Rasmussen SPK3E User manual

1
THE GAS LOG COMPANY
4c
Wireless On/Off
Remote
(SR-2R)
Wireless On/Off
Remote with
Thermostat
(THR-2R)
Wireless Wall
Switch
(WS-2R)
Wireless Wall
Thermostat
(TS-2R)
HI/LODC
Motor Drive
(STV-VMD)
Wireless Wall Timer
(30/60/120 Minutes)
(WT-2R)
UPGRADE OPTIONS
“RE” “Variable Flame Height” Remote Control
Upgrade Kit (RE-UP1)
Kitto upgrade from “ME”or “SE” to“RE”functionality.Includes:
DCMotor Drive,Receiver, Transmitterand batteries.
Our optional Ceramic Log House accessory (RH2) offers heat
protection for the Battery Pack/Receiver while being pleasing
to the eye.
Variable Flame Height Remote Control Transmitter (STR-RMD)
Battery Pack/Receiver
(BPR3)
Latching Solenoid for Remote
Ready (STV-LS) Battery Pack/Receiver
(BPR3)
“SE” “Remote Ready” Upgrade Kit (SE-UP1)
Kit to upgrade from “ME” to “SE” functionality. Includes:Solenoid, Receiver
and batteries. One offour Wireless Remote Transmitter Devices* is also
required (each sold separately, see below)
*Wireless Remote Transmitter Devices (each sold separately)
See instructions included with remote devices for operation.
SPK3E PARTS LIST
5. 10-32 x 3/8 bolts (qty. 3)
6. 10-32 Hex nut (qty. 3)
7. Valve Knob Extender (STV-KE2)
8. 10” flex Connector (SSCB-10)
9. Pilot-Thermocouple Assembly (J95R -NG or -LP)
10. “EASY” Safety Valve (STV-10) and Heat shield (HS-ST1)
1. Air Mixerfor LP Gas Burner Inlet Assembly (MA2)
2. Burner Orifice #’s 45, 49, 51,53 (01-XX)
3. Internally Tapped 3/8 Flared x 3/8 MIP Elbow (A2T)
4a. Pilot Support Bracket for F & TNA burners (PB-1)
4b. Pilot Support Bracket for CS & CXF burners (PB-2)
4c. Thermocouple Heat Shield for left side gas supply (PB-4)
REQUIRED TOOLS AND MATERIALS
Adjustable Wrench, PipeWrench, Flat Head Screwdriver, Phillips Screwdriver, Pipe Sealing compound
(Only required if fittings not already prepared with pre-wrapped Teflon thread tape).
SPK3E - Manual “ EASY” Control
General Assembly,Installation, and Operation Instructions for use with Natural Gas Burners;
F, FX, CS, CXF, TNAor Propane GasBurners: FA,FAX, CA, CXFA, TNA/LP
9
(Green mark indicates Natural Gas,
Red indicates Propane Gas)
2 3 4a
1
5
6
10
7
ATTENTION! READ INSTRUCTIONS CAREFULLY BEFORE ASSEMBLY
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE ●CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE
4b
REV: SPK3E-0910
Last Printed 9/17/2010
8
Owner’s Manual
12028 E. PHILADELPHIA ST.
WHITTIER, CA 90601 U.S.A.
www.rasmussen.biz
®
Report # 10-38

