connector (2x)
13 = USB 3.0 (1x) / USB 2.0 (1x)
14 = LAN port - remote control R&S TSMA6B
Rear panel view

Instrument tour
R&S®TSMA6B
13User Manual 4901.4026.02 ─ 01
15 = Status LEDs - Scanner Pwr / State
16 = GPS Ant. connector (SMA) - GPS antenna input
17 = RF In connector
WLAN/Bluetooth ON/OFF
Switches WLAN and Bluetooth on and off.
SCAN port (RJ45 connector)
The SCAN port provides a high-speed 1 Gbit Ethernet interface with an RJ 45 connec-
tor. It is used to connect the R&S TSMA6B to a separate R&S TSME6 as a second
scanner. It can be used for MIMO scenarios and for increasing bandwidth and mea-
surement rate.
LAN port - remote control (RJ45 connector)
The LAN port provides a high-speed 1 Gbit Ethernet interface with an RJ 45 connector.
It is used to connect the R&S TSMA6B to a host PC.
The LAN interface can be used for Remote Control / Remote Desktop Connections.
Alternatively, it can also be used for distributed applications of R&S NESTOR.
The LEDs on the LAN port indicate the status of the connection to the host PC. LED 1
(yellow, link status) is on the left side of the port, LED 2 (green, activity status) is on the
right.
CPU ON/OFF
Switches between scanner mode (scanner only) and standard mode (CPU and scan-
ner) For details, see Chapter 6.3.1.6, "Scanner mode", on page 46.
AUX connector
The AUX connector has two functions.
●Input/output: Synchronization with up to 4 connected R&S TSME6 (requires sync
cable R&S TSME6-ZC2, R&S no. 4900.1800.02 or R&S TSME6-ZC4, R&S no.
4900.1817.02)
●Input: Synchronization of R&S TSMA6B with an external 10 MHz reference
(requires dedicated sync cable)
USB 3.0 (5x)
The USB 3.0 ports can be used for connecting external storage devices, data sticks
and test mobile phones.
Power limit: max. 900 mA / port
Overall USB current (USB-C, USB 3.0 and USB 2.0): max. 3 A
Rear panel view

Instrument tour
R&S®TSMA6B
14User Manual 4901.4026.02 ─ 01
USB 2.0 (1x)
The USB 2.0 can be used for connecting external devices, e.g. keyboard, mouse or
software dongle.
Power limit: max. 500 mA / port
Overall USB current (USB-C, USB 3.0 and USB 2.0): max. 3 A
USB-C
The USB-C port (multiport for Thunderbolt, display and standard USB-C 3.1) can be
used for connecting external storage devices, tablets and test mobile phones.
Total power (USB-C): max. 3 A
Overall USB current (USB-C, USB 3.0 and USB 2.0): max. 3 A
DC IN connector
The DC IN connector is used to supply the R&S TSMA6B with DC power. A wide DC
input range 11 V to 18 V / max. 7 A is supported.
Docking connector R&S TSMA6B-BP
Restore
Press the RESTORE button ( > 20 sec) to bring the system partition of the embedded
Windows CPU back to factory default or to a user backup (if created).
Status LEDs - Mode, Meas
The status LEDs [Mode] and [Meas] indicate different states of the R&S TSMA6B. For
a detailed description, see Chapter 3.4, "Status LEDs", on page 16.
Power ON/OFF
The POWER ON/OFF button turns on and off the device.
Press and hold the button results in a coldstart of the R&S TSMA6B.
HDMI connector (2x)
The HDMI connectors can be used for connecting an external monitor (max. resolution:
2560 x 1600 pixel).
Status LEDs - Scanner Pwr / State
The status LEDs, [Scanner State] and [Scanner Pwr] indicate different states of the
R&S TSMA6B. For a detailed description, see Chapter 3.4, "Status LEDs",
on page 16.
GPS Ant.
An SMA connector is provided for the supplied external active GPS antenna (Antenna
power: 3 V, max. 25 mA).
Rear panel view

