Inflatable Dock Slide
Owner’s Manual
#00002
WWW.RAVESPORTS.COM
Copyright © 2018
All rights reserved. No part of this publication may be reproduced or transmitted in any form
or by any means, electronic or mechanical, including photocopy, recording, or any
information storage and retrieval system, without permission in writing from the publisher.
Requests should be mailed to RAVE Sports, 985 Aldrin Drive #301, Eagan MN, 55121

1
Table of Contents
Introduction ............................................................................2
Safety rules and information...................................................3
Dock compatibility guide ........................................................5
Assembling your Dock Slide ....................................................6
Operation ...............................................................................10
Deflation .................................................................................11
Cleaning and storage .............................................................12
Troubleshooting ....................................................................12
Repairs....................................................................................13
Contents in this package
•Dock Slide Tube
•2 Attachment Straps
•Electric (120 volt) Inflator/Deflator (#02704)
•Repair Kit
Please make sure you have received the contents listed, and
then record the following information for future reference.
Date Purchased: _________________________________
Purchased from: _________________________________

2
Introduction
Water sports can be safe and fun for all levels of enthusiasts.
The Owner’s Manual is presented to enhance your enjoyment
of the sport. It is intended to alert you to some of the
potentially dangerous conditions that can arise in all water
sports.
Please take a few minutes to read this manual before
assembling and using the product. Although the product is
simple to use, this manual contains important safety
information that you and all users must understand to safely
enjoy the Dock Slide.
If you have any questions regarding this product, please call
RAVE Sports at 1-800-659-0790, or visit www.ravesports.com.
Please have the serial number (if available) from your
product ready when you call.
W A R N I N G
UNSAFE USE OF THE DOCK SLIDE CAN RESULT
IN PERSONAL INJURY OR DEATH.
To reduce the risk of injury, read and follow all
instructions and warnings in this manual. Do not use
this product unless you understand and accept the
risk of injury involved with this activity.
!
!
!!

3
Safety Rules and Information
•Read and understand all of the information contained in this
owner’s manual before assembling and using your product.
•Make sure that everyone who uses the product is provided with
and understands these safety rules and information. This product
is not recommended for non-swimmers.
•The Dock Slide is designed to be used only on docks that allow for
safe attachment. Ensure that straps are properly attached to the
dock and securely tightened before using. Do not use if attachment
straps are damaged or incorrectly attached.
•Choose a location for your product that is most protected from wind,
of at least 6 feet water depth at slide location, and free of
obstructions above and below the water for at least 20 feet to the
front and sides of the Dock Slide. Dock should have at least 12 inches
but not greater than 30 inches of clearance above water surface.
•Always wear a U.S. Coast Guard approved Type III (PFD) personal
floatation device when using the product.
•Never use the product after sunset, before dawn, or any other
time in poor lighting conditions.
•Never use the product in rough surface water conditions, during
storms, or when there is lightning. If an unexpected storm arises
while using the product, seek shelter on shore. Do not stay on the
product.
•Never use the product under the influence of alcohol or drugs,
which may impair balance and proper judgement.
•Always stay under control while using the product.
•Always make sure water near slide entry is clear of swimmers or
other obstructions including dock posts, benches, and boat lifts.
•Never swim or play under the Dock Slide.
•This product is not a towable; do not tow behind a boat or other
vehicle.

4
•Do not allow more than one person (up to 180 lbs.) to slide and/or
climb on the slide at one time. Exceeding this may result in injury.
•Never dive headfirst down the Dock Slide or attempt other
acrobatic maneuvers on the product. Always slide feet first.
•No pushing or shoving persons while on the Dock Slide.
•Do not climb up the Dock Slide to exit the water. Use boarding
ladder on the dock.
•Never jump from top of Dock Slide and stay in a seated position at
all times. Do not stand on, leap, or dive from the dock slide.
•Never use the product while tired or fatigued. Use extreme caution
while swimming around the dock.
•Do not use Dock Slide in close proximity to moving boats or other
water craft in operation.
•Always inspect the areas around and under the product before
each use to ensure the water is deep enough and free of all rocks,
logs, sand bars, and underwater obstructions and that the product
is a safe distance from above water hard objects. Ask about local
water conditions before using the product in unfamiliar water.
•When not in use, deflate Dock Slide and store in a secure area.
Never leave slide inflated and unattended. Never drag your dock
slide on the ground; always lift it to move it.
•Inspect your product for any worn, defective, or missing parts and
replace or repair before using. Do not use if product is damaged,
leaking air, or under-inflated.
•Use the Dock Slide only under mature, knowledgeable adult
supervision.

