Rave RKIO-P650PBT User manual

RKIO-P650PBT Pendant Speaker
WWW.RAVETECHNOLOGY.COM
Rave Technology
4100 East Baldwin Road Holly,
Michigan, 48442 USA
Tel: [phone]
[email protected]
•Tweeter: 1” Silk Dome
•Woofer: 6.5” Kevlar Cone Rubber Surround
•Impedance: 8Ω
•Sensitivity: 85±3dB
•Power Handing RMS: 40W
•Frequency Range: 100Hz~20KHz
•Includes: Wall/Landscape/Pendant Mount
•Transformer: 70V Taps 5W-10W-20W-40W
•IPX66: Weatherproof Certified
•Black ABS Housing
5-Year Limited Warranty
Rave Technology products are warranted to be free from
defects in workmanship and materials for a period of
Five (5) years from the date of purchase without charge
for parts or labor.
This warranty does not apply to units that have been
subject to misuse, abuse, neglect or improper
installation, and does not apply to repairs or alterations
made by unauthorized professional. This warranty
specifically excludes responsibility for consequential
damage.Retention of your original bill of sale is required
to obtain service under the terms of this warranty.
© 2020 Rave Technology. All rights reserved. All
trademarks are the property of their respective owners.
Specifications are subject to change without notice.
Specifications
WWW.RAVETECHNOLOGY.COM

Warnings and Safety
Please read the instructions carefully before installation and use. Keep the
manual safe for future reference.
• Prior to installing the speakers into any ceiling or wall, check the
structure for weight bearing ability and avoid contact with any wiring or
plumbing that might be behind the surface area.
• Installing on soft materials or in areas incapable of supporting the
speakers weight may cause personal injury or damage to the speaker.
• When installing speakers outside, choose areas such as the underside of
eaves to avoid strong direct weather and sunlight which may affect the
color and life of the speaker enclosure.
• When placing the speakers on a wall or shelf, it is recommended that
speakers be installed at the level of the ear or higher.
• Damage to the woofer and tweeter may occur if the speaker is dropped
or hit - resulting in no sound or distorted sound.
• Use only approved and certified wiring in your installation, do not
stretch or place the wire in contact with sharp objects.
• Never overdrive your speakers to the point of distortion and always
reduce volume prior to switching input sources.
• Turn off the power to the speaker when unused for long periods of time.
• Direct sun and/or bad weather exposure can damage your speakers. We
recommend you to place your speakers in a sheltered location (under an
overhang) and to remove them in the winter.
• Rave RK Series speakers require a run-in period before they deliver their
best performance. They must get adapted to the temperature and
humidity conditions of their environment. This breaking-in period
depends on the encountered conditions and can last several weeks.
However, you can shorten this period by letting your loudspeakers
operate for about twenty hours at moderate volume.
Rave speakers are designed for standard wall, ceiling or drop ceiling
applications. Please refer to the installation guidelines below for the
best speaker placement for your audio application.
Stereo Placement
In a standard two channel (stereo) audio, the speakers should be installed
approximately 6 to10 feet apart. If possible, the left and right speakers should be
located the same distance from the listening position. The pivoting adjustable
tweeters that are useful to focus the audio in the direction of the intended
listening location.
Surround (5.1) Placement
These speakers should be installed approximately 6 to 10 feet apart. When using
the speakers as rear channels, the speakers should be located from 2 to 6 feet
behind the main listening position and 6 to 10 feet apart.
Distributed Audio Placement
Rave Technology speakers possess extremely smooth and predictable off-axis
frequency response. The chart below shows how far apart the speakers can be
placed in a distributed audio system. The calculations are based on+/- 45 degrees
of coverage from the speaker, and listener ear heights of 62'' for standing and 40''
for seated listener.
Speakers spacing Standing Listener Seated Listener
8 foot ceiling
10 foot ceiling
12 foot ceiling
14 foot ceiling
5.7'
9.7'
13.7'
17.7'
9.5’
13.5’
17.5’
21.5’

Wire Gauge and Quality
The total wire resistance should be less than 10% of the speaker
impedance. If using an 8 ohm speaker, your total wire resistance should be
no more than 8 ohms. In simple terms, the extra resistance from the wire
will have a very negative effect on the sound quality of the speaker. The
sound can be less dynamic, definition of bass frequencies can be reduced,
an in extreme cases, the high frequencies can be attenuated. Amplifier
power is also wasted in the wire, reducing the maximum output level of
the system. Please refer to the following chart when deciding on the
appropriate wire gauge.
Distance in Feet
20 gauge
18 gauge
16 gauge
14 gauge
12 gauge
10 gauge
50’ 100’ 150’ 200’ 250’ 300’
Wire resistance in ohms vs. Length of cable run
.86 1.73 2.59 3.45 4.32 5.18
.65 1.30 1.94
2.59
3.24
3.89
.43 .85 1.28 1.71 2.14 2.56
.27 .54 .81 1.08 1.35 1.62
.17
.34 .51 .68 .85 1.02
.11
.22
.33 .44 .56 .67 Transformer settings
Depending on the customer needs you may use the speaker as 8ohm
or 70/100V. if you are using a stereo amplifier select the 8Ohm
(default) position on the transformer dial. If you are using a 70/100V
amplifier select the 70/100V output tap according to the application.
Speaker connection and lack bar
First remove the block style speaker connector, then connect the
speaker wires to the correct terminals according to the application.
Use the lock bar to secure the speaker cable connection.

Pendant Installation
Locate the landscape/ground installation hardware, assemble as
shown in fig 2. Be sure to run the cable through the end cap prior
making the speaker wire connection.
Wall Installation
locate the wall mount installation hardware, remove the ball socket
from the mount. Install mounting base on the wall, connect the
ball socket to the speaker and then to the base as shown in fig 1.
Landscape Installation
Locate the landscape/ground installation hardware, assemble as
shown in fig 3.
1
2
3
