Raven CR7 User manual

Manual No. 016-0171-667 Rev. A EC29613 06/17 1
CR7 Installation Guide
This guide provides an overview of CR7 field computer connections as well as drawings that illustrate the cab
connections for various machine configurations.
CR7 Connections
The image below shows the connections on the back of the CR7 that will be used for installation. Please note
that, depending on machine configuration, some of these connections may not be used.
FIGURE 1. Back of CR7
Wiring Illustrations
The illustrations on the next few pages show CR7 wiring diagrams for various cabling generations with optional
accessories and are for reference only.
Ethernet
Port
I/O Cable
Power
Button
USB Port
Power and
GPS
Connection
2
FIGURE 2. CR7 Basic Installation
Manual No. 016-0171-667 Rev. A EC29613 06/17 3
FIGURE 3. Gen II Cabling CR7 SmarTrax/AccuBoom Only
4
FIGURE 4. Full Gen II Cabling CR7 SmarTrax/AccuBoom
Manual No. 016-0171-667 Rev. A EC29613 06/17 5
FIGURE 5. Gen 3 or IBBC Cabling CR7 SmarTrax/AccuBoom
6
FIGURE 6. Gen 3 or IBBC Cabling CR7 SmarTrax ISO Product Control
Manual No. 016-0171-667 Rev. A EC29613 06/17 7
FIGURE 7. Gen 3 or IBBC Cabling CR7 RS1/ISO Product Control
8
