Range Master Classic 100 Induction Instruction Manual

USER GUIDE &
INSTALLATION INSTRUCTIONS
Built from experience
U110683-03a
Classic, Classic Deluxe and Professional+
100 Induction

To enter all you have to do is send in photos of your
Rangemaster kitchen and tell us in one sentence what
makes Rangemaster the heart of your kitchen? Entries
can be posted on our Facebook page, Instagram or Twit-
ter by tagging @RangemasterUK and using #MyRange-
master. Or, if you prefer, simply send in your entry via
e-mail to [e-mail].
Rangemaster will feature a number of entries on the
website online gallery and on the Rangemaster Facebook
page, and some kitchens may be selected to be profes-
sionally photographed.
Show off your kitchen with ...
#MyRangemaster
This is
*Terms & Conditions
1. This is my Rangemaster is open to residents of UK mainland only, aged 18 years & over. 2. All entries should be submitted to the advertised e-mail address, or Rangemaster UK Facebook, Instagram or Twitter page
using the advertised hashtag & tag. 3. If we would like to professionally photograph your kitchen, you will be contacted via e-mail, Facebook / Twitter message or Instagram comment. 4. We cannot guarantee your
kitchen will be professionally photographed. 4. Any photographs received and professional photographs taken will belong to AGA Rangemaster plc with full usage rights. E&OE.
Simply snap and share a picture of your kitchen and tag #My-
Rangemaster for the chance to win £200 of
Rangemaster cookware. If selected we will also send a photog-
rapher round to professionally photograph you at
home with your range. You might even feature in some
of the UK’s top home interest titles!
Our range cookers are well known for providing the best
possible cooking performance and years of faithful service.
However, a great cooker alone cannot guarantee perfect
results every time. The other vital ingredients are of course
enthusiasm and quality cookware.
We offer cookware to work perfectly with all fuel types
manufactured by Rangemaster, including induction hobs.
You can be assured of functionality with style, as well as the
quality and meticulous attention to detail you expect from
the pioneers of range cooking.
Visit www.rangemastercookshop.co.uk
Search Rangemaster UK
*Terms & Conditions Apply

i
Contents
1. Before you start... 1
Personal safety 1
Electrical connection safety 1
Peculiar smells 2
Ventilation 2
Maintenance 2
Induction care 3
Oven care 4
Hob care 5
Grill/glide-out grill™ care 5
Cooling fan 5
Cooker care 5
Cleaning 5
2. Cooker Overview 6
The Hob 6
The Glide-out Grill 10
The Ovens 11
Main Oven Light 13
Accessories 14
3. 2 Button - rotary clock 15
4. 3 Button clock 18
5. 6 Button clock 20
6. Cooking tips 22
7. Cooking Table 23
8. Cleaning your cooker 24
9. Troubleshooting 28
10. Installation 31
Dear Installer 31
Safety Requirements and Regulations 31
Provision of Ventilation 31
Location of Cooker 31
Positioning the Cooker 32
Moving the Cooker 32
Lowering the Two Rear Rollers 33
Completing the Move 33
Fitting the Stability Bracket 33
Repositioning the Cooker Following
Connection 33
Levelling the Cooker 33
Electrical Connection 34
Final Fitting 35
Final Checks 35
Customer Care 35
11. Circuit Diagrams 36
12. Technical Data 39

ii

1
Your cooker should give you many years of trouble-free
cooking if installed and operated correctly. It is important
that you read this section before you start.
Personal safety
This appliance is for cooking purposes only. It must not be
used for other purposes, for example heating a room. Using
it for any other purpose could invalidate any warranty or
liability claim. Besides invalidating claims this wastes fuel and
may overheat the control knobs.
• This appliance can be used by children aged from
8years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved.
• Children less than 8 years of age should be kept away
unless continuously supervised. Children shall not play
with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
• This appliance is designed for domestic cooking only.
Use for any other purpose could invalidate any warranty
or liability claim.
• The appliance and its accessible parts become hot
during use and will retain heat even after you have
stopped cooking. Care should be taken to avoid
touching heating elements.
• A long term cooking process has to be supervised from
time to time. A short term cooking process has to be
supervised continuously.
• DANGER OF FIRE: DO NOT store items on the cooking
surfaces.
• To avoid overheating, DO NOT install the cooker behind
a decorative door.
• Accessible parts will become hot during use and will
retain heat even after you have stopped cooking. Keep
babies and children away from the cooker and never
wear loose-fitting or hanging clothes when using the
appliance.
• DO NOT use a steam cleaner on your cooker.
• ALWAYS keep combustible materials, e.g. curtains,
and flammable liquids a safe distance away from your
cooker.
• DO NOT spray aerosols in the vicinity of the cooker
while it is on.
Electrical connection safety
The electrical installation must be installed in accordance
with all relevant British Standards/Codes of Practice, BS7671.
Or with the relevant national and local regulations and with
the local gas and electricity supply companies’requirements.
Otherwise, all installations must be in accordance with the
relevant instructions in this booklet.
Read the instructions before installing or using this appliance.
• This appliance is heavy so take care when moving it.
• The cooker may be installed in a kitchen/kitchen diner
but NOT in a room containing a bath or shower.
• This appliance MUST be earthed.
• The cooker MUST NOT be connected to an ordinary
domestic power point.
• It is normal for the hob control display to flash for about
2 seconds during first power setting.
• Set the clock to make sure that the oven is functional –
see the relevant section in this manual.
• The appliance must be installed in accordance with the
regulations in force and only in a well ventilated space.
• Failure to install the appliance correctly could invalidate
any warranty or liability claims and lead to prosecution.
• DO NOT install the appliance on a platform.
• DO NOT manouvre the cooker while it is plugged into
the electricity supply.
• Before electrical reconnection, check that the appliance
is electrically safe.
1. Before you start...

