RCA THOMSON Joggable RP2440 User manual

RP2440/LAD990U
IMPORTADOR
Comercializadora Thomson
de Mexico, S.A. de C.V.
Miguel de Cervantes Saavedra No. 57
Col. Granada
Mexico D.F. C.P. 11520
Telefono: 52 54 53 73
R.F.C.: CTM-980723-KS5
0137
BASS BOOST
Thomson multimedia Inc.
10330 N. Meridian St.
Indianapolis, IN 46290
© 2001 Thomson multimedia Inc.
Trademark(s) ® Registered
Marca(s) ® Registrada(s)
Marque(s) ® Deposée(s)
www.rca.com
55171820 rev.1(EN/E/F)
It is important to read this instruction book prior to using your new product for the first time.
Es importante leer este manual antes de usar por vez primera su euipo.
RP2440IB EN 10/22/01 9:32 AM Page 2

FCC INFORMATION FCC INFORMATION
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must
accept any interference received, including interference that
may cause undesired operation.
In accordance with FCC requirements, changes or modifica-
tions not expressly approved by Thomson multimedia Inc.
could void the user’s authority to operate this product.
This device generates and uses radio frequency (RF) energy,
and if not installed and used properly, this equipment may
cause interference to radio and television reception.
If this equipment does cause interference to radio or televi-
sion reception (which you can determine by unplugging the
unit), try to correct the interference by one or more of the
following measures:
o Re-orient the receiving antenna (that is, the antenna for
the radio or television that is "receiving" the interference).
o Move the unit away from the equipment that is receiving
interference.
o Plug the unit into a different wall outlet so that the unit
and the equipment receiving interference are on different
branch circuits.
If these measures do not eliminate the interference, please
consult your dealer or an experienced radio/television techni-
cian for additional suggestions. Also, the Federal
Communications Commission has prepared a helpful booklet,
"How To Identify and Resolve Radio TV Interference
Problems." This booklet is available from the U.S.
Government Printing Office, Washington, DC 20402. Please
specify stock number 004-000-00345-4 when ordering copies.
This product complies with DHHS Rules 21 CFR Subchapter J.
Applicable at the date of manufacture.
For Your Records
In the event that service should be required, you may need both
the model number and the serial number. In the space below,
record the date and place of purchase, and the serial number:
Model No.
Date of Purchase
Place of Purchase
Serial No.
Service Information
This product should be serviced only by those specially trained in
appropriate servicing techniques. For instructions on how to
obtain service, refer to the warranty included in this Guide.
WARNING:TO PREVENT FIRE
OR ELECTRICAL SHOCK HAZARD,
DO NOT EXPOSE THIS PRODUCT
TO RAIN OR MOISTURE.
SEE MARKING ON BOTTOM / BACK OF PRODUCT
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
THE EXCLAMATION
POINT WITHIN THE
TRIANGLE IS A
WARNING SIGN
ALERTING YOU OF
IMPORTANT
INSTRUCTIONS
ACCOMPANYING
THE PRODUCT.
THE LIGHTNING
FLASH AND ARROW-
HEAD WITHIN THE
TRIANGLE IS A
WARNING SIGN
ALERTING YOU OF
"DANGEROUS
VOLTAGE" INSIDE
THE PRODUCT.
CAUTION: TO REDUCE THE
RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER
(OR BACK). NO USER-
SERVICEABLE PARTS IN-
SIDE. REFER SERVICING
TO QUALIFIED SERVICE
PERSONNEL.
Have a Blast- Just Not in Your Eardrums
Make sure you turn down the volume on the unit
before you put on headphones. Increase the volume
to the desired level only after headphone are in place.
This Class B digital apparatus complies with Canadian
ICES-003.
Accessories:
1. the main unit;
2. one remote control;
3. one external backup batteries pack;
4. one headphones;
5. one carrying pouch;
6. AC/DC adaptor;
7. user manual.
8. carrying strap
9. 2 x AAA batteries (LAD990RC only)
1 2
EN EN
RP2440IB EN 10/22/01 9:32 AM Page 4

SAFETY INFORMATION SAFETY INFORMATION
ADVARSEL!
