R&S TSMA User manual

R&S®TSMA
Autonomous Mobile
Network Scanner
Getting Started
Getting Started
Version 10
1177560402
(;ÛÆ42)

This manual describes the following R&S®TSMA models:
●R&S®TSMA (1514.6520.20)
© 2019 Rohde & Schwarz GmbH & Co. KG
Mühldorfstr. 15, 81671 München, Germany
Phone: [phone] - 0
Fax: [phone]
Email: [email protected]
Internet: www.rohde-schwarz.com
Subject to change – Data without tolerance limits is not binding.
R&S® is a registered trademark of Rohde & Schwarz GmbH & Co. KG.
Trade names are trademarks of the owners.
1177.5604.02 | Version 10 | R&S®TSMA
Throughout this manual, products from Rohde & Schwarz are indicated without the ® symbol , e.g.
R&S®TSMA is indicated as R&S TSMA.

Contents
R&S®TSMA
3Getting Started 1177.5604.02 ─ 10
Contents
1 Safety Information................................................................. 5
2 Documentation Overview......................................................6
2.1 Getting Started Manual.........................................................................6
2.2 User Manuals and Help........................................................................ 6
2.3 Basic Safety Instructions..................................................................... 6
2.4 Data Sheets and Brochures................................................................. 6
2.5 Release Notes and Open Source Acknowledgment (OSA)...............7
3 Key Features.......................................................................... 8
4 Preparing for Use...................................................................9
4.1 Unpacking the Instrument..................................................................10
4.2 Connecting External Devices.............................................................11
4.3 Connecting Power Supply................................................................. 14
4.3.1 Connecting to a Vehicle DC Power Supply...........................................14
4.3.2 Connecting an AC Power Supply..........................................................14
4.3.3 Connecting the R&S TSMA-BP Battery Pack Unit................................14
4.4 Connecting an Additional R&S TSME for MIMO Support................20
4.4.1 MIMO 2x2 Upgrade Kit......................................................................... 21
4.4.2 Mounting R&S TSME ...........................................................................22
4.5 Connecting Test Mobile Phones........................................................24
4.6 R&S TSMA Driver Update...................................................................25
4.6.1 Installation MIMO Extension ................................................................ 25
4.6.2 Installation ROMES/NESTOR Mobile Device Drivers...........................28
5 Instrument Tour................................................................... 30
5.1 Front Panel.......................................................................................... 30

Contents
R&S®TSMA
4Getting Started 1177.5604.02 ─ 10
5.2 Rear Panel........................................................................................... 30
5.3 Status LEDs.........................................................................................34
5.3.1 PWR, SCAN, STATE.............................................................................34
5.3.2 SCAN LINK........................................................................................... 36
6 Configuring the R&S TSMA................................................ 37
6.1 Accessing the R&S TSMA..................................................................37
6.1.1 Start the R&S TSMA Web-GUI............................................................. 37
6.1.2 Establish a Remote Desktop Connection............................................. 38
6.2 Changing Password of R&S TSMA................................................... 40
6.3 Measurement Setup............................................................................42
6.4 Measurement Modes.......................................................................... 43
6.4.1 Remote ViCom Server Mode................................................................ 43
6.4.2 QualiPoc Mode..................................................................................... 44
6.4.3 NESTOR and NESTOR Probe Mode....................................................47
6.4.4 ROMES Mode.......................................................................................49
6.4.5 PC Mode............................................................................................... 50
6.4.6 Scanner Only Mode.............................................................................. 50
6.5 Power Settings.................................................................................... 51
Index..................................................................................... 52

Safety Information
R&S®TSMA
5Getting Started 1177.5604.02 ─ 10
1 Safety Information
The product documentation helps you use the R&S TSMA safely and efficiently.
Follow the instructions provided here and in the printed "Basic Safety Instruc-
tions". Keep the product documentation nearby and offer it to other users.
Intended use
The R&S TSMA is intended for the development, production and verification of
electronic components and devices in industrial, administrative, and laboratory
environments. Use the R&S TSMA only for its designated purpose. Observe the
operating conditions and performance limits stated in the data sheet.
Where do I find safety information?
Safety information is part of the product documentation. It warns you about the
potential dangers and gives instructions how to prevent personal injuries or dam-
age caused by dangerous situations. Safety information is provided as follows:
●The printed "Basic Safety Instructions" provide safety information in many lan-
guages and are delivered with the R&S TSMA.
●Throughout the documentation, safety instructions are provided when you
need to take care during setup or operation.

