Overview
The Raven CAN Switch Box is designed to interface with Raven field computers
such as the Envizio Pro and Envizio Pro II and offer product and section control
features at the operator’s finger tips.
The CAN Switch Box features:
• Internal boom sense and speed node and CANbus terminator for simplified
cabling and installation. The CAN Switch Box provides section status
information (based upon switch positions) to the product control console or field
computer for section mapping and rate control adjustments.
• Bright backlit switch panel.
• Four section switches for quick implement section control.
• A Master/Override switch for full boom or implement control.
• An Increase/Decrease switch for quick application rate adjustments.
• A Logic Power LED.
• In addition to the above features, the CAN Switch Box for use with OmniRow
systems offers implement control switches which may be used to control
several functions connected to the OmniRow control system.
Care and Maintenance
Refer to the following items when selecting a mounting location for the CAN
Switch Box and Raven control console.
• The switch box is not weatherproof. Mount the switch box inside of the machine
cab or driver compartment within easy reach of the driver or operator.
• The switch box should be mounted in a location where it will not be jarred during
normal equipment operation. Keep the console and switch box clear of moving
elements within the cab.
• Route all cables to avoid pinching, kinking or damaging the cable and to avoid
tripping hazards.
CAN Switch Box
for OmniRow Systems
(P/N 063-3001-011)

2
Installation
Refer to the following sections to install the console specific mounting bracket and
to connect the CAN Switch Box.
Mounting the CAN Switch Box
Envizio Pro XL Bracket (P/N 107-0172-197)
Note: The supplied mounting bracket must be attached to the Envizio Pro XL so
that the CAN Switch Box is mounted below the field computer.
1. Set the mounting bracket over the mounting posts on the back of the field
computer.
2. Set the RAM mounting arm over the mounting plate and secure using the
screws supplied with the field computer.
3. Align the CAN Switch Box with the remaining predrilled holes and secure using
screws supplied with the switch box.
At Raven Industries, we strive to make your experience with our
products as rewarding as possible. One way to improve this experience
is to provide us with feedback on this manual. Your feedback will help
shape the future of our product documentation and the overall service
we provide. We appreciate the opportunity to see ourselves as our
customers see us and are eager to gather ideas on how we have been
helping or how we can do better. To serve you best, please send an
email with the following information to
[email protected]
-Cruizer II™ Operation Guide
-Manual No. 016-0171-415 Rev. E
-Any comments or feedback (include chapter or page numbers if
applicable).
-Let us know how long have you been using this or other Raven
products.
We will not share your email or any information you provide with anyone
else. Your feedback is valued and extremely important to us.
Thank you for your time.

3
Envizio Pro or Envizio Pro II Bracket (P/N 107-0171-841)
Note: The supplied mounting bracket must be attached to the Envizio Pro or
Envizio Pro II field computer so that the CAN Switch Box is mounted below
the field computer.
1. Set the mounting bracket over the mounting posts on the back of the field
computer.
2. Set the RAM mounting arm over the mounting plate and secure using four
screws (P/N 311-0007-015).
3. Align the CAN Switch Box with the remaining predrilled holes and secure using
two lock washers (P/N 313-4000-007) and two screws (P/N 311-0001-007).
Cable Connections
The CAN Switch Box connects to the control console and CANbus system with
the Viper Pro/Envizio Pro chassis interface cable (P/N 115-0171-926).
To connect the CAN Switch Box:
1. Connect the 4-pin Deutsch connector on the console or interface cable to the
CANbus port on the back of the CAN Switch Box.
2. Connect the 2-pin Deutsch connector on the console or interface cable to the
switched power port on the back of the CAN Switch Box.
3. If connecting to an Envizio Pro using the chassis interface cable (P/N 115-0171-
926), connect the round, 3-pin connector on the interface cable to the speed
sensor port on the back of the CAN Switch Box.
Note: If the CAN Switch Box is connected as instructed above, the switch box will
be powered on or off using the Raven console or field computer switched
power. Refer to the console or field computer manual for instructions to
properly power down the console.
CANbus
Mounting Posts
Switched
Power
Speed
Sensor