2
Peculiar smells
When you rst use your cooker it may give o an odour. This
should stop after use.
Before using your cooker for the rst time, make sure that all
packing materials have been removed and then, to dispel
manufacturing odours, turn all the ovens to 200°C and run for
at least an hour.
Before using the grill for the rst time you should also turn on
the grill and run for 30 minutes with the grill pan in position,
pushed fully back and the grill door open.
Make sure the room is well ventilated to the outside air
(see‘Ventilation’below). People with respiratory or allergy
problems should vacate the area for this brief period.
Ventilation
The use of a cooking appliance results in the production
of heat and moisture in the room in which it is installed.
Make sure that the kitchen is well ventilated. Keep natural
ventilation holes open or install a powered cooker hood that
vents outside.
Prolonged intensive use of the appliance may call for
additional ventilation, for example opening a window, or
more eective ventilation, for example increasing the level of
mechanical ventilation where present.
Maintenance
• Only a qualied service engineer should service the
appliance and only approved spare parts should be
used. It is recommended that this appliance is serviced
annually.
• DO NOT use cooking vessels on the hotplate that
overlap the edges.
• ALWAYS allow the cooker to cool and then switch it
off at the mains before cleaning or carrying out any
maintenance work, unless specified otherwise in this
guide.
• DO NOT use the control knobs to manoeuvre the
cooker.
• NEVER operate the cooker with wet hands.
• DO NOT use a towel or other bulky cloth in place of a
glove – it might catch fire if brought into contact with a
hot surface.
• DO NOT use hotplate protectors, foil or hotplate covers
of any description. These may affect the safe use of
your hotplate burners and are potentially hazardous to
health.
• NEVER heat unopened food containers. Pressure build
up may make the containers burst and cause injury.
• DO NOT use unstable saucepans. ALWAYS make sure
that you position the handles away from the edge of the
hotplate.
• NEVER leave the hotplate unattended at high heat
settings. Pans boiling over can cause smoking,
and greasy spills may catch on fire. Use a deep fat
thermometer whenever possible to prevent fat
overheating beyond the smoking point.
• Unattended cooking on a hob with fat or oil can be
dangerous and may result in fire.
• NEVER leave a chip pan unattended. ALWAYS heat fat
slowly, and watch as it heats. Deep fry pans should be
only one third full of fat.
• NEVER try to move a pan of hot fat, especially a deep
fat fryer. Wait until the fat is cool. Filling the pan too full
of fat can cause spill over when food is added. If you use
a combination of oils or fats in frying, stir them together
before heating, or as the fats melt.
• Foods for frying should be as dry as possible. Frost on
frozen foods or moisture on fresh foods can cause hot
fat to bubble up and over the sides of the pan. Carefully
watch for spills or overheating of foods when frying at
high or medium high temperatures.
• DO NOT use the top of the flue (the slots along the back
of the cooker) for warming plates, dishes, drying tea
towels or softening butter.
• DO NOT use water on grease fires and never pick up
a flaming pan. Turn the controls off and then smother
a flaming pan on a surface unit by covering the pan
completely with a well fitting lid or baking tray. If
available, use a multi-purpose dry chemical or foam-
type fire extinguisher.
• DO NOT modify this appliance. This appliance is not
intended to be operated by means of external timer or
separated remote-control system.
• If flammable materials are stored in the drawer, oven(s)
or grill(s) it may explode and result in fire or property
damage.

