Rane SM 82S User manual

SM82S
STEREO LINE MIXER

ATTENTION: RISQUE DE CHOCS ELECTRIQUE - NE PAS OUVRIR
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
To reduce the risk of electrical shock, do not open the unit. No user
serviceable parts inside. Refer servicing to qualied service personnel.
e symbols shown below are internationally accepted symbols
that warn of potential hazards with electrical products.
is symbol indicates that a dangerous voltage
constituting a risk of electric shock is present
within this unit.
is symbol indicates that there are important
operating and maintenance instructions in the
literature accompanying this unit.
WARNING
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance with manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, registers, stoves, or other apparatus (including ampliers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A
grounding-type plug has two blades and a third grounding prong. e wide blade or third prong is provided for your safety. If the provided plug
does not t into your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord and plug from being walked on or pinched particularly at plugs, convenience receptacles, and the point where it exits from
the apparatus.
11. Only use attachments and accessories specied by Rane.
12. Use only with the cart, stand, tripod, bracket, or table specied by the manufacturer, or sold with the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualied service personnel. Servicing is required when the apparatus has been damaged in any way, such as power supply
cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does
not operate normally, or has been dropped.
15. e plug on the power cord is the AC mains disconnect device and must remain readily operable. To completely disconnect this apparatus from
the AC mains, disconnect the power supply cord plug from the AC receptacle.
16. is apparatus shall be connected to a mains socket outlet with a protective earthing connection.
17. When permanently connected, an all-pole mains switch with a contact separation of at least 3 mm in each pole shall be incorporated in the
electrical installation of the building.
18. If rackmounting, provide adequate ventilation. Equipment may be located above or below this apparatus, but some equipment (like large power
ampliers) may cause an unacceptable amount of hum or may generate too much heat and degrade the performance of this apparatus.
19. is apparatus may be installed in an industry standard equipment rack. Use screws through all mounting holes to provide the best support.
WARNING: To reduce the risk of re or electric shock, do not expose this apparatus to rain or moisture. Apparatus shall not be exposed to dripping
or splashing and no objects lled with liquids, such as vases, shall be placed on the apparatus.
NOTE: is equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
ese limits are designed to provide reasonable protection against harmful interference in a residential installation. is equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAUTION: Changes or modications not expressly approved by Rane Corporation could void the user's authority to operate the equipment.
is Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
WARNING: is product may contain chemicals known to the State of California to cause cancer, or birth defects or other reproductive harm.

ATTENTION: RISQUE DE CHOCS ELECTRIQUE - NE PAS OUVRIR
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
An d’éviter tout risque de choc électrique, ne pas ouvrir l’appareil.
Aucune pièce ne peut être changée par l’utilisateur. Contactez un
SAV qualié pour toute intervention.
Les symboles ci-dessous sont reconnus internationalement
comme prévenant tout risque électrique.
Ce symbole indique que cette unité utilise un
voltage élevé constituant un risque de choc
électrique.
Ce symbole indique la présence d’instructions
d’utilisation et de maintenance importantes dans le
document fourni.
ATTENTION
INSTRUCTIONS DE SÉCURITÉ
1. Lisez ces instructions.
2. Gardez précieusement ces instructions.
3. Respectez les avertissements.
4. Suivez toutes les instructions.
5. Ne pas utiliser près d’une source d’eau.
6. Ne nettoyer qu’avec un chion doux.
7. N’obstruer aucune évacuation d’air. Eectuez l’installation en suivant les instructions du fabricant.
8. Ne pas disposer près d’une source de chaleur, c-à-d tout appareil produisant de la chaleur sans exception.
9. Ne pas modier le cordon d’alimentation. Un cordon polarisé possède 2 lames, l’une plus large que l’autre. Un cordon avec tresse de masse possède
2 lames plus une 3è pour la terre. La lame large ou la tresse de masse assurent votre sécurité. Si le cordon fourni ne correspond pas à votre prise,
contactez votre électricien.
10. Faites en sorte que le cordon ne soit pas piétiné, ni au niveau du l, ni au niveau de ses broches, ni au niveau des connecteurs de vos appareils.