4
CAN Switch Box Operation
Important: The CAN Switch Box must be used as the primary control interface
for section, master or product control status.
Make sure to toggle the master switch to the off position when closing or
exiting a job to avoid unintentional product application once the field
computer or control console closes application management functions. It
is also good practice to shut off product and section switches when the
application system is not being used.
The CAN Switch Box puts the section and product control modes right at the
operator’s finger tips.
Refer to the following sections for detailed
operation of the CAN Switch Box:
Logic Power LED
This LED indicates the status of CAN logic
power into the CAN Switch Box. This LED
should be on (solid) during normal
operation.
The Logic Power LED will begin flashing if
low logic power is supplied to the CAN
Switch Box. Troubleshoot the logic power
system before proceeding with operations.
If this LED is not lit when the Raven console or field computer is powered up,
troubleshoot the CANbus system before starting any system operations.
Transport/Plant Mode Switch
The transport mode switch is used lock out switch box functions when the
implement is being transported over the road or when ready for work in the field.
TRANS. Toggle the mode switch to “TRANS” mode when transporting the
implement. This mode allows the operator to use the fold, wing, and latch
features.
PLANT. Toggle the switch to field “PLANT” mode to use the switch box during field
operations.
Transport/Plant
Mode Switch
Logic
Power LED

5
Transport Mode Switch Functions
Note: The implement proximity switch installed with the OmniRow system will
override the section and master switches when the implement is raised to
transport height.
1 - Fold Switch. (Only functional in transport mode) Use the Fold switch to fold or
unfold the implement. Toggle the switch up to fold the implement or down to unfold
the implement.
Note: Operation of this switch requires the implement to be raised to at least the
high field limit position before folding the implement in.
2 - Wing Wheel Switch. (Only functional in transport mode) Use the Wing Wheel
switch to raise or lower the wing wheels.
3 - Latch Switch. (Only functional in transport mode) Use the Latch switch to lock
or unlock the wing folding functions if equipped on the implement during
transportation.
4 - Tool Bar Raise/Lower Switch. In transport mode, the Tool Bar switch will only
actuate the implement valves while the switch is held. Hold the Tool Bar switch in
the up position to raise the implement or in the down position to lower the
implement.
Plant Mode Switch Functions
1 - Marker Mode Switch. Toggle the marker mode to select the left marker, right
marker, or automatic marker control modes.
Select the left or right marker to manually raise or lower the left or right marker
using the marker function switch.
Set the marker mode switch to automatic (AUTO) to control each marker in
sequence during an active job.
Note: The automatic marker mode will only function while in an active job on the
field computer. If the field computer is not in an active job, toggling the
switch to the up position will raise both markers simultaneously. The down
position will not function outside of an active job with the Marker Mode
switch set to automatic.
123
4
12
7654
3
8

6
2 - Marker Raise/Lower Function Switch. Toggle the marker function switch to
raise or lower the implement markers as determined by the Marker Mode switch.
To utilize the automatic marker control mode during an active job:
1. Toggle the Marker Mode switch to the AUTO position.
2. Toggle the Marker Function switch to the down position to lower the first marker.
3. At the end of the swath, toggle the Function switch to the up position to raise the
first marker.
4. When starting the next swath, toggle the Function switch to the down position to
lower the second marker in sequence.
3 - Tool Bar Raise/Lower Switch. In plant or field mode, hold the Tool Bar switch
in the up position for at least two seconds to automatically raise the implement to
the field high limit position. Hold the Tool Bar switch in the down position for at
least two seconds to automatically lower the implement for 10 seconds.
4 - Auxiliary (AUX) Controls Switch. Toggle the AUX switch on (I) or off (O) to
engage the fan or vacuum system or a down pressure control system connected
to the OmniRow system for seed handling and singulation.
5 - Lights Switch. The Lights switch may be connected to a work light system or
provide auxiliary output for general purpose use.
6 - Section Switches. The 3-way selectable section switches may be used to
toggle each section (up to four individual sections).
The section switches may be used to toggle up to ten individual sections. Raven
field computers are also capable of controlling additional sections using the
section mapping feature to group sections to the same switch. Refer to the field
computer Installation and Operation Manual for additional information.
Note: Envizio Pro software version 3.5 or newer is required to access section
mapping. Contact a local Raven dealer for additional information.
Each of the four section switches may be toggled individually to one of the three
following positions:
• ON - manually control the section on. AccuBoom control of the section is
disabled and will not automatically control this section based on coverage, zone
maps or field boundaries.
• ACCU - AccuBoom automatic section control is enabled for the section. If
installed and properly set up for the active job, the AccuBoom features will
automatically turn sections on or off based upon previous coverage, zone maps
or field boundaries created or active in the job.
Refer to the control console or field computer operation manual for more
information about using the AccuBoom system.
• OFF - manually control the section off. This section will remain off regardless of
AccuBoom control features.
Note: Leave the section switch in the off position for any sections not connected
or controlled by the Raven control console or field computer.