3
Induction care
• IMPORTANT INFORMATION FOR PACEMAKER AND
IMPLANTED INSULIN PUMP USERS: The functions
of this hob comply with the applicable European
standards on electromagnetic interference. If you are
fitted with a pacemaker or implanted insulin pump and
are concerned please consult your doctor for medical
advice.
• When the hob is in use keep magnetic items away, such
as credit and debit cards, floppy disk, calculators, etc.
• To fully utilise the power of your induction hob and
to ensure longevity of performance, we recommend
the use of AGA Rangemaster Induction Pots and
Pans. If you decide to purchase an alternative set
of pans for use on your induction cooker, we would
strongly recommend that composite aluminium
pans with steel inserts, example shown Fig. 1.1,
are avoided. This type of pan construction can
significantly reduce the lifetime and performance of
your induction cook top.
• Take care when touching the marked cooking areas of
the hob.
• Use adequately sized pans with flat bottoms that are
large enough to cover the surface of the hotplate
heating area. The use of undersized pans will expose a
portion of the surface unit to direct contact and may
result in the ignition of clothing.
• Only certain types of glass, glass-ceramic, earthenware
or other glazed containers are suitable for use on the
warming zone; others may break because of the sudden
change in temperature.
• Only certain types stainless steel, enamelled steel pans
or cast iron pans with enamelled bases are suitable for
induction hob cooking.
• Take care NOT to scratch the surface when placing
cookware on the glass panel.
• Only certain types of glass, glass-ceramic, earthenware
or other glazed containers are suitable for hotplate
cooking; others may break because of the sudden
change in temperature. NEVER cook directly on the hob
surface (Fig. 1.2).
• DO NOT leave the hob zones switched on unless being
used for cooking.
• DO NOT stand or rest heavy objects on the hob.
Although the ceramic surface is very strong, a sharp
blow or sharp falling object (e.g. a salt cellar) might
cause the surface to crack or break (Fig. 1.3).
• Should a crack appear in the surface, disconnect the
appliance immediately from the supply and arrange for
its repair.
• ALWAYS LIFT pans off the hob. Sliding pans may cause
marks and scratches (Fig. 1.4).
ArtNo.312-0001 Not cooking surface
ArtNo.312-0003 Moving pans
Fig. 1.1
Fig. 1.2 Fig. 1.3
Fig. 1.4

4
ArtNo.090-0007 90 Ceramic:
oven steam out the back
• Take care NOT TO PLACE HOT LIDS onto the hob
surface (Fig. 1.5). Lids that have been used to cover
a hot pan can“stick”or create a“vacuum”effect to
the Glass Hob. Should this occur, DO NOT attempt
to lift the lid off the glass surface, this may damage
the glass. Instead slide the lid to the edge of the hob
surface and remove, taking care not to scratch the hob
surface. Alternatively wait until the lid has cooled to
room temperature, the vacuum has been released, then
remove the lid by lifting it from the hob surface.
• DO NOT place anything between the base of the pan
and the hob surface (e.g. asbestos mats, aluminium foil,
wok stand).
• Take care NOT to place metallic objects such as knives,
forks, spoons and lids on the hob surface since they can
get hot.
• We recommend that you avoid wiping any surface unit
areas until they have cooled and the indicator light
has gone off. Sugar spills are the exception to this (see
‘Cleaning your Cooker’). After cleaning, use a dry cloth
or paper towel to remove any cleaning cream residue.
• The ceramic surface should be washed after use in
order to prevent it from becoming scratched or dirty.
However, you should clean the hob with caution as
some cleaners can produce noxious fumes if applied to
a hot surface.
• DO NOT leave the hob unattended. Care should be
taken to not allow your cookware to boil dry. It will
damage your cookware and Induction Glass Hob.
• After use, switch off the hob element by its control. DO
NOT rely on the pan detector.
Oven care
• When the oven is not in use and before attempting to
clean the appliance ALWAYS be certain that the control
knobs are in the OFF position.
• Use oven gloves to protect your hand from potential
burns.
• Cooking high moisture content foods can create a
‘steam burst’ when the oven door is opened (Fig. 1.6).
When opening the oven, stand well back and allow any
steam to disperse.
• The inside door face is constructed with toughened
safety glass. Take care NOT to scratch the surface when
cleaning the glass panel.
• Accidental damage may cause the door glass panel to
fracture.
• Keep oven vent ducts unobstructed.
• DO NOT use harsh abrasive cleaners or sharp metal
scrapers to clean the oven door glass since they can
scratch the surface, which may result in shattering of
the glass.
ArtNo.324-0001 Steam burst
ArtNo.312-0001 Not cooking surface
Fig. 1.5
Fig. 1.6
Fig. 1.7

