Razor Bumper Buggie User manual

Owner’s Manual
Read and understand this entire manual before using!
DO NOT RETURN TO STORE
Item Number:
25117460

WARNING: Riding the Bumper BuggieTM can be
a hazardous activity. Certain conditions may cause the
equipment to fail without fault of the manufacturer. BECAUSE
THIS PRODUCT MOVES, CHILDREN USING IT COULD GET
INTO DANGEROUS SITUATIONS PRESENTING POSSIBLE
RISKS OF INJURY OR DEATH EVEN WHEN USED WITH
PROPER SAFETY PRECAUTIONS. ADULT SUPERVISION IS
NECESSARY TO PROMOTE AND ASSURE SAFE PLAY IN A
BUMPER BUGGIE. USE COMMON SENSE.
This manual contains many warnings and cautions concerning
the consequences of failing to maintain, inspect or properly
use your Bumper Buggie. Because any incident can result in
serious injury or even death, we do not repeat the warning
of potential serious injury or death each time such a possibility
is mentioned.
APPROPRIATE RIDER USE AND
PARENTAL SUPERVISION
Direct adult supervision is required at all times. This manual
contains important safety information. It is your responsibility
to review this information and make sure that all children
obey all warnings, cautions, instructions and safety topics and
assure that young riders are able to safely use this product.
Razor recommends that you periodically review and reinforce
the information in this manual with young riders, and that you
inspect and maintain your children’s vehicle to insure their
safety. The recommended rider age of 3 years and older for
Bumper Buggie is only an estimate, and can be affected by the
rider’s size, weight or ability. Any child unable to fit comfortably
on the Bumper Buggie should not be allowed to attempt to
ride it. A parent’s decision to allow his or her child
to ride this product should be based on the child’s
maturity, skill and ability.
DO NOT EXCEED THE WEIGHT LIMIT OF 55 pounds.
Rider weight does not necessarily mean a child’s size is
appropriate to fit or maintain control of the Bumper Buggie.
Refer to the section on safety for additional warnings.
ACCEPTABLE RIDING PRACTICES AND
CONDITIONS
Direct parental supervision is required at all times. The Bumper
Buggie is meant to be used only in controlled environments
appropriate for young children’s play always free of potential
traffic hazards and never on public streets. Do not allow your
child to ride the Bumper Buggie in any areas where vehicle
traffic is present. The child must remain seated at all times
when using the Bumper Buggie. Never allow more than one
child at a time to ride the Bumper Buggie. Never use near
steps, sloped driveways, hills, roadways, alleys or swimming
pool areas.
Do not allow any child to ride the Bumper Buggie in wet
weather. The Bumper Buggie is intended for use on solid,
flat, clean and dry surfaces such as pavement or level ground
without loose debris such as rocks or gravel. Wet, slick or
uneven and rough surfaces may impair traction and contribute
to possible accidents. Bumper Buggie should not be ridden
in mud, ice, puddles or water. Bumper Buggie should not be
ridden at night or when visibility is impaired.
PROPER RIDING ATTIRE
A child should always wear shoes, never ride barefooted
or in sandals, and keep shoelaces tied and out of the way
of the wheels.
USING THE CHARGER
The charger supplied with the Bumper Buggie should be
regularly examined for damage to the cord, plug, enclosure
and other parts, and in the event of such damage, the Bumper
Buggie must not be charged until the charger has been
repaired or replaced.
Use only with the recommended charger.
The charger is not a toy.
Always disconnect from the charger prior to wiping down and
cleaning your Buggie Bumper with liquid.
FAILURE TO USE COMMON SENSE AND HEED THE
ABOVE WARNINGS INCREASES RISK OF SERIOUS
INJURY. USE WITH APPROPRIATE CAUTION AND
SERIOUS ATTENTION TO SAFE OPERATION.
SAFETY WARNINGS
Safety Warnings ............................................................ 1
Before You Begin........................................................... 2
Assembly and Usage..................................................... 3
Repair and Maintenance................................................ 4
1
Troubleshooting Guide................................................... 5
Bumper Buggie Parts .................................................... 6
Warranty ........................................................................ 8
CONTENTS