7
7 - Increase/Decrease Rate Switch.
Note: The INC/DEC switch only controls the selected product in automatic or
manual mode. Refer to the field computer or control console manual for
more information on selecting products during application.
For selected products set to automatic control mode, the INC/DEC switch is used
to increase or decrease the target rate of products selected and actively displayed
on the console or field computer.
In order for this switch to work properly, a ‘Rate Bump’ (Rate +/-) value must be
programmed for each product. Refer to the control console or field computer
operation manual for more information on programming this feature.
For selected products set to manual control mode, holding the INC/DEC switch
will open or close the product control valve, increasing or decreasing the flow of
product respectively. Refer to the control console or field computer operation
manual for instructions on programming products or switching a product to
manual mode.
8 - Master/Override Switch. The master switch toggles all section switches on or
off. When the master switch is in the ‘ON’ position, each section will function
according to the corresponding section switch (see the “Section Switches” section
on page 6). Toggle the master switch to the ‘OFF’ position to turn all boom or
implement sections off.
Toggle the master switch to the ‘OVERRIDE’ position to operate all seed disks
one full revolution to prime the seed disks. Holding the master switch in the
‘OVERRIDE’ position will temporarily override any sections controlled by an
optional AccuRow system on.

8
Troubleshooting
General Issues
Issue Possible
Cause Solution
Console or field
computer does
not power up No power to
console
Check chassis cable battery
connections.
Check chassis cable fuses.
Logic power
LED not lit No power to CAN Switch Box
Check CAN Switch Box switched power
connection.
Ensure console or field computer is
powered on.
Check chassis cable power and ground
connections.
Check chassis cable fuses.
Console or field
computer not
detecting CAN
nodes
CAN Switch Box
notconnectedto
CANbus
Check CANbus connector on CAN
Switch Box.
Check CAN connections and cabling.
Check CAN terminator on end of
CANbus line.
Check for +12 volts on switched power
connector.
Console not set
up for CANbus
control
Verify that the console or field computer
product control configuration is set to
CAN.
Boom valves do
not turn on Faulty CAN high
current power
connection
Verify high current (HC) power LED on
product controller node is lit. If LED not
lit, refer to troubleshooting information
in control console or field computer
manual.
Boom sections
do not turn off
Remote section
switches in
incorrect
position
Remote section switches must be in the
OFF position to allow the CAN Switch
Box to control sections.

9
Setup Issues
Job Issues
Issue Possible
Cause Solution
Previous
calibration data
lost Poor CAN
connections Refer to the “CAN Troubleshooting” section on page 11.
Issue Possible
Cause Solution
Section status
displays as
inactive
CAN Switch Box
switches in the
off position Toggle the section and master switches
to the on position.
Automatic
section control
enabled but
sections do not
turn on
Check the speed sensor connection on
the back of the CAN Switch Box.
Move vehicle into a previously
unapplied area and maintain a speed of
at least
0.7 mph [1.1 km/h].
Enable the Override feature on the
control console or field computer
Section status
does not turn
green (ON)
when sections
enabled
Master switch
must be toggled
off at power-up Cycle the master switch off then back
on.
Sections not
properly
configured Verify section setup on the control
console or field computer.
Nodes not
programmed
properly Verify all node calibration data is
entered.
Product function
switches do not
work
Master switch
must be toggled
off at power-up Cycle the master switch off then back
on.
Product
application
turned off
Toggle product control switches to
AUTO or MAN mode to turn product(s)
on.

10
Product applied
to zero rate
zones
Wrong valve
type installed
A fast close or PWM close valve must
be selected to shut off product
application in zero rate zones. Refer to
field computer or control console
manual for more information about
selecting valve type.
Incorrect valve
setting Check valve or PWM settings.
Sectionswitches
toggled on in
zero rate zones Toggle the section switches to the
ACCU or OFF positions.
Sections
enabled but field
computer not
recording
coverage
Remote section
switches left in
the ON position
Toggle all remote section switches to
the off position. Remote switches will
override the section switch status and
automatic section control features.
Issue Possible
Cause Solution

11
CAN Troubleshooting
Although the control algorithm is located within the CAN node(s), the same
troubleshooting techniques that apply to traditional hard wired control systems still
apply to a CANbus control network. CAN allows for modularization of the control
system, but the behavior of the system remains the same. Flow and speed
sensors, the control valve and any boom valves, are used in the same manner.
The following are some common causes for communication failures:
Issue Possible
Cause Solution
Console or
CANbus cannot
find nodes
Switch Box is
not properly
connected
Check switched power connection.
Check the CANbus connection to the
Switch Box and reinitialize the console
to detect the Switch Box nodes.
Ensure console is powered on.
No power to
Switch Box Check chassis cable power and ground connections.
Weak or dirty
power to CAN
nodes Verify at least +10V DC is present on
the switched power connector.
Corrosion in
CAN
connections Disconnect and clean the cable
connections
CANbus not
terminated
properly Check the CAN Terminator(s)