11. N’utilisez que des accessoires recommandés par Rane.
12. N’utilisez que les éléments de transport, stands, pieds ou tables spéciés par le fabricant ou vendu avec l’appareil. Quand vous utlisez une valise de
transport, prenez soin de vous déplacer avec cet équipement avec prudence an d’éviter tout risque de blessure.
13. Débranchez cet appareil pendant un orage ou si vous ne l’utilisez pas pendant un certain temps.
14. Adressez-vous à du personnel qualié pour tout service après vente. Celui-ci est nécessaire dans n’importe quel cas où l’appareil est abimé : si le
cordon ou les ches sont endommagés, si du liquide a été renversé ou si des objets sont tombés sur l’appareil, si celui-ci a été exposé à la pluie ou
l’humidité, s’il ne fonctionne pas correctement ou est tombé.
15. La che du cordon d’alimentation sert à brancher le courant alternatif AC et doit absolument rester accessible. Pour déconnecter totalement
l’appareil du secteur, débranchez le câble d’alimentation de la prise secteur.
16. Cet appareil doit être branché à une prise terre avec protection.
17. Quand il est branché de manière permanente, un disjoncteur tripolaire normalisé doit être incorporé dans l’installation électrique de l’immeuble.
18. En cas de montage en rack, laissez un espace susant pour la ventilation. Vous pouvez disposer d’autres appareils au-dessus ou en-dessous de celui-
ci, mais certains (tels que de gros amplicateurs) peuvent provoquer un buzz ou générer trop de chaleur au risque d’endommager votre appareil et
dégrader ses performances.
19. Cet appareil peut-être installé dans une baie standard ou un chassis normalisé pour un montage en rack. Visser chaque trou de chaque oreille de
rack pour une meilleure xation et sécurité.
ATTENTION: an d’éviter tout risque de feu ou de choc électrique, gardez cet appareil éloigné de toute source d’humidité et d’éclaboussures quelles
qu’elles soient. L’appareil doit également être éloigné de tout objet possédant du liquide (boisson en bouteilles, vases,…).
REMARQUE: Cet équipement a été testé et approuvé conforme aux limites pour un appareil numérique de classe B, conformément au chapitre 15
des règles de la FCC. Ces limites sont établis pour fournir une protection raisonnable contre tout risque d’interférences et peuvent provoquer une
énergie de radiofréquence s'il n'est pas installé et utilisé conformément aux instructions, peut également provoquer des interférences aux niveaux
des équipements de communication. Cependant, il n'existe aucune garantie que de telles interférences ne se produiront pas dans une installation
particulière. Si cet équipement provoque des interférences en réception radio ou télévision, ceci peut être detecté en mettant l'équipement sous/hors
tension, l'utilisateur est encouragé à essayer de corriger cette interférence par une ou plusieurs des mesures suivantes:
• Réorienter ou déplacer l'antenne de réception.
• Augmenter la distance entre l'équipement et le récepteur.
• Connecter l'équipement à une sortie sur un circuit diérent de celui sur lequel le récepteur est branché.
• Consulter un revendeur ou un technicien radio / TV expérimenté.
ATTENTION: Les changements ou modications non expressément approuvés par Rane Corporation peuvent annuler l'autorité de l'utilisateur à
manipuler cet équipement et rendre ainsi nulles toutes les conditions de garantie.
Cet appareil numérique de classe B est conforme à la norme Canadienne ICES-003.
Cet appareil numérique de classe B est conforme à la norme Canadienne NMB-003.

Manual-1
OPERATORS MANUAL SM82S
STEREO MIXER
QUICK START
No one likes to read manuals. Everyone likes to just start pushing buttons and turning knobs until the desired results magically
emerge. at’s usually OK, and with a very few exceptions, damage is unlikely to result from such procedures with the SM82S.
is product is quite obvious: Input LEVEL controls make Inputs louder or not, the stereo SENDs make things happen at the
LOOP SEND outputs, and so on. No real magic there. You should be aware, however, that if you want to connect a mono source to
the SM82S, use only the LEFT Input of a channel so that the mono source will drive both the Left and the Right channels.
