Raycus RFL-P30MX Installation instructions

版本号
密级
内部
A0
会签
阶段
标记
C
RFL-P30MX
30MX 激光器英文说明书
RFL-P30MX·JS02
部门脉冲激光器技术研究部
编写叶蓬勃 20210303
校对刘红20210305
审核李科20210305
标审李其军 20210305
批准黄保20210308
武汉锐科光纤激光技术股份有限公司
谢良
夏巨江
旧底图登记号
/
底图登记号
/

User
Instruction
RFL-P30MX
Wuhan Raycus Fiber Laser Technologies CO., Ltd.
2021

@2020 Raycus Corporation
1
Safety Information
Please read this instruction carefully and familiarize yourself with the information we have
provided before you use the product. In this brochure, important operation procedures, safety and
other information are provided for you and all future users. In order to ensure operating safely
and optimal performance of the product, please act according to following warnings, cautions
and other information.
a) Raycus pulsed fiber laser is classified as a high power Class IV laser device. Before
supplying the power to the device, please make sure that the correct voltage of 24V DC
is connected and the anode and cathode are right.Incorrect polarityor voltage will harm
severely the device.

b) The device emits invisible light with a wavelength from
 
1060nm to
 
1085nm
with average power of 30W. Do not expose your eyes or skin to the radiation of the
laser.
c) Do not take apart the device, because there are no replaceable accessories available for
users to use. Any maintenance can only be proceeded in Raycus.
d) Do not look into the light output end directly. Use appropriate laser safety eye-wear(i.e.
laser goggles) when operating the device.
Safety labels and locations
Figure 1 Warning Signs
The two labels above in Figure 1 are located on the top of the cover of the device, representing
laser radicalization.

Wuhan Raycus Fiber Laser Technologies CO., Ltd.
P30MX Pulsed Fiber Laser User’s Guide V1
@2020 Raycus Corporation
2
Content
1. Description ............................................................................................................1
1.1. Product description........................................................................................................................1
1.2. Actual configuration list................................................................................................................1
1.3. Environmental requirements and cautions ....................................................................................1
1.4. Specifications ................................................................................................................................1
2. Mounting............................................................................................................... 1
2.1. Mounting dimensions....................................................................................................................1
2.2. Method of installation....................................................................................................................2
3. Control Interface.................................................................................................. 3
4. Operation Regulations......................................................................................... 7
4.1 Pre-inspection................................................................................................................................7
4.2 Operation procedures.....................................................................................................................7
4.3 Cautions.........................................................................................................................................7
5. Instructions for warranty, return and maintenance ........................................ 9
5.1 General warranty ...........................................................................................................................9
5.2 Limitations of warranty.................................................................................................................9
5.3 Service and repairs ........................................................................................................................9

Wuhan Raycus Fiber Laser Technologies CO., Ltd.
P30MX Pulsed Fiber Laser User’s Guide V1
@2021 Raycus Corporation
1
1. Description
1.1. Product description
The main oscillator power amplifier (MOPA) structure is used in the Raycus P30MX Pulsed Fiber
Laser, in which the semiconductor laser is used as the seed source and the power amplifier is realized
by the fiber amplifier. The Raycus P30MX Pulsed Fiber Laser has the advantages of wider range for
pulse width andfrequency selection, high single pulse energy, excellent beam quality, high peak power,
excellentpower stability, availability of first pulse and faster response of layer switching. Thus it is an
ideal light source for high-end industrial laser marking and other applications.
The figure of Raycus P30MX pulse fiber laser is shown in Figure 2 The laser is pumPing by the
way of fiber coupling output semiconductor laser, so the efficiency of pump light conversion is very
high.The laser uses air cooling system and thefan can change speed in real time according to the
temperature of the laser, which has the characteristics of compact structure, energy saving and
environmental protection. Thus the device can be used in the laboratory or outdoor environment. The
laser is designed with integrated all fiber laser and easy to operate and it can be used independently or
embedded in user equipment.
The device can emit 1060~1085nm wavelength pulsed light under the control of industrial laser’s
standard interface driven by 24VDC power source.
Figure 2 Photos of Raycus P30MX Pulsed Fiber Laser
1.2. Actual configuration list
Table 1 Configurationlist
Items
Quantity
Remark
Fiber Lasermodule
1
-
1.3. Environmental requirements and cautions
Pulsed laser should be driven by 24VDC±1V power source.

