Raylios K2-100 User manual

1
User Manual
Internet Protocol Camera
2M / HD 720P
Ver.2012 / 08

2
Table of Contents
Reading Before Using
4
Warning Before Using
4
Package Content
5
Physical Description
6
Network & Basic Connecting
11
Minimum PC Requirements
11
Accessing IP Camrea
12
ActiveX Setup
18
Ready to Use
20
Operation Manual
Live view page introduction
21
Setup
1. Network
---IP Networking
23
---Dynamic DNS
24
---UPnP
24
---Bonjour
24
---Connection Ports
25
---IP Filter
25
---E-mail Server
25
2. Camera
26
---Image Setting
26
---Text Overlay
27
3. Media
28
---Video
28
---Audio
29
4. Events
30
---Event Servers
30
---Motion Setup
33
---Tampering Detection
34
---Alarm I/O
34
---Alarm Definition
35
---Schedule Definition
Example Operation
37
48
5. System
38
---Information
38
---System Name
38
---Date and Time
Example Operation
38
66
---Users
38
69
---Maintenance
39
---Logs
39

3
Copyrights & Trademarks
Copyright
© 2012
Trademarks
Microsoft and Windows are registered trademarks of Microsoft Corporation.
All other trademarks mentioned in this document are trademarks of their respective
owners.
Disclaimer
This document is intended for general information purposes only, and due care has
been taken in its preparation.
Any risk arising from the use of this information rests with the recipient, and nothing
herein should be construed as constituting any kind of warranty.
The distributor reserves the right to make adjustments without prior notification.
All names of people and organizations used in these documents examples are
fictitious. Any resemblance to any actual organization or person, living or dead, is
purely coincidental and unintended.

4
Reading Before Using
You should read all the safety and operating instructions before using this product.
The use of surveillance devices may be prohibited by law in your country. The IP
Camera is not only a high-performance web-ready camera, but can also be part of a
flexible surveillance system. It is the user’s responsibility to ensure that the operation
of such devices is legal before installing this unit for its intended use.
Warning Before Using
1. Abnormal: Power off the IP Camera immediately when the smoke or unusual
odors are detected.
2. Voltage: Don not use the power supply with other voltages, if you use a power
supply with different voltage than the one included with this device. It is likely to
be damaged or damage other equipments / personnel.
3. Humidity: Keep the IP Camera dry inside. If it becomes wet, power off is
necessary! Do not place it in high humidity environments.
4. Temperature: Refer to your user’s manual for the operating temperature; do not
place around heat sources, direct sunlight.
5. Disassemble: Do not open the housing of this IP Camera; avoid disassembling
and inserting the sharp or tiny things.
6. Accessory: Do not use attachment / accessory not recommend by Raylios.
All warranty will be voided in the situations above.

5
Package Content
*Lens not included
*accessory package is included
*accessory package is included
Product CD in the package contains the following:
1. Search Tool (Skate2). 2. CMS. 3. User Manual / QIG
Power Adaptor
Software CD
Box Cam
IR Tube
Vandal Dome
IR Vandal Dome (35*IR LED)
IR Vandal Dome (50*IR LED)
IR Tube (Slim type)

6
Physical Description
Front Panel
Back Panel
Lens & Sensor
Back Focus
Adjustment
Digital Input / Output
Ethernet 10/100
RJ45 Connect
Auto-Iris Control
Cable Socket
DC 12V Power Input
Audio Input
Audio output
Reset Button
Power Status LED

7
Vandal Dome (IR/ Without IR)
IR Vandal Dome

8
IR Tube
IR Tube (Slim type)

9
Ethernet Port
The IP device connects to the Ethernet via a standard RJ45 connector. Supporting
NWAY, this IP device can auto detect the speed of local network segment
(10Base-T/100Base-TX Ethernet).
Reset Button
You can use the Reset Button to do the following settings:
1. Restore to factory default: Press the reset button for 8 seconds.
2. Reset the IP Cam: Press the reset button for 1 second.
3. Enable the Easy Focus function: Quick press twice within a second.
4. Disable the Easy Focus function: Quick press twice within a second.
Audio Input / Output
The IP device supports audio input and output with earphone jack.
Digital Input / Output
Used in applications like motion detection, event triggering, time lapse recording,
alarm notifications, etc., the I/O terminal connector provides the interface to:
1. Transistor output –for connecting external devices such as relays and LEDs.
Connected devices can be activated by Output buttons on the Live View page or
through video management software.
2. Digital Input –An alarm input for connecting devices that can toggle between an
open and closed circuit, for example: PIRs, door/window contacts, glass break
detectors, etc. The device will detect the change in digital input and transmit the
signal to video surveillance servers.

