Ranger TruSensor TS58R User manual

1645 Lemonwood Dr.
Santa Paula, CA 93060 USA
Toll Free 1 [phone]
Tel: [phone]
rangerproducts.com
TruSensor Tire Pressure Monitoring System
Diagnostic & Service Tool
User Guide
Manual 5900313 - Revision A - March 2023
Model
• TS58R
Designed and engineered by BendPak Inc. in Southern California, USA. Made in China.
Read the entire contents of this manual before using
this product. Failure to follow the instructions and safety
precautions in this manual can result in serious injury or
death. Make sure all other operators also read this manual.
Keep the manual near the product for future reference. By
proceeding with setup and operation, you agree that you
fully understand the contents of this manual and assume
full responsibility for product use.
DANGER

TS-58R TPMS Diagnostic Tool 5900313 - Rev. A - March 2023
2
Manual. TS58R TruSensor Tire Pressure Monitoring System Diagnostic & Service Tool, User
Guide, P/N 5900313, Manual Revision A, March 2023.
Copyright. Copyright © 2023 by BendPak Inc. All rights reserved. You may make copies
of this document if you agree that: you will give full attribution to BendPak Inc., you will not
make changes to the content, you do not gain any rights to this content, and you will not use
the copies for commercial purposes.
Trademarks. BendPak, the BendPak logo, Ranger, and the Ranger logo are registered
trademarks of BendPak Inc. All other company, product, and service names are used for
identification only. All trademarks and registered trademarks mentioned in this manual are the
property of their respective owners.
Limitations. Every effort has been made to use complete and accurate instructions in this
manual. However, product updates, revisions, and/or changes may have occurred since
this manual was published. BendPak Ranger reserves the right to change any information in
this manual without incurring any obligation for equipment previously or subsequently sold.
BendPak Ranger is not responsible for typographical errors in this manual. You can always
find the latest version of the manual for your product at the BendPak website.
Warranty. The BendPak Ranger warranty is more than a commitment to you: it is also a
commitment to the value of your new product. For full warranty details, contact your nearest
BendPak Ranger dealer or visit bendpak.com/support/warranty. Go to
bendpak.com/support/register-your-product/ and fill out the online form to register your
product (be sure to click Submit).
Safety. Your new product was designed and manufactured with safety in mind. Your safety
also depends on proper training and thoughtful operation. Do not set up, operate, maintain,
or repair the unit without reading and understanding this manual and the labels on it; do not
use this product unless you can do so safely! pnematic
Owner Responsibility. In order to maintain your product properly and to ensure operator
safety, it is the responsibility of the product owner to read and follow these instructions:
• Follow all setup, operation, and maintenance instructions.
• Make sure product setup conforms to all applicable local, state, and federal codes, rules,
and regulations, such as state and federal OSHA regulations.
• Read and follow all safety instructions. Keep them readily available for operators.
• Make sure all operators are properly trained, know how to safely operate the unit, and are
properly supervised.
• Do not operate the product until you are certain that all parts are in place and operating
correctly.
• Carefully inspect the product on a regular basis and perform all maintenance as required.
• Service and maintain the unit only with approved replacement parts.
• Keep the manual with the product and make sure all labels are clean and visible.
• Only use this product if it can be used safely!
Unit Information. Enter the Model Number, Serial Number, and the Date of Manufacture from the label
on your unit. This information is required for part or warranty issues.
Model:______________________________ Serial No:___________________________
Date of Manufacture: _________________________