Instrument tour
R&S®TSMA6B
15User Manual 4901.4026.02 ─ 01
The integrated multi-GNSS (GPS / BeiDou / Galileo / GLONASS) receiver allows to
use three satellite systems in parallel. This offers an accuracy improvement of 30 % to
50 % by using a second constellation of satellites.
Following combinations are allowed:
●GPS only
●GPS / GLONASS / Galileo
●GPS / BeiDou
The R&S TSMA6B can perform dead reckoning in tunnels to provide position informa-
tion even if no satellites are available. The dead reckoning is performed in the device
itself by built-in electronic gyroscopes.
For enabling untethered dead reckoning, see Chapter 5.8, "Calibrating GPS for dead
reckoning", on page 32.
RF IN connector
The RF IN connector is the RF input of the R&S TSMA6B. The multi-band RF paddle
antenna (700 MHz to 2.6 GHz), which is included in the shipment of R&S TSMA6B or
any custom RF source is connected to this SMA connector. The maximum input power
is +20 dBm/10 V DC.
Risk of instrument damage
Do not overload the maximum allowed input of +20 dBm.
Non-compliance destroys the input mixer.
3.3 Removable SSD option (R&S TSMA6B-BEB)
The R&S TSMA6B can be ordered with a removable SSD option. With this option the
system disk (SSD) is mounted in an external SSD enclosure and connected via the
USB3.1 port of the R&S TSMA6B. These disk incorporates operating system and user
data. There is no internal disk assembled / fitted in the R&S TSMA6B.
Removable SSD option (R&S TSMA6B-BEB)

Instrument tour
R&S®TSMA6B
16User Manual 4901.4026.02 ─ 01
Figure 3-3: R&S TSMA6B - removable disk option
1 = External enclosure with SSD hard disc
2 = USB connection between R&S TSMA6B and SSD hard disc
For removing the external disk from the enclosure, see Chapter 5.9, "Using external
SSD option (R&S TSMA6B-BEB)", on page 33.
3.4 Status LEDs
The four LEDs on the rear panel display the following states.
●[Scanner State / Scanner Pwr]
Indicates the state of the scanner component
●[Mode]
Indicates the device status
●[Meas]
Indicates the state of the SW application
Device Scanner
[Mode] LED [Meas] LED [Pwr] LED [State]LED Comment
Off Off Off Off Power Off
green (BLINKING, 1
Hz)
--- --- --- Power On Selftest /
Power Down
Status LEDs

Instrument tour
R&S®TSMA6B
17User Manual 4901.4026.02 ─ 01
Device Scanner
[Mode] LED [Meas] LED [Pwr] LED [State]LED Comment
green (CONT.) --- --- --- Power On / WLAN
Off
blue (CONT.) --- --- --- Power On / WLAN
On
--- --- green (BLINKING
rapidly => ON)
red (Off-On < 5s => Off ) Scanner configura-
tion ongoing
--- --- green (CONT.) --- Scanner ready
--- yellow (CONT.) green (CONT.) green (BLINKING) SW loading
--- green (CONT.) green (CONT.) green (CONT.) SW ready
--- green (BLINKING, 0.5 Hz) green (CONT.) green (BLINKING) SW measuring
--- green/blue (BLINKING rapidly) green (CONT.) green (BLINKING) SW recording
--- yellow (BLINKING, 2 Hz) --- --- SW warning
blue (BLINKING, 1
Hz)
--- --- --- Restore/
Backup/FW, SW
installation (in pro-
gress)
blue (BLINKING, 0.5
Hz)
--- --- --- Scanner mode
green (BLINKING,
0.2 Hz, ton = 1 s)
--- --- --- Delayed start activa-
ted
Error States
blue (BLINKING
rapidly)
--- --- --- Selftest Failed/
Scanner Interface
not accessible
--- --- --- red (BLINKING, 2 Hz) Scanner Error
Temperature Warn-
ing
--- --- --- red (CONT.) Scanner Error
Temperature Error
--- red (BLINKING rapidly) --- --- SW error
Status LEDs