USYNLIG LASERSTRÅLNING VED
ÅBNING NAR SIKKERHEDSAFBRYDERE
ER UDE AF FUNKTION. UNGDÅ
UDSAETTELSE FOR STRÅLNING.
VORSICHT!
UNSICHTBARE LASERSTRALUNG
WENN ABDECKUNG GEÖFFNET UND
SICHERHEITS– VERRIEGELUNG
ÜBERBRÜCKT.
NICHT DEM LASERSTRAHL AUSSETZEN!
CLASS 1 LASER PRODUCT
LASER KLASSE 1
APPAREIL A LASER DE CLASSE 1
LUOKAN 1 LASERLAITE
KLASS 1 LASERAPPARAT
CAUTION – INVISIBLE LASER
RADIATION WHEN OPEN AND
INTERLOCKS FAILED OR DEFEATED.
AVOID EXPOSURE TO BEAM.
ATTENTION – RAYONNEMENT LASER
INVISIBLE DANGEREUX EN CAS
D'OUVERTURE ET LORSQUE LA
SECURITE EST NEUTRALISEE.
EXPOSITION DANGEREUSE AU
FAISCEAU.
VARNING–
OSYNLIG LASERSTRÅLNING NÄR
DENNA DEL ÄR ÖPPNAD OCH
SPÄRRAN ÄR URKOPPLADE.
BETRAKTA EJ STRÅLEN.
VARO!
AVATTAESSA JA SOUJALUKITUS
OHITETTAESSA OLET ALTTIINA
NÄKYMÄTTÖMÄLLE.
LASERSÄTEILYLLE ÄLÄ KATSO
SÄTEESEEN.
Have a Blast- Just Not in
Your Eardrums
Make sure you turn down
the volume on the unit
before you put on
headphones. Increase the
volume to the desired level only after
headphone are in place.
Please respect the environment!
Before throwing any batteries
away, consult your distributor
who may be able to take them
back for specific recycling. The descriptions and characteristics given in this document are given as a gen-
eral indication and not as a guarantee. In order to provide the highest quality
product possible, we reserve the right to make any improvement or modifica-
tion without prior notice. The English version serves as the final reference on
all products and operational details should any discrepancies arise in other
languages.
Thomson information CAUTION
Invisible laser radiation when open. Avoid exposure to beam. Class I
laser product. This system must be opened only by qualified techni-
cians to prevent accidents caused by the laser beam.
LASER λ = 780 nm, P max = 5 mW
Rating Information: At bottom of the unit
this unit comply with the existing requirements
In accordance with the rating plate of the unit,this unit complies with
current standards concerning electrical safety and electromagnetlc
compatibility.
3 4
RP2440IB EN 10/22/01 9:32 AM Page 6

CD PLAYER CD PLAYER
1. Play/pause -- Plays CD, or pauses during playback.
2. Stop -- stops CD playback.
3. Skip backward -- skips to the previous track(remote only).
4. Skip forward -- skips to the next track
5. B. Boost -- Press to activate Bass Boost./Surround function.
6. Vol+/Vol- -- increases/decreases volume level.
7. Mode -- toggles among repeat / random/ intro mode.
8. Memory -- selects display mode (time elapsed / remaining time)
activates program mode (at CD stop mode only)
9. Control -- slides to HOLD position to lock keys function (no
signal will be displayed)
BASS BOOST
1. Play/pause -- Plays CD, or pauses during playback.
2. Stop -- stops CD playback.
3. Skip forward -- skips to the next track.
4. Bass Boost--activates Bass Boost/surround sound function.
5. Vol+/Vol- -- increases/decreases volume level (from 0 to 30)
6. Phones -- jack for headphones/optical out.
7. Control -- jack for remote control.
8. Recharge indicator -- light on when charging batteries.
9. Open -- slides to open the door.
10. Hold -- locks keys on the main unit, a signal will be dis-
played when lock mode is ON.
11. DC in -- jack for external power.
1 2 3411
10
9
Note: The "Hold" switch on the main unit is to lock the
keys on the main unit only.