Wuhan Raycus Fiber Laser Technologies CO., Ltd.
P30MX Pulsed Fiber Laser User’s Guide V1
@2021 Raycus Corporation
2
a) Caution: Make sure the corresponding wires of the device are properly grounded.
b) All the maintenance to the device should only be done by Raycus, because there is no
replacement or accessory provided with the device. Please do not try to damage the labels or
open the cover in order to prevent against electric shock, or the warranty will be invalid.
c) The output head of the product is connected with an optical cable. Please be careful handling
the output head. Avoid dirt and any other contamination. Please use the specialized lens paper
when cleaning the lens. Please lid the laser with protective cover of the light isolator to be
against dirt only when the laser is not installed in the device or not in working.
d) If the operating the device fails to follow this instruction, the protective function will be
weakened. Therefore, it should be used under normal conditions.
e) Do not install the collimating device into the output head when the laser device is in working.
f) The device has three cooling fans at the rear panel to dissipate heat. In order to guarantee
enough airflow to help giving heat off, there must be a space of at least 10 cm’s width for
airflow in front and rear side of the device. As the cooling fans are working at blow condition,
if laser is mounted in a cabinet with fans, the direction should be same as laser’s fans.
g) Do not look into the output head of the device directly. Please do wear appropriate laser safety
eyewear during operation of the device.
h) Make sure the pulse repetition rate(PRR) is higher than 1kHz.
i) The longest time without pulse is only100
s 
. If there is no pulse output, please stop marking
at once to avoid the further damage of the device.
j) Power source sudden interruption will do great harm to the laser device. Please make sure the
power supply works continuously.

Wuhan Raycus Fiber Laser Technologies CO., Ltd.
P30MX Pulsed Fiber Laser User’s Guide V1
@2021 Raycus Corporation
1
1.4. Specifications
Technical Data are shown in Table 2.
The possible pulse repetition rates (PRR) and the maximum average energy P for different
duration

are given in the Table 3 .To give a quick overview the dependencies according to Figures 4,
5 and 6 (which show the shape of the average power)and Figures 7 and 8(which show the pulse
energies) are plotted.Note that a pulse duration of
600ns 
in the Table 3 is continuous mode,and
continuous laser is output for any frequency setting.
The waveforms for different pulse duration

for their maximum pulse energy,i.e. at the cut-off
repetition rate PRR0 are shown in Figure 3. When any pulses of a pulse duration from
2ns 
to
500ns 
(see Table 2) are used, the nominal output rated power is Pmax=30W, if the pulse repetition
rate PRR is greater than the corresponding cut-off pulse repetition rate PRR0. If the pulse repetition
rate PRR is less than the cut-off frequency PRR0, the output power is linearly related to the pulse
repetition rate, as shown in the Figure 4 below.
However the dependence of the emitted average power P on the pulse repetition rate PRR and the
pulse duration

are shown in Figure 5 and 6. Furthermore the pulse energies Epulse for different
pulse duration

and pulse repetition rates PRR are revealed in Figure 7 and 8. For any higher pulse
duration

higher than

=500 ns the emission is CW. Figure 3 shows the pulse waveforms at full-
power outpower for different pulse duration

at the corresponding cut-off pulse repetition rates PRR0.
Figure. 3 The pulse waveforms corresponding to the maximum single pulse energy

