Razor POCKET ROCKET User manual

Remove the plastic seat. The controller is located un-
der the seat section (see Figure 1b).
Using the supplied 5mm Allen wrench, remove the
two screws that hold the plastic seat to the frame
(see Figure 1a).
Figure 1a Figure 1b
Figure 2 Figure 3
Carefully unplug the 5 wiring connections attached
to the controller. Each connector is a snap-lock type
connection that requires depressing a small tab to
allow the connector to release (see Figure 2). Do
not attempt to disconnect by pulling on the wires!
Using the 5mm Allen wrench, remove and save the
two mounting screws that secure the old controller.
You should now be able to remove the old controller
(see Figure 3). Discard the old controller.
Step 1a: Remove the motor cover
Step 2: Unplug the wire connections Step 3: Remove the old controller
Need Help? Visit our website for additional video instructions at www.razor.com or call toll-free at 866-467-2967 Monday - Friday
8:00am - 5:00pm Pacifi c Time.
CAUTION: To prevent shock, turn power switch off before installing the new controller.
This kit includes:
NOTE: The supplied adapter (6-pin connector on one
end and 4-pin & 2-pin connectors on the other end) is
only applicable to certain Pocket Rocket products.
If your existing controller has a 6-pin connector, the
replacement controller will require use of the adapter.
• The 6-pin connector of the adapter should
be connected to the Pocket Rocket.
• The 4-pin & 2-pin connectors of the adapter
should be connected to the new controller.
If your existing controller already has a 4-pin and a
2-pin connection, disregard connecting the supplied
adapter.
Step 1b:
ABD
EF
G
A - Washers (2)
B - Lock Washers (2)
C - 5mm Allen wrench
D - Pocket Rocket™ Handlebar
Replacement bolts (2)
POCKET ROCKET™
CONTROLLER INSTALLATION GUIDE
1
E - Adapter
F - Qili™ Charger
G - Controller
(CT-201C6)
C

POCKET ROCKET™
HANDLEBAR BOLT REPLACEMENT
Figure 1a
Using the supplied 5mm Allen wrench, remove
and discard the old bolts (see Figure 1a).
Step 1: Remove the old bolts
Figure 1b
Using the same 5mm Allen wrench, screw in the
new bolts with a washer and a lock washer (see
Figure 1b).
Step 2: Install the new bolts
Need Help? Visit our website for additional video instructions at www.razor.com or call toll-free at 866-467-2967 Monday - Friday
8:00am - 5:00pm Pacifi c Time.
Figure 4a
Secure the new controller in place and tighten the
mounting screws (see Figure 5). Reattach plastic
cover to frame (see Figure 1a).
Step 5: Secure the new controller
Figure 5
Reconnect all plug-in connections (see Figure 4a).
Each connection point is unique, so the system can
only be connected in one way: the right way.
Note: If your existing controller has a 6-pin connector (see
Figure 4b), the replacement controller will require use of the
supplied adapter.
Step 4: Reconnect the wire connections
Figure 4b