TRACK MIN SEC
MEMORY
CONTROLS
ON HOLD
MODE
B.BOOST
6
3 4
219
8
57
VOLVOL
5
6
7
5 6
EN EN
The multi-purpose jack on the main unit can be connected to the
following devices(figures are shown below):
Main
unit
Optical-out
Headphone
Line-out
or
Remote
Main
unit
Headphone
Line-out
or
Main
unit
8
P
1
BASS BOOST
SURROUND
RP2440IB EN 10/22/01 9:32 AM Page 8

Program
Note: the CD player must be in Stop mode.
1. Press memory button on the remote .
2. Select the track to be stored by pressing or .
3. Press memory again to confirm and store.
4. Repeat steps 2-3 to store other tracks.
5. Press play button to listen to your programmed songs.
Note: you can program up to 24 tracks.
To cancel your program, press and hold the Mode button when in
stop mode. Erase will appear on the display.
Program edit
1. Press and hold the MEMORY button when in stop mode.
2. Display shows “e.g.13 E_01”, rightmost number shows the program
number, leftmost number shows the track number, “E” indicates it is
in edit mode.
3. Press or to change the track number.
4. Press MEMORY to accept and move to next program number.
5. To delete a program number, select track 00 and press MEMORY.
6 Repeat steps 3-5 to edit other tracks.
7. Press PLAY button to listen to your programmed songs.
CD PLAYER
Repeat and Random Playback
Press mode repeatedly to
1. Replay the entire disc;
2. Replay the current track;
3. Random playback each track on disc once;
4. Repeat random tracks.
5. Intro mode
6. Back to standard playback.
Intro mode
1. Press mode repeatedly until “Scan” signal is displayed, the unit
will play the first 10 seconds of each track.
Smart Resume
When you stop CD play and power off the unit, or if CD compart-
ment lid is opened, Smart Resume is automatically activated. It
stores all the current settings and modes: current track, Shuffle, time
display, Mode (Repeat/Repeat All/Program), volume, bass boost and
surround When play mode is on again, the unit RESUMES to the set-
tings and plays the last track you listen to.
Note: If a different CD is inserted, playback will start from the first
track; if you press STOP to return to stop mode, then press PLAY
again without powering off the unit, the unit will play from track
one.
7
EN
Listening to a Compact Disc
1. Slide the OPEN switch to the right to open the door. Insert a
disc and press lightly on the centre to lock. Close the door.
2. Press PLAY/PAUSE button, then the total number of tracks and
time of the CD will be displayed on the remote.
3. CD starts to play back.
4. You can skip to next track by pressing the button.
CD PLAYER
8
EN
1
RP2440IB EN 10/22/01 9:32 AM Page 10

CD PLAYER
The JOGGABLE SHOCK PROTECTION system prevents sound inter-
ruptions when impacts or vibrations occur, and this function is
always ON, in order to provide uninterrupted playback and preserve
batteries.
Note: the anti-shock function will be automatically disabled when
optical output is connected.
9
Troubleshooting Tips
No power, does not work?
• Batteries may be inserted
incorrectly.
• Batteries may be empty.
Recharge (only Ni-Cd/Ni-MH
battery) or replace new bat-
teries.
• Connection may be loose if
using AC/DC transformer.
• HOLD button may be acti-
vated.
Disc cannot be played?
• Disc may not be inserted
correctly with label side fac-
ing upward.
• CD-RW (or CD-R) disc may not
be recorded properly.
Skipping tracks or bad sound
quality?
• Disc may be dirty or scratched
badly.
• Disc lens may be dirty and
need cleaning.
• There may be strong magnetic
fields (e.g. too close to TV) near
the unit.
Battery type
AAAx2
AAx2 (ext. batt. pack)
AAAx2 + AAx2
Estimated time for playing
14 hrs.
30 hrs.
50 hrs.
CD PLAYER
Recharge function
To charge Ni-Cd/Ni-MH batteries (not included):
1. Insert 2 rechargeable batteries in the main unit compart-
ment.