Raven Industries will not assume any expense or liability for
repairs made outside our facilities without written consent.
Raven Industries is not responsible for damage to any
associated equipment or products and will not be liable for
loss of profit, labor, or other special damages. The obligation
of this warranty is in lieu of all other warranties, expressed or
implied, and no person or organization is authorized to
assume any liability for Raven Industries.
Damages caused by normal wear and tear, misuse,
abuse, neglect, accident, or improper installation and
maintenance are not covered by this warranty.
What is not Covered by this Warranty?
Upon confirmation of the warranty claim, Raven Industries will
(at our discretion) repair or replace the defective product and
pay for the standard return freight, regardless of the inbound
shipping method. Expedited freight is available at the
customer’s expense
What Will Raven Industries Do?
Bring the defective part and proof of purchase to your Raven
dealer. If the dealer approves with the warranty claim, the
dealer will process the claim and send it to Raven Industries
for final approval. The freight cost to Raven Industries will be
the customer’s responsibility. The Return Materials
Authorization (RMA) number must appear on the box and all
documentation (including proof of purchase) must be
included inside the box to be sent to Raven Industries.
How Can I Get Service?
Raven Applied Technology Division products are covered by
this warranty for 12 months from the date of retail sale. In no
case will the Limited Warranty period exceed 24 months from
the date the product was issued by Raven Industries Applied
Technology Division. This warranty coverage applies only to
the original owner and is non-transferable.
How Long is the Coverage Period?
This warranty covers all defects in workmanship or materials
in your Raven Applied Technology Division product under
normal use, maintenance, and service when used for
intended purpose.
What Does this Warranty Cover?
RAVENINDUSTRIES
Limited Warranty

Raven Applied Technology products that have been registered online are
covered for an additional 12 months beyond the Limited Warranty for a
total coverage period of 24 months from the date of retail sale. In no case
will the Extended Warranty period exceed 36 months from the date the
product was issued by Raven Industries Applied Technology Division.
This Extended Warranty coverage applies only to the original owner and
is non-transferable.
How Long is the Extended Warranty Coverage Period?
To register, go online to www.ravenhelp.com and select Product Registration.
Where Can I Register My Product for the Extended Warranty?
Yes. Products/systems must be registered within 30 days of retail sale to
receive coverage under the Extended Warranty. If the component does
not have a serial tag, the kit it came in must be registered instead.
Do I Need to Register My Product to Qualify for
the Extended Warranty?
This warranty covers all defects in workmanship or materials in your
Raven Applied Technology Division product under normal use,
maintenance, and service when used for intended purpose.
What Does this Warranty Cover?
RAVENINDUSTRIES
Extended Warranty
Raven Industries will not assume any expense or liability for repairs made
outside our facilities without written consent. Raven Industries is not
responsible for damage to any associated equipment or products and will
not be liable for loss of profit, labor, or other damages. Cables, hoses,
software enhancements, and remanufactured items are not covered by
this Extended Warranty. The obligation of this warranty is in lieu of all
other warranties, expressed or implied, and no person or organization is
authorized to assume any liability for Raven Industries.
Damages caused by normal wear and tear, misuse, abuse, neglect,
accident, or improper installation and maintenance are not covered
by this warranty.
What is Not Covered by the Extended Warranty?
Upon confirmation of the product’s registration for the Extended Warranty
and the claim itself, Raven Industries will (at our discretion) repair or
replace the defective product and pay for the standard return freight,
regardless of the inbound shipping method. Expedited freight is available
at the customer’s expense
What Will Raven Industries Do?
Bring the defective part and proof of purchase to your Raven dealer. If the
dealer approves with the warranty claim, the dealer will process the claim
and send it to Raven Industries for final approval. The freight cost to
Raven Industries will be the customer’s responsibility. The Return
Materials Authorization (RMA) number must appear on the box and all
documentation (including proof of purchase) must be included inside the
box to be sent to Raven Industries. In addition, the words “Extended
Warranty” must appear on the box and all documentation if the failure is
between 12 and 24 months from the retail sale.
How Can I Get Service?

Notice: This document and the information provided are the property of Raven
Industries, Inc. and may only be used as authorized by Raven Industries, Inc.
All rights reserved under copyright laws.
Raven Industries
Applied Technology Division Toll Free (U.S. and Canada): (800)-243-5435
P.O. Box 5107 or Outside the U.S. :1 605-575-0722
Sioux Falls, SD 57117-5107 Fax: [phone]
www.ravenprecision.com www.ravenhelp.com
©Raven Industries, Inc. 2013
CAN Switch Box™
for use with OmniRow Systems
Installation & Operation Guide
(P/N 016-0171-545 Rev A 2/13 E21066)
