Raycus ABP Series User manual

Raycus ABPSeries High Power
Continuous Wave Fiber Laser User
Guide
Applicable:
RFL-1500/1500-ABP
RFL-2000/2000-ABP
RFL-3000/3000-ABP
RFL-4000/2000-ABP
RFL-2000/4000-ABP
RFL-4000/4000-ABP
RFL-6000/6000-ABP
Wuhan Raycus Fiber Laser Technologies Co.,
Ltd.

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C3000XZ~RFL-C12000XZ
CONTENT
1SAFETY INFORMATION....................................................................................................................................................2
1.1 SECURITY LABEL.........................................................................................................................................................2
1.2 LASER SAFETY GRADE......................................................................................................................................................3
1.3 OPTICALSAFETY...............................................................................................................................................................3
1.4 ELECTRICALSAFETY.........................................................................................................................................................3
1.5 OTHER SAFETY GUIDELINES .............................................................................................................................................4
2PRODUCT DESCRIPTION..................................................................................................................................................5
2.1 FEATURES..........................................................................................................................................................................5
2.2 PACKAGE PARTS ................................................................................................................................................................5
2.3 UNPACKING AND INSPECTION............................................................................................................................................5
2.4 OPERATION ENVIRONMENT...............................................................................................................................................6
2.5 ATTENTIONS......................................................................................................................................................................7
2.6 SPECIFICATIONS.................................................................................................................................................................7
3INSTALLATION....................................................................................................................................................................9
3.1 DIMENSIONS......................................................................................................................................................................9
3.2 INSTALLATION REQUIREMENTS.......................................................................................................................................12
3.3 COOLING REQUIREMENTS...............................................................................................................................................14
3.3.1 Requirements for CoolingWater:............................................................................................................................14
3.3.2 Requirements for DeliveryCable CoolingSystem:..................................................................................................15
3.3.3 Other Requirements:...............................................................................................................................................16
4USING THE PRODUCT .....................................................................................................................................................17
4.1 FRONT PANEL..................................................................................................................................................................17
4.2 REAR PANEL....................................................................................................................................................................18
4.3 POWER CONNECTION......................................................................................................................................................20
4.4 CONTROLINTERFACE DEFINITION ..................................................................................................................................22
4.4.1 Safety XP2 24 PinInterface ....................................................................................................................................23
4.4.2 Hardwire XP1.........................................................................................................................................................26
4.4.3 XP3 RS232 Interface ..............................................................................................................................................29
4.4.4 XP4 Analog Interface .............................................................................................................................................29
4.4.5 XP5 Ethernet Interface...........................................................................................................................................29
4.5 INTERLOCKING................................................................................................................................................................30
4.6 SCHEMATIC DIAGRAM OF THE LASER ELECTRICALCIRCUIT...........................................................................................30
4.7 OPERATION START-UPS SEQUENCES................................................................................................................................31
5CONTROL MODE SELECTION ......................................................................................................................................32
5.1 ON MODE .......................................................................................................................................................................33
5.1.1 AD Mode Enable ....................................................................................................................................................34
5.1.2 Emission External ControlEnable..........................................................................................................................34
5.1.3 Guide laser (Red Guide Beam) Control.................................................................................................................34
5.1.4 Programming Mode................................................................................................................................................34
5.2 REM MODE.....................................................................................................................................................................34
5.2.1 AD Mode.................................................................................................................................................................34
5.2.2 External Control.....................................................................................................................................................35
5.2.3 Guide laserControl.................................................................................................................................................35
5.2.4 Programming Mode................................................................................................................................................35
6LASER WIRING MODE AND OPERATION STEPS ....................................................................................................36
6.1 INTERNALCONTROLIN ON MODE ..................................................................................................................................36
6.2 LASER OPERATINGIN EXTERNALCONTROLMODE...........................................................................................................36
6.3 IN ON MODE,THE LASEREMISSION POWERIS EXTERNALLYCONTROLLEDBY ANALOGSIGNAL.....................................37
6.4 LASER OPERATINGIN PROGRAMMINGMODE...................................................................................................................38
6.5 SET THE POWERANALOGQUANTITYIN REM MODE TO CONTROLTHE LASEREMISSION.................................................39

