RCA X2400 - Lyra Video Flash Recorder User manual

X2400
user
manual
It is important to read this instruction book prior to using your new product for the first time.
Es importante leer este manual antes de usar por vez primera su euipo.
Lyra

EN
FCC Information
The descriptions and characteristics given in this document are given as a general indication and not as a guarantee. In
order to provide the highest quality product possible, we reserve the right to make any improvement or modification
without prior notice. The English version serves as the final reference on all products and operational details should
any discrepancies arise in other languages.
FCC Information
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following
two conditions: (1) This device may not cause
harmful interference, and (2) this device
must accept any interference received,
including interference that may cause
undesired operation.
In accordance with FCC requirements,
changes or modifications not expressly
approved by Thomson Inc. could void the
user’s authority to operate this product.
This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to Part 15 of FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference in a residential installation . This
equipment generates, uses, and can radiate
radio frequency energy and, if not installed
and used in accordance with the instructions,
may cause harmful interference to radio
communications. However, there is no
guarantee that interference will not occur in
a particular installation. If this equipment
does cause harmful interference to radio or
television reception, which can be
determined by turning the equipment off
and on, the user is encouraged to try to
correct the interference by one or more of
the following measures
• Reorient or relocate the receiving
antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an outlet on a
circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced
radio/TV technician for help.
Also, the Federal Communications
Commission has prepared a helpful booklet,
"How To Identify and Resolve Radio TV
Interference Problems." This booklet is
available from the U.S. Government Printing
Office, Washington, DC 20402. Please specify
stock number
004-000-00345-4 when ordering copies.
This product complies with DHHS Rules 21
CFR Subchapter J. Applicable at the date of
manufacture.
This Class B digital apparatus complies with
Canadian ICES-003.
Cet appareil numérique de la class B est
conforme à la norme du NMB-003 du
Canada
RCA
X2400A
Equipment tested for
compliance as a
complete unit
WARNING:TO PREVENT FIRE OR ELECTRICAL
SHOCK HAZARD, DO NOT EXPOSETHIS PRODUCT
TO RAIN OR MOISTURE.
SEE MARKING ON BOTTOM / BACK OF PRODUCT
CAUTION
RISKOFELECTRICSHOCK
DONOTOPEN
THE EXCLAMATION
POINT WITHIN THE
TRIANGLE IS A
WARNING SIGN
ALERTING YOU OF
IMPORTANT
INSTRUCTIONS
ACCOMPANYING
THE PRODUCT.
THE LIGHTNING
FLASH AND ARROW-
HEAD WITHIN THE
TRIANGLE IS A
WARNING SIGN
ALERTING YOU OF
"DANGEROUS
VOLTAGE" INSIDE
THE PRODUCT.
CAUTION: TO REDUCE THE
RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER
(OR BACK). NO USER-
SERVICEABLE PARTS IN-
SIDE. REFER SERVICING
TO QUALIFIED SERVICE
PERSONNEL.

EN
Safety Information
Product Registration
Please fill out the product registration card
and return it immediately. Returning this
card allows us to contact you if needed.
For Your Records
Keep your sales receipt for proof of
purchase to obtain warranty parts and
service.
In the event that service should be required,
you may need both the model number and
the serial number. In the space below,
record the date and place of purchase, and
the serial number:
Date of Purchase
Place of Purchase
Serial No.
Service Information
This product should be serviced only by those
specially trained in appropriate servicing
techniques. For instructions on how to obtain
service, refer to the warranty included in this
Guide.
Technical Specification
Product: Portable Multimedia Player
Brand: Lyra
Model: X2400A
Electrical Consumption
Lithium polymer rechargeable battery
IMPORTER
Comercializadora Thomson de México, S.A. de
C.V.
Álvaro Obregón No. 151. Piso 13.
Col. Roma. Delegación Cuauhtémoc
C.P. 06700. México, D.F.
Telefono: 52-55-11-020360
RFC: CTM-980723-KS5