Wuhan Raycus Fiber Laser Technologies CO., Ltd.
P30MX Pulsed Fiber Laser User’s Guide V1
@2021 Raycus Corporation
2
Table 2 P30MX pulsed fiber laser specifications
NO.
Characteristic
Test condition
Min
Typ.
Max.
Unit
1
Mode of operation
Pulsed
2
Polarization
Random
3
Maximum pulse energy
500ns/30kHz/30W
1
mJ
4
Nominal average output power
30
31
32
W
5
Pulse duration
2
/
500
ns
6
Output power adjustment range
0
/
100
%
7
Long-term average power
instability
5
%
8
Pulse repetition rate
1
/
2000
kHz
9
Central emission wavelength
FWHM
1060
1064
1085
nm
10
Emission bandwidth
FWHM
3
8
15
nm
11
Beam quality M2
/
1.5
/
12
Output beam diameter
@86% power
6
7
8
mm
13
Laser switching ON time
0-90% power
2
20
50
μs
14
Laser switching OFF time
100-10% power
2
5
μs
15
Output fiber cable length
/
3
/
m
16
Supply voltage
23
24
25
VDC
17
Guide Laser Power
0.2
0.5
1
mW
18
Anti Strong Back Reflection
Yes
19
Cooling
Forced Air Cooled
20
Operating Temperature
0
/
40
℃
21
Storage Temperature
-20
/
60
℃
22
Humidity
/
/
80
%
23
Power Consumption
/
/
150
W
24
Laser module dimensions
W×D×H
286×215×95
mm

Wuhan Raycus Fiber Laser Technologies CO., Ltd.
P30MX Pulsed Fiber Laser User’s Guide V1
@2021 Raycus Corporation
3
Figure 4 Relation between pulse repetition rate PRR and maximum average power P
Figure 5 Relation between pulse repetition rate PRR and maximum average power P forvarious pulse
duration

0500 1000 1500 2000
0
5
10
15
20
25
30
average laser power P[W]
pulse repetition rate PRR[kHz]
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns

Wuhan Raycus Fiber Laser Technologies CO., Ltd.
P30MX Pulsed Fiber Laser User’s Guide V1
@2021 Raycus Corporation
4
Figure 6 Relation between pulse repetition rate PRR and maximum average power P forvarious pulse
duration

Figure 7 Relation between pulse repetition rate PRR and maximum average power Epulseforvarious
pulse duration

0100 200 300 400 500
0
5
10
15
20
25
30
average laser power P[W]
pulse repetition rate PRR[kHz]
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
500 1000 1500 2000
0.0
0.2
0.4
0.6
0.8
1.0
pulse energy Epulse[mJ]
pulse repetition rate PRR[kHz]
ns
ns
ns
ns
ns
ns
ns
ns
ns
50ns
ns
ns

Wuhan Raycus Fiber Laser Technologies CO., Ltd.
P30MX Pulsed Fiber Laser User’s Guide V1
@2021 Raycus Corporation
5
Figure 8 Relation between pulse repetition rate PRR and maximum average power Epulseforvarious
pulse duration

Table 3 Pulse repetition rate PRR according to Figure 8 and maximum pulse energy EPules,max for
different pulse duration

NO.

[ns]
PRRmin[kHz]
PRR0[kHz]
PRRmax[kHz
]
Pmax[W]
EPules,max[mJ]
1
2
1
2000
2000
30
0.015
2
4
1
500
2000
30
0.06
3
8
1
375
1000
30
0.08
4
14
1
250
1000
30
0.12
5
20
1
170
1000
30
0.18
6
30
1
135
1000
30
0.22
7
50
1
100
1000
30
0.3
8
100
1
65
1000
30
0.46
9
200
1
45
500
30
0.67
10
250
1
40
400
30
0.75
11
350
1
36
400
30
0.83
12
500
1
30
300
30
1
13
600
--
--
--
30
CW
100 200 300 400 500
0.0
0.2
0.4
0.6
0.8
1.0
pulse energy Epulse[mJ]
pulse repetition rate PRR[kHz]
ns
ns
ns
ns
ns
ns
ns
ns
ns
50ns
ns
ns