Set the levels of the mixer so that the red lights stay o. If they come on, you are overdoing it and distortion will result.
SM82S CONNECTION
When connecting the SM82S to other components in your
system for the rst time, leave the power supply for last. is will
give you a chance to make mistakes and correct them before any
damage is done to your fragile speakers and ears.
If you are making your own cables, or experience any hum
problems after hookup, please refer to the RaneNote, “Sound
System Interconnection” (supplied with this manual and avail-
able at rane.com).
INPUTS
e SM82S’s Inputs are unbalanced. is means that standard
¼" connectors on the ends of any good quality cable will work
well between your signal sources, signal processing and ampli-
cation. For best rejection of nasty things like hum and RF,
keep input cables under 10 feet (3 meters) in length.
Most sources give you the choice of stereo or mono output.
e mixer gives you the same choice. You will note that nomen-
clature has been placed beneath the input jacks indicating which
is RIGHT and which is LEFT (MONO). If a source is plugged
only into the Left jack and not into the Right, both Right and
Left channels will be fed with the Left Input. is allows the use
of either stereo or mono sources.
OUTPUTS
e SM82S oers balanced main outputs only. is means that
you may use them as either balanced or unbalanced, the choice
being made by the way the connectors are wired. It’s a good idea
to always use a TRS or stereo connector in the outputs no matter
which mode you are using. If a “mono” connector is used, insert-
ing it into the output will short the ring (–) to ground and could
conceivably cause a small amount of distortion to be placed on
the tip (+). While this is not destructive, it may be signicant
enough to be audible. Balancing therefore requires that both tip
(+) and ring (–) be wired to the following device. Unbalanced
requires only tip and sleeve connected, leaving the unused ring
open.
EFFECTS DEVICES
External devices which might be used could be either mono in
and out, while some may be mono in and stereo out, while still
others may be stereo on both ends. e SM82S easily accom-
modates all of these varieties. If your eect is mono on both
ends, connect its input to the SM82S LEFT LOOP SEND and
the eect’s output to the SM82S LEFT LOOP RETURN. is
conguration will sum Right and Left Loop Outputs to the
mono eect input and will sum the mono eect output to the
Left and Right Input buses. A mono-in stereo-out device would
connect to the loop outputs in the same way; however the stereo
outputs connect to the respective LEFT and RIGHT LOOP
RETURNS.
EXPANDING
Connecting two or more SM82Ss together to achieve more than
eight stereo Inputs requires that a stereo cable (tip, ring, sleeve)
be connected between the MAIN EXPAND OUTPUT of the
rst mixer and the MAIN EXPAND INPUT of the second.
All 32 inputs will then appear at the main OUTPUT of mixer
number two. Only the rst sixteen Inputs will be available at the
main Outputs of mixer number one. Should you wish to have all
Loop buses tied, connect the LOOP SENDS of mixer one to the
LOOP EXPAND INPUT of mixer two. All sixteen stereo sends
will then become active at the LOOP SENDS of the second mix-
er. e expand Inputs and Outputs are unbalanced signals, so to
prevent hum, keep expand cables under 10 feet (3 meters) in
length.
WEAR PARTS: is product contains no wear parts.
1
2
SM82S
STEREO MIXER
SEND
PAN
SEND
PAN
3
SEND
PAN
4
SEND
PAN
5
SEND
PAN
6
SEND
PAN
7
SEND
PAN
8
RETURN
OUTPUT
SEND
PAN
PAN
PAN
LEVEL
LEVEL
LEVEL
LEVEL
LEVEL
LEVEL
LEVEL
LEVEL
LEVEL
LEVEL
POWER
0
5
10
0
5
10
0
5
10
0
5
10
0
5
10
0
5
10
0
5
10
0
5
10
R
C
L
R
C
L
R
C
L
R
C
L
R
C
L
R
C
L
R
C
L
R
C
L
R
C
L
R
C
L
10
0
2
4
8
6
10
0
2
4
8
6
10
0
2
4
8
6
10
0
2
4
8
6
10
0
2
4
8
6
10
0
2
4
8
6
10
0
2
4
8
6
10
0
2
4
8
6
10
0
2
4
8
6
10
0
2
4
8
6
OL
OL
OL
OL
OL
OL
OL
OL
OL
OL

Manual-2
FRONT PANEL DESCRIPTION
1Input LEVEL controls: are rotary stereo attenuators that adjust the amount of both Left and Right signals applied to an Input.