5
• Make sure the shelves are pushed firmly to the back
of the oven. DO NOT close the door against the oven
shelves.
• DO NOT use aluminium foil to cover shelves, linings or
the oven roof.
• When the oven is on, DO NOT leave the oven door
open for longer than necessary, otherwise the control
knobs may become very hot.
• DO NOT use the timed oven if the adjoining oven is
already warm.
• DO NOT place warm food in the oven to be timed.
• DO NOT use a timed oven that is already warm.
• Use dry oven gloves when applicable – using damp
gloves might result in steam burns when you touch a
hot surface.
Hob care
• NEVER allow anyone to climb or stand on the hob.
• DO NOT use the hob surface as a cutting board.
• DO NOT leave utensils, foodstus or combustible items
on the hob when it is not in use (e.g. tea towels, frying
pans containing oil).
• DO NOT place plastic or aluminium foil, or plastic
containers on the hob.
• ALWAYS turn the control to the OFF position before
removing a pan.
• Avoid heating an empty pan. Doing so may damage
both the hob and pan.
Grill/glide-out grill™ care
• When using the grill, make sure that the grill pan is
in position and pushed fully in, otherwise the control
knobs may become very hot.
• DO NOT leave the grill on for more than a few moments
without the grill pan underneath it, otherwise the knobs
may become hot.
• NEVER close the grill door when the grill is on.
• Accessible parts may be hot when the grill is in use.
Young children should be kept away.
Cooling fan
This appliance may have a cooling fan. When the grill or oven
is in operation the fan will run to cool the fascia and control
knobs.
Cooker care
As steam can condense to water droplets on the cool outer
trim of the oven, it may be necessary during cooking to wipe
away any moisture with a soft cloth. This will also help to
prevent soiling and discolouration of the oven exterior by
cooking vapours (Fig. 1.7).
Cleaning
• Isolate the electricity supply before carrying out any
thorough cleaning. Allow the cooker to cool.
• In the interests of hygiene and safety, the cooker should
be kept clean at all times as a build up in fats and other
food stuff could result in a fire.
• Clean only the parts listed in this guide.
• Clean with caution. If a wet sponge or cloth is used to
wipe spills on a hot surface, be careful to avoid steam
burns. Some cleaners can produce noxious fumes if
applied to a hot surface.
• NEVER use paint solvents, washing soda, caustic
cleaners, biological powders, bleach, chlorine based
bleach cleaners, coarse abrasives or salt.
• DO NOT mix different cleaning products – they may
react together with hazardous results.
• All parts of the cooker can be cleaned with hot soapy
water.
• Take care that no water seeps into the appliance.
• Before you remove any of the grill parts for cleaning,
make sure that they are cool or use oven gloves.
• DO NOT use any abrasive substances on the grill and
grill parts.
• DO NOT put the side runners in a dishwasher.
• DO NOT put the burner heads in a dishwasher.
• NEVER use caustic or abrasive cleaners as these will
damage the surface.
• DO NOT use steel wool, oven cleaning pads or any
other materials that will scratch the surface.
• NEVER store flammable materials in the drawer.
This includes paper, plastic and cloth items, such
as cookbooks, plastic ware and towels, as well as
flammable liquids.
• DO NOT store explosives, such as aerosol cans, on or
near the appliance.
• DO NOT use steel wool, oven cleaning pads, or any
other materials that will scratch the surface.
• DO NOT attempt to disassemble or clean around any
burner while another burner is on, otherwise an electric
shock could result.

6
A
B
C
D
E
2. Cooker Overview
The 100 induction cooker (Fig. 2.1) has the following
features:
A. 5 induction cooking zones
B. A control panel
C. A separate glide-out grill
D. A fan oven or multifunction oven (depending on model)
E. Tall fan oven
The Hob
Use only pans that are suitable for induction hobs. We
recommend stainless steel, enamelled steel pans or cast iron
pans with enamelled bases. Note that some stainless steel
pans are not suitable for use with an induction hob so please
check carefully before purchasing any cookware.
Pans made of copper, aluminium or ceramic are not suitable
for use on an induction hob. The kind of pan you use and the
quantity of food aects the setting required. Higher settings
are required for larger quantities of food.
Pots and pans should have thick, smooth, at bottoms
(Fig. 2.2). This allows the maximum heat transfer from the
hob to the pan, making cooking quick and energy ecient.
Never use a round-bottomed wok, even with a stand.
Fig. 2.1
Fig. 2.2

7
Max: 1.85 kW
Boost: 2.5 kW
Max: 1.85 kW
Boost: 3.0 kW
Max: 1.85 kW
Boost: 2.5 kW
Max: 1.15 kW
Boost: 2.0 kW
Max: 1.15 kW
Boost: 2.0 kW
Zone 1
Zone 2
Zone 3 Zone 5
Zone 4
The very best pans have bases that are very slightly curved
up when cold (Fig. 2.3). If you hold a ruler across the bottom
you will see a small gap in the middle. When they heat up the
metal expands and lies at on the cooking surface.
Make sure that the base of the pan is clean and dry to prevent
any residue burning onto the hob panel. This also helps
prevent scratches and deposits.
Always use pans that are the same size as (or slightly larger
than) the areas marked on the hob. Using a lid will help the
contents boil more quickly.
 Take care when placing hot lids onto the hob
surface. Lids that have been covering boiling or
steaming foods can ‘stick’ to the ceramic glass.
Should this occur, DO NOT attempt to lift the lid
o the hotplate: this may damage the hob surface.
Instead, slide the lid to the edge of the hob surface
and remove.
 Always take care before touching the surface, even
when the hob is turned o. It may be hotter than you
think!
The induction hob comprises of ve cooking zones
containing induction elements with dierent ratings and
diameters (Fig. 2.4) each with a pan detector and residual
heat indicator, and a hob control display.
The hob control display (Fig. 2.5) informs you of the
following induction hob functions:
• Pan detector
• HResidual heat indicator
• AAutomatic heat-up
• Child lock
• L1/L2 Low temperature setting
• PPower boost setting
Pan Detector,
 IMPORTANT: After use, switch o the hob element
by its control and DO NOT RELY on the pan detector.
If a cooking area is switched on and there is no pan in place
or if the pan is too small for the cooking area, then no heat
will be generated. The symbol [ ] will appear on the hob
control display; this is the“pan-missing symbol”. Place a pan
of the correct size on the cooking area and the [ ] symbol
will disappear and cooking can begin. After 10 minutes
without detecting a pan the cooking zone will switch o
automatically.
Table 2.1 shows the minimum pan sizes recommended for
each cooking zone.
Note: Using pans with a base diameter smaller than those
recommended will result in a power reduction.
Fig. 2.4
Fig. 2.3
ArtNo.051-0002 - Min pan diameter
Cooking Zone Minimum Pan Diameter
(Pan Base) mm
Front left
Rear left
Centre
Rear right
Front right
120
140
180
140
140
Fig. 2.5
Table 2.1