5
Dock Compatibility Guide
IMPORTANT:FOR
DOCK SLIDE USE ONLY
. DO NOT ATTEMPT TO
USE ON DECKBOATS, RUNABOUTS, FISHING BOATS OR OTHER CRAFT.
BEFORE ASSEMBLING OR USING YOUR SLIDE, MAKE SURE YOUR DOCK
MEETS THE FOLLOWING CRITERIA:
1.A secure deck with a height of 12-30 inches from the top of
dock deck to the top of the water below.
2.Water depth should be a minimum of 6 feet deep (72”) at
location where the slide will be mounted.
3.The Dock Slide should not be used with docks that have less
than 12 inches or more than 30 inches of clearance between
the water surface and the top of the dock or with less than the
recommended water depth as indicated above.
4.1/8” x 1 ½” openings in the decking to allow attachment straps
to be fed through.
These criteria must be met in order for the Dock Slide to be securely
fastened to the dock. If your dock does not meet these criteria, do not
attempt to use the product.
6 ft (72”) minimum water depth

6
Assembling your Dock Slide
Step 1 – Confirm Dock Conditions
Make sure the dock deck and surrounding water are free
from obstructions and that you have a minimum water
depth as listed previously. Ensure the dock deck is secure
and stable with a height between 12 - 30 inches above the
water.
Do not use if your dock does not meet these requirements.
Place deflated Dock Slide on the
shore or similar firm surface with
sufficient clearance to inflate. Make
sure the area is free of all sharp
sticks, rocks or other objects which
could puncture the product.
Step 2 - Inflate
Using the RAVE Sports electric (120
volt) high-speed inflator / deflator
(#02704) with a long reinforced
hose and 5 inflation adapters that
is included with the dock slide,
inflate the main chamber of the
dock slide until it is very firm (1.5 –
2.0 psi).
A 0-15 psi Digital Pressure Gauge (Item # 02809) is available
separately from RAVE Sports.

7
CAUTION: Always use caution when using electricity near
water. We recommend inflating your dock slide in an area
on land a safe distance away from water, then lifting your
dock slide to the dock.
Locate the main valve (on climb side of
slide) and remove cap. A special inflation
adaptor is included with this product.
Simply lock the adaptor onto the end of the
inflation hose and insert into the valve
body. Turn ¼ turn clockwise to lock in place.
NOTE:
This inflation adaptor will automatically open the valve
when inserted and will close the valve when removed. You do
not need to manually open/close the valve when using this
special adaptor.
Inflate the main chamber of the slide until it is firm. Properly
inflated, the slide will be firm and will not buckle during use.
Inflate both side rail tubes last.
When main chamber is fully
inflated, then inflate the side rails
using the same valve connector.
To remove inflator, turn adaptor ¼ turn counter-clockwise.
Install outer cap.
CAUTION: Do not over-inflate. Do not exceed 2 PSI if filling
with compressed air. Excessive pressure can cause the tube

8
to rupture with potentially damaging force to eyes, ears,
skin and limbs. Use of an air compressor or over-inflation
can rupture the tube beyond repair, thus voiding the
warranty.
To manually open valve, depress
the stem and rotate clockwise. To
close valve, depress the stem and
rotate counter-clockwise.
NOTE: It is normal for air pressure within the tube to
fluctuate depending on air and water temperatures. It may
be necessary to increase or decrease the air pressure in your
product accordingly. To avoid damage on
extremely hot days it may be necessary
to check and release the air pressure
from your product throughout the day.
On cool days you may need to add air.
Step 3 – Carry (do not drag) slide to dock and attach straps to
dock
Attach the 48-inch, black attachment straps by looping the
strap around the planks of your dock.

