Eneo PXD-2080MIR C User manual

Full Manual
Mega Pixel Network Dome Camera
PXD-2080MIR
DE
EN
FR
PL

2
Contents
Notes on Safety........................................................................................................4
General Description ...............................................................................................4
Scope of delivery .....................................................................................................4
Description of parts .................................................................................................5
Installation .................................................................................................................6
Surface Mount .......................................................................................................6
Flush Mount...........................................................................................................7
Setup of the Zoom and FOCUS.............................................................................7
Limit of Pan and Tilt.................................................................................................8
Power Supply Connections....................................................................................8
EMI Ferrite Core Connections ...............................................................................9
Setup Menu...............................................................................................................9
In the menu............................................................................................................9
MAIN Menu ............................................................................................................ 10
SYMBOL descriptions for joystick operation .......................................................10
EXPOSURE Menu ................................................................................................. 11
BLC Menu............................................................................................................... 12
HSBLC Menu ......................................................................................................... 13
LENS Menu ............................................................................................................ 14
FOCUS ADJ. Menu............................................................................................... 14
DAY/NIGHT Menu................................................................................................. 15
DAY / NIGHT AUTO menu and IR SMART menu................................................15
NR menu .............................................................................................................16
PICT ADJ. Menu.................................................................................................... 17
SPECIAL Menu ...................................................................................................... 18
D-ZOOM menu ...................................................................................................18
CAM TITLE menu ................................................................................................19
MOTION menu ....................................................................................................20
PRIVACY menu ...................................................................................................20
PIXEL COMP menu ............................................................................................21
Dimensional Drawings ......................................................................................... 22

3
Specications ........................................................................................................ 23
Smart Viewer User‘s Manual ............................................................. Appendix A
Web Admin User‘s Manual ................................................................ Appendix B

4
• 1x IR Dome camera
• 1x Installation and Operating Instructions
• 1x Mounting template
• 1x Blind cover ①
• 1x Pipe spacer ②
• 1x Hex L-wrench ③
• 1x Focus adjust driver ④
• 3x Wrench bolt for surface mount ⑤
• 4x Anchors ⑥
• 4x Mount screws ⑦
• 1x BM screw ⑧
• 1x Video Sub-out cable ⑨
• 1x Coupler for RJ45 Cable ⑩
• 1x EMI Ferrite Core ⑪
Scope of delivery
Notes on Safety
Please also pay attention to the enclosed safety instructions, and carefully read through this instruction guide
before initial operation.
Important points of advice are marked with a caution symbol.
Mega Pixel IP camera which realizes 1.3M, 1280x720(30p/25p) or 2.0M, 1920x1080(30p/25p).
Serves real time live view Max 30fps live view @ 1280x720p & 1920x1080p
Compatible with Onvif / PSIA
Highly detailed pictures can be achieved and color reproducibility deserves attention.
With ICR mechanism,
- Enhances its sensitivity about 10x at night time
- Can accepts the infrared light
With 24VAC/12VDC dual power & PoE (Power Over Ethernet) design,
- Oers the exibility of installation
- Ensures the reliability
Main features are;
• 1/3” Panasonic Progressive Scan CMOS imager
• 1280x720(30p/25p)/1920x1080(30p/25p) with 1.3MP/2MP Sensor
• 16:9 Video format for most popular commercial HDTV monitors
• Switchable HDTV standard for EU and US in menu
• Auto TDN without focus shift by dual lter switcher
• Patented Exact FOCUS setting aid
• Smart IR support • Smart 3DNR
• NTSC/PAL auxiliary video output for installation & maintenance
• Flickerless mode for 50(60)Hz area at US(EU) HDTV standard
• Onvif / PSIA Conformance
• H.264/MJPEG dual streaming with TI DM365/368 engine
• Full duplex 2 way audio, Alarm IN/OUT
• Low latency & Max. 16 simultaneous user connection
• Max 30fps live view @ 1280x720p & 1920x1080p
• PoE (Power Over Ethernet), IEEE 802.3af
• AC24V/DC12V dual type of Local power
• Changeable surface mount and ush mount
• Focus & Zoom Adjustment on Gimbal
• Perfect 3-Axis Gimbal
General Description
①
②
③
④
⑤
⑥
⑦
⑧
⑨
⑩ ⑪