8
Residual Heat Indicator, H
After use, a cooking zone will remain hot for a while as heat
dissipates. When a cooking zone is switched o the residual
heat indicator symbol [H ], will appear in the display. This
shows that the cooking zone temperature is above 60°C and
may still cause burns. Once the temperature has dropped to
below 60°C the [H ] will go out.
Automatic Heat-up, A
This function is available on all of the cooking zones. It
allows rapid heating up of the element to bring the selected
cooking zone up to temperature. Once the zone is at the
required cooking temperature the power level will reduce
automatically to the preset level.
The function is selected by turning the control knob to the
‘A’ position. This can be selected by turning the control knob
momentarily counter-clockwise from the zero position until
the symbol [A] is shown on the hob control display.
Once the [A ] is displayed, turn the control knob to the level
of your choice (1 to 9). The pan will heat up at 100% power
for a specied time before the power is reduced to the level
selected.
When the Automatic Heat-up function is activated, the hob
control display will ash alternately between the [A ] setting
and the chosen power level.
Once the automatic heat-up time has ended the hob display
will stop ashing and will show the chosen power level.
The Automatic Heat-up function can be stopped by either
turning the control knob back to the“0”power setting or
turning the control knob to the“9”power setting.
For your guidance Table 2.2 shows the time available at
100% power depending on the power level selected in the
Automatic Heat-up mode.
Child Lock,
To prevent the unwanted use by children, the hob can be
locked.
 IMPORTANT: This can only be activated when all the
cooking zones are switched o.
To lock the hob, simultaneously turn the two left-hand
controls counter-clockwise (Fig. 2.6) and hold until the
symbol appears in the centre of the hob control display
(Fig. 2.7).
Note: [A ] will ash when locking the hob – this is normal.
Locking the hob will NOT aect the oven; it can still be used.
To unlock the hob, simultaneously turn the two left-hand
controls counter-clockwise and hold until the symbol
disappears from the centre of the hob control display.
Power Level Automatic heat-up time at
100% (min:sec)
1 0:48
2 2:24
3 3:50
4 5:12
5 6:48
6 2:00
7 2:48
8 3:36
9
Fig. 2.7
Fig. 2.6
Table 2.2

9
Low Temperature Setting, L1/L2
 This function should only be used when cooking
from cold.
Each cooking area is equipped with 2 low temperature
settings:
• L1 will maintain a temperature of about 40°C – ideal for
gently melting butter or chocolate.
• L2 will maintain a temperature of about 90°C – ideal for
simmering (bring the pan to the boil and then select L2
to keep soups, sauces, stews, etc at an optimal simmer).
The maximum time this setting can be used is 2 hours, after
which the hob will switch o automatically. If required, you
can immediately restart the Low Temperature function by
reactivating L1 or L2. To increase the heat, just turn the control
knob to the required level.
The maximum times for all other power levels are shown in
Table 2.3.
Power Boost Setting, P
All of the induction cooking zones have Power Boost
available, activated by turning the control knob clockwise
until [P] is shown on the hob control display.
Power Boost allows additional power to be made available for
each of the cooking zones. This is useful to bring a large pan
of water to the boil quickly.
The Power Boost function operates for a maximum
of 10minutes on each zone, after which the power is
automatically reduced to setting 9.
When using the Power Boost function, the cooking zones are
linked.
Fig. 2.8 shows the hob layout. Zones A and B are linked
together as are zones C, D and E.
This means that when using zone A on Power Boost and then
switching zone B to Power Boost, the power to zone A will
reduce slightly. The last zone switched to Power Boost always
takes priority. Zones C, D and E work in the same way.
 This is a built in safety device.
Deactivate the Power Boost function by turning the control
knob to a lower setting.
Induction
A B C
DE
A & B linked
C, D & E linked
Fig. 2.8
ArtNo.051-0002 - Min pan diameter
Power Level Maximum Operating Time
2 hours
6 hours
6 hours
5 hours
5 hours
4 hours
1.5 hours
1.5 hours
1.5 hours
1.5 hours
10 minutes
L1 and L2
1
2
3
4
5
6
7
8
9
Power Boost
Table 2.3