Remove contents from box. Remove the foam separators that protect the components from damage during shipping.
Inspect the contents of the box for scratches in the paint, dents or kinked cables that may have occurred during
shipping. Because the Bumper Buggie was 95 percent assembled and packed at the factory, there should not be any
problems, even if the box has a few scars or dents.
Estimated Assembly and Set-Up Time
Adult assembly required.
Allow up to 15 minutes for assembly, not including initial charge time.
Allow up to 12 hours for initial charge (see below for charging information).
BEFORE YOU BEGIN
2
WARNING:
DO NOT USE NON-RAZOR
PRODUCTS WITH YOUR
RAZOR BUMPER BUGGIE.
The Bumper Buggie has been
built to certain Razor design
specifications. The original
equipment supplied at the time
of sale was selected on the basis
of its compatibility with the other
parts. Certain aftermarket products
may or may not be compatible.
Required Tools
We recommend the use of mechanic’s grade tools.
Need Help? Visit our web site for updates and a list of authorized service centers at www.razor.com
or call toll-free at 866-467-2967 Monday - Friday 8:00 AM - 5:00 PM Pacific Time.
Phillips Screwdriver
Charging the Battery
Your Bumper Buggie may not have a fully charged battery; therefore it is a good idea to charge the battery prior to use.
•Initial charge time: 12 hours • Run time: up to 40 minutes
•Recharge time: up to 8 hours, • Average battery life: 250 charge/discharge cycles
depending on the level of depletion
1Plug the charger port into the
input socket on the back of the
Bumper Buggie. The charger works
with the power switch in either the
on or off position.
Battery should be charged a minimum
of 8 hours after each use. When the
vehicle is not in regular use recharge
the battery at least once a month
until normal use is resumed.
2Plug the charger plug into a wall
outlet.
WARNING: Always
disconnect your Bumper Buggie
from the charger before cleaning
with liquid.
WARNING: Always
recharge the battery once a month
when product is not in regular use.
Failure to do so could result in a
battery that will no longer accept
a charge.
Note: If your charger does not
look like the one illustrated,
your unit has been supplied
with an alternative charger.
The specifications and charging
procedure would not change.
Chargers have built-in over-charge
protection to prevent battery from
being over-charged.
Be sure to properly align the
groove on the charger port with
the corresponding socket on
the back of the Bumper Buggie;
otherwise, no charging action
will occur.
Charger
Plug
Charger
Port

3
ASSEMBLY AND USAGE
Attaching the Seat and Seat belt
1Align holes in seat with seat
mounts inside the
Bumper Buggie.
2Using a Phillips screwdriver,
secure seat with the four screws
provided.
Controlling Your Bumper Buggie
The left and right joysticks con-
trol both the steering and motion
of the bumper buggie.
Forward Motion
Push both joysticks at the same
time to the front position.
Backward Motion
Push both joysticks at the same
time to the rear position.
Spinning Motion
Push both joysticks at the same
time in opposite directions.
Turning left or right
Push the right joystick forward to
make a left turn or push the left joy-
stick forward to make a right turn.
3When installed correctly the
seat belt should be able to easily
buckle around rider’s waist.
WARNING: The seat
belt provided is for “play” use only.
It is not an ASTM-approved lap
restraining device. The seat belt is
not required for normal use. Use at
your own risk.

4
q Battery Care and Disposal
Do not store the battery in temperatures above 75° or below -10° F.
CONTAINS SEALED LEAD BATTERY. BATTERY MUST BE RECYCLED.
Disposal: Your Razor product uses sealed lead-acid batteries which must be recycled or disposed of in an
environmentally sound manner. Do not dispose of a lead-acid battery in a fire. The battery may explode or leak. Do not
dispose of a lead-acid battery in your regular household trash. The incineration, land filling or mixing of sealed lead-
acid batteries with household trash is prohibited by law in most areas. Return exhausted batteries to a federal or state
approved lead-acid battery recycler or a local seller of automotive batteries. If you live in Florida or Minnesota, it is
prohibited by law to throw away lead-acid batteries in the municipal waste stream.
q Charger
The transformer/charger supplied with the Bumper Buggie should be regularly examined for damage to the cord, plug,
enclosure and other parts, and, in the event of such damage, the vehicle must not be charged until it has been repaired
or replaced.
Use ONLY with the recommended charger.
q Replacement Parts
The most frequently requested replacement parts (wheels, tires, tubes, batteries and chargers) are available for
purchase at some Razor retail partners or online at www.razorama.com. For other parts contact an authorized Razor
repair center.
q Repair Centers
For a list of authorized Razor repair centers:
• Check online at www.razor.com.
• Send an e-mail to [email protected] or call 866-467-2967 for the center nearest you.
WARNING: If a battery
leak develops, avoid contact with
the leaking acid and place the
damaged battery in a plastic bag.
Refer to the disposal instructions at
left. If acid comes into contact with
skin or eyes, flush with cool water
for at least 15 minutes and contact
a physician.
REPAIR AND MAINTENANCE