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C3000XZ~RFL-C12000XZ
6.6 POWER COMMUNICATION SETTING IN REM MODE........................................................................................................40
6.7 PROGRAMMING MODE IN REM MODE............................................................................................................................41
7RS232 AND INTERNET COMMUNICATION COMMANDS ......................................................................................43
7.1 PORT CONFIGURATION ....................................................................................................................................................43
7.2 LASER COMMUNICATION PROTOCOL (ETHERNET PORT &SERIALPORT).......................................................................43
8RAYCUS LASER CONTROL SYSTEM INSTRUCTIONS ...........................................................................................48
8.1 MAIN INTERFACE OF THE SOFTWARE..............................................................................................................................48
8.2 MULTI-LASER CONTROL..................................................................................................................................................48
8.2.1 Add/DeleteLaser.....................................................................................................................................................49
8.2.2 Delete Laser............................................................................................................................................................50
8.2.3 Modify Laser IP......................................................................................................................................................50
8.3 MAIN WORKINGSTATUSDISPLAY....................................................................................................................................51
8.3.1 Laser’s CumulativeOperatingTimeDisplayArea ....................................................................................................52
8.3.2 Laser WorkingStatusDisplayArea...........................................................................................................................52
8.3.3 Laser Power-up, Mode Selection, Laser Emission Control Area ..........................................................................53
8.3.4 Programming Mode Test Area................................................................................................................................54
8.3.5 Power Slow Rise & Down Parameter Setting Area ...............................................................................................55
8.3.6 Laser Emission Parameters Read the SettingsArea...............................................................................................56
8.4 LASER PARAMETER DISPLAYAREA..................................................................................................................................57
8.5 ALARM TYPEDISPLAYAREA............................................................................................................................................57
8.6 RING LIGHT PARAMETERS SETTING................................................................................................................................58
8.7 RAYCUS LASER CONTROL SOFTWARE OPERATING MODE SELECTION............................................................................59
8.8 LANGUAGE......................................................................................................................................................................60
8.9 AUTHORIZATION (TIME-LIMITED LOCKING) ...................................................................................................................60
8.9.1 Authorization in UserMode....................................................................................................................................60
8.9.2 Authorization in Authorization Mode.....................................................................................................................61
8.10 ABOUT.............................................................................................................................................................................63
8.11 LOG (IN DIAGNOSTICMODE)...........................................................................................................................................64
8.11.1 Download Log........................................................................................................................................................64
8.11.2 Download Record of HistoricalFault.....................................................................................................................64
8.11.3 Downloaded FileAddress .......................................................................................................................................65
8.12 MODULE PARAMETERS (IN DIAGNOSTICMODE) .............................................................................................................65
8.13 PROGRAMMING SETTINGS (WAVEFORMEDITING)...........................................................................................................66
8.13.1 View the Number of WaveBarsInside the CurrentLaser.........................................................................................66
8.13.2 Check WaveformContent ........................................................................................................................................66
8.13.3 Empty AllWaveforms...............................................................................................................................................67
8.13.4 Edit Waveform ........................................................................................................................................................67
8.13.5 Command Explanations .........................................................................................................................................69
9WARRANTY, REPAIRAND RETURN ............................................................................................................................71
9.1 GENERALWARRANTY .....................................................................................................................................................71
9.2 LIMITATIONS OF WARRANTY...........................................................................................................................................71
9.3 SERVICEAND REPAIR.......................................................................................................................................................71

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C3000XZ~RFL-C12000XZ
Figure List
Figure 1 Dimensions of RFL-1500/1500-ABP........................................................................................................................9
Figure 2 Dimensions of RFL-4000/4000-ABP......................................................................................................................10
Figure 3 Dimensions of RFL-6000/6000-ABP......................................................................................................................11
Figure 4 External dimensions of the RFL-HQBH fiberdeliverycable connector ..................................................................12
Figure 5 External dimensions of the RFL-QD fiberdeliverycable connector........................................................................12
Figure 6 Product top lifting rings and bottom level adjustment casters.................................................................................13
Figure 7 Schematic diagram of laser cooling system connection..........................................................................................15
Figure 8 Front panel ...............................................................................................................................................................17
Figure 9.-View of laser rear panel..........................................................................................................................................20
Figure 10 Power cords of differentmodels.............................................................................................................................21
Figure 11 Power cordplug and socket ....................................................................................................................................21
Figure 12 Control signal connectors ......................................................................................................................................23
Figure 13 Mod signal schematic diagram ..............................................................................................................................24
Figure 14 Internal schematic diagram....................................................................................................................................25
Figure 15 Recommended wiring diagram..............................................................................................................................25
Figure 16 Internal circuit diagram..........................................................................................................................................25
Figure 17 Recommend wiring diagram..................................................................................................................................26
Figure 18 Recommended wiringdiagram...............................................................................................................................26
Figure 19 XP2 Remote mainpowersupplywiringdiagram......................................................................................................26