Option concept
R&S®TSMA6B
18User Manual 4901.4026.02 ─ 01
4 Option concept
The option concept is designed as follows.
●Hardware options
– R&S TSMA6B-BEP (extern. SSD)
– R&S TSMA6B-B1T (Enhancement of 1Tbyte SDD and 16 Gbyte RAM)
●Software options (scanner)
●Software options (applications)
4.1 Software options (scanner)
4.1.1 Technology options
Technology options allow the R&S TSMA6B to scan the input based on a specific tech-
nology, for example, LTE. All technology options can be installed on the same instru-
ment; the R&S TSMA6B can measure various technologies simultaneously.
Following technology options are available:
Table 4-1: Available R&S TSMA6B technology options
Option Order Number Description
R&S TSMA6B-K10 4901.0989.02 R&S TSMA6B Block IQ
R&S TSMA6B-K21 4901.0789.02 R&S TSMA6B scanner option: WCDMA
R&S TSMA6B-K22 4901.0766.02 R&S TSMA6B scanner option: CDMA2000
R&S TSMA6B-K23 4901.0795.02 R&S TSMA6B scanner option: GSM
R&S TSMA6B-K24 4901.0750.02 R&S TSMA6B scanner option: 1xEV-DO
R&S TSMA6B-K25 4901.0814.02 R&S TSMA6B scanner option: CW
R&S TSMA6B-K26 4901.0743.02 R&S TSMA6B scanner option: TETRA
R&S TSMA6B-K27 4901.0720.02 R&S TSMA6B scanner option: RF Power Scan
R&S TSMA6B-K28 4901.0737.02 R&S TSMA6B scanner option: WiMAX™
R&S TSMA6B-K29 4901.0772.02 R&S TSMA6B scanner option: LTE
R&S TSMA6B-K30 4901.0714.02 R&S TSMA6B scanner option: LTE-MIMO
R&S TSMA6B-K32 4901.0643.02 R&S TSMA6B scanner option: LTE eMBMS
R&S TSMA6B-K34 4901.0808.02 R&S TSMA6B scanner option: NB-IoT/Cat NB1-Scanning
R&S TSMA6B-K35 4901.0208.02 R&S TSMA6B scanner option: LTE-M scanning
R&S TSMA6B-K40 4901.0614.02 R&S TSMA6B scanner option: Automatic Channel Detec-
tion (ViCom only, not for R&S ROMES4)
Software options (scanner)

Option concept
R&S®TSMA6B
19User Manual 4901.4026.02 ─ 01
Option Order Number Description
R&S TSMA6B-K50 4901.0966.02 R&S TSMA6B scanner option: 5G NR scanning
R&S TSMA6B-K51 4901.0250.02 R&S TSMA6B scanner option: 5G NR scanning add-ons
R&S TSMA6B-K61 4901.0672.02 R&S TSMA6B scanner option: QualiPoc® Support
R&S TSMA6B-K80 4901.0972.02 R&S TSMA6B scanner option: BTS PE
4.1.2 Band options
The R&S TSMA6B hardware simultaneously measures in all wireless communications
bands from 350 MHz to 6 GHz. Using band licenses, more cost-efficient configurations
are available for applications where only a limited number of bands need to be mea-
sured simultaneously. These configurations limit the number of bands that can be mea-
sured in parallel. You can reconfigure the bands for each measurement as desired.
Upgrade options are available to increase the bandwidth of the R&S TSMA6B from a
limited number of bands to full bandwidth.
Following band options are available:
Table 4-2: Available R&S TSMA6B band options
Option Order Number Description
R&S TSMA6B-KAB 4901.0708.02 All bands measured simultaneously
R&S TSMA6B-K1B 4901.0695.02 1 band measured simultaneously
R&S TSMA6B-K2B 4901.0689.02 2 bands measured simultaneously
R&S TSMA6B-K3B 4901.0672.02 3 bands measured simultaneously
R&S TSMA6B-K4B 4901.0666.02 4 bands measured simultaneously
R&S TSMA6B-K5B 4901.0650.02 5 bands measured simultaneously
R&S TSMA6B-KUB 4901.0950.02 Upgrade: 1 additional band measured simultaneously
4.2 Software options (applications)
4.2.1 R&S SmartONE Expert (ROMES) options
A later enhancement of the R&S TSMA6B with the R&S ROMES application requires a
ROMES license. The license can be provided with one the follwing solutions.
●WIBU dongle
●WIBU SW key
●Hardlock dongle
Software options (applications)

Option concept
R&S®TSMA6B
20User Manual 4901.4026.02 ─ 01
For activating licenses via WIBU, refer to R&S ROMES4 - WIBU License Management
manual.
Accompanied with the hardlock dongle, a a license key file is offered.
This license key file has to be copied as a post process after software installation (see
"Install ROMES Option" on page 134).
Software options (applications)
