Raypak CHX Setup guide

CATALOG NO. 9300.73
Effective: 07-15-06
Replaces: 05-10-06
THE PARTS LISTED ARE FOR STANDARD EQUIPMENT FOR THIS MODEL TYPE. RAYPAK RESERVES
THE RIGHT TO SUBSTITUTE, DELETE OR CHANGE ANY PART WITHOUT NOTIFICATION. THE
ADDITION OF OPTIONS MAY ALSO CHANGE SOME OF THE PARTS. ORDER REPLACEMENT PARTS
FROM ACTUAL HEATER COMPONENTS.
Raypak, Inc., 2151 Eastman Avenue, Oxnard, CA 93030
[phone] Fax [phone]
Litho In U.S.A.
RAYPAK ILLUSTRATED PARTS LIST
FOR DETAILED INSTRUCTIONS, SEE "HOW TO USE YOUR RAYPAK ILLUSTRATED PARTS LIST",
CATALOG NO. 9001.10
COMMERCIAL
CHX (CONDENSING HEAT EXCHANGER)
MODEL SIZES: 500, 750, 1000, 1500
MODEL TYPE: CHX
DATE OF MANUFACTURE: 2004 THRU CURRENT

CALL
OUT DESCRIPTION 500-6 500-8 750-8 1000-10 1000-12 1500-12 1500-14
H HEAT EXCHANGER
1-H Heat Exchange Assy. Bronze 007618F 007618F 007619F 007620F 007620F 007941F 007941F
2-H Inlet Header Bronze 007621F 007621F 007621F 007622F 007622F 007622F 007622F
3-H Outlet Header Bronze 007623F 007623F 007623F 007624F 007624F 007624F 007624F
4-H Tube Bundle Cupro-Nickle 007625F 007625F 007626F 007627F 007627F 007942F 007942F
5-H Studbolt 007628F 007628F 007628F 007628F 007628F 007628F 007628F
6-H Header Gasket Kit 007343F 007343F 007343F 007343F 007343F 007343F 007343F
7-H Condensing Drain w/Support Bracket 007629F 007629F 007629F 009553F 009553F 009901F 009901F
S SHEETMETAL
1-S Internal Chamber 009583F 009583F 009584F 009585F 009585F 009586F 009586F
2-S Base Assy 009587F 009587F 009587F 009588F 009588F 009588F 009588F
3-S Cover Panel Front 009589F 009589F 009590F 009591F 009591F 009592F 009592F
4-S Cover Panel Rear 009593F 009593F 009594F 009595F 009595F 009596F 009596F
5-S Cover Panel Left Side 007642F 007642F 007643F 007644F 007644F 007946F 007946F
6-S Cover Panel Right Side 007645F 007645F 007646F 007647F 007647F 007947F 007947F
7-S Header Top Cover 007648F 007648F 007648F 007648F 007648F 007648F 007648F
8-S Intake Baffles 009542F 009542F 009543F 009544F 009544F 009545F 009545F
9-S Access Panel 009546F 009546F 009546F 009546F 009546F 009546F 009546F
10-S Vent Adapter-15 Degree Intake & Exhaust 009547F 009548F 009549F 009550F 009551F 009551F 009552F
11-S Vent Adapter-Straight Intake & Exhaust 009826F N/A 009827F *N/A 009830F N/A
12-S Vent Elbow-15 Degree 010816F N/A 010817F ** N/A 009820F N/A
13-S Base Extension 011647 011647 011648 011649 011649 011650 011650
*FOR ADB MODEL 1000 USE 009828F (9" Inlet / 10" Outlet)
FOR ADB MODELS 1000A AND 1001, USE 009829F (10" Inlet / 10" Outlet)
** FOR ADB MODEL 1000 USE 010818F (9" Inlet / 10" Outlet)
FOR ADB MODELS 1000A AND 1001, USE 010819F (10" Inlet / 10" Outlet)