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C3000XZ~RFL-C12000XZ
Table List
Table 1 Operation conditions for the laser ...............................................................................................................................6
Table 2 Product specifications..................................................................................................................................................7
Table 3 Water cooling requirements.......................................................................................................................................14
Table 4 Definition and parameter requirements of AC interface...........................................................................................22
Table 5 Safety XP2 24 pin interface definition......................................................................................................................23
Table 6 XP1 Hardwire interface definition ............................................................................................................................27
Table 7 XP3 serial interface definitions .................................................................................................................................29
Table 8 XP4 analog interface definitions ...............................................................................................................................29
Table 9 XP5 communication interface definition...................................................................................................................29
Table 10 Control modes and their subsequent operating methods.........................................................................................32
Table 11 Laser protocol contents and command examples....................................................................................................43
Table 12 The laser main display content and meanings.........................................................................................................51
Table 13 The laser main display area clarification.................................................................................................................53
Table 14 Laser power-on, mode selection, laser emission control display area explanation ................................................54
Table 15 Laser operating mode and explanation....................................................................................................................59
Table 16 Command explanations in laser working status......................................................................................................69

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C3000XZ~RFL-C12000XZ
2
1Safety Information
Thank you for choosing Raycus Fiber Laser Products, hereinafter refers as the Product/Products or
Lasers/Laser. This users’ manual provides you with important safety, operation, maintenance, and other
relevant information. Please read the manual carefully before using the product. To ensure safe operation
and optimum product operation, please observe the following cautions and warnings as well as other
information within this manual.
1.1 SECURITY LABEL
WARNING: May cause serious injury to the person or even endanger
the safety of life.
CAUTION: May cause general injury to the person or damage to
products or equipment.
English label
Chinese label
English label
Chinese label
English label
Chinese label
1. LaserEmission
Aperture
2．Class 4 LaserProduct
3．Class 2M laserProduct
–1 mWGuide laser
4．CE Certification
5．Product Nameplate
6．LaserRadiation Hazard

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C3000XZ~RFL-C12000XZ
3
7. Electrical Hazard
1.2 Laser Safety Grade
According to European Standard EN 60825-1, Clause 9, this series of laser products are Class 4 laser
products. This productemitslaser radiation ata wavelengthof 1080 nmor around 1080 nm, and the average
laser power of the products listing in this User Guide radiated from the fiber delivery cable is ranged from
3000W to 12000W (depending on the product model). Either directly or indirectly being exposed to high
power laser radiation will bring permanent damage to the eye or skin. Even though the radiant laser is not
visible at the wavelength of about1080nm, the beam will cause irreparable damage to the retina or cornea,
so appropriate and certified laser safety glasses must be worn throughout the laser emitting.
WARNING: Users must wear appropriate laser goggles when operating
this device. The laser goggles should be selected according to the range
of wavelength emitted from this product. Users must ensure that the
protect range of laser goggles over the entire range of laser wavelengths.
It is forbidden to watch the laser fiber delivery connector during laser
emission.
1.3 Optical Safety
The dust on the end of the fiber delivery connector may bring damage to the lens or the entire laser
device.
CAUTION: DO NOT emit the laser when the black plastic protective
cap is not removed, otherwise the lens or the crystal will be damaged.
1.4 Electrical Safety
a) Ensure that the product is effectively grounded, and the installation environment is safe and
reliable.

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C3000XZ~RFL-C12000XZ
4
WARNING: The disconnection of the product grounding will cause the
product shell to become electrified, which may result in personal injury
to the operator.
b) Ensure that the AC voltage is supplied normally.
CAUTION: Wrong wiring mode or power supply voltage will cause an
irrecoverable damage to the laser device.
1.5 Other Safety Guidelines
a) DO NOT watch the fiber delivery connector of the product directly by anytime when the product
is powered on.
b) DO NOT use the product in a dark or dim place.
c) If the product is used in a manner not specified in this document, the resulted impairment to the
laser will not be covered by the warranty.
d) There are no user serviceable parts, equipment, or assemblies inside the product. All service and
maintenance shall be performed and conducted by the Raycus engineer or authorized personnel.
In order to prevent electric shock, DO NOT break the seal or remove the shell. Failure to comply
with this instruction and the resulted impairment to the laser will not be covered by the warranty.