3
TS-58R TPMS Diagnostic Tool 5900313 - Rev. A - March 2023
Table of Contents
Introduction......................... 3 Sensor Programming by OBD................. 14
Shipping Information............ 4 Sensor Programming by Activation......... 17
Safety Considerations.......... 4 Location (Position) Learning.................... 22
FAQ..................................... 6 Remote Key Signal Strength................... 24
Specifications...................... 7 Log and System Settings........................ 25
Quick Start.......................... 9 Device Information and Updates............. 26
TPMS Diagnosis.................. 10 Care and Maintenance........................... 27
OBD Diagnostic Function.... 12
Introduction
The TS58R is a quick, reliable tool for the service, diagnosis, and programming of
Tire Pressure Monitoring Systems. An internal processor reads and programs Original
Equipment Manufacturer (OEM) TPMS codes for the majority of OEM makes and models
through the On-Board Diagnostic (OBD II) interface or wirelessly for light and medium
duty vehicles. The TS58R provides a 2.25 in. x 3.75 in. bright TFT LCD touch screen
display in a rugged case. Simple controls are accessible through sealed membrane
pushbuttons. TS58R features include:
• Activates almost all OEM Tire Pressure Sensors
• Reads/Clears TPMS DTCs
• Checks TPMS Sensor Battery levels
• Reads Sensor pressure and temperature output
• Verifies ECU stored TPMS sensor ID matches the current sensor ID
• Program 4-5 Sensors at a time
• ODB II Error Code Reading
• Key Fob Signal Testing
• Online Software Updates
This manual is mandatory reading for all users of the TS58R TPMS Diagnostic and
Service Tool, including anyone who sets up, operates, or maintains this device.
⚠
DANGER
Be very careful when setting up, operating, maintaining, or repairing
this equipment; failure to do so correctly could result in property
damage, product damage, injury, or (in very rare cases) death. Make
sure only authorized personnel operate this equipment. All repairs
must be performed by an authorized technician. Do not make
modifications to the unit; this voids the warranty and increases the
chances of injury or property damage. Make sure to read and follow
the instructions on the labels on the unit.
Keep this Operating Manual near the equipment so that anyone who uses or
services the TS58R can accesses it.

TS-58R TPMS Diagnostic Tool 5900313 - Rev. A - March 2023
4
Assistance with your TS-58R is available from your dealer, by calling Ranger at
[phone], or by emailing [email protected]. You may also contact
Ranger for parts replacement (please have the serial number and model number of your
unit available).
This user manual contains instructions and procedures for using the TS58R. The figures
and photos used in this guide are samples, and the actual screen may differ depending
on the vehicle under test and the software version. Always adhere to the instructions
and menus on the device.
Shipping Information
Your equipment was carefully checked before shipping. Nevertheless, you should
thoroughly inspect the shipment before you sign to acknowledge that you received it.
When you sign the bill of lading, it tells the carrier the items on the invoice were
received in good condition. Do not sign the bill of lading until after you have inspected
the shipment. If any of the items listed on the bill of lading are missing or are damaged,
do not accept the shipment until the carrier makes a notation on the bill of lading that
lists the missing and/or damaged goods.
If you discover missing or damaged goods after you receive the shipment and have
signed the bill of lading, notify the carrier at once and request the carrier to make an
inspection. If the carrier will not make an inspection, prepare a signed statement to the
effect that you have notified the carrier (on a specific date) and that the carrier has failed
to comply with your request.
It is difficult to collect for loss or damage after you have given the carrier a signed bill of
lading. If this happens to you, file a claim with the carrier promptly. Support your claim
with copies of the bill of lading, freight bill, invoice, and photographs, if available. Our
willingness to assist in helping you process your claim does not make us responsible
for collection of claims or replacement of lost or damaged materials.
⚠
WARNING
California Proposition 65. This product can expose you to chemicals
including styrene and vinyl chloride which are on a list of over 900
chemicals identified by the State of California to cause birth defects
or reproductive harm. ALWAYS use this product in accordance with
BendPak and Cool Boss’ instructions. For more information go to
www.P65Warnings.ca.gov.
Safety Considerations
Read this manual carefully before using your new product. Do not set up or
operate the product until you are familiar with all operating instructions and warnings.
Do not allow anyone else to operate the product until they are also familiar with all
operating instructions and warnings.
⚠
WARNING
This device utilizes a Lithium Polymer Battery. Dispose of in
accordance with all national and local regulations.
• This product is a Tire Pressure Monitoring System Testing and Programming Tool
use it only for its intended purpose.
• This product should only be operated by authorized personnel. Children should not
be allowed to operate the TS-58R. Make sure all operators read and understand
the Warning labels and this User Guide.
• While the engine is running, never leave a vehicle unattended.