5
Vehicle does not run
Vehicle was running but
suddenly stopped
Short run time (less than
30 minutes per charge)
Vehicle runs sluggishly
Sometimes the vehicle
doesn’t run, but other
times it does
Charger gets warm
during use
Problem Possible Cause Solution
Undercharged battery
Charger is not working
Loose wires or connectors
Undercharged battery
Battery is old and will not accept
full charge
Driving conditions are too stressful
Vehicle is overloaded
Loose wires or connectors
Motor or electrical switch damage
Normal response to charger use
Charge the battery. A new battery should have been charged for at least 12
hours before using the vehicle for the first time and up to 8 hours after each
subsequent use.
Check all connections. Make sure the charger port is tightly plugged into the
charging port on the Bumper Buggie, and that the charger is plugged securely
into the wall.
Make sure power flow to the wall outlet is on.
You may check to see if your charger is working by using a volt meter or
asking your local Razor authorized service center to test your charger for you.
Check all wires and connectors to make sure they are tight.
Charge the battery. A new battery should have been charged for at least 12
hours before using the vehicle for the first time and up to 8 hours after each
subsequent use.
Check all wires and connectors. Make sure the battery connector is tightly
plugged into the charger connector, and that the charger is plugged securely
into the wall.
Make sure power flow to the wall outlet is on.
Even with proper care, a rechargeable battery does not last forever. Average
battery life is 1 to 2 years depending on vehicle use and conditions. Replace
only with a Razor replacement battery.
Use only on solid, flat, clean and dry surfaces such as pavement or level
ground.
Make sure you do not overload the vehicle by allowing more than one rider
at one time, exceeding the 55 lb. maximum weight limit, going up a hill or
towing objects behind the vehicle.
Check all wires around the motor and all connectors to make sure they
are tight.
Contact your local Razor authorized service center for diagnosis and repair.
No action required. This is normal for some chargers and is no cause for
concern. If your charger does not get warm during use, it does not mean that
it is not working properly.
TROUBLESHOOTING GUIDE
Need Help? Visit our web site for updates and a list of authorized service centers at www.razor.com
or call toll-free at 866-467-2967 Monday - Friday 8:00 AM - 5:00 PM Pacific Time.

Keep your Bumper Buggie running for years with genuine Razor parts. Visit our web site or e-mail us for more information on spare part availability.
(Specifications subject to change without notice.)
Bumper Buggie parts
01 Faux headlight cover (right/left)
02 Upper body
03 Joystick switch/grip
04 Faux taillight cover (right/left)
05 Seat
06 Seat belt
07 Charger port w/ wires
08 On/off switch
09 Bumper
10 Chassis/ Lower body
11 Battery (6V/ 8Ah)
11-1 Battery hold-down
12 Reset button w/ wire
13 Swivel caster/ Front wheel
14 Rear wheel complete
15 Gear box
16 Motor (6V 30W)
17 Rear axle set
6

7
SB 1918 (CALIFORNIA) DECLARATION
YOUR INSURANCE POLICIES MAY NOT PROVIDE COVERAGE FOR ACCIDENTS
INVOLVING THE USE OF THIS SCOOTER/ELECTRIC VEHICLE. TO DETERMINE
IF COVERAGE IS PROVIDED, YOU SHOULD CONTACT YOUR INSURANCE
COMPANY OR AGENT.

8
Razor Limited Warranty
The manufacturer warranties this product to be free of manufacturing defects
for a period of 90 days from date of purchase. This Limited Warranty does
not cover normal wear and tear, tires, tubes or cables, or any damage, failure
or loss caused by improper assembly, maintenance, or storage or use of the
Razor Bumper Buggie.
This Limited Warranty will be void if the product is ever
• used in a manner other than for recreation;
• modified in any way;
• rented.
The manufacturer is not liable for incidental or consequential loss or damage
due directly or indirectly to the use of this product.
Razor does not offer an extended warranty. If you have purchased an
extended warranty, it must be honored by the store at which it was
purchased.
For your records, save your original sales receipt with this manual and write
the serial number below.
__________________________________________
Item Number:
25117460
WARRANTY
Need Help? Visit our web site for updates and a list of authorized service centers at www.razor.com
or call toll-free at 866-467-2967 Monday - Friday 8:00 AM - 5:00 PM Pacific Time.
Patent Pending
Printed in China for:
Razor USA LLC
PO Box 3610
Cerritos, CA 90703
© Copyright 2006 Razor USA, LLC. All rights reserved.
RAZOR(R) and the Razor Logo Design are among the registered
trademarks of Razor USA LLC and/or it’s affiliated companies in
the United States and select foreign countries. 120607
DO NOT RETURN TO STORE
Do not use this vehicle for the first time until you
have charged the battery for at least 12 hours.
Failure to follow these instructions may damage
your vehicle and void your warranty.