10
LED
While connecting the IP Camera to power, the IP Camera immediately starts the
self- test, at this moment the power LED turns orange. After the self-test, the power
LED will turn green, means the Ethernet or WiFi connections are successfully set
up.
Mounting the Lens to the Camera
1. Mount the lens by turning clockwise onto the camera mount slowly until it stops.
2. Connect the Auto-Iris control cable to the socket (Auto-Iris lens only, optional)

11
Network & Basic Connecting
With PoE (Power Over Ethernet) supported switch or injector:
1. Connect IP Camera to the switch / injector by CAT 5 / CAT 6 network cable with
RJ45 connector.
2. Connect your switch / injector to PC with another CAT5 / CAT6 network cable.
Without PoE (Power over Ethernet) supported switch or injector:
1. Connect the power adaptor to IP Box Camera.
2. Connect IP Camera to the switch / injector by CAT 5 / CAT 6 network cable with
RJ45 connector.
3. Connect a PC to the switch / injector by CAT 5 / CAT 6 network cable with RJ45
connector.
Minimum PC Requirements
CPU：Intel Core i3-2120 Dual Core 3.3GHz or up
Memory：2G(Suggest to have 4G or more, for better system performance)
OS：Windows Vista,/2000/XP/ Win 7
Browser：Internet Explorer 7.0 or later version (Also Supports FireFox. Chrome)

12
Accessing Camera
You can easily find and access the IP Camera with our “IP Camera Search Tool”, which
is in our package CD with the camera.
1. Put the CD into the CD/DVD player in your PC. The AutoRun will start
automatically.
2. Click “IP Camera Search Tool”
3. If your PC can’t execute AutoRun, please execute the program “autorun.exe” in
the CD.
4. Click “Search”, the IP Cameras will be found with ID, Name, IP address…etc.
5. Select the IP Camera you would like to access. You should be able to see the
video in the preview window.

13
6. Select the IP Camera you would like to access, click “Open Browser”.
7. When you see the login window, please input default user name and password:
Default Username: admin Default Password: password
8. After logging in, you will see the live view from camera. To go to the setup page,
select “Setup” from the menu on the top right.
If you are using a single camera, this is enough to access the device.
If you are using multiple IP Cameras, repeat the above procedures.

14
If you can not access the camera after above mentioned procedure, you may have
your PC with fixed IP, in this case please follow the steps to change the IP of IP
Camera to the same subnet with your PC:
1. Check you PC’s IP address by going to Control Panel Manage Network
Connections Right click on the connection to change Option TCP/IP IPv4
Properties.
2. You can find your PC’s IP address in the “IP Address” column. In our example it’s
192.168.1.99
Please memorize it.
Select “OK”
3. Put the CD into the CD/DVD player in your PC. The AutoRun will start
automatically.
4. Click “IP Camera Search Tool“
5. If your PC can’t execute AutoRun, please execute the program “autorun.exe” in
the CD.
6. Click “Search”, the IP Cameras will be found with ID, Name, IP address…etc.

15
7. Select the IP Camera you would like to access. You should be able to see the
video in the preview window.
8. Click “Network Setting”, the click “OK”. The Network Setting Window will pop-up.
9. Select “Fixed IP”. Input the first 3 prefix as the same of your PC’s IP. In our
example it’s 192.168.0. The last number should be any number from 1 to 254,
except the one your PC’s IP is, in our example it’s 101.

16
10. In “Netmask” column, input the prefix as the same of your PC’s Subnet Mask. In
our example it’s 255.255.255.0
11. Input the Gateway number, please ask your MIS for it or check your PC in the
same network. Then click “Save”.

17
12. Click “Search” again, you will find your camera with a new IP address which you
assigned.
13. Select the IP Camera you would like to access. You should be able to see the
video in the preview window.
14. Select the IP Cam you would like to access, click “Open Browser”.
15. When you see the login window, please input default user and password:
Default Username: admin Default Password: password

18
16. After logging in, you will see the live view from camera. To go to the setup page,
select “Setup” from the menu on the top right.
Set ActivX
1. Toolbar→Tools→Internet Options

19
2. Security→Click the Custom Level…
3. “Download signed ActiveX controls”and”Download unsigned ActiveX controls”,
Click the “Prompt”

20
4. Click the “Alppy”
Ready to Use
Access the IP Cam and be able to see the live view according to the procedures
mentioned in this quick installation guide。