5
TS-58R TPMS Diagnostic Tool 5900313 - Rev. A - March 2023
• Before working on any Vehicle put the transmission into Park for automatic
transmissions or neutral for manual transmissions and verify that the parking brake
is set. Always chock the drive wheels.
• Keep all parts of your body, and tools away from moving, rotating and or hot engine
components.
• Keep the TS58R and all cables away from hot engine components, oil,
water, sharp tools, harsh chemicals, and moving parts.
• Avoid dropping the TS58R.
• Avoid strong magnetic fields e.g. electric motors, speakers, microwave ovens,
alternators, distributors, ignition coils, etc.
• While the engine is running, exercise care around distributors, ignition and spark
plug wires and coils. These components can generate dangerous voltages.
• Never use sharp instruments (e.g. screwdrivers, pins, or keys, etc.) to actuate the
TS58R pushbuttons. This will puncture the switch membrane, damage the tool, and
void the warranty.
• Do not make any modifications to the product. Modifications void the warranty and
increases the chances of serious injury or property damage.
• Do not spray any part of the TS58R with water. Moisture can harm the internal
electronic components.
• Refer to the service manual for vehicle under test and adhere to the manufacturer’s
procedures and precautions. Failure to follow the manufacturer’s instructions may
cause personal injury or damage to equipment.
• Make a visual inspection of the product before using it. Check for damaged or
missing parts. Do not use the product if you find problems with the unit. Instead,
remove it from service, then contact your dealer, call BendPak Ranger at
[phone].
• Save these instructions!
Symbols
⚠
WARNING
Calls attention to an immediate hazard the that will result in death or
severe injury.
⚠
DANGER
Calls attention to a hazard or unsafe practice that could result in death
or severe personal injury.
⚠
CAUTION
Calls attention to a hazard or unsafe practice that could result in minor
personal injury, product damage, or property damage.
Calls attention to information that can help you use your tool better.
Tip
Liability Information
BendPak Inc. assumes no liability for damages resulting from:
• Use of the equipment for purposes other than those described in this manual.
• Modifications to the equipment without prior, written permission from BendPak Inc.
• Injury or death caused by modifying, disabling, overriding, or removing safety
features.
• Damage to the equipment from external influences.
• Incorrect operation of the equipment.

TS-58R TPMS Diagnostic Tool 5900313 - Rev. A - March 2023
6
Frequently Asked Questions
Question: How does the TPMS work?
Answer: Each tire in a TPMS contains a pressure/temperature sensor and transceiver.
These sensors monitor the tire air pressure and temperature then sends this data to the
vehicle’s Electronic Control Unit (ECU) along with the sensor ID number. When the tire
pressure falls below factory specifications, the ECU triggers an alert to notify the vehicle
operator of a low tire pressure condition.
Question: What is a TPMS Diagnostic Tool used for?
Answer: The service, diagnosis, and programming of Tire Pressure Monitoring Systems
and components.
Q: What is the most likely source of a TPMS error?
A: If a TPMS is creating a false alert, the most likely problem is one of the Tire Pressure
Sensors. These sensors are exposed to harsh conditions such as water, salt,
vibration and temperature extremes. In addition, the sensors all use batteries with a
service life of between five to seven years depending on the environmental conditions
they have been exposed to.
Q: How does the TPMS know what tire has low pressure?
A: Each pressure sensor has a unique hexadecimal identifier (ID) that is transmitted
to the ECU along with the tire pressure and temperature. If a replacement sensor
is installed, the ECU must be reprogrammed to allow it to communicate with the new
sensor.
Q: Does the TS58R need to be plugged in to the Vehicle?
A: The TS58R can interrogate tire pressure sensors with or without connecting to the
vehicle’s On-Board Diagnostic System (OBD) system. The TS58R must be
connected to the OBD to allow reprogramming of the ECU when replacing pressure
sensors.
Abbreviations
1. OBD On-Board Self-Diagnostic
2. ECU Electronic Control Unit
3. DLC Data Link Connector
4. DTC Diagnostic Trouble Codes
5. ID Identification number. Tire pressure sensors transmit a unique hexadecimal
identification number.
6. S/N Serial number
7. TPMS Tire Pressure Management System

7
TS-58R TPMS Diagnostic Tool 5900313 - Rev. A - March 2023
Specifications
Characteristic TS58R
A - Length 8.25 in. / 209.5 mm
B - Width 3.75 in. / 95 mm
C - Depth 1.5 in. / 38 mm
Weight 1.5 lbs. / 680 g
Battery 3.7V at 3500 mAh Lithium Polymer
Battery Endurance 5 hours continuous use
Battery Charging Input 5VDC at 2A (10W)
Operating Temp. +32° to +122°F / 0° to +50°C
Storage Temp. -4° to +158°F / -20° to +70°C
Humidity ≤95% Non-Condensing
Outline Drawing

TS-58R TPMS Diagnostic Tool 5900313 - Rev. A - March 2023
8
TS58R Control Panel
Item Description Function
1 Touch Screen
Display
LCD Touch Screen displays menu selections and
test results.
2 UP Scroll Button Scrolls the selection cursor up.
3 Activation Key Sends the confirmation to wirelessly recognize and
program sensors.
4 Right Scroll Button Moves the Selection cursor to the right.
5 Confirm Button OK - accepts data or input.
6 ON/Off Button Press ≈3 seconds power on/off.
7 Down Scroll Button Moves the selection cursor down.
8 Help Button Accesses the Help information.
9 Left Scroll Button Moves the selection cursor left.
10 Back/Return Button Return to the previous menu.
11 SD Memory Card
Port
SD Card Port.
12 USB-C Port USB-C connector for charging the TS-58R.
13 OBD II Test Interface
Connector
Connects to the Vehicle’s Engine Control Unit
(ECU) through the On-Board Diagnostic (OBD)
interface.