5
Description of parts
ⓔDome base
ⓕ Mount holes (x3) for dome base
ⓖ OSD control joy stick
ⓗ Video Sub-output
ⓘClear bubble
ⓙ Ring cover xing screws (x3)
ⓚRing cover
ⓐ Zoom & Focus
ⓑ Lens hood
ⓒ Light sensor for IR LEDs
ⓓIR LED
ⓛ Pipe hole
ⓜ Dome base xing screw taps (x3)
ⓝ Surface mount holes (x4)
ⓐ ⓑ ⓒ ⓓ
ⓔ ⓕ ⓖ ⓗ
ⓘ ⓙ ⓚ
ⓛ ⓜ ⓝ

6
Surface Mount
1. Locate the mounting template at the installation
position and drill the ceiling or wall if needed.
2. Place mount base on pre-drilled position and
x it through mount base mount holes ⓝ (4x)
by using mount screws.
Assemble the cable pipe, otherwise tighten
blind cover.
3. Open bubble by loosening ring cover xing
screws ⓙ (3x).
CAUTION
Extreme care should be taken NOT to scratch
the dome surfaces and to protect it from dirt or
dust at any time.
4. Mount holes ⓕ (x3) for dome base and hole
ⓜ should be aligned before xing dome base
to mount base by using wrench bolts. And
tighten wrench bolts.
5. Route the power/video cable to the connecting
place.
CAUTION
Care should be taken the cable is NOT to be
damaged, kinked or exposed in the hazardous
area.
6. Set the camera’s angle (Pan, Tilt, inclination)
7. Adjust Zoom & Focus ⓐ by using focus adjust
driver.
8. Put bubble over dome base and tighten ring
cover xing screws ⓙ (3x) by using L-shape
star wrench.
CAUTION
Tighten enough ring cover xing screws ⓙ (3x)
so that there should be NO gap between lens
hood ⓑand clear bubble ⓘ to avoid the light
inow from IR LEDs.
Ceiling or wall
Mount base
Mount screws
and blind co-
ver for mount
base
Dome base
Wrench bolts
for tting to
mount base
Bubble
L-Wrench
Installation

7
1. Locate the mounting template at the installation
position and drill the ceiling or wall if needed.
2. Open Dome bubble assembly by loosening
ⓙRing cover xing screws(x3)
CAUTION
Extreme care should be taken NOT to scratch
the dome surfaces and to protect it from dirt or
dust at any time.
3. Place Dome base assembly on pre-drilled
position and x it through ⓕ mount holes(x3)
by using Mount screws. (Use three screws only
out of Mount screws(4x))
4. Route the power/ video cable to the connec
ting place.
CAUTION
Care should be taken the cable is NOT to be
damaged, kinked or exposed in the hazardous
area.
5. Set the camera’s angle (Pan, Tilt, inclination)
6. Adjust ⓐ Zoom & Focus by using focus adjust
driver.
7. Put Dome bubble assembly over Dome
camera assembly and tighten ⓙRing cover
xing screws(x3) by using L-shape hex
wrench
CAUTION
Tighten enough ⓙRing cover xing screws(x3)
so that there should be NO gap between
ⓑLens hood and ⓘClear bubble to avoid the
light inow from IR LEDs.
Ceiling or wall
Mount screws
Dome base
Bubble
L-Wrench
Flush Mount
Setup of the Zoom and FOCUS
• Remove the dome bubble assembly and power up the camera.
• Adjust ⓐZoom setting using focus adjust driver.
• Adjust ⓐFocus setting using focus adjust driver.
• Close the dome bubble assembly and tighten ⓙRing cover xing screws(x3) using ③L-shape hex wrench.
Tips for the precise adjustment of lens at outside
1. It is recommended to place a ND (Neutral Density) lter in front of the lens.
This results the lens iris open and narrow depth of eld and allows the precise focus adjustment.
2. When ND lter is NOT available, follow the process carefully.
CAUTION : This process is a little complicated and requires 'MUST FOLLOW THE STEPS'.
1) Enter SETUP menu.
2) Select MANUAL at MAIN menu-1>LENS .and Exit SETUP menu.