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C3000XZ~RFL-C12000XZ
5
2Product Description
2.1 Features
Fiber lasers are compact and ready to use in comparison with conventional laser products, featuring
higher electrical to optical conversion efficiencies, lower power consumption and better beam quality.
Furthermore, thanks to its flexible laser emission design by using a shielded optical fiber, it can be easily
and safely integrated into a varies of laser application systems.
Main features:
a) High beam quality;
b) Adjustable output beam;
c) Center/ring power adjusted independently;
d) High reliability
e) Maintenance-free operation;
f) High electrical-optical efficiency;
g) Convenient control interface;
h) Fast modulation.
Typical Applications:
a) Power battery welding and high anti mental welding;
b) Scientific research.
2.2 Package Parts
Please refer to the enclosed Package Parts List to cross check what accessories should be contained in
the packing box.
2.3 Unpacking and Inspection
Through the specially designed packaging materials and cabinets, Raycus ensures that the lasers are
fully protected during the transportation. Nevertheless, in order to prevent any unpredictable situation
during transportation, the users still need to carefully check whether the package is correctly handled before
unpacking, and whether there is any damage or suspicious appearance such as collision, crack or water
stain on the outside of the box. Once users find that there is an abnormality in the external cabinet, please
inform Raycusat once.
Please double check if each listed content is inside the package;and contact Raycus assoon as possible
if there is any unusual issue.
Take extra care when removing the product from the package and try to make the fiber delivery cable

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C3000XZ~RFL-C12000XZ
6
with its connector staying away from collision and vibration. Please DO NOT distort, bend, or pull the
delivery cable when unpacking the device; and avoid any collision to the quartz or protective cap of laser
emission.
CAUTION: The fiber delivery cable and its connector are precise optic
instrument, any vibration or impact to the fiber delivery cable or connector, twist
or excessive bend will damage the product.
2.4 Operation Environment
The required operation conditions are listed as in the Table 1:
Table 1 Operation conditions for the laser
Model
1500/1500
2000/2000
3000/3000
2000/4000
4000/2000
4000/4000
6000/6000
Supply Voltage
Three-phase four-wire, AC 323V~AC 437V, 50/60Hz (with PE)
Power Supply Capacity
＞15 kVA
> 18 kVA
> 25 kVA
> 25 kVA
> 25 kVA
> 35 kVA
>50 kVA
Water Cooling Flow
＞35 L/min
> 35 L/min
> 52 L/min
> 52 L/min
> 52 L/min
> 64 L/min
> 94 L/min
Installation Environment
Flat, no vibration nor impact
Ambient Temperature
10℃~ 40 ℃
Relative Humidity
＜70%
a) Make sure the product is properly grounded before use.
b) Thefiber delivery cable connector is well connected withthe fiber optic cable (delivery cable). Please
inspect the fiber delivery cable connector carefully for dust or other contaminations. Use appropriate
lens cleaning paper to remove the dust before laser emission.
c) Failure to follow the instructions when using the laser may cause malfunction or damage.
d) DO NOTinstall the fiber delivery cable connector during laser emission.
e) DO NOT watch the fiber delivery cable connector lens directly if the laser is powered on. MUST
wear the appropriate protective goggles all the time when operating the laser.
TIPS:
Install the laser in an air-conditioned environment will offer the product to benefit a longer life and
better performance.