Documentation Overview
R&S®TSMA
6Getting Started 1177.5604.02 ─ 10
2 Documentation Overview
This section provides an overview of the R&S TSMA user documentation. Unless
specified otherwise, you find the documents on the R&S TSMA product page at:
www.rohde-schwarz.com/manual/tsmx
2.1 Getting Started Manual
Introduces the R&S TSMA and describes how to set up and start working with the
product. Includes basic operations, typical measurement examples, and general
information, e.g. safety instructions, etc. A printed version is delivered with the
instrument.
2.2 User Manuals and Help
Contains the description of all instrument modes and functions. Includes the con-
tents of the getting started manual .
2.3 Basic Safety Instructions
Contains safety instructions, operating conditions and further important informa-
tion. The printed document is delivered with the instrument.
2.4 Data Sheets and Brochures
The data sheet contains the technical specifications of the R&S TSMA. It also
lists the firmware applications and their order numbers, and optional accessories.
The brochure provides an overview of the instrument and deals with the specific
characteristics.
See www.rohde-schwarz.com/brochure-datasheet/tsmx
Data Sheets and Brochures

Documentation Overview
R&S®TSMA
7Getting Started 1177.5604.02 ─ 10
2.5 Release Notes and Open Source Acknowledg-
ment (OSA)
The release notes list new features, improvements and known issues of the cur-
rent firmware version, and describe the firmware installation.
The open source acknowledgment document provides verbatim license texts of
the used open source software.
See www.rohde-schwarz.com/firmware/tsmx
Release Notes and Open Source Acknowledgment (OSA)

Key Features
R&S®TSMA
8Getting Started 1177.5604.02 ─ 10
3 Key Features
As in-building traffic in cellular networks grows, there is an increased need for
indoor measurements. While traditional drive test systems consist of a laptop with
test mobile phones and scanners, there are also walk-test solutions that use tab-
lets and smartphones.
The R&S TSMA enhances such solutions, providing the user with accurate insight
into the RF environment.
The R&S TSMA combines the technology of the R&S TSME ultra-compact drive
test scanner with a high-performance Intel processor. The scanner can run PC-
based drive test software, and smartphones can be connected via USB. The
scanner measures up to eight technologies simultaneously in the 350 MHz to
4400 MHz wireless communications bands. It can be combined with an R&S
TSME to perform LTE MIMO measurements.
●User-definable input frequency range from 350 MHz to 4400 MHz
●RF and signal processing path with a bandwidth of 20 MHz
●Parallel measurement of all technologies in all bands (up to eight technologies
simultaneously)
●Integrated Intel PC with Microsoft® Windows operating system which allows
to install any drive test software supporting the R&S TSMA (e.g R&S ROMES)
●Open remote ViCom interface in order to integrate into Windows and Android-
based software tools.
●Automatic detection of active channels in a specified band (Automatic Chan-
nel Detection (ViCom only), R&S TSMA-K40, Order No. 1524.6339.02 or R&S
ROMES4ACD )
●Analysis of the DL allocations of the strongest eNodeBs during measurement
(LTE Downlink Allocation Analyzer, R&S TSMA-K31, Order No. 1524.6322.02)

Preparing for Use
R&S®TSMA
9Getting Started 1177.5604.02 ─ 10
4 Preparing for Use
Risk of injury and instrument damage
The instrument must be used in an appropriate manner to prevent electric
shock, fire, personal injury, or damage.
●Do not open the instrument casing.
●Read and observe the "Basic Safety Instructions" delivered as a printed
brochure with the instrument.
In addition, read and observe the safety instructions in the following sec-
tions. Notice that the data sheet may specify additional operating condi-
tions.
Risk of instrument damage during operation
An unsuitable operating site or test setup can cause damage to the instru-
ment and to connected devices. Ensure the following operating conditions
before you switch on the instrument:
●The instrument is dry and shows no sign of condensation.
●The instrument is positioned as described in the following sections.
●Signal levels at the input connectors are all within the specified ranges.
EMI Suppression
Electromagnetic interference (EMI) may affect the measurement results.
To suppress generated electromagnetic interference (EMI):
●Use suitable shielded cables of high quality. For example, use double-
shielded RF and LAN cables.
●Always terminate open cable ends.
●Note the EMC classification in the data sheet.

Preparing for Use
R&S®TSMA
10Getting Started 1177.5604.02 ─ 10
4.1 Unpacking the Instrument
The following section describes how to setup the instrument.
Risk of instrument damage due to inappropriate operating conditions
Specific operating conditions are required to ensure accurate measure-
ments and to avoid damage to the instrument. Observe the information on
appropriate operating conditions provided in the basic safety instructions
and the instrument's data sheet.
Check the equipment for completeness using the delivery note and the accessory
lists for the various items. Check the instrument for any damage. If there is dam-
age, immediately contact the carrier who delivered the instrument. Make sure not
to discard the box and packing material.
Packing material
Retain the original packing material. If the instrument needs to be transpor-
ted or shipped later, you can use the material to protect the control ele-
ments and connectors.
Accessory list
The following items are included with shipment of the R&S TSMA:
●SCAN Link interconnection cable (SCAN <-> SCAN)
●12 V DC power supply cable with a cigarette lighter connector
●Wide range RF paddle antenna (700 MHz to 2600 MHz)
●Active GPS patch antenna
●Two stub antennas for WLAN/Bluetooth®
Unpacking the Instrument