8
1. Pan limit
Pan is limited to +/- 165°.
Do NOT force to rotate the gimbal over the limit to prevent from the internal damage.
2. Tilt limit
Tilt is limited to 25° min ~ 90° max. with reference to the ceiling when the inclination of camera module
is 0°, that is, the image is aligned horizontally.
CAUTION : Tilt may NOT reach 25° min. if some IR light reects to the lens when the inclination is NOT 0°.
When Tilt is set to near the minimum limit, examine and verify that NO IR refection occurs.
3. Inclination limit (Horizontal image alignment)
Inclination limited to +/-60° max.
3) Adjust ③Zoom & Focus.
4) Enter SETUP menu again.
5) Restore FACTORY DEFAULT by MAIN menu-2>CAMERA RESET (See 7.15 CAMERA RESET).
6) Save the restored parameters by moving cursor to SAVE ALL and pressing ● button.
7) Set all other functions if necessary.
8) Save the changes by moving cursor to SAVE ALL and pressing ● button.
9) Exit SETUP menu
Limit of Pan and Tilt
Camera can work with either 24AC or 12VDC, dual voltage power and PoE(IEEE Std. 802.3af).
It is strongly required the polarity-matched connection for 12VDC supply, otherwise IR LEDs will not operate at
night.
Primary and secondary grounds are completely isolated to avoid the possible ground-loop problems.
Power Supply Connections

9
AUDIO IN
AUDIO OUT
AC24V/GND
AC24V/DC12V
GRN ALM IN /
GRNWHT GND
BLU ALM OUT /
BLUWHT GND
LAN CABLE with
RJ-45 and PRO-
TECTION CAP
Please connect EMI Ferrite Core as shown below.
EMI Ferrite Core Connections
Setup Menu
In the menu
Setup menu can be accessed and controlled by OSD control joy stick on the side of camera.
Five commands are available with the joy stick.
The design of OSD could be dierent according to the Model.
SDCardSlot
VIDEOSUB-OUT
connector
IPReset
Joystick
50mm
50mm

10
SYMBOL descriptions for joystick operation
▲,▼,◄,► denotes the directions of Joystick lever operation.
● denotes Pressing straight down of Joystick lever
In the menu, use ▲,▼ to move menu, ◄,► to change the settings and press ● to select or enter.
FACTORY DEFAULT values in this manual may NOT be the same as the default values by FACTORY SET due to
the changes for the improvements or the customer‘s requirements.
In the case of IP setting, please refer to separate IP installer and Admin Manual.
MAIN Menu
To enter menu, press ● when MENU is not active
MAIN Factory
Default
Descriptions
EXPOSURE - Sets SHUTTER, AGC, SENSE-UP, BRIGHTNESS, D-WDR, DEFOG, BACK LIGHT.
LENS DC Selects DC or MANUAL lens according to the mounted or built-in lens. BRIGHTNESS for both
lenses can be set in the menu.
FOCUS ADJ. - Helps adjust the exact needle focus by simulating DAY & NIGHT and avoids from out of focus
at night.
DAY/NIGHT AUTO Sets DAY / NIGHT to EXT, AUTO, COLOR and B/W.
EXT – Used when DAY or NIGHT is determined by the external light sensor. Camera with IR
LED must be set to EXT.
AUTO – Used when DAY or NIGHT is determined by the light level through the lens and DAY
from/to NIGHT is switched automatically.
DELAY, D-->N and N-->D can be set in the menu.(See DAY/NIGHT AUTO)
NIGHT – Removes IR cut lter and switches to B/W regardless of light level.
DAY – DAY/NIGHT is disabled and outputs color video.
NR - Sets 2DNR, 3DNR, LEVEL, SMART NR.(See 2D & 3D NR)
PICT ADJUST - Sets WHITE BAL, SHARPNESS, MONITOR, OSD, CORNER COMP, D-EFFECT. (See PIC AD-
JUST)
SPECIAL - Sets CAM TITLE, MOTION, PRIVACY, LANGUAGE, PIXEL COMP, TV SYSTEM. (See SPECIAL)
FACTORY RESET Pressing ● at RESET will restores all parameters from the factory default.
EXIT -Saves and Exits.
