Rane SIXTY-TWO User manual

VirtualDJ 8 –Rane Sixty-Two
1

VirtualDJ 8 –Rane Sixty-Two
2
Table of Contents
Installation................................................................................................................................3
Connections ...........................................................................................................................3
Drivers....................................................................................................................................4
VirtualDJ 8 Setup ...................................................................................................................4
Advanced Setup.....................................................................................................................5
VirtualDJ & Hardware Functionality ......................................................................................6
A. Volume Mixer..................................................................................................................7
B. HotCues & Sampler........................................................................................................7
C. Effects.............................................................................................................................8
D. Equalizer, Filter & Effects...............................................................................................9
E. Microphone & Video Software Controls .......................................................................10
F. Master & Booth.............................................................................................................11
G. Loop, Browser & Other Controls..................................................................................11
H. Auxiliary/Sampler..........................................................................................................12
I. Headphones..................................................................................................................13
J. Front panel....................................................................................................................13
K. Rear Panel....................................................................................................................14
Advanced Audio Setups .......................................................................................................15
Timecode (DVS)...................................................................................................................15
Sampler Output....................................................................................................................16
Back to back.........................................................................................................................17
Recording.............................................................................................................................17

VirtualDJ 8 –Rane Sixty-Two
3
Installation
Connections
Connect your computer to USB A (or B) port at the rear panel of Rane Sixty-Two.
Connect your Left deck’s RCA cables to ANALOG INPUT 1.
If it’s a CD player, select CD with the switch above the input jacks.
If it’s a turntable, select PH (Phono) with the switch above the input jacks. Secure the
ground wire to a Phono Ground terminal.
Connect your Right deck’s RCA cables to ANALOG INPUT 3.
If it’s a CD player, select CD with the switch above the input jacks.
If it’s a turntable, select PH (Phono) with the switch above the input jacks. Secure the
ground wire to a Phono Ground terminal
Set the SOURCE selector for DECK 1 to A (or B if the USB B port is used).
Set the SOURCE selector for DECK 2 to A (or B if the USB B port is used).
Connect the Rane Sixty-Two with AC power using the provided cable and power on
the unit

VirtualDJ 8 –Rane Sixty-Two
4
Drivers
Windows: Download and install the necessary ASIO drivers from
http://dj.rane.com/products/sixty-two (Downloads tab)
Mac OSX: Download and install the necessary CoreAudio drivers from
http://dj.rane.com/products/sixty-two (Downloads tab)
.
.
VirtualDJ 8 Setup
Download and install VirtualDJ 8 from
http://www.virtualdj.com/download/index.html
(in case you have not done already)
Once VirtualDJ 8 is launched, a Login Window
will appear. Login with your virtualdj.com
account credentials.
A Pro Infinity, a PLUS* or a Pro
Subscription License is required to use the
Rane Sixty-Two. Without any of the above
Licenses, the controller will operate for 10
minutes each time you restart VirtualDJ.
http://www.virtualdj.com/buy/index.html
*For DVS Support an additional Timecode Plus
license is required if the Rane 62 Plus license is
purchased.
A window will appear next, to verify the
proper detection.
Click on the “Use Soundcard” button and
VirtualDJ will automatically create and apply
the pre-defined audio configuration using the
built-in audio interface of the Rane Sixty-
Two.
Click to OK.
The unit is now ready to operate with VirtualDJ.

VirtualDJ 8 –Rane Sixty-Two
5
Advanced Setup
MIDI Operation
The unit should be visible* in the
CONTROLLERS tab of Config and the
“factory default” available/selected from the
Mappings drop-down list.
The factory default Mapping offers the
functions described in this Manual, however
those can be adjusted to your needs via VDJ
Script actions.
Find more details at
http://www.virtualdj.com/wiki/VDJscript.html
AUDIO Setup
The unit has a pre-defined Audio setup and
a special button in the AUDIO tab of Config
to provide that. Alternative setups can be
applied in the same window.
Timecode (DVS)* configuration is pre-
configured (see DVS Support for more
details).
*requires Pro Infinity or Timecode License
http://www.virtualdj.com/buy/index.html
For further software settings please refer to the User Guides of VirtualDJ 8.
http://www.virtualdj.com/wiki/PDFManuals.html