Outputs are summed for mixing with all other Inputs. e unity gain position of this control is located at “7.5.”
2Input OverLoad indicators: glow red whenever its corresponding Input’s output exceeds a level 4 dB below clipping, letting you
know it’s a good idea to turn this Input down a bit.
3Input PAN controls: operate as ‘PAN’ with a mono signal, and ‘BALANCE’ with a stereo signal.
PAN: When a mono input is used (no plug in the RIGHT Input jack), the signal ‘moves’ from the Left to Right channels. At the
“L” extreme top of travel the sound source is heard from the Left output; at the other “R” extreme bottom it is heard only from the
Right output. In the middle, the sound is heard equally from each output, but is reduced in level by 3 dB relative to its original
value. is guarantees that as the sound is panned from one side to the other, it maintains equal loudness (power) for all positions.
BALANCE: In its center detent, Left and Right signals to each channel are allowed to pass at their original relative levels, there-
fore preserving the stereo image from devices connected to both of the Inputs. When the control is moved vertically toward the
“L” position, the Right channel level is decreased while the Left channel level is maintained. e opposite occurs if the control is
moved from the detent down toward the “R”.
4Input SEND Level controls: determine the amount of Post-Fade stereo Input is fed to the Loop Send buses. Each Input’s stereo
SEND is summed on this bus and is available at the respective LEFT and RIGHT LOOP SENDS on the rear of the mixer.
5RETURN LEVEL control: is a rotary stereo attenuator that controls the amount of Return which is to be added to the Main
Output. e unity gain position of this control is located at “7.5."
6RETURN OverLoad indicator: glows red whenever the return levels exceed a level of 4 dB below clipping.
7RETURN PAN control: is a vertical slider that controls the eect or source connected to the LOOP RETURN in the same way
the Input PAN controls work (see 3above).
8OUTPUT LEVEL control: is a rotary stereo attenuator that controls the nal signal Level at the main OUTPUT jacks. e
unity gain position of this control is located at “7.5".
9OUTPUT OverLoad indicator: glows red any time the output level exceeds 4 dB below clipping.
qOUTPUT PAN control: is a vertical slider that operates in the same fashion as the PAN control described in item 3above. It
however, determines the relative levels of the LEFT and RIGHT MAIN OUTPUTS only.
1
2
SM82S
STEREO MIXER
SEND
PAN
SEND
PAN
3
SEND
PAN
4
SEND
PAN
5
SEND
PAN
6
SEND
PAN
7
SEND
PAN
8
RETURN
OUTPUT
SEND
PAN
PAN
PAN
LEVEL
LEVEL
LEVEL
LEVEL
LEVEL
LEVEL
LEVEL
LEVEL
LEVEL
LEVEL
POWER
0
5
10
0
5
10
0
5
10
0
5
10
0
5
10
0
5
10
0
5
10
0
5
10
R
C
L
R
C
L
R
C
L
R
C
L
R
C
L
R
C
L
R
C
L
R
C
L
R
C
L
R
C
L
10
0
2
4
8
6
10
0
2
4
8
6
10
0
2
4
8
6
10
0
2
4
8
6
10
0
2
4
8
6
10
0
2
4
8
6
10
0
2
4
8
6
10
0
2
4
8
6
10
0
2
4
8
6
10
0
2
4
8
6
OL
OL
OL
OL
OL
OL
OL
OL
OL
OL
3 2
14
67 9 10
5 11 8

Manual-3
REAR PANEL DESCRIPTION
1Channel Input jacks: consist of eight pairs of unbalanced ¼" tip-sleeve jacks, used to connect any line-level signal source to the
SM82S. As indicated, only the LEFT is to be used if the Input is mono and should therefore appear in both Left and Right chan-
nels, depending on the position of the front panel PAN control.