Wuhan Raycus Fiber Laser Technologies CO., Ltd.
P30MX Pulsed Fiber Laser User’s Guide V1
@2021 Raycus Corporation
1
2. Mounting
2.1. Mounting dimensions
Figure 9 Dimension drawing of laser module (Unit: mm).
Figure 10 Dimension drawing of output isolator (Unit: mm).
Figure 11 Wiring diagram of recommended electrial connection and power supply

Wuhan Raycus Fiber Laser Technologies CO., Ltd.
P30MX Pulsed Fiber Laser User’s Guide V1
@2021 Raycus Corporation
2
2.2. Method of installation
a) Fix the module stable to the bracket and keep the laser in good ventilation.
b) Connect the power line to 24VDC power and ensure enough DC output power. Keep it
clear to the polarity of the electric current:
Anode-brown
Cathode-blue
PE-yellow and green.
c) Make sure that the interface of the external controller matches the laser and the control
cable is well connected to the laser’s interface. The recommended electrical connection
is shown in Figure 11.
d) The bending radius of the delivery fiber should not exceed 15 cm.

Wuhan Raycus Fiber Laser Technologies CO., Ltd.
P30MX Pulsed Fiber Laser User’s Guide V1
@2021 Raycus Corporation
3
3. Control Interface
There are DB9 andDB25 interfaces at the rear of the laser. The DB9 is a RS232 interface
only used for debugging, no needs to connect. And DB25 is the joint interface connecting control
system to the laser system,please make sure the connection is reliable before operation. Feet of
the DB25 are defined as follows in Figure 12.
Figure 12 Pin definition of DB25 controll interface
Table 4 Definition of connect ports of controller
Pin No.
Name
Description
1-8 (D0-D7)
Power Setting
8 bit Parallel port;
D0 is minimum bit and D7 is maximum bit;
Range: 0-255 (hexadecimal: 0X00-0XFF).
10,14
Ground
Digital GND.
11,12,16,21
Laser alarms status
see alarm codes in Table 5.
17
VCC
+5VDC power supply input for independent operation
of the guide laser and PCB
18
EE
Emission Enable (EE) signal.
HIGH(>3V): Emission Enable
LOW or disconnected (<1V): Emission Disable
19
EM
Emission Modulation (EM) input.
HIGH (>3V): Emission ON
LOW or disconnected (<1V): Emission OFF
20
Sync
Pulse Repetition Rate (Synchronization) input, square
wave.
23
Emergency Off
Emergency Switch Off(Enable: 5V TTL)
9
Obligate Pin
Reserved
a) The pump current of the diode laser and the laser output power are controlled by setting
the value of Pin1-Pin8 (TTL level). Pin1-Pin8 can be set from 0to 255，corresponding
to the laser output power from 0to100％(the actual laser power may not be strictly
linear with the setting value). The relationship between Pin value and output power is
shown in Table 5.
b) Pin 10and Pin 14are all digital GND.

Wuhan Raycus Fiber Laser Technologies CO., Ltd.
P30MX Pulsed Fiber Laser User’s Guide V1
@2021 Raycus Corporation
4
Table 5 Definition of power control Pins.
Setting 1
Setting 2
Setting 3
Setting 4
Setting 5
Pin 1
0
0
0
0
1
Pin 2
0
0
0
0
1
Pin 3
0
0
0
0
1
Pin 4
0
0
0
0
1
Pin 5
0
0
0
1
1
Pin 6
0
0
1
1
1
Pin 7
0
1
1
1
1
Pin 8
1
1
1
1
1
Current
~50 %
~75 %
~87.5 %
~93.75 %
100%
c) Pin 17 receives external 5V DC voltage to provide power supply for alarm signal.
d) Pin 18 is the start signal of the MO. Pin19 is the input for the optical output signal. The
electrical level for both Pin18 and Pin19 are 5V. Before turning on Pin 19, MO signal
must be switched ON, in other word, the signal of Pin 18 must be ahead of Pin 19 at
least 5 ms, and otherwise the laser machine may be damaged.
e) Pin 20 provides control of the frequency. The frequency range should be 1kHz~2000
kHz, depends on the varying power levels of different laser machines.
ATTENTION: The frequency signal must be ahead of the EM signal at least 5 ms,
otherwise the laser machine may be damaged.
f) Below figure shows DB25 sequence diagram:
Figure 13 DB25 sequence diagram