2
With the PILOT THERMOCOUPLE ASSEMBLY (Figure 2A) attached to the PILOT SUPPORT BRACKET (Figure 2B),
insert the 10-32 BOLTS (Figure 2C) through the pre-drilled holes of the Pilot Support Bracket and into the threaded
holes of the Pilot Thermocouple Assembly (Figure 2A). Tighten with flathead screwdriver.
STEP TWO: ATTACH PILOT (Figures 2 thru 5)
NOTE: The following pilot attachment instructions apply to each burner model shown in Figures 2 thru 5.
FIGURE 2 (F, FX, FA and FAX Burners)
B) Pilot Support
Bracket
E) 10-32 nut
C) 10-32 bolts
F) Burner Pipe
FIGURE 3
CS/CA Burners
10-32 bolts
ASSEMBLY
STEP ONE: BURNER PAN FITTINGS (Figure 1)
NOTE: If fittings do not come pre-wrapped with Teflon threaded tape, pipe compound must be applied to the non-flared
threads.
1. Ensure that the BURNER PLUG (Figure 1A.) is inserted into the opposite end of the BURNER PIPE (Figure 1B)
and wrench tightened.
2. Thread the Natural Gas or Propane Burner Pan Inlet Assembly into the BURNER PAN (Figure 1C).
• Natural Gas Burners (NG) (F, FX, CS, CXF, TNA) Insert theBURNER ORIFICE (Figure 1D) into the INTERNALLY
TAPPED 3/8 FLARED x 3/8 MIP ELBOW (Figure 1E)and wrench tighten. (Orifices and Fittings are provided with the
Burner Pan)
• Propane Burners (LP) (FA, FA-X, CA, CXFA, TNA/LP) requiresMA (Figure 1F) or MA-2 (Figure 1G) AIR MIXER
ASSEMBLY. Insert the Internally Tapped 3/8 Flared x 3/8 MIP Elbow and wrench tighten. Thread the Air Mixer onto
the 3/8 Flared x 3/8 MIP Elbow and wrench tighten with air intake hole positioned horizontally and parallel with the floor.
A) Burner Plug
B) Burner Pipe
C) Burner Pan
E) Internally Tapped 3/8 Flared x 3/8
MIP Elbow
FIGURE 1
G) Air Mixer For CA Burner Inlet Assembly (MA)
(Supplied with burner only)
F) Air Mixer For LP Gas Burner Inlet Assembly (MA2)
D) Orifice
Propane Burner
Inlet Assembly
Natural Gas Burner
Inlet Assembly
A) Pilot Thermocouple Assembly
Pilot
Thermocouple
Assembly

3
A) 10” FLEX CONNECTOR
B) VALVE OUTPUT 3/8 FLARED FITTING
C) BURNER INPUT
3/8 FLARED x 3/8
MIP ELBOW
VALVE INPUT
VALVE OUTPUT
3/8 FLARED FITTING WITH
10” FLEX CONNECTOR ATTACHED
VALVE INPUT 3/8 FLARED FITTING
(Attach to Gas Supply)
PILOT INPUT
FIGURE 4 (CXF AND CXFA Burners
Pilot Thermocouple
Assembly
10-32 bolts
FIGURE 5
(TNA / TNA-LP Burners)
10-32 nuts
& bolts
Pilot
Thermocouple Assembly
FIGURE 6
Connect 10” FLEX CONNECTOR (Figure 6A) between the
flared ends of the VALVE OUTPUT 3/8 FLARED FITTING
(Figure 6B) and the BURNER INPUT 3/8 FLARED 3/8 x
MIP ELBOW (Figure C). Bend the 10” Flex Connector to the
optimum Valve position (forward and to the side of the Burner
pan, low to the floor).
STEP THREE: CONNECT BURNER AND PILOT GAS SUPPLY

4
10-32 bolts
Pilot Thermocouple
Assembly
C)
Internally Tapped 3/8 Flared x 3/8 MIP Elbow
Burner Plug
Burner Pipe
Air Mixer For LP Gas
Burner Inlet Assembly
10” Flex Connector
Burner Pan
Pilot Thermocouple Assembly
Burners
B) “EASY” Safety Valve
Heat Shield
A)
LEFT SIDE GAS SUPPLY CONNECTION
Attach the Pilot Support Bracket (PB-1) to the left side of the burner pan using a 10-32 nut and bolt (Figure 7A), then place the
Pilot Thermocouple Assembly overthe bracket aligning the two screw holes (Figure 7b). Place the Thermocouple Heat Shield
over the Thermocouple Assembly and bolt onto the Pilot Support Bracket using the supplied 10-32 nuts and bolts (Figure 7C).
Burner Plug
SUGGESTED FIREBOX LAYOUT AND REQUIRED PARTS
The “EASY” Safety Valve can be adversely affected by heat and must be placed as far forward and to the side of the
burner pan as possible (Figure 8B). It may also be placed open face side down with heat shield up as shown in
Figure 8C. The example below shows an FX style burner. For other styles of burners see next page.
C
10-32 nut
10-32 bolt
Pilot Support
Bracket
(PB-1)
A) B)
Gas Supply Pipe
FIGURE 7
Thermocouple
Heat Shield
(PB4)
FIGURE 8