10
1
2
3
4
ArtNo.235-0007 - Classic
DL grill control
Overheat Function
This function identies when the temperature of the pan rises
rapidly and works to maintain a safe level of pan temperature.
It should not interfere with normal cooking.
Cookware with bases that become distorted (Fig. 2.2) when
heated may interfere with the operation of the Overheat
Function. This may result in damage to your cookware or
Induction Glass Hob.
 Please remember not to leave the hob unattended.
Care should be taken to not allow your cookware to
boil dry. Damage to your cookware and Induction
Glass Hob may result.
Please read and follow the manufacturers’instructions
carefully before using cookware on your induction hob.
The Glide-out Grill
 CAUTION: This appliance is for cooking purposes
only. It must not be used for other purposes, for
example room heating.
 Accessible parts may be hot when the grill is in use.
Young children should be kept away.
Open the door and pull the grill pan carriage forward using
the handle (Fig. 2.9,Fig. 2.10 depending on model).
The grill has two elements that allow either the whole area of
the pan to be heated or just the right-hand half.
Adjust the heat to suit by turning the knob. To heat the whole
grill, turn the knob clockwise (Fig. 2.11).
To heat the right-hand half, turn the knob counter-clockwise.
The neon indicator light by the grill control will come on.
For best results, slide the carriage back into the grill chamber
and preheat the appropriate part(s) of the grill for two
minutes. The grill trivet can be removed and the food placed
on it while you are waiting for the grill to preheat.
 DO NOT leave the grill on for more than a few
moments without the grill pan underneath it,
otherwise the knobs may become hot.
Once the grill has preheated, slide the carriage out again.
With the trivet back in place with the food on it, slide the
carriage back into the grill chamber. Make sure that it is
pushed right in.
The grill pan trivet on the Classic & Professional + can be
turned over to give two grilling positions (Fig. 2.12).
The Classic Deluxe grill pan trivet can be set to four dierent
grilling heights by a combination of turning it back to front
and turning it upside down (Fig. 2.13).
Do not leave the grill on for more than a few moments,
without the grill pan underneath it.
 Never close the grill door when the grill is on.
Fig. 2.11
Fig. 2.12
Fig. 2.13
Fig. 2.10
Fig. 2.9
ArtNo.331-0001Grill pan pulled forwards
Classic Deluxe
Classic
Professional +
ArtNo.331-0002 Grill pan high/low position

11
ArtNo.321-0002 Fan assisted oven
ArtNo.323-0002 Tall oven
Fig. 2.14
Fig. 2.15
Fig. 2.16
Function Use
Rapid Response To pre-heat the oven faster than normal
Defrost To thaw small items in the oven without heat
Fan oven A full cooking function, even heat throughout,
great for baking
Fanned grilling Grilling meat and sh with the door closed
Fan assisted A full cooking function good for roasting and
baking
Conventional
oven
A full cooking function for roasting and baking in
the lower half of the oven
Browning element To brown and crisp cheese topped dishes
Base heat To crisp up the bases of quiche, pizza or pastry
The Ovens
The clock must be set to the time of day before the ovens will
work. See the following section on ‘The Clock’ for instructions
on setting the time of day.
References to‘left-hand’ and‘right-hand’ovens apply as
viewed from the front of the appliance.
Classic Deluxe: The left-hand oven is a multifunction oven
(Fig. 2.14). The right-hand oven is a fan oven (Fig. 2.16).
Classic & Professional +: The left-hand oven is a
programmable fan oven (Fig. 2.15). The right-hand oven is a
fan oven (Fig. 2.16).
The Fan Oven
Fan ovens circulate hot air continuously, which means
faster, more even cooking. The recommended cooking
temperatures for a fan oven are generally lower than those
for a non-fan oven.
The Multi-function Oven
Multifunction ovens have an oven fan and oven fan element,
as well as two extra heating elements. One element is in
the top of the oven and the second is under the oven base.
Take care to avoid touching the top element and element
deector when placing or removing items from the oven.
The multifunction oven has 3 main cooking functions: fan,
fan assisted and conventional cooking. These functions
should be used to complete most of your cooking.
The browning element and base heat can be used in the
latter part of the cooking process to ne tune the results to
your particular requirements.
Use fanned grilling for all your grilling needs and defrost to
safely thaw small items of frozen food.
Table 2.4 gives a summary of the multifunction modes.
The multifunction oven has many varied uses. We suggest
you keep a careful eye on your cooking until you are familiar
with each function. Remember, not all functions will be
suitable for all food types.
Note: Please remember that all cookers vary so temperatures
in your new ovens may dier to those in your previous
cooker.
ArtNo.321-0006 - Multi-function oven
Multi-function oven
Tall fan oven
Table 2.4
Fan oven