Precautions for the Unit
• Do not use the unit immediately after
transportation from a cold place to a
warm place; condensation problem
may result.
• Avoid shock to the unit.
• Do not store the unit near fire, places
with high temperature or in direct
sunlight.
• Clean the unit with a soft cloth or a
damp chamois leather. Never use
solvents.
• The unit must only be opened by
qualified personnel.
Caution
• Keep product out of direct sunlight.
Exposure to direct sunlight or extreme
heat (such as inside a parked car) may
cause damage or malfunction.
• Do not expose to rain or moisture.
• The apparatus shall not be exposed to
dripping or splashing and that no
objects filled with liquids, such as
vases, shall be placed on the
apparatus.
Caution while driving
Use of headphones while operating an
automobile or moving vehicle is not
recommended and is unlawful in some
states and areas. Be careful and attentive
on the road. Stop operation of the unit
if you find it disruptive or distracting
while driving.
Headset safety
Have a Blast- Just Not in
Your Eardrums
Make sure you turn down
the volume on the unit
before you put on
headphones. Increase the volume to the
desired level only after headphones are
in place.
• Do not play your headset at a high
volume. Hearing experts warn
against extended high-volume play.
•If you experience a ringing in your
ears, reduce volume or discontinue
use.
• You should use extreme caution or
temporarily discontinue use in
potentially hazardous situations.
Even if your headset is an open-air
type designed to let you hear outside
sounds, don’t turn up the volume so
high that you are unable to hear
what is around you.
EN
Important Information
Warning:
Use of this product is for your
personal use only. Unauthorized
recording or duplication of copyrighted
material may infringe upon the rights of
third parties and may be contrary to
copyright laws.
!

EN
Important Information
Important Battery
Information
• Charge the unit for at least 2 hours
before first use.
• Charge the unit for at least 2 hours after
putting away the unit for a long time.
• The battery used in this device may
present a risk of fire or chemical burn if
mistreated. Do not separately
recharge, disassemble, heat above
100ºC (212ºF), or incinerate.
• Do not attempt to open the unit. No
user serviceable parts inside.
• To reduce risk of injury, use only
rechargeable battery recommended by
the manufacturer for this product.
Other types of battery may burst
causing damage and personal injury.
• Keep the unit away from children. Do
not disassemble or incinerate.
• Only use the charger provided in the
package. Use of another charger may
present a risk of fire or explosion.
Caution
• The battery used in this
device may present a risk of
fire, explosion, or chemical
burn if mistreated. Do not
separately recharge,
disassemble, heat above 100ºC
(212ºF), or incinerate.
• Do not place the battery under direct
sunlight or in excessively hot places
over 45ºC (113ºF) such as the
dashboard of car.
• Dispose of used battery promptly.
Keep away from children. Do not
disassemble and do not dispose of in
fire.
• Do not separately recharge,
disassemble, incinerate, or expose to
high temperatures. Examples of high
temperatures that may damage your
product include leaving it in a locked
car in the summer, or putting it on top
of other heat generating electronics
devices (such as power amplifiers and
computer monitors).
Lithium

EN
IMPORTANT SAFETY INSTRUCTIONS
PLEASE READ AND SAVE FOR FUTURE REFERENCE
Some of the following information may
not apply to your particular product;
however, as with any electronic product,
precautions should be observed during
handling and use.
•Read these instructions.
•Keep these instructions.
•Heed all warnings.
•Follow all instructions.
•Do not use this apparatus near water.
•Clean only with dry cloth.
•Do not block any ventilation openings.
Install in accordance with the
manufacturer’s instructions.
•Do not install near any heat sources
such as radiators, heat registers, stoves,
or other apparatus (including
amplifiers) that produce heat.
•Do not defeat the safety purpose of
the polarized or grounding-type plug.
A polarized plug has two blades with
one wider than the other. A grounding
type plug has two blades and a third
grounding prong. The wide blade or
the third prong is provided for your
safety. If the provided plug does not fit
into your outlet, consult an electrician
for replacement of the obsolete outlet.
•Protect the power cord from being
walked on or pinched particularly at
plugs, convenience receptacles, and
the point where they exit from the
apparatus.
•Only use attachments/accessories
specified by the manufacturer.
•Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the
apparatus. When a cart is used, use
caution when moving the
cart/apparatus combination to avoid
injury from tip-over.
•Unplug this apparatus during lightning
storms or when unused for long
periods of time.
•Refer all servicing to qualified service
personnel. Servicing is required when
the apparatus has been damaged in
any way, such as power-supply cord or
plug is damaged, liquid has been
spilled or objects have fallen into the
apparatus, the apparatus has been
exposed to rain or moisture, does not
operate normally, or has been
dropped.
]
Portable Cart Warning