2. Connect the main adaptor.
3. Make sure the HOLD switch is off.
4. Press STOP to start battery charging.
5. An animated battery logo will be displayed when charg-
ing is in progress.(recharge indicator light on)
6. When the batteries are fully charged, “Full” will be dis-
played, and charging will automatically stop.
7. You can also stop recharge operation by pressing PLAY
button/ removing the AC adaptor.
Attention: To avoid battery leakage, please do not activate
the recharge function using non-rechargeable batteries.
If error occurs during the recharge process, “bAtErr” will be
displayed. For example, non-rechargeable batteries are
inserted into the unit by mistake.
AC OUTLET POWER SUPPLY
You can power your CD player with the supplied AC/DC Adapter.
Refer to the table for details of the operating voltage of the
Adapter supplied with your unit.
AC/DC Adapter is purposed for indoor use in dry rooms only.
Remove the jack from the device to use it with the batteries.
Note : Power is fed to the unit even when it is not function-
ing. To cut the power supply off, the AC/DC Adapter must
be unplugged.
EN
10
EN
Model Number
RP2440
LAD990RC
LAD990U
AC/DC Adapter
5-4142
Required Rating:
Input: 120V 60Hz 9.0W
Output:4.5VDC@700mA
Batteries
AAAx2(not included)
5-4143 (230v 50Hz) AAAx2(included)
5-4144 (230v 50Hz) AAAx2(included)
SPC: Sound Pressure Control at 100dB maximum (only for
Thomson models)
RP2440IB EN 10/22/01 9:32 AM Page 12

US LIMITED WARRANTY
What your warranty covers:
• Defects in materials or workmanship.
For how long after your purchase:
• One year from date of purchase.
The warranty period for rental units begins with the first rental or 45 days
from date of shipment to the rental firm, whichever comes first.
What we will do:
• Provide you with a new, or at our option, a refurbished unit. The exchange
unit is under warranty for the remainder of the original product’s warranty
period.
• Proof of purchase in the form of a bill of sale or receipted invoice which is
evidence that the product is within the warranty period must be presented to
obtain warranty service. For rental firms, proof of first rental is also required.
How to make a warranty claim:
• Properly pack your unit. Include any cables, etc., which were originally pro-
vided with the product. We recommend using the original carton and pack-
ing materials.
• Include evidence of purchase date such as the bill of sale. Also print your
name and address and a description of the defect. Send via standard UPS or
its equivalent to:
Thomson multimedia Inc.
Product Exchange Center
11721 B Alameda Avenue
Socorro, Texas 79927
• Insure your shipment for of loss or damage. Thomson accepts no liability in
case of damage or loss en route to Thomson.
• Pay any charges billed to you by the Exchange Center for service not covered
by the warranty.
• A new or refurbished unit will be shipped to you freight prepaid.
What your warranty does not cover:
• Customer instruction. (Your Owner’s Manual provides information regard-
ing operating Instructions and user controls. For additional information, ask
your dealer.)
• Installation and set-up service adjustments.
• Batteries.
• Damage from misuse or neglect.
• Products which have been modified or incorporated into other products.
• Products purchased or serviced outside the USA.
• Acts of nature, such as but not limited to lightning damage.
11
MORE INFORMATION
• Do not store CDs in damp areas.
• Do not expose CDs to high temperatures.
• Do not put any tape or adhesives on either side of the disc.
• You should avoid leaving the CD door open. Dust is liable
to impair performance of the laser optical unit.
• Do not use your set immediately after transport from a
cold place to a warm place : there may be condensation prob-
lems.
• Do not touch the playing surface. Make sure that you keep
your set away from water and high temperatures.
• If you do not use your set on battery power for more than
one month, we advise you to take out all the batteries.
• To prevent personal injury, do not reverse any battery and
do not mix battery types.
• Discard leaking batteries immediately. Leaking batteries
can cause skin burns or other personal injury.
• Prolonged use of the CD player at full volume can damage
the user’s ear.
MAINTENANCE
Clean the player with a soft cloth, or a damp chamois leather.
Never use solvents.