Preparing for Use
R&S®TSMA
11Getting Started 1177.5604.02 ─ 10
Figure 4-1: Scope of R&S TSMA Delivery
1 = SCAN Link interconnection cable
2 = Car Adapter cable
3 = RF Antenna
4 = GPS Antenna
5 = WiFi/Bluetooth Antennas
4.2 Connecting External Devices
The following external devices must be connected before connecting the power
supply.
To select the correct connectors, see the following picture.
Connecting External Devices

Preparing for Use
R&S®TSMA
12Getting Started 1177.5604.02 ─ 10
Figure 4-2: R&S TSMA - Rear Panel
1 = POWER ON/OFF
2 = STATUS LEDs
3 = AUX Connector
4 = SCAN (scanner port from scanner)
5 = SCAN (scanner port to embedded PC)
6 = USB 2.0 (2x)
7 = USB 3.0 (2x)
8 = mini HDMI
9 = MINI Display Port
10 = LAN Connector CPU
11 = DC IN Connector
12 = RF IN Connector
13 = GPS Antenna Connector
14 = Antenna 1 Connector (Bluetooth® / WLAN MIMO)
15 = Antenna 2 Connector (WLAN)
16 = RESTORE
1. Connect the SCAN ports of scanner and PC unit of the R&S TSMA.
Figure 4-3: Connection between scanner unit and internal PC unit
1 = SCAN Link connector (CPU port)
2 = SCAN Link connector (Scanner Port)
3 = SCAN Link interconnection cable
Connecting External Devices

Preparing for Use
R&S®TSMA
13Getting Started 1177.5604.02 ─ 10
Note: Use only the LAN interconnection cable (R&S No. 5016.1890.00) for
connecting the SCAN ports.
2. Connect the RF antenna to the RF IN connector.
3. Connect the GPS antenna to the GPS ANT port.
4. Connect the accessory WLAN / Bluetooth stub antennas to ANT1 and ANT 2.
5. Connect mouse and keyboard to the USB 2.0 ports and a monitor to the
appropriate monitor port (mini HDMI or MINI Display port) if you want to use
local operation. (optional)
If necessary, following display port adapters can be used:
● Display Port Adapter to DVI/HDMI, R&S TSPC-DPDH (R&S No.
3592.4060.02)
Figure 4-4: Display Port Adapter to DVI/HDMI
● Display Port Adapter to VGA, R&S TSPC-DPVG (R&S No. 3592.4076.02)
Display Port Adapter to VGA
6. Connect a LAN cable to the LAN port if you want to use the R&S TSMA via
Remote Desktop or as distributed system. (optional)
7. Connect external devices/storage devices and test mobile phones to USB
2.0/USB 3.0 ports.
Note: The length of the connected USB cables should not exceed 3 m.
Connecting External Devices

Preparing for Use
R&S®TSMA
14Getting Started 1177.5604.02 ─ 10
4.3 Connecting Power Supply
This section describes how to connect the R&S TSMA to a power supply unit.
4.3.1 Connecting to a Vehicle DC Power Supply
Use the accessory DC cable with cigarette lighter adapter to power the R&S
TSMA from the vehicle power supply. Connect the 7-pin connector to DC IN.
For DC Supply Only
The R&S TSMA is to be used with a 12 V vehicle power supply only.
DC-based lab networks are not allowed to be used for power supply!
4.3.2 Connecting an AC Power Supply
To operate the R&S TSMA with an AC power supply, connect the DC IN connec-
tor with the AC power supply (R&S TSMA-Z1, R&S No. 1523.8450.02).
Use only the R&S TSMA-Z1, R&S No. 1523.8450.02 as AC power supply.
Figure 4-5: TSMA-Z1 AC Power Supply
4.3.3 Connecting the R&S TSMA-BP Battery Pack Unit
Alternatively, it is possible to power the R&S TSMA via the R&S TSMA-BP Bat-
tery Pack Unit.
To use the R&S TSMA with the battery pack, the following steps must be per-
formed.
1. Insert the batteries into the R&S TSMA.
Connecting Power Supply

Preparing for Use
R&S®TSMA
15Getting Started 1177.5604.02 ─ 10
Note: The R&S TSMA may be used only with closed battery cover.
Note: Make sure, that the batteries are inserted in the correct orientation.
Figure 4-6: R&S TSMA - Battery Orientation
1 = Battery insert orientation
2. Attach the R&S TSMA base unit with the bottom side (see Figure 4-8) on top
of the R&S TSMA-BP (see Figure 4-7).
Figure 4-7: R&S TSMA-BP
1 = Connectors for R&S TSMA base unit
Connecting Power Supply