Wuhan Raycus Fiber Laser Technologies CO., Ltd.
P30MX Pulsed Fiber Laser User’s Guide V1
@2021 Raycus Corporation
5
1) T1 represent the initialization time of the laser machine. The initialization time is
less than 10s from power-on to perform initialization.
2) T2 represent the pump recharge time, usually around 5ms.
3) T3 represent the frequency switching time. Frequency needs to be adjusted before
optical laser output, and the switching time should not less than 5ms.
4) T4 2-8mswith external frequent mode, recommend 4ms.
5) TON represents the pulse build-up time. Usually the build-up time is less than 50
us from the pump current raising up to reach the 90% power of the optical pulse.
6) Iis the simmer pump current.
7) Pmeans the height of the first pulse is adjusted by the pre-injection current I and
the reasonable height of the first pulse has been set before the laser leaves the
factory, which can meet the needs of most users. Special needs shall be put
forward in the customized contract.
g) Definition of alarm signal
Table 6 Definition of alarm signal
Pin12
Pin11
Pin16
Pin21
Alarm content
×
Low
Low
Low
Laser TemperatureAlarm1
×
Low
Low
High
Normal
×
High
Low
Low
System Error 2
×
Low
High
High
Power Error3
1) PS 1：Pin 17 receives external DC voltage to provide power supply for alarm signal.
Therefore, please make sure Pin17 is connected to the +5Vpower supply. The
temperature warning willremain if the power or DB25port is not well connected.
2) PS 2: If the voltage or current states of the laser are abnormal, the alarm might
present “POWER ERR”due to using different marking card (for example:
Beijing JCZ Technology Co. marking card).
3) PS 3: If the laser output system is abnormal, the alarm might present “SYSTEM
ERR”due to using different marking card (for example: Beijing JCZ Technology
Co. marking card).
h) Introduction of laser pulse duration control
Pin2, 3, and 22 on DB25 port not only used for the foundation control of the laser
machine, but also achieves the pulse duration control as the extender.

Wuhan Raycus Fiber Laser Technologies CO., Ltd.
P30MX Pulsed Fiber Laser User’s Guide V1
@2021 Raycus Corporation
6
Table 7 Laser duration control signal
Pin
Name
Description
2
Serial input
The setting of the data bits synchronize with rising edge of
theserial clock.
3
Serial clock
Serial clock, frequency range: 10kHz～1MHz.
22
Pulse duration controlEnable
High：Enable，Pin2 and Pin3 control the pulse duration;
Low or disconnected：Disable
1) Marking machine sendsthe command to the laser machine by the Pin2 on the DB25
port, meanwhile sends the clock signal to the Pin3. The comment is the binary
form, and delivers the most significant bit as the priority.
2) The order structure from marking machine to the laser machine is:
0xA5+instruction code.
3) 0xA5（A5h）is the comment byte to active the laser pulse duration control port.
0xA5 and the following data will be directly sent as the serial input form to the
Pin2 on the DB25 port.
4) The input data length is 4 bytes: the first byte of instruction code should be 0x01
（01h）,the second byte and the third byte are the value of the binary coding of
laser duration (for example: 200 is the decimal number of 0x00C8, represents the
setting pulse duration is 200ns).
5) Pin22 is the Enable signal. The Enable should achieve high state at least 10us
before Pin2 and Pin3 changing. The Enable should achieve low state at least 10us
after Pin2 and Pin3 changing. Figure 14 shows the adjustment process of laser
duration control.
6) Pin19 should decrease to low state before adjusting laser pulse duration.
Figure 14. Schematic of laser pulse duration adjustment（200ns）