Notes on CD-R/RW Discs
• CD-R/RW discs recorded by personal computers or some CD-
R/RW recorders may not be played properly due to varied
quality of software and recorder.
• Do not load an unrecorded CD-R/RW disc into the unit.
This may take a longer time to read the disc.
TECHNICAL SPECIFICATIONS
* Frequency response: 20Hz to 20kHz
Power Supply
• 4.5V DC (through AD/DC Adapter)
• 2 “AAA” alkaline/ rechargeable Ni-cd/ Ni-MH batteries;
• 2 “AA” batteries for External Backup Battery Pack.
• 4.5V DC (through car DC Adapter)(not included)
EN
12
EN
RP2440IB EN 10/22/01 9:32 AM Page 14

US LIMITED WARRANTY CANADIAN LIMITED WARRANTY
Product Registration:
• Please complete and mail the Product registration Card packed with your
unit. It will make it easier to contact you should it ever be necessary. The
return of the card is not required for warranty coverage.
Limitation of Warranty:
• THE WARRANTY STATED ABOVE IS THE ONLY WARRANTY APPLICABLE
TO THIS PRODUCT. ALL OTHER WARRANTIES, EXPRESS OR IMPLIED
(INCLUDING ALL IMPLIED WARRANTIES OF MERCHANTABILITY OR FIT-
NESS FOR A PARTICULAR PURPOSE) ARE HEREBY DISCLAIMED. NO VER-
BAL OR WRITTEN INFORMATION GIVEN BY THOMSON MULTIMEDIA
INC., ITS AGENTS OR EMPLOYEES SHALL CREATE A GUARANTY OR IN
ANY WAY INCREASE THE SCOPE OF THIS WARRANTY.
• REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS
THE EXCLUSIVE REMEDY OF THE CONSUMER. THOMSON MULTIMEDIA
INC. SHALL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAM-
AGES RESULTING FROM THE USE OF THIS PRODUCT OR ARISING OUT OF
ANY BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS PROD-
UCT. THIS DISCLAIMER OF WARRANTIES AND LIMITED WARRANTY ARE
GOVERNED BY THE LAWS OF THE STATE OF INDIANA. EXCEPT TO THE
EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON THIS
PRODUCT IS LIMITED TO THE APPLICABLE WARRANTY PERIOD SET
FORTH ABOVE.
How state law relates to this warranty:
• Some states do not allow the exclusion nor limitation of incidental or conse-
quential damages, or limitations on how long an implied warranty lasts, so
the above limitations or exclusions may not apply to you.
• This warranty gives you specific legal rights, and you also may have other
rights that vary from state to state.
If you purchased your product outside the USA:
• This warranty does not apply. Contact your dealer for warranty informa-
tion.
Thomson multimedia Ltd. warrants to the purchaser or gift recipient that if any manufactur-
ing defect becomes apparent in this product within 1 year from the original date of pur-
chase, it will be replaced free of charge, including return transportation.
This warranty does not include damage to the product resulting from accidents, misuse or
leaking batteries.
Should your product not perform properly during the warranty period, either:
1. Return it to the selling dealer with proof of purchase for replacement,
OR
2. Remove the batteries (where applicable), and pack product complete with accessories in
the original carton (or equivalent). Mail prepaid (with proof of purchase) and insured to:
Thomson multimedia Ltd.
6200 Edwards Blvd.,
Mississauga, Ontario,
L5T 2V7
Canada
The provisions of this written warranty are in addition to and not a modification of or sub-
traction from the statutory warranties and other rights and remedies contained in any
applicable legislation, and to the extent that any such provisions purport to disclaim,
exclude or limit any such statutory warranties and other rights and remedies, such provi-
sions shall be deemed to be amended to the extent necessary to comply therewith.
If you are unable to find a qualified servicer for out of warranty service, you may write to:
Thomson multimedia Inc.
P.O. Box 0944
Indianapolis, Indiana, U.S.A., 46206-0944
Attach your sales receipt to this booklet for future reference. This information is required if
service is needed during the warranty period.
PURCHASE DATE
NAME OF STORE
13 14
RP2440IB EN 10/22/01 9:32 AM Page 16