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C3000XZ~RFL-C12000XZ
7
2.5 Attentions
a) Make sure that the mail power supply of AC 380V correctly connected. Wrong connection will
damage the product.
b) It is important to keep the fiber delivery cable connector clean, otherwise it will damage the product.
c) Please cap the fiber delivery cable connector when it is not in use. DO NOT touch the top lens of
the connector at any time. Use appropriate lens cleaning paper to clean it when any dust or dirt is
noticed.
d) Keep the cap safety in the storage box when using the product. To avoid dust inside the cap that may
pollute the lens of the connector, make sure the opening direction of the cap is put down.
e) Failure to follow those above instructions may cause laser power loss, such loss will not be covered
by warranty.
2.6 Specifications
Table 2 Product specifications
Optical Characteristics
Test condition
Product
1500/
1500
2000/
2000
3000/
3000
2000/
4000
4000/
2000
4000/
4000
6000/6000
Emission Power
3kW
4kW
6kW
6kW
6kW
8kW
12 kW
/
Center emission
power
1.5 kW
2 kW
3 kW
2 kW
4 kW
4 kW
6 kW
Ring emission
power
1.5 kW
2 kW
3 kW
4 kW
2 kW
4 kW
6 kW
Operation Mode
Continuous Wave / Modulated
/
Polarization
Random
/
Emission Power
Range
10%～100%
/
Emission
Wavelength
1080±5 nm
Nominal Emission
Power
Emission Power
Instability
±1.5%
Nominal Emission
Power；Continuous
running time：
greater than 5hrs；
operating
temperature ：
25℃
Modulation
Frequency
50~5000Hz
50~2000Hz
Nominal Emission
Power
Red GuideLaser
Power
0.5mW～1mW
/
Fiber delivery
cable connector
IHQB
QD
/
Center Beam
Quality *(86%)
(BPP,mm•mrad
)
＜2.2（@50um）/ ＜4（@100um）
Nominal Emission
Power
Centerbeam
mrad*(86%)
（mrad）
＜90(@50um) / ＜90（@100um）
Nominal Emission
Power

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C3000XZ~RFL-C12000XZ
8
Ring Beam
Quality*(86%)
(BPP,mm•mrad
)
＜7.0(@50um) / ＜17（@300um）
Nominal Emission
Power
Ring beam
mrad*(86%)
（mrad）
＜100(@150um) / ＜110（@300um）
Nominal Emission
Power
Centerbeam
Fiber Core
Diameter
(μm)
50、100 um、Customizable
100 um
Customizable
Ring beam
Fiber Core
Diameter
(μm)
150、300 um、Customizable
300 um
Customizable
Fiber Delivery
Cable Length
20 m
Customizable
Electrical Characteristics
Operating
Voltage
Three-phase four-wire system AC 340V ~ 420V, 50/60Hz (with PE)
/
Max.Power
Consumption
9kw
11.5kw
17.5kw
17.5kw
17.5kw
23kw
34.5kw
/
Way to Control
Serial Communication / AD
/
Other Characteristics
/
Dimension
W×H×D
670×990×
1160mm
900×960×1160mm
1200×960
×1160mm
Includes casters and
rings, without
warning lights
Weight
＜250kg
＜360kg
＜
400kg
＜500kg
Air conditioning
included
Operating
Ambient
Temperature
10～40°C
/
Humidity
＜70 %
/
Storage
Temperature
-10～60°C
/
Cooling Method
Water Cooling
/

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C3000XZ~RFL-C12000XZ
9
3Installation
3.1 Dimensions
The mechanical dimensions of RFL-1500/1500-ABP，RFL-2000/2000-ABP，RFL-3000/3000-ABP，
RFL-2000/4000-ABP ，RFL-4000/2000-ABP ，RFL-4000/4000-ABP and RFL-6000/6000-ABP are
shownas follow:
a) The dimensions of the RFL-1500/1500-ABP，RFL-2000/2000-ABPare shown in Figure 1 (taking
RFL-1500/1500-ABP as an example).
Figure 1.a - Front and rear view
Figure 1.b - Top and leftside view of the product
Figure 1 Dimensions of RFL-1500/1500-ABP
Those two models of RFL-1500/1500-ABP and 2000/2000-ABP share a same cabinet, henceforth
the same dimensions of 670×990×1160mm (width ×depth ×height, including casters and rings,
excluding the stats lamps), and the weight is about 250kg forRFL-1500/1500-ABP, and about 280kg
for RFL-2000/2000-ABP.

