RATH MICROTECH SmartPhone VI User manual

On-Board Programming
SmartPhone VI Consolidator Feature (Capability of 10 Phones/One Line)
Remote Programming
(Detailed Programming Instructions)
Standard Operations
N56 W24720 N. Corporate Circle Sussex, WI 53089
800-451-1460 262-246-4828 (fax) www.rathmicrotech.com 05/10
Made in the USA
3 Year Warranty
SmartPhone VI
RP8200910
Revision 1
A. Press 1, 9, Enter, 2
Note: This will automatically set the Timer for 3 minutes
* Skip Step 3
Step 1. Begin Program Mode
A. Press Enter
Step 3. Program Emergency Numbers
A. Press 1, Enter, (Phone Number), Stop
Note: Press 2-5 In Step 3A For Emergency Numbers
2-5 As Needed
Step 4 . Program Location Message
A. To Turn On Message Press 1, 3, Enter, 2
B. Press 6, Record, (Speak Your Message), Stop
(To Replay Message Press 6, Play/Pause)
C. Program Frequency of Message Press 1, 3, Enter, _
1= Plays Message (1) Time
2= Plays Message (2) Times (Default)
3= Plays Message Until Receiving Party Presses *
On Their Phone
D. For No Message Press 1, 3, Enter, 0
Step 5. Program Talk Timer
A. Press 8, Enter, (3 Digit Number in Minutes)
Ex: 2 Minutes = 002
Note: After Talk Timer Expires, Phone Will Prompt Called Party
to Extend Call for 3 Minutes
Step 7. To Exit Program Mode
A. Press Stop For 3 Seconds
Step 6. Change Telephone Security Code (Default 1111)
A. Press 2, 2, Enter, (Desired 4-digit code)
Note: Cannot Be 0000
Step 2. If Ring Down (No Dial Tone)
A. Press 1, 9, *, 2
Note: This will automatically set the Timer for 3 minutes
* Skip Step 3
Step 1. Begin Program Mode
A. Call Into Phone
B. After 1st Simulated Ring Press #, #
C. Key in Security Code (Default is 1111)
Step 3. Program Emergency Numbers
A. Press 1, * (Phone Number), *, #
Note: Press 2-5 In Step 3A For Emergency Numbers
2-5 As Needed. For “Pause” Press #, *
Step 4 . Program Location Message
A. To Turn On Message Press 1, 3, *, 2
B. Press 6, *, (Speak Your Message), #, *, #
(To Replay Message Press 6, #)
C. Program Frequency of Message Press 1, 3, *, _
1= Plays Message (1) Time
2= Plays Message (2) Times (Default)
3= Plays Message Until Receiving Party Presses *
On Their Phone
D. For No Message Press 1, 3, *, 0
Step 5. Program Timer
A. Press 8, *, (3 Digit Number in Minutes)
Ex: 2 Minutes = 002
Note: After Talk Timer Expires, Phone Will Prompt Called
Party to Extend Call for 3 Minutes
Step 2. If Ring Down (No Dial Tone)
Step 6. To Exit Program Mode
A. Press *, #, 0 (You Will Hear Beep, Beep) *, #
A. Press 7, Enter
B. Press *, 1-5 For Corresponding Elevator (1-5)
Step 1. Begin Program Mode
A. Press Enter
Step 3. Program ID Numbers for Phones 6-10
A. Press 7, Enter
B. Press #, 1-5 For Corresponding Elevator (6-10)
Step 2. Program ID Numbers for Phones 1-5
Step 5. Confirm Consolidator Operation
A. Dial Phone Number SmartPhones are Installed on:
All Phones Will Answer
B. To Select Individual Phone
Press *1 (Phone #1) Press #1 (Phone #6)
Press *2 (Phone #2) Press #2 (Phone #7)
Press *3 (Phone #3) Press #3 (Phone #8)
Press *4 (Phone #4) Press #4 (Phone #9)
Press *5 (Phone #5) Press #5 (Phone #10)
Press *0 (All Phones)
Step 4. Program Emergency Numbers
A. Press Stop For 3 Seconds