2MAIN EXPAND INPUT: A ¼" TRS stereo Input jack may link two or more SM82Ss together, or accept the output from
another mixer. is may also be used to sum any xed-level stereo signal into the Main Outputs, producing a ninth stereo Input
when added with 1. A stereo Tip-Ring-Sleeve cable must be used here. e Left input is on the Tip, Right is on the Ring and the
Sleeve is ground.
3LOOP EXPAND INPUT: Another ¼" TRS stereo Input, expands the stereo Loop buses of two SM82Ss so they share the same
eects loop. A stereo Tip-Ring-Sleeve cable must be used here. Connect the LEFT and RIGHT LOOP SENDS (4)of the rst
unit to the LOOP EXPAND INPUT of the second SM82S. (Tip = left; Ring = right.)
4LOOP SEND: is pair of ¼" jacks may drive an eect or similar device which is to be returned to item 5below. If a mono
device is used, both the Left and Right Send channels of the SM82S are summed together and presented at the LEFT Output if
nothing is inserted in the RIGHT Output.
5LOOP RETURN: ese ¼" aux returns may connect the output of a reverb or other eect unit to the Loop bus of the SM82S.
If no eect is used, they can be used as a tenth stereo Input to the mixer in addition to those described in 1 and 2. As with the
other stereo Inputs, mono signal may be connected to the LEFT input to obtain two-channel mono operation.
6MAIN EXPAND OUTPUT: is ¼" TRS stereo (Tip = left, Ring = right) Output jack connects one SM82S to another for the
purpose of expanding the number of Inputs available. Use only a stereo plug in this jack — a mono jack or cable will cause loss of
Right channel signal and possibly distortion to the Left channel. is Output also serves as a xed pre-fader level useful as record
outputs or other applications. A send/return cable can be ideal for this output to drive a second amplier or recorder. See the dia-
gram below.
7Main BALANCED OUTPUT: ese balanced Tip-Ring-Sleeve jacks connect the main Outputs of the SM82S to a power am-
plier or to additional signal processing. As is the AES standard with all Rane balanced outputs using ¼" TRS jacks, the Tip is (+),
the Ring is (–) and the Sleeve is ground.
8 Power connector: e internal universal switching power supply operates on any AC mains 100 to 240 VAC, 50 or 60 Hz (most
places in the world). All that is required when traveling is the appropriate IEC line cord.
1 2 378 6 5 4
ALL INPUTS ARE UNBALANCED
TIP=L, RING=R
TIP=L, RING=R
RANE CORP. MADE IN U.S.A.
8
7
6
5
4
3
2
1
LEFT
(MONO)
RIGHT
LEFT
(MONO)
RIGHT
OUTPUT
BALANCED
LOOP SEND
UNBALANCED
MAIN
EXPAND
INPUT
LOOP
EXPAND
INPUT
LEFT
(MONO)
RIGHT
LEFT
(MONO)
RIGHT
LEFT
(MONO)
RIGHT
LEFT
(MONO)
RIGHT
LEFT
(MONO)
RIGHT
LEFT
(MONO)
RIGHT
LEFT
RIGHT
RIGHT
LEFT (MONO)
ACN 001 345 482
LOOP RETURN
UNBALANCED
MAIN
EXPAND
OUTPUT
UNBALANCED
RIGHT
LEFT (MONO)
COMMERCIAL AUDIO
EQUIPMENT 24TJ
R
100-240 V
50/60 Hz 7 WATTS
SM82S
1-CONDUCTOR SHIELDED CABLE
1-CONDUCTOR SHIELDED CABLE
T = LEFT R = RIGHT S = SHIELD
+ + LEFT
RIGHT
+ +
SHIELD SHIELD
SHIELD
A Send-Return cable works well to connect other equipment to any of the Expand Inputs or Outputs.