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C3000XZ~RFL-C12000XZ
10
b) The dimensions of the RFL-3000/3000-ABP，RFL-2000/4000-ABP，RFL-4000/2000-ABP，RFL-
4000/4000-ABPare shown in Figure 2 (taking RFL-4000/4000-ABP as an example)
Figure 2.a - Front and rear view
Figure 2.b -Top and left side view
Figure 2 Dimensions of RFL-4000/4000-ABP
RFL-3000/3000-ABP ，RFL-4000/2000-ABP ，RFL-2000/4000-ABPand RFL-4000/4000-ABP
share a same cabinet, and henceforth the same dimensions of 900×960×1160 mm (width ×depth ×
height, casters and rings, excluding alarm lights), and the weight is less than 400kg for all four types
of laser.
c) dimensions of the RFL-6000/6000-ABP are shown in Figure 3:

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C3000XZ~RFL-C12000XZ
11
Figure 3.a - Front and rear view
Figure 3.b - Top and left side view
Figure 3 Dimensions of RFL-6000/6000-ABP
RFL-6000/6000-ABP share a cabinet, and henceforth the same dimensions of 1200×960×1160 mm
(width ×depth ×height, casters and rings, excluding alarm lights), and the weight is about 500kg
for RFL-6000/6000-ABP.
The type and dimensions ofRFL-1500/1500-ABP，RFL-2000/2000-ABP，RFL-3000/3000-ABP，
RFL-2000/4000-ABP ，RFL-4000/2000-ABP ，RFL-4000/4000-ABP ，RFL-6000/6000-ABP’s fiber
delivery cable and cable connector are as follows:
a) RFL-1500/1500-ABP，RFL-2000/2000-ABP，RFL-3000/3000-ABP，RFL-2000/4000-ABP，RFL-
4000/2000-ABP，RFL-4000/4000-ABPuses the RFL-HQBH model cable connector, and the
external dimensions of the cable connector are shown in Figure 4:

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C3000XZ~RFL-C12000XZ
12
Figure 4 External dimensions of the RFL-HQBH fiber delivery cable connector
b) RFL-6000/6000-ABP uses the RFL-QD model cable connector, and the external dimensions of the
output optical cable connector are shown in Figure 5:
Figure 5 External dimensions of the RFL-QD fiber delivery cable connector
NOTE:
a) The dimensions in the above figures are in the unit of mini-meter (mm).
b) Before the laser is powered on, make sure that the two copper contacts (interlock pins) on the fiber
connector are shorted well, otherwise the laser will not work properly.
c) Before installing the fiber delivery cable connector into the laser processing head, the lens of the
fiber delivery cable must be inspected carefully.
d) If the fiber delivery cable lens is dirty, the lens must be cleaned well. It is forbidden to disassemble
the protective lens by anyone other than staff of Raycus or Raycus authorized personnel, otherwise
the warranty will be invalidated.
3.2 Installation Requirements
a) Place the laser horizontally in a suitable position and fix it as necessary;
b) Before the laser is powered on, check if the power supply has the correct voltage (AC 323V ~ 437V,
50/60Hz, see Table 2 Product Technical Data Sheet for details), and the grounding line (PE)shall be
well grounded all time during powering on;

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C3000XZ~RFL-C12000XZ
13
c) Connect the power cable and control cable to the product when power supply is OFF;
d) Connect the cooling system to the laser and output optical cable connector according to the water
inlet and outlet signs;
e) Please check the laser fiber delivery connector and make sure to clean it before installing it in the
equipment;
f) DO NOT step on, squeeze, or excessively bend the protective tube during the installation of the
output optical cable to avoid damage to the optical fiber;
g) In the process of installing the fiber delivery connector, ensure the cleanliness of the surrounding
environment (DO NOT use electric fans to dissipate heat when it is hot in summer to avoid large
dust in the air);
h) The minimum bending diameter of the laser transmission cable in non-working conditions such as
transportation and storage shall not be less than 20cm. When the laser is emitting, the minimum
bending diameter shall not be less than 30cm;
i) Users can use the four rings on the top of the product to carry the product or the four casters at
bottom to move it. As Figure 6, and MUST check that the rings are firmly installed and that the
casters are fully active before lifting the laser.
Figure 6.a - Lifting Rings (RFL-4000/4000-ABP as an example)
Figure 6.b - Leveling casters (RFL-40000/40000-ABP as an example)
Figure 6 Product top lifting rings and bottom level adjustment casters
Lifting Rings
环环
环环
Lifting Rings
Horizontal adjustment caster
Horizontal adjustment caster