9
IMPORTANT: Your decking must have openings that are a
minimum of 1/8” x 1 ½” wide to accommodate the straps
passing through.
For planks that run perpendicular to the slide direction (Fig.
A), insert the straps around the second or third plank. Space
straps approximately 36” apart.
For planks that run parallel to the slide direction (Fig. B),
insert the straps behind a frame support member that is
running perpendicular to the decking. This is critical to
prevent the straps and slide from slipping forward.
Attach both straps to the dock and tighten securely.
Figure A Figure B

10
Step 4 – Buckle straps to Dock Slide
Place a piece of foam or other non-slip
mat (not included) on the surface of the
deck where the slide will be positioned.
This will help protect the inflatable slide
from wear and possible puncture.
Position the slide between the two straps. Attach the free
end of both straps to the buckle on each side of the slide.
Feed the strap through the backside (slide side) of the buckle
jaw and pull snug. Pull both straps tight so the slide is
securely fastened to the surface of the dock. Tie off the
remaining loose end of both straps in a secure fashion.
NOTE: Two extra D-rings are
attached to the Dock Slide on the
upper left and right sides of the
steps side. If your Dock Slide is not
secure with the 2 lower straps
included, you may add extra
security by tying ropes or other
straps here. This is an additional
option for extra security, but is not absolutely necessary.
Before sliding, check to make sure the slide is securely fastened
to the dock and the decking will not lift during use. Secure
decking if necessary.
Operation
Before sliding, wet slide surface with water. Sliding on a dry
surface can cause burns to the skin or lack of sliding
movement.

11
Climb up slide using hand and foot holds. Use
top handles when transitioning from the
climbing position to a seated position. NEVER
STAND ON THE TOP OF THE SLIDE.
Always slide feet first. Ensure water is clear of
obstructions and other people before going
down slide.
Deflating your Dock Slide
Step 1
Loosen all connection straps from dock deck.
Step 2
Lift dock slide and carry it to an area on land safely away from
water. Locate the main valve (on climb side of slide) and
remove cap. Using the electric (120 volt) high speed inflator /
deflator included with your dock slide, and the special inflation
adaptor also included with this
product, simply lock the adaptor
onto the end of the inflation hose
and insert into the valve body.
Turn ¼ turn clockwise to lock in
place. Set pump on “deflate”
option, turn on, and deflate
completely.
For deflation: Deflate both side rails first and deflate main slide second. Once all
air is removed, make sure slide is completely dry for storage. Fold or roll to a
compact size.

12
Cleaning and Storage
•When the inflatable product is not being used, store it in a
covered, shaded area. This will help protect it against
ultraviolet (UV) rays and extend the life of the product.
•Clean the inflatable completely with a mild soap and fresh
water. NEVER USE PETROLEUM BASED PRODUCTS OR
SOLVENTS FOR CLEANING.
NEVER USE A POWER WASHER
SINCE THE HIGH PRESSURE WATER WILL DAMAGE THE
TUBE BEYOND REPAIR.
•For storage, roll the product loosely and place in a
container, preferably one that rodents can’t chew through.
•Secure against unauthorized and unsupervised use.
•Store in a cool, dry location. Do not store product directly
on concrete surface. Place mothballs around stored
inflatable to keep mice and insects away.
Troubleshooting
Air chambers won’t hold air:
•Check to make sure all valves are completely closed.
•Check for holes in the slide following the procedures in
the “Repairs” section.

13
Repairs
Additional repair patches can be purchased at
www.ravesports.com
For Minor Holes or Tears:
•Inflate the slide and locate the leak by spraying the tube
with soapy water. Bubbles will appear where there is a
leak.
•Determine the hole size and cut a circular patch ½ - 1
inch wider than the hole with repair kit included with the
product.
•Remove air from the tube and dry tube completely
where the patch is to be applied.
•Peel off paper back from patch, apply repair patch to
area and work out any air bubbles from beneath the
patch.
•Apply weight to the patched area for one hour before re-
inflating.
For warranty and return information, please visit
www.ravesports.com.

14

15
WWW.RAVESPORTS.COM
RAVE SPORTS
A Revel Match, LLC Company
985 Aldrin Drive #301
Eagan MN, 55121
800.659.0790
July 2018