9
TS-58R TPMS Diagnostic Tool 5900313 - Rev. A - March 2023
TPMS Quick Start
Diagnosing and replacing a defective Tire Pressure Sensor with a new TruSensor
1. TPMS Diagnosis, refer to pp. 10-11.
a. Press the on-off button for ≈3 seconds to power up the device.
b. Select TPMS from the main menu screen.
c. Select make, model, and year of the vehicle.
d. Select TPMS Diagnosis, read the guidelines.
e. Select Confirm.
f. Driver’s side front wheel will be selected on the display. Hold the TS58R within
10 CM of that wheel’s valve stem and press the button to read the sensor
ID and data.
g. Repeat this process with the remaining wheels and include the spare if there is a
sensor is installed there.
h. A green will appear next to Sensors that have communicated successfully
with the TS58R. Wheel position, ID, pressure, temperature, and battery status will
be displayed in a table. A red Xindicates a failed communication.
2. If a sensor tests as low battery or inoperative it must be removed and replaced.
3. Run the TS58R Sensor Programming by OBD with a new TruSensor, refer to
pp. 14-16.
a. Press the on-off button for ≈3 seconds to power up the device.
b. Select TPMS from the Main Menu Screen.
c. Select make, model, and year of the vehicle.
d. Select Sensor Programming.
e. Select Copy by OBD.
f. Connect the OBD Cable to the vehicle’s DLC interface connector and turn the
ignition to the on position.
g. Click on the Confirm button, the TS58R will read all the Tire Pressure Sensor
IDs currently saved on the vehicle’s ECU board and display them on the TS58R
screen.
h. Place the new replacement TruSensor within 10cm of the top of the TS58R.
i. Select the Sensor ID (wheel position) you wish to program and then click on
Programming.
j. To continue programming sensors, click Return and repeat steps g through i.
4. Remove the tire and inoperative sensor from the wheel.
5. Install the programmed TruSensor in place of inoperative sensor.
6. Remount the tire on the wheel.
7. Inflate and install the wheel and tire on the vehicle.
8. Repeat with the remaining sensors and wheels, if required.

TS-58R TPMS Diagnostic Tool 5900313 - Rev. A - March 2023
10
TPMS Overview
Tire pressure monitoring system diagnosis on the TS58R will cover five sections:
1. Basic TPMS Diagnosis Function. Allows wireless reading/scanning of Tire
Pressure Sensors. Providing the Sensor status, ID information, Pressure, Temperature
and Battery Charge Status. Data available may vary based on sensor type.
2. OBD Diagnostic Function. Allows reading/scanning of Tire Pressure Sensor data
through the OBD interface comparing the Tire Sensor ID value to the vehicle’s stored ID
value.
3. Sensor Programming Function by OBD. This function uses the OBD interface
to read the Tire Pressure Sensor ID registered on the Vehicle’s Computer Board and
programs (stores) it on a new TruSensor Sensor. When this new TruSensor is installed in
the same wheel there is no need to perform the Location Learning function.
4. Sensor Programming Function by Activation. This function is used to activate
the original Sensor in order to retrieve its original Sensor ID. This ID may then be
programmed onto a new TruSensor. When the new TruSensor is installed on the same
wheel as the old Sensor there is no need to perform the Location Learning function.
The original Sensor ID may also be manually input into the new TruSensor through the
TS58R.
5. Location Learning Function. The TS58R is capable of using three different
methods of position learning: Stationary, Automatic, and OBD. On some vehicles the
Re-Learning Function can be completed by driving. See “Learning Process Guide” in
the TS58R on-screen help page.
Read/Scan TPMS Sensors
1. Press the on-off button for ≈3 seconds to power up the device.
2. Check the TS58R tool battery status displayed in the upper right-hand corner to
verify there is enough power to complete your test. If the power is low, recharge the
unit through the USB-C port before attempting to test or program the sensors.
3. On the Main Menu select TPMS, then select the Make, Model, and Year, of the
Vehicle under test.
TPMS Diagnosis

11
TS-58R TPMS Diagnostic Tool 5900313 - Rev. A - March 2023
4. On the next page select TPMS diagnosis, read the guidelines then select confirm
on the next page.
5. The driver side front tire will be selected on the display. Hold the TS58R within 10 cm
of that tire’s valve stem and press to read the sensor ID and Data.
Repeat this process on the remaining tires and include the spare if a sensor is
installed there.
A green check mark will appear next to Sensors that have communicated successfully
with the TS58R. Tire position, ID, pressure, temperature, and battery status will
appear in a table. A red Xindicates a failed communication. A red !indicates a repeat
activation.