12
Multi-function Oven Functions
Rapid Response
The Rapid Response setting enables you to preheat
the oven faster than normal. It uses the fan oven
element with additional heat from one of the
elements in the top of the oven. Fan ovens heat up quickly;
but the Rapid Response feature speeds this process up
enabling you to start cooking sooner.
To use the Rapid Response feature, turn the function control
knob to Rand set the temperature required. The light on the
control panel next to the function control will come on.
When the required temperature is reached the top element
will switch o and the light will go out.
The oven temperature is then maintained by the fan oven
element and fan.
Should you choose to place food into the cold oven prior to
cooking while using the Rapid Response function, make sure
that cakes, etc. are not positioned too near the top of the
oven.
Fan Oven
This function operates the fan and the heating
element around it. An even heat is produced
throughout the oven, allowing you to cook large
amounts quickly.
Fan oven cooking is particularly suitable for baking on several
shelves at one time and is a good‘all-round’ function. It may
be necessary to reduce the temperature by approximately
10°C for recipes previously cooked in a conventional oven.
If you wish to preheat the oven, wait until the indicator light
has gone out before inserting the food.
Fanned Grilling
This function operates the fan whilst the top element
is on. It produces a more even, less erce heat than a
conventional grill. For best results, place the food to
be grilled, on a trivet over a roasting tin, which should be
smaller than a conventional grill pan. This allows greater air
circulation. Thick pieces of meat or sh are ideal for grilling in
this way, as the circulated air reduces the erceness of the
heat from the grill.
The oven door should be kept closed while grilling is in
progress, so saving energy.
You will also nd that the food needs to be watched and
turned less than for normal grilling. Preheat this function
before cooking.
For best results we recommend that the grill pan is not
located on the uppermost shelf.
Fan Assisted Oven
This function operates the fan, circulating air heated
by the elements at the top and the base of the oven.
The combination of fan and conventional cooking
(top and base heat) makes this function ideal for cooking
large items that need thorough cooking, such as a large meat
roast.
It is also possible to bake on two shelves at one time,
although they will need to be swapped over during the
cooking time, as the heat at the top of the oven is greater
than at the base, when using this function.
This is a fast intensive form of cooking; keep an eye on the
food cooking until you have become accustomed to this
function.
Conventional Oven (Top and Base Heat)
This function combines the heat from the top and
base elements. It is particularly suitable for roasting
and baking pastry, cakes and biscuits.
Food cooked on the top shelf will brown and crisp faster than
on the lower shelf, because the heat is greater at the top of
the oven than at the base, as in‘Fan assisted oven’function.
Similar items being cooked will need to be swapped around
for even cooking. This means that foods requiring dierent
temperatures can be cooked together, using the cooler zone
in the lower half of the oven and hotter area to the top.
The exposed top element may cook some foods too quickly,
so we recommend that the food be positioned in the lower
half of the oven to cook. The oven temperature may also need
to be lowered.
Browning Element
This function uses the element in the top of the oven
only. It is a useful function for the browning or
nishing of pasta dishes, vegetables in sauce,
shepherds pie and lasagne, the item to be browned being
already hot before switching to the top element.
Base Heat
This function uses the base element only. It will crisp
up your pizza or quiche base or nish o cooking the
base of a pastry case on a lower shelf. It is also a
gentle heat, good for slow cooking of casseroles in the
middle of the oven or for plate warming.
The Browning and Base Heat functions are useful additions
to your oven, giving you exibility to nish o items to
perfection.

13
ArtNo.235-0003 - Classic DL MF knobs
Temperature Function
Defrost
This function operates the fan to circulate cold air
only. Make sure the temperature control is at 0°C and
that no heat is applied. This enables small items such
as desserts, cream cakes and pieces of meat, sh and poultry
to be defrosted.
Defrosting in this way speeds up the process and protects
the food from ies. Pieces of meat, sh and poultry should
be placed on a shelf, over a tray to catch any drips. Be sure to
wash the shelf and tray after defrosting.
Defrost with the oven door closed.
Large items, such as whole chickens and joints should not be
defrosted in this way. We recommend this be carried out in a
refrigerator.
Defrosting should not be carried out in a warm oven or when
an adjoining oven is in use or still warm.
Make sure that dairy foods, meat and poultry are completely
defrosted before cooking.
Operating the Ovens
Multi-function Oven
The multi-function oven has two controls: a function selector
and a temperature selector (Fig. 2.17).
Turn the function selector to a cooking function. Turn the
temperature selector to the temperature required (Fig. 2.18).
The oven indicator light will glow until the oven has reached
the temperature you selected (Fig. 2.19). It will then cycle on
and o during cooking as the oven maintains the selected
temperature.
Fan Oven
Turn the temperature selector to the desired temperature
(Fig. 2.18).
The oven indicator light will glow until the oven has reached
the temperature you selected (Fig. 2.19). It will then cycle on
and o during cooking as the oven maintains the selected
temperature.
Main Oven Light
Press the button to turn the light on (Fig. 2.20). If the oven
light fails, turn o the power supply before changing the
bulb. See the‘Troubleshooting’section for details on how to
change the bulb.
ArtNo.235-0004 -
Classic DL oven 1
Fig. 2.17
Fig. 2.18
ArtNo.235-0005 - Classic
DL oven control 2
Fig. 2.19
ArtNo.320-0017
Main oven light
Fig. 2.20