Manual-4
LEFT
(MONO)
INPUT
CHANNEL 1
+6 dB
BALANCE
INPUT
RIGHT
LEFT
(MONO)
INPUT
RIGHT
RFI
FILTER
FILTER
RFI
INPUT
LEVEL
+6 dB
INPUT
OVERLOAD
OL
SENSE
CH 2
LEVEL
SEND
RIGHT MAIN
RIGHT SEND
LEFT MAIN
LEFT SEND
R
R
L
L
L
LR
R
CH 3
L
LR
R
CH 4
L
LR
R
CH 5
L
LR
R
CH 6
L
LR
R
CH 7
L
LR
R
CH 8
0 dB
0 dB
SUMMING
AMPLIFIERS
DRIVERS
BALANCED
BALANCED
DRIVERS
OUTPUT
BALANCE
AMPLIFIERS
SUMMING
0 dB
0 dB
+L+R
LOOP
SENDS
RIGHT
LEFT
OUT
EXPAND
MAIN
RING
TIP
RIGHT
LEFT
+6 dB
+6 dB
LEVEL
OUTPUT
SENSE
OL
OVERLOAD
OUTPUT
LEFT
RIGHT
MAIN
OUTPUTS
SENSE
OL
OVERLOAD
RECEIVE
+6 dB
LEVEL
RECEIVE
RFI
FILTER
FILTER
RFI
RIGHT
INPUT
RECEIVE
BALANCE
+6 dB
RETURNS
INPUT
(MONO)
LEFT
LOOP
LEFT
RIGHT
TIP
RING
MAIN
EXPAND
INPUT
INPUT
EXPAND
LOOP
RING
TIP
RIGHT
LEFT
OPERATING INSTRUCTIONS
CIRCUIT DESCRIPTION
Learning to operate the SM82S might be a bit easier if you
glance at the Block Diagram below. All eight stereo Inputs
operate in exactly the same way. Signal applied to the Inputs is
acted on by a radio interference lter (we have assumed that local
broadcasts should not be a part of your music) and is then routed
to a stereo LEVEL control. If you are using a mono source, con-
nect it only to the LEFT Input to send this mono signal to both
the Left and Right sides of the input circuitry. e output of the
Level control sections is applied to a unity gain buer to prevent
the LEVEL control from adversely interacting with downstream
circuitry. e Input overload sensor monitors here to alert the
user via LED to any possible Input overload conditions. Left and
Right audio is then subjected to the channel PAN control to al-
low the user to place the stereo image of the source as desired to
the Left and Right Outputs. A stereo SEND control adjusts the
amount of each Input routed to the Loop Output.
All eight stereo Inputs are simultaneously adjusted for stereo
placement by the OUTPUT PAN control. e resultant signal is
added together and fed to the OUTPUT LEVEL control, which
has it’s own Overload indicator. e main Outputs are fully
actively balanced, allowing the use of correctly wired long cables.
EFFECTS LOOP
e LOOP SENDS receive their audio from the Send bus which
is the sum of all the Inputs as determined by the Input SEND
controls. is Output may be used to drive a stereo eects pro-
cessor. e output of the eect device is returned to the SM82S
through the LOOP RETURNS. e level of the returned eect
is determined by the RETURN LEVEL control on the front
panel. e return section also provides a BALance control for
image placement.
PAN / BALANCE CONTROLS
ese operate as ‘PAN’ with a mono signal plugged in the LEFT
input only, and ‘BALANCE’ with a stereo signal (both jacks
plugged in). ese do not increase the level of either Left or
Right signal. As the controls are moved toward one channel, the
level of the other channel is only reduced.
HIGH NOISE IMMUNITY
One of the most unusual features of the SM82S is its inher-
ent immunity from noise. All eight of the stereo inputs may be
turned all the way up without increasing the internal noise of
the mixer. is is critical due to the wide variation in output
levels found in musical instruments and tape devices. A fairly
low-level guitar may be combined in the same system with a
high level synthesizer without any undesirable side-eects. e
SM82S eliminates the concerns normally associated with mixing
so-called -l0 dBV units with +4 dBu types.
©Rane Corporation 10802 47th Ave. W., Mukilteo WA 98275-5000 USA TEL [phone] FAX [phone] WEB rane.com
107271
Block Diagram
