D-2 Power Vent
Litho in U.S.A. ©2004-2008 Raypak, Inc. Catalog No. 6000.23D Effective: 10/01/08
For dimensions and technical specifications, see catalog number 6000.36.
In keeping with its policy of continuous progress and product improvement, Raypak reserves the right to make changes without notice.
D-2 Power Vent
Sometimes, equipment rooms or unusual venting configurations require the use of a power
vent. Being the heater experts, we have this option for you when the need may arise.
Through-the-Wall Capable
The D-2 Power Vent assembly is a Category III mechanical draft venting system that operates
under a positive static pressure and prevents excessive condensate production in the vent. All
sizes are capable of relieving flue gases up to a maximum of 100 equivalent feet of vent
length. All models have a standard 4”-diameter exhaust connection.
Multi-Position
Using the Raypak-supplied adjustable 90° elbow, the flue gases may be discharged in any
direction (see D-2 Power Vent manual for details). The D-2 Power Vent is also dual-voltage
capable (120/240 volt) and engineered for long life and smooth operation.
Model BTUH Input
207 199,500
267 266,000
337 332,500
407 399,000
Cabinet
•Outdoor top - (standard)
•Wind-resistant design
•Channels rainwater out
•Textured powder-coat finish
•Optional indoor top
Digital Controls
•Microprocessor-controlled
•Built-in diagnostics
•Backlit LCD display
•Pool and spa settings
•Lexan cover
•Remote-compatible
Burner Tray
• Easily removable
• Stainless steel burners
• Brass orifices
• Aluminized metals
• Stainless steel heat shield
• Spark-to-pilot ignition
• 120/240V Combustion fan motor
Heat Exchanger
• Integral copper fin tube -
•(standard)
• Automatic bypass
• Unitherm governor
• Polymer headers
• Stainless steel tube sheet
• Reversible for left-side
•water connections.
• ASME - (optional)
• Cupro-nickel - (optional)
2” CPVC Connections
High Limits and Controls
• Mounted on the in/out header
Ceramic Fiber
Combustion Chamber
Non-Combustible Base
• Heater can be installed on a
•combustible surface
120/240V
• Incoming power can be
• connected to the right or
• left side.
Optional D-2 Power Vent
Anything But Basic
Raypak, Inc. 2151 Eastman Avenue, Oxnard, CA 93030, [phone]. Fax [phone]
www.raypak.com

Raypak Digital Low NOx
Pool and Spa Heater
The Pool and Spa Heating ExpertsSM

Digital Control
Microprocessor-Controlled Thermostat
The Raypak Digital gas heater is equipped with a micro-
processor-based control center. This control allows you to
set your pool or spa temperature precisely at your preferred
setting just by pressing an up or down temperature control
button. The digital display gives you a constant readout of
your water temperature. Just set it, and forget it! Truly sim-
ple. If only your VCR were this easy to operate.
Self-Diagnostic
Troubleshooting a Raypak gas heater has never been easi-
er. The Raypak Digital has on-board diagnostic controls
that let the user and the service professional know what is
going on with the heater at all times. In the unlikely event
that a problem develops, the digital display easily points out
the problem and the probable cause. It's like having a serv-
ice technician built into every heater!
Remote-Compatible
The Raypak Digital is compatible with most major pool control and remote systems on the market today. Any two- or three-wire remote
can connect to the Raypak Digital and be integrated into the pool control system of your choice.
Heat Exchanger
Condensation-Free Operation
Both water temperature and flow rate inside the heater are controlled to help
eliminate condensation, sooting and scale buildup that can shorten the life of
a heater. Raypak engineered the Unitherm Governor specifically for pool
heater applications, regulating low-temperature incoming water to help
reduce condensation. For over 30 years, Raypak has led the industry, setting
the standard for condensation protection.
Rust-Free Waterways
The Raypak Digital, with polymer headers, is equipped with an integral cop-
per finned-tube heat exchanger and stainless steel tube sheets. This unique
construction guarantees rust-free operation, especially important when heat-
ing spas and smaller pools. Even the smallest details such as the studs and
nuts are made out of stainless steel. The payoff? A heater that will last year
after year and can easily be serviced if the need should ever arise.
Burners
Stainless Steel Burners
Burner design is a critical component in any gas heater. The stainless steel burner
system used in the Raypak Digital is inherently forgiving and extremely robust. The
burner is self-adjusting to compensate for gas pressure fluctuations, allowing the
heater to always burn clean and safe.
Fan-Assisted Combustion
Not all low NOx heaters are made the same. The Raypak Low NOx design uses a
fan to provide cool, controlled combustion air to the burners. Other brands use a fan
to pull hot flue gases through the heater. The Raypak design allows the heater to
outperform all others during cold starts and provides longer component life.
Pilot Ignition
The Raypak Digital use a spark-to-pilot ignition system. This is the most reliable and
robust ignition system available–an industry proven standard for over 20 years.
Expect MoreSM
The Raypak Digital Low NOx

ASME
The Raypak Digital heater is also available in an
optional ASME version. Raypak has state inspectors
on-site daily performing certifications for our pool
heater and commercial boiler production that may
require ASME. Being in the boiler business for over 50
years truly makes Raypak the leader for your commer-
cial needs. Why ASME? Most local codes require that
public pools, pools that are in condominiums, apart-
ments, or other commercial applications, be ASME
certified. ASME stands for American Society of
Mechanical Engineers, a non-profit group which sets
many industrial and manufacturing standards. A pool heater that is made to ASME stan-
dards must perform to a set of specifications as determined by ASME, specifically in rela-
tion to the operating water pressure the appliance can handle. Each and every ASME
heat exchanger that goes into a Raypak heater is certified by a state inspector to make
sure it complies with all ASME codes for pool heaters.
Glass-Lined Cast Iron Headers
Raypak has applied its years of commercial boiler experience to the design of the cast
iron glass-lined header. A metal header design allows for the higher working pressures
required by ASME. Only after the material meets the stress analysis and metal composi-
tion tests is it approved for use in an ASME unit.
Choices
3 Levels of Performance
L
W
ASME
On-site state inspectors
Cast iron headers
Copper Fin Tube - Residential
The Raypak Digital is built to last with the highest quality integral
copper fin tube available. Copper is well known for its ability to
efficiently transfer heat, and is the first choice for pool and spa
heat exchanger construction. Pure copper has stood the test of time
as the industry standard for efficiency, quality and product life.
ASME Copper Fin Tube - Commercial
The Raypak Digital ASME is designed specifically to meet
State and local code requirements for public pools and commercial appli-
cations. This heater is equipped with a thicker walled fin tube allowing it to
meet the ASME certification requirements.
Cupro-Nickel Fin Tube - Specialty
Raypak Digital heaters can be ordered with cupro-nickel fin tube heat
exchangers for added protection against aggressive water chemistry. Although
rare, there are certain applications, like health club spa’s, where copper is just not
the best choice. Cupro-nickel offers superior tolerance to bad and fluctuating water
chemistry, thanks to a harder surface and a thicker walled fin tube.