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C3000XZ~RFL-C12000XZ
14
CAUTION: All the cables can only be connected when power supply is off. Hot
plug may damage the device.
CAUTION:
a) The placement of the laser delivery cable should be as natural as possible,
and the delivery cable should not be twisted;
b) If the coil diameter of the delivery optical cable is too small, it will damage
the laser.
CAUTION:
a) In the process of installation and disassembly, please handle the laser fiber
delivery connector gently, and DO NOT subject it to vibration;
b) Before installing the laser fiber delivery connector, ensure that the optical lens
and laser processing head cavity are clean and free of pollution.
3.3 Cooling Requirements
Table 3 Water cooling requirements
Model
1500/1500
2000/2000
3000/3000
2000/4000
4000/2000
4000/4000
6000/6000
Cooling Capacity
≥ 9 kW
≥ 12 kW
≥ 18 kW
≥ 18 kW
≥ 18 kW
≥ 24 kW
≥ 36 kW
Min. Flow Rate
＞35 L/min
＞35 L/min
＞52 L/min
＞52 L/min
＞52 L/min
＞64 L/min
＞94 L/min
Max. Input Pressure
4 ~ 6 Bar
Hose Inner Diameter
Φ25 mm
Φ32 mm
3.3.1 Requirements for Cooling Water:
a) The cooling water connection of the laser is shown in Figure 7, and the arrow direction represents
the flow direction
b) The cooling water uses the pure water, may use the drinking pure water.
c) Inorder to prevent the growthof mold thatmay lead to water blockage of the product, adding alcohol
solution to about 10% portion of the total volume is recommended.
d) If ambient temperature is between -10℃and 0℃, it is recommended to usethe 30% portion volume
alcohol, and replace it by every 2 months entirely.

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C3000XZ~RFL-C12000XZ
15
e) If the ambient temperature is below -10℃, the cooling system (chiller) with both heating and cooling
functions must be activated, and shall keep it in full-time operation by 24 hours to avoid the fiber
delivery cable connector and modules inside the product that containing the always waterways from
freezing.
Figure 7 Schematic diagram of laser cooling system connection
3.3.2 Requirements for Delivery Cable Cooling System:
a) Water flow requirements:
b) RFL-HQBH model fiber delivery cable: 1.5L~2.0 L/min
c) RFL-QD model fiber delivery cable:2.5~3.0 L/min.
d) Pressure of liquid flow: < 0.6 MPa at the inflow.
e) Type of liquid exchange junction: Two-Touch Fitting M5 to ϕ6 mm.
f) Type of tube: outer diameter ϕ6 mm; inner diameter ϕ4 mm.
g) Direction of cooling liquid: unidirectional; connect the tube with the water-pipe strictly according to
direction shown on the layer of the tube.
h) Type of liquid: de-ionized water, condensed water, purified water; it is recommended to replace the
coolant once a month, not exceeding two months at most.

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C3000XZ~RFL-C12000XZ
16
i) PH value of liquid: 5.5 ~ 9.
j) Filter element/cartridge is needed for the cooling system, and the size of the solid residual particles
should be ≤ 100 μm; replace the filter element/cartridge once a month.
k) Maximum temperature of liquid: 45 ℃.
l) Minimum temperature of liquid: 5 ℃above the saturated dew-point.
m) Additive to the liquid: satisfies the requirements of PH value and size of solid residual particles as
above.
n) Radius of the bending of the armored pipe: off-work state (i.e., transportation and reservation):
minimum radius of bending ≥ 15 cm; in-work state: minimum radius of bending ≥ 20 cm.
o) Long-term vibration < 2 G; Impact < 10 G.
3.3.3 Other Requirements:
a) When initiating the cooling system before using the product eachtime, check the entire water system
and joints to prevent the water leakage. The external water pipe must be installed and connected
according to the water inlet (IN) and water outlet (OUT) identified on the rear panel of the product.
Otherwise, the product may not work properly.
b) If the product is not used for a long time, the cooling water inside the cooling system and the product
should be drained totally, and then both the inlet and outlet must be covered with proper caps.
Otherwise, the product may be damaged due to the frozen.
c) Please use compressed gas below 0.5 MPa when draining the water from the product. Failure to do
so may cause permanent and irrecoverable damage to the cooling system.
CAUTION:
a) Set the water temperature of the cooling system correctly according to the
ambient temperature. If the water temperature was set too high, it will result in
the product de-functioning. If the water temperature was set too low, it will cause
condensation inside the product or the laser fiber delivery cable, which will cause
damage to the product as well;
b) Before turning on the product, the cooling system must be working properly and
the water temperature should be suitable for the temperature.