TS-58R TPMS Diagnostic Tool 5900313 - Rev. A - March 2023
12
OBD Diagnostic Function
This function allows display of the pressure sensor status and determines if the Tire
Sensor IDs match the IDs stored on the ECU.
1. Select the make, model, and year, of the vehicle.
2. Connect the OBD Cable to the vehicle’s DLC interface and the TS58R.
3. Select OBD Diag. and follow the next screen’s instructions to connect the TS58R to
the vehicle’s Data Link Connector (DLC).
⚠
WARNING
Do not connect or disconnect any equipment while the ignition or
engine is on.

13
TS-58R TPMS Diagnostic Tool 5900313 - Rev. A - March 2023
5. Click Confirm on the touchscreen. The TS58R will automatically read the sensor
identification numbers saved on the vehicle’s ECU board and displays them on the
screen.
Green - ECU Computer Board Pressure Sensor ID and Tire Sensor ID
match.
Red – ECU Computer Board Pressure Sensor ID does not match Tire
Sensor ID.
6. Select view DTCs (Diagnostic Trouble Codes).

TS-58R TPMS Diagnostic Tool 5900313 - Rev. A - March 2023
14
7. Click Clear to automatically clear the fault code and poll the ECU board to
ensure all fault codes have been deleted; or click Save to store the fault code. Saved
Fault Codes may be viewed in the “data record.”
Sensor Programming by OBD
This section covers programming the new TruSensor Tire Pressure Sensors. There
are four methods to program the Sensors: Copy by OBD, Copy by Activating, and
Automatically Create ID.
Sensor Programming - Copy by OBD (ON-BOARD DIAGNOSTIC)
This section programs New TruSensor Tire Pressure
Sensors with the Sensor ID registered on the Vehicle’s
Computer Board.
Note: Recommended practice is to install a new
TruSensor in the same wheel, then writes the Sensor
ID to the Computer Board without performing the
Location Learning function. This method (if available)
programs a new sensor.
To Program a New TruSensor using Copy by
OBD:
1. After Vehicle selection is complete, select
Sensor Programming then select Copy by
OBD.

15
TS-58R TPMS Diagnostic Tool 5900313 - Rev. A - March 2023
2. Connect the OBD Cable to the Vehicle’s DLC interface connector and turn the
ignition to the on position.
3. Click on the Confirm button, the TS58R will read the Tire Pressure Sensor ID saved
on the Vehicle’s Control Board and displays it on the TS58R screen.
4. Place a new TruSensor within 4 in. (10 cm) from the top of the TS58R.

TS-58R TPMS Diagnostic Tool 5900313 - Rev. A - March 2023
16
5. Select the Sensor ID and then click on Programming.
6. To continue programming, click Return to repeat steps 3 through 5.

17
TS-58R TPMS Diagnostic Tool 5900313 - Rev. A - March 2023
1. After Vehicle selection, select Sensor Programming then Copy by Activation.
2. Click Activate or the button to activate the Sensor.
Sensor Programming-Copy by Activation

TS-58R TPMS Diagnostic Tool 5900313 - Rev. A - March 2023
18
3. If activation is successful,
the OE sensor ID is displayed
at the bottom of the screen.
4. Place a new TruSensor within 4 in.
(10 cm) from the top of the TS58R.
5. Select Programming, the TS58R will begin to detect nearby TPMS sensors.

19
TS-58R TPMS Diagnostic Tool 5900313 - Rev. A - March 2023
SENSOR PROGRAMMING - Manual Input
1. After Vehicle selection, select
Sensor Programming then
Manual Input.
2. Enter the 8-digit hexadecimal sensor
ID number, then select Confirm.
3. Select Confirm to continue
the programming process.

TS-58R TPMS Diagnostic Tool 5900313 - Rev. A - March 2023
20
4. Place a new TruSensor within 4 in. (10 cm) of the top of the TS58R. The TS58R
automatically detects the nearby sensor.
5. If the Sensor programmed
successfully, the Sensor data
will be displayed on theTS58R
screen.