5
FURTHER SAMPLES OF FIREBOX LAYOUT
TNA STYLE BURNER
CXF AND CXFA STYLE BURNER
CS AND CA STYLE BURNER
Burners
Burner Plug
Burner Pipe
Flex Connector
Heat Shield
Pilot Thermocouple Assembly
Internally Tapped
3/8 Flared x 3/8 MIP Elbow
Burners
Burner Pipe
Burner Pan
Pilot Thermocouple Assembly Flex
Connector
Heat Shield
Burner Pipe
Burner Pan
Pilot Thermocouple Assembly
Flex Connector
Heat Shield
“EASY” Safety Valve
Each shown with “EASY” Safety Valve placed asfar forward and to the side of the burner pan as possible.
“EASY” Safety Valve
“EASY” Safety Valve

6
LIGHTING AND OPERATION
VALVE
PLUG
B) PILOT ADJUSTMENT
SCREW
A) VALVE KNOB
C) KNOB POSITION INDICATOR
FIGURE 9 “EASY” SAFETY VALVE
1. Turn VALVE KNOB (Figure 9A) to “PILOT” position.
2. Depress and hold until air is bled and gas flows to Pilot
(Figure 10A).
3. Light Pilot with a Match or Lighter.
4. Once Pilot is lit, continue to depress and hold until the
Pilot flame remains lit (approximately 30 to 60 seconds).
5. If Pilot does not remain lit, depress and turn Valve Knob
clockwise to “OFF” position and wait at least 5 minutes to
allow gas to dissipate. Repeat steps 1 thru 4.
STEP ONE: PILOT LIGHTING
1. The Pilot flame should be steady, surrounding the
THERMOCOUPLE TIP (Figure 10B).
2. If pilot flame adjustment is necessary, use a narrow long stem flathead
screwdriver to turn PILOT ADJUSTMENT SCREW (Figure 9B) above.
3. Turn clockwise for less flame, counterclockwise for more.
4. If after pilot adjustment the burner begins to shutdown,
re-adjust for a longer pilot flame.
STEP TWO: PILOT ADJUSTMENT
FIGURE 10
PILOT THERMOCOUPLE
ASSEMBLY
A) PILOT
B) THERMOCOUPLE TIP
STEP THREE: BURNER OPERATION
1. Turn VALVE KNOB counter clockwise to “ON” position (Figure 11A).
2. Adjust the burner flame height by turning the valve knob clockwise to
lower and counter-clockwise to raise up to full on.
NOTE: The VALVE KNOB has complete control of gas to the pilot and
burner. It cannot be turned to “OFF” without first depressing dial to the
“PILOT “ position and then rotating clockwise to “OFF” (see figure 9A).
During the heating season leave valve knob in “PILOT” position for
convenience. Otherwise, turn to “OFF” position for any prolonged non-use.
FULL ON LOWER
FIGURE 11
A)
IMPORTANT! READ THESE WARNINGS PRIOR TO OPERATION IMPORTANT!
• CHIMNEY DAMPER MUST BE WIDE OPEN! The flue must vent all products of combustion. Damper and glass
doors MUST be fully open before lighting or burning for proper ventilation and to prevent heat damage to valve.
• Your gas log set should be operated for the first 2-3 hours at a low flame setting to allow tempering of the
refractory logs.
• DO NOT REMOVE HEAT SHIELD (Figure 8A). It is intended to prevent premature valve failure and voiding
of warranty. Replace immediately if removed for any reason.
• The “EASY Safety Control Valve must be protected to a maximum ambient temperature of 225° F. Excessive heat
to the valve is indicated by melted plastic or wiring on the valve body and is not warrantable.
• Allow an adequate period of cooling after use before closing glass doors.
• NEVER operate your gas log set with glass doors closed.