14
Accessories
Oven Shelves – Left-hand (Main) Oven
The oven shelves (Fig. 2.21) are retained when pulled
forward but can be easily removed and retted.
Pull the shelf forward until the back of the shelf is stopped by
the shelf stop bumps in the oven sides (Fig. 2.22).
Lift up the front of the shelf so the back of the shelf will pass
under the shelf stop and then pull the shelf forward
(Fig. 2.23).
To ret the shelf, line up the shelf with a groove in the oven
side and push the shelf back until the ends hit the shelf stop.
Lift up the front so the shelf ends clear the shelf stops, and
then lower the front so that the shelf is level and push it fully
back (Fig. 2.24).
Oven Shelves – Right-hand (Tall) Oven
The tall oven is supplied with four at cooking shelves
(Fig. 2.25) and a plate warming shelf (Fig. 2.26).
When using the tall oven, you can cook on all shelves at the
same time, but make sure that they are well spaced out to
allow the hot air to circulate.
The Handyrack (Main Oven)
The Handyrack (Fig. 2.27) ts to the left-hand oven door
only. Food cooking on it is easy to attend to, because it is
accessible when the door is open.
The maximum weight that can be held by the Handyrack
is 5.5kg (12lb). It should only be used with the supplied
roasting tin, which is designed to t the Handyrack. Any other
vessel could be unstable.
It can be tted at two dierent heights. One of the oven
shelves must be removed and the other positioned to suit.
When the Handyrack is used in its highest position, other
dishes can be cooked on the bottom shelf position or base of
the oven.
When the Handyrack is used in its lowest position, other
dishes can be cooked on the second shelf position or base of
the oven.
To t the Handyrack, locate one side of it on the door bracket
(Fig. 2.28).
Then spring the other side out to clip it onto the other
bracket (Fig. 2.29).
ArtNo.320-0013 Removing the shelf 3
ArtNo.320-0014 Handyrack on LH door
ArtNo.320-0015
Fitting the Handyack 1
ArtNo.320-0016
Fitting the handyrack 2
ArtNo.320-0011 Removing the shelf 1
ArtNo.320-0012 Removing the shelf 2
Fig. 2.22 Fig. 2.23
Fig. 2.24
ArtNo.324-0002 Oven shelf
ArtNo.324-0010 Plate warming shelf
Fig. 2.25
Fig. 2.26
Shelf guard
Front
Fig. 2.21
Fig. 2.27
Fig. 2.28 Fig. 2.29

15
ArtNo.300-0005 2BC
minute minder setting
E
A B
ArtNo.300-0005 2BC
minute minder setting
A B
C D
The clock must be set to the time of day before the oven
will work.
Setting the Clock
1. Once the cooker is connected and switched on, the
display will start to ash.
2. To set the time, turn the Timer (A) knob to the Clock
(C) setting and back to the Manual (D) position. The
centre dot will ash indicating the time can be set. Turn
the Adjusting (B)knob either clockwise or counter-
clockwise (Fig. 3.1) to set the time.
3. Once you have set the time, allow the centre dot to stop
ashing, the time is now set.
Setting the minute minder
A Minute Minder (E) is a feature that can be set for a number
of minutes and sounds an alarm once the specied amount
of time has elapsed.
1. Turn the Timer (A) knob to the Minute Minder (E)
setting – it should click into position (Fig. 3.2).
2. Turn the Adjusting (B) knob to set the amount of time
required. Minimum time 1 minute (Fig. 3.3).
3. Turn the Timer (A) knob back to the Manual (D) setting
to see the current time and the‘Bell’ symbol on the
display.
Cancel the timer alarm
Once the specied time has elapsed it will emit an alarm.
There are two ways to cancel the alarm:
1. Turn the Adjusting (B) knob counter-clockwise or
clockwise (Fig. 3.4).
2. Turn the Timer (A) knob to the Clock (C) or the Minute
Minder (E) setting, and back to the Manual (D) mode,
to return to normal cooking (Fig. 3.4).
NOTE
If the alarm is not manually switched o it will stop after
approximately 2 minutes.
When the Minute Minder is active the clock will not dim
between the hours of 10 pm and 6 am
ArtNo.301-0007 2BC
Stopping the oven 1
D
A B
E
C
E
A B
Fig. 3.1
A – Timer knob, B – Adjusting knob
Fig. 3.2
Fig. 3.3
Fig. 3.4
3. 2 Button - rotary clock

16
D
A B
A B
ArtNo.311-0004 RShaw
2BC stoppingOven 1
H
A B
To stop the oven at a specific time of day
You have set the required temperature and function mode
and you would like the oven to automatically stop.
TOP TIP
Make a note of the current time so you do not forget.
1. Turn the Timer (A) knob to the Stop Time (G) setting.
‘AUTO’ will show in the display (Fig. 3.5).
2. Turn the Adjusting (B) knob to the amount of cooking
time required. The display will show the current time
plus the additional cooking time you have set (Fig. 3.6).
3. Turn the Timer (A) knob to the Auto (H) setting. The
display will show the current time, the cooking symbol
and the word‘AUTO’ (Fig. 3.7).
4. Once the specied time has elapsed it will emit an alarm
and the oven will stop working. The cook pot symbol on
the display will disappear and the word ‘AUTO’will ash
(Fig. 3.8).
5. When you return, turn the Timer (A) knob to the
Manual (D) setting to return to manual cooking (Fig.
3.8).
TOP TIP
You can check how much time you have left, to the
programmed stop time, by turning Timer (A) from Auto
(H) to Stop Time (G) and back to Auto (H).
G
A B
Fig. 3.5
Fig. 3.6
Fig. 3.7
Fig. 3.8