Wuhan Raycus Fiber Laser Technologies CO., Ltd.
P30MX Pulsed Fiber Laser User’s Guide V1
@2021 Raycus Corporation
7
For example, if using Beijing JCZ Technology Co. marking card to adjust laser pulse
duration, the setting processes are described as follows:
a) Make sure the power supply, DB25 cable, control card and computer are correctly
connected, and then turn on the 24V power supply.
b) Open Ezcad2.7.6 (or other versions), then click ‘F3’, the configuration parameter
should show up, select ‘Fiber’ in the category of the ‘Laser Control’ panel, follow that
select ‘IPG_YLPM’, and then close this window.
c) Pulse duration can be modified by the ‘Duration’ on the right side of the window. If the
setting duration is smaller than the limiting minimum value, the duration of output laser
will be 2ns (minimum). If the setting duration is larger than the limiting maximum
value, the duration of output laser will be continuous work (maximum). If the setting
duration within the range, the duration of output laser will tend to the smaller side.
4. Operation Regulations
4.1. Pre-inspection
a) Make surethe device appearance is in good condition and the output fiber is neither
excessively bended nor broken.
b) Make sure signal line of laser and marking system are properly connected.
4.2. Operation procedures
a) Starting procedures
1) Please make sure the control system is on before you turn on the fiber laser. Only
after at least 1
2) minute since the power turned on, the subsequent operations can be proceeded.
b) Frequency set introductions
The frequency setting range is from 1 kHz to 2000 kHz.
c) Laser marking checking
For the device initial testing, first turn the power down to zero without turning on the
marking system after the device is successfully started. Then draw a quadrate, marking
continuously while slowly increasing the power from 1% to 100% at the same time. Meanwhile,
use a ceramic material to observe the laser and the laser should become stronger, otherwise shut
down the device and check.
If operating normally, the marking system can be used in common order afterwards.

Wuhan Raycus Fiber Laser Technologies CO., Ltd.
P30MX Pulsed Fiber Laser User’s Guide V1
@2021 Raycus Corporation
8
4.3. Cautions
a) Marking frequency must be in the range of 1 kHz to 2000 kHz.
b) It should not modify the frequency while marking.
c) Stop marking first before shutting down the device, then turn the power down to zero
and cut the power off.

Wuhan Raycus Fiber Laser Technologies CO., Ltd.
P30MX Pulsed Fiber Laser User’s Guide V1
@2021 Raycus Corporation
9
5. Instructions for warranty, return and
maintenance
5.1. General warranty
All products are warranted by Raycus against defects and problems in materials and
workmanship during the warranty period according to the purchase order or specifications and
we guarantee the product will accord with the specification under normal use.
Raycus has the right to choose to repair or replace any product that proves to be defective in
materials and workmanship selectively during the warranty period. Only products with particular
defects are under warranty. Raycus reserves the right to issue a credit note for any defective
products which aere produced in normal conditions.
5.2. Limitations of warranty
The warranty does not cover the maintenance or reimbursement of our product of which the
problem results from tampering, disassembling, misuse, accident, modification, unsuitable
physical or operating environment, improper maintenance, damages due to excessive use or
notfollowing the instructions caused by those who are not from Raycus. Customer has the
responsibility to understand and follow this instruction to use the device. Any damage caused by
fault operating is not warranted. Accessories and fiber connectors are excluded in this warranty.
According to the warranty, client should write to us within 31days since the defect is
discovered. This warranty does not involve any other party, including specified buyer, end-user
or customer and any parts, equipment or other products produced by other companies.
5.3. Service and repairs
Raycus is responsible for all the maintenance, for there is no accessory available inside for
users to use. Please contact Raycus as soon as possible when problems under warranty about
maintenance happen to the product. The product returned with permission should be placed in a
suitable container. If any damage happens to the product, please notify the carrier in document
immediately.
All the items about warranty and service above provided by Raycus are
only for reference; formal contents about warranty and service are subject to
the contract.
Wuhan Raycus Fiber Laser Technologies Co., Ltd.All Rights Recerved.
