Ravel REVAC User manual

REVAC
Conventional PA System
Installation, Commissioning & Operating
user Manual

RE/DD/UM/REVAC 1.0-01 Page 2
Table of Contents
1.Product Description: ........................................................................................................................3
2.Control and Indications....................................................................................................................5
3.Program............................................................................................................................................6
Suppressed Events .................................................................................................................................. 6
Mode .........................................................................................................................................7
Alarm Mode:..............................................................................................................................7
Mic Mode: ................................................................................................................................. 8
Music Mode:.............................................................................................................................. 8
DVA Mode: ............................................................................................................................9
Alarm DVA............................................................................................................................................. 10
Program.................................................................................................................................................10
Advanced .............................................................................................................................................. 11
About ....................................................................................................................................................11

RE/DD/UM/REVAC 1.0-01 Page 3
1.Product Description:
REVAC is for the purpose of making announcements, conveying information
and messages needed in a particular location or zone. This find, wide
application in large areas like Hotels, Offices, Hospitals, Factories, commercial
complexes, Airports, Education Institutions and Auditoriums. The consoles
comes in a range begins from 16 Zone Expandable upto 128 zones with
multiplication of 16zones. This console is user friendly system with option of
zone selection for individual zone announcement and common announcement
through microphones.
Product Features:
* Operates on 220V 50 Hz, AC Main switch mode power supply.
* Standby backup 24VDC battery.
* 19”, Rack mountable.
* System ON, Power Fault, Common fault indications.
* Membrane Keypad for user friendly operation.
* Inbuilt amplifier maximum 125 / 250 watts can accommodate in a console.
* Additional Amplifier can expand up to 250W.
* One Inbuilt Microphone for announcement.
* Zone Wise (Speaker line) Selection facility with LED indication.
* Voice / Alarm / Allcall selection facility
* MIC mode selection facility.
* Programmable Mode (Alarm, Mic, Music, DVA) selection facility.
* 100V audio output for Speaker.
* Alarm activated on automatically announcing mode.
* Compatible with RE-900 Series via RS 485 Communication.

RE/DD/UM/REVAC 1.0-01 Page 4
* Voice recording option available only with 250w Amplifier combination.
* DVD Input Facility.
* Zone expansion in Multiples of 16.
Specification:
Primary Power : 220VAC ± 10%, 50 Hz.
Standby Power : 24VDC
Charging Circuit
Charging Voltage : 28 V ±0.2V Nominal
Charging Current : 1.2A (Max.).
Temperature:
Operating Temperature : 0 - 49° C/32-120° F.
Relative Humidity : 93 ± 2% RH (non-condensing) at 32 ±2° C/90 ±3° F.
DC Output : 24 VDC @ Max 3A
Audio
audio output : 100V
Max Wattage : Built-in 125W / 250W ; 500W Max.
Audio Input : Inbuilt MIC & Alarm tone
MIC Type : Hand mobile
Communication Interface : RS-485
Dimensions(3U) : (484 W X 134 H X 325 D)mm

RE/DD/UM/REVAC 1.0-01 Page 5
2.Control and Indications
LED Indication
System ON – Green
Power Fault– Yellow
Common Fault– Yellow
Allcall– Yellow
Alarm– Red
MIC– Yellow
Connection diagram
REVAC is compatible with Conventional RE-900 Series Panel.

RE/DD/UM/REVAC 1.0-01 Page 6
3.Program
MENU KEY - FLOW DIAGRAM
Menu
Key
1. S upp re sse d
Events
2. Mode: Alarm
3. Alarm DVA: D
4. Program
< Alarm >
Defa ult
1. Record
Note:
1. Use Cursor key ( ) to move the menu list and to interchange the status of the menu.
2. Use Enter Key ( ) toselect the menu list and conformthe change of the status.
DE
2. Erase
Recording...
Time : 020 Sec
Erasing...
5.Advanced
5.1 Set Slave
Address : 0
5.2 Configure
Slave
6. About REVAC
Ve rsion 1.0
<Mic >/ < Music> / < DVA
>
54321
654321
Suppressed Events
From the Suppressed Fault Event program screen, By pressing
the “Enter” key the system enters into the Suppressed Fault
Event. In this mode the suppressed fault events can be viewed