Preparing for Use
R&S®TSMA
16Getting Started 1177.5604.02 ─ 10
Figure 4-8: R&S TSMA Base Unit (bottom side)
1 = Connectors for R&S TSMA-BP
3. Move the R&S TSMA base unit to the front side (2) until the connectors are
locked.
Figure 4-9: Connected R&S TSMA Base Unit and R&S TSMA-BP
1 = Vertical attachment of R&S TSMA base unit (bottom) with R&S TSMA BP (top)
2 = Move T&S TSMA base unit to the front side
4. Lock the interconnection using the lock (3).
Connecting Power Supply

Preparing for Use
R&S®TSMA
17Getting Started 1177.5604.02 ─ 10
Figure 4-10: Connection of R&S TSMA with R&S TSMA
1 = R&S TSMA Base Unit
2 = R&S TSMA
3 = Lock (front side)
5. Via the cable (3), you have to connect the DC IN connector on the R&S TSMA
(1) with the TSMA connector (7 pins) on the R&S TSMA-BP (2).
Figure 4-11: Cabling of R&S TSMA with R&S TSMA
Connecting Power Supply

Preparing for Use
R&S®TSMA
18Getting Started 1177.5604.02 ─ 10
1 = DC IN Connector of R&S TSMA Base Unit
2 = TSMA Connector R&S TSMA-BP
3 = Interconnection Cable (R&S TSMA Base Unit <-> R&S TSMA-BP)
Note: The interconnection cable (3) is included in the delivery package of the
R&S TSMA-BP.
The cable plugs are marked at both sides with a red spot.
Figure 4-12: Cable
Connected at the DC IN (1) of the R&S TSMA, this red spot must face
upwards, at the TSMA connector (2) of the R&S TSMA-BP it must face down-
wards.
The boot behavior after connecting the R&S TSMA-BP Battery Pack Unit
(including charged batteries or connected to an external DC power supply)
with the R&S TSMA depends on the system settings on the R&S TSMA.
The R&S TSMA-BP Battery Pack Unit can be connected with an external power
supply. The following steps must be performed.
1. DC powered from a vehicle supply (see Figure 4-14)
Connect the DC IN connector (4) of the R&S TSMA-BP Battery Pack Unit with
the 7-pin plug cable (5) and connect the 4-pin socket with the accessory car
adapter cable of the R&S TSMA.
Note: The 7-pin to 4-pin adapter cable is a standard accessory of the R&S
TSMA-BP Battery Pack Unit
Figure 4-13: 7-pin to 4-pin adapter cable
2. AC powered
Connecting Power Supply

Preparing for Use
R&S®TSMA
19Getting Started 1177.5604.02 ─ 10
Connect the DC IN connector (4) of the R&S TSMA-BP Battery Pack Unit with
the 7-pin to 4-pin adapter cable (5) and connect the 4-pin socket with AC
power supply (R&S TSMA-Z1, R&S No. 1523.8450.02).
If a valid DC input voltage is applied to DC IN of the R&S TSMA-BP, the R&S
TSMA is powered from this external DC supply and the batteries inside the
R&S TSMA-BP are charged.
If the external DC supply is not available the R&S TSMA is powered from the
batteries.
Figure 4-14: Connecting the R&S TSMA with an AC power supply
1 = DC IN connector R&S TSMA Base Unit
2 = TSMA connector R&S TSMA-BP Battery Pack Unit
3 = DC power interconnection cable (R&S TSMA Base Unit <-> R&S TSMA-BP Battery Pack
Unit)
4 = DC IN connector R&S TSMA-BP Battery Pack Unit
5 = Adapter cable (7-pin to 4-pin)
6 = DC IN (TSMA-Z1 resp. car adapter cable, standard accessory of R&S TSMA)
Connecting Power Supply

Preparing for Use
R&S®TSMA
20Getting Started 1177.5604.02 ─ 10
4.4 Connecting an Additional R&S TSME for MIMO
Support
MIMO measurements with the R&S TSMA require to extend the device with one
R&S TSME.
To make this extension the following is needed:
●MIMO 2x2 Upgrade Kit, R&S No. 15246439.02
●R&S TSMA driver update software, TSMA_DriverUpdate_1.00.exe, which
can be downloaded from the Rohde & Schwarz web site.
The R&S TSMA driver update must be performed before connecting the
additional R&S TSME.
Figure 4-15: R&S TSMA with R&S TSMA-BP battery pack unit and mounted R&S TSME
(front side view)
Connecting an Additional R&S TSME for MIMO Support