N56 W24720 N. Corporate Circle Sussex, WI 53089
800-451-1460 262-246-4828 (fax) www.rathmicrotech.com 05/10
Made in the USA
3 Year Warranty
RP8200950
Revision 1
Troubleshooting & Diagrams
SmartPhone VI
Wiring Diagrams: 24v Models
24+ 24-
To 24 Volt Power
Supply
Enter
Record
Play/Pause
Stop
Bat
RJ11
RJ11
Relay Alarm
LED Switch
To Phone Line
MIC Speaker
+ -
24v
AC/DC
Direct 24vac/dc Powered Note:
If utilizing our
Modem
feature,
connect to our
“Relay
Connection”
Modem Operation:
Both the SmartPhone VI and your controller
will share the phone line. Your diagnostic
program will call into this phone number.
Once it hears the “pseudo” ring, it will need to
output a *, 7 to take control of the line.
At this point, your diagnostic program can
communicate with your controller. You must
connect our “Relay” output to a 24v common
ground at your controller. This will tell your
controller that the phone needs the use of the
line upon activation of the phone push button.
Note:
If utilizing our
Modem
feature,
connect to our
“Relay
Connection”
Optional Annunciator Output Board
To Speaker
120vac to 24vac/dc Powered
To Phone Line
Enter
Record
Play/Pause
Stop
RP7300144-24/5VA
Black
Hot Green
Ground
Red
Neutral
120 vac
Bat
Relay Alarm
LED Switch
MIC Speaker
+ -
RJ11
RJ11
Relay 1
Relay 2
To H1 on SP VI
To Speaker connection on
SP VI Circuit Board
To Audio output
of Annunciator
Twisted,
shielded pair
Twisted,
shielded pair
COM
NC
NO
COM
NC
NO

Diagnostic Test: Press Enter 2 6 Play/Pause phone will play back (5) Beeps (1st Beep=External Power
Supply; 2nd Beep=LED; 3rd Beep=Microphone; 4th Beep=Speaker; 5th Beep=Back-Up Battery). If any item fails
during test you will hear a Blat not a Beep. If you hear a Blat, contact the Rath Microtech Technical Dept.
Connect to standard RJ11 phone jack. If splicing connection, only hook up Red and Green Wires from the phone cable.
If connecting to a SmartRescue unit, you must connect all four wires. (Check for 24vdc or 48vdc supply at the splice)
Initial Set-Up:
If the phone does not respond, make sure the green LED (D1) on the circuit board is lit. If not, check to be sure the power is
properly connected.
3.
If the phone dials only one digit and hangs-up, there is another Auto-Dialer on the line. You need to re-wire the system so
that our unit is either in parallel or ahead of it.
1.
2. If the phone dials a couple of digits and gets a busy signal, the unit is installed on a switchboard line and needs to be
programmed to dial the appropriate access code to get an outside line. (Usually an 8 or 9)
Troubleshooting:
N56 W24720 N. Corporate Circle Sussex, WI 53089
800-451-1460 262-246-4828 (fax) www.rathmicrotech.com 05/10
Made in the USA
3 Year Warranty
Revision 1
Troubleshooting & Diagrams
SmartPhone VI
1.
2.
Wiring Diagrams: 12v Models
Transf-12v To 120 vac
Black/Hot
12+ 12-
To 12 Volt Power
Supply
Enter
Record
Play/Pause
Stop
Bat
RJ11
RJ11
Relay Alarm
LED Switch
To Phone Line
MIC Speaker
+ -
RJ11
RJ11
To Phone Line
White/Neutral
12v
AC/DC
Direct 12 vac/dc Powered Note:
If utilizing our
Modem
feature,
connect to our
“Relay
Connection”
Note:
If utilizing our
Modem
feature,
connect to our
“Relay
Connection”
120 vac to 12 vac/dc Powered
Enter
Record
Play/Pause
Stop
Bat
Relay Alarm
LED Switch
MIC Speaker
+ -
12v
AC/DC
Twisted,
shielded pair Twisted,
shielded pair