RE/DD/UM/REVAC 1.0-01 Page 7
sequentially using the right / left arrow keys during zone output
is ON condition. After entering the suppressed fault events,
screen will be as below. The Suppressed event will be amplifier
power fault, Zone Faults.
Sup-Fault [x /y]
EVENT
Mode
Mode Selection is selected by using the cursor key, then
Enter Key to choose the mode. The REVAC has Four types of
mode namely Alarm, MIC, Music & DVA. In this modes
Display as shown below.
2. Mode: Alarm
< Alarm> < Mic > / < Music> / < DVA
>
Alarm Mode:
The alarm mode shall be selected manually from keypad or
automatically through the RE – 900 via RS485. If the alarm mode is
selected manually then the corresponding zone to be select to
give alarm. The selected zone and mode shall be identified by
corresponding LED’s and also shown in LCD.
If there is a Fault, LCD screen display will be shown below.
AFault [X/Y]
Type of Fault
Where “A” represents in Alarm mode.

RE/DD/UM/REVAC 1.0-01 Page 8
In System Healthy screen the LCD display will be
Alarm Mode
System Healthy
Mic Mode:
The MIC mode is used to announce the invitation / some
messages / information to particular zone by selecting that
particular zone with continuation of MIC mode switch. If the MIC
mode is selected manually then the corresponding zone to be
select to give alarm. The selected zone and mode shall be
identified by corresponding LED’s and also shown in LCD.
If there is a Fault , LCD screen display will be shown below.
M Fault [X/Y]
Type of Fault
Where “M” represents in Mic mode.
In Normal System Healthy screen the LCD display will be
MICMode
System Healthy
Note: If the Alarm signal is received from FACP via RS485, then
REVAC automatically changes to alarm mode with corresponding
Zone.
Music Mode:
The Music mode is used to Play Music file that connected via DVD
I/P, information to particular zone by selecting that particular zone
with continuation of Music mode switch. If the Music mode is
selected manually then the corresponding zone to be select to

RE/DD/UM/REVAC 1.0-01 Page 9
give alarm. The selected zone and mode shall be identified by
corresponding LED’s and also shown in LCD.
If there is a Fault , LCD screen display will be shown below.
S Fault [X/Y]
Type of Fault
Where “S” represents in Music mode.
In Normal System Healthy screen the LCD display will be
Music Mode
System Healthy
DVA Mode:
The DVA mode is used to Play Recorded Messages, information to
particular zone by selecting that particular zone with continuation
of DVA mode switch. If the DVA mode is selected manually then
the corresponding zone to be select to give alarm. The selected
zone and mode shall be identified by corresponding LED’s and
also shown in LCD.
If there is a Fault , LCD screen display will be shown below.
V Fault [X/Y]
Type of Fault
Where “V” represents in DVA mode .
In Normal System Healthy screen the LCD display will be
DVA Mode
System Healthy

RE/DD/UM/REVAC 1.0-01 Page 10
Alarm DVA
Alarm DVA is selected by pressing the no ‘3 ‘ from the menu
screen. The LCD Display will be shown below.
3.AlarmDVA: D DE
D – Disable ; E- Enable
Press Left / Right Key to Enable / Disable the Alarm DVA.
Note:-
If Alarm DVA is in Disable mode, then if any fire is detected
wailing tone will played
If Alarm DVA is in Enable mode, then if any fire is detected
Recorded Message will played
Program
Access to programming is possible only by Admin password
(Default Password – 54321).
By selecting the number 4 from the menu screen, system enters
into the program mode. We can Record a voice and Erase a
voice in this mode.
A)Record.
By pressing the number 1 from the Program screen, the we can
record a voice. The time delay range is 1 to 60 Seconds. The LCD
Display shows as follows.
1. Record Recording...
Time : 020 Sec
B) Erase
By pressing the number 2 from the Program screen, then we can
erase record a voice. The LCD Display shows as follows.

RE/DD/UM/REVAC 1.0-01 Page 11
2. Erase Erasing...
Advanced
Access to advanced is possible only by Advanced password
(Default Password – 654321).
By selecting the number 5 from the menu screen, system enters
into the advanced mode. Here there are two sub headings Set
Slave & Configure are available.
A)Set Slave
The LCD Display of the Set Slave is shown below.
5.1 Set Slave
Address :
B) Configure
The LCD Display of the Configure is shown below.
5.2 Configure
Slave
About
From this menu, by entering ‘ENTER’ key, system enters into the
about screen. The LCD shows as follows with the details of the
model and version.
REVAC
Version 1.0

RE/DD/UM/REVAC 1.0-01 Page 12