EN
IMPORTANT SAFETY INSTRUCTIONS
•ADDITIONAL SAFETY INFORMATION
•Apparatus shall not be exposed to
dripping or splashing and no objects
filled with liquids, such as vases, shall
be placed on the apparatus.
•Always leave sufficient space around
the product for ventilation. Do not
place product in or on a bed, rug, in a
bookcase or cabinet that may prevent
air flow through vent openings.
•Do not place lighted candles,
cigarettes, cigars, etc. on the product.
•Connect power cord only to AC power
source as marked on the product.
•Care should be taken so that objects do
not fall into the product.
•Do not attempt to disassemble the
cabinet. This product does not contain
customer serviceable components.
•IF YOUR PRODUCT OPERATES ON
BATTERIES, adhere to the following
precautions:
A. Any battery may leak electrolyte if
mixed with a different battery type, if
inserted incorrectly, or if all batteries
are not replaced at the same time.
B. Any battery may leak electrolyte or
explode if disposed of in fire or an
attempt is made to charge a battery
not intended to be recharged.
C. Discard leaky batteries immediately.
Leaking batteries can cause skin burns
or other personal injury. When
discarding batteries, be sure to dispose
of them in the proper manner,
according to your state/provincial and
local regulations.

EN
End User License Agreement
IMPORTANT-READ CAREFULLY: This End User
License Agreement ("Agreement") is a
legal agreement between you and
Thomson Inc. ("Thomson") for the Lyra
Device application/driver software program
and associated documentation, if any
("Program").
ACKNOWLEDGMENT
BY INSTALLING THE SOFTWARE OR CLICKING ON
THE ACCEPTANCE BUTTON OF THE SOFTWARE,
COPYING OR OTHERWISE USING THE PROGRAM,
YOU ACKNOWLEDGE AND AGREE THAT YOU
HAVE READ THIS AGREEMENT, UNDERSTAND IT,
AND AGREE TO BE BOUND BY ITS TERMS AND
CONDITIONS. IF YOU DO NOT AGREE TO THE
TERMS OF THIS LICENSE AGREEMENT, CLICK ON
THE REJECTION BUTTON AND/OR DO NOT
INSTALL THE SOFTWARE AND/OR DO NOT USE
THE PROGRAM.
LICENSE
a) You are granted the license (i) to use
the Program on a single workstation
and (ii) to make one (1) copy of the Program
into any machine-readable form for backup of
the Program, provided the copy contains all of
the original Program’s proprietary notices.
b) You may transfer the Program and license,
only as part of the Audio Device, to another
party if the other party agrees to accept the
terms and conditions of this Agreement. If
you transfer the Program, you must at the
same time either transfer all copies to the
same party or destroy any copies not
transferred.

EN
End User License Agreement
LICENSE RESTRICTIONS
a) Except for the licenses expressly granted to
you in this Agreement, no other licenses are
implied.
b) You may not (i) modify, translate, reverse
engineer, decompile, disassemble (except to
the extent that this restriction is expressly
prohibited by law) or create derivative works
based upon the Program or (ii) copy the
Program, except as expressly permitted
herein. You agree that you shall only use the
Program in a manner that complies with all
applicable laws in the jurisdictions in which
you use the Program, including, but not
limited to, applicable restrictions concerning
copyright and other intellectual property
rights.
c) The Program may contain pre-release code
that does not perform at the level of a final
code release. In this case, the Program may
not operate properly. Updated versions of
the Program can be downloaded from
www.rca.com.
d) Thomson is not obligated to provide support
services for the Program.
e) The Program is provided with "RESTRICTED
RIGHTS". Use, duplication, or disclosure by
the U.S. Government is subject to restrictions
as set forth in subparagraph (c)(1)(ii) of
DFARS 252.227-7013, or FAR 52.227-19, or in
FAR 52.227-14 Alt. III, as applicable.
TERM AND TERMINATION
a) The license is effective on the date you accept
this Agreement, and remains in effect until
terminated by either party.
b) You may terminate this license without any
notice or delay, by destroying or permanently
erasing the Program and all copies thereof.
c) If you use, copy, modify, or transfer the
Program, or any copy, in whole or part,
except as expressly provided for in this
license, your license is automatically
terminated.
d) When the license is terminated, you must
destroy or permanently erase the Program
and all copies thereof.

EN
End User License Agreement
OWNERSHIP RIGHTS
All title and intellectual property rights in and to
the Program and any copies thereof are owned by
Thomson or its suppliers. All title and intellectual
property rights in and to the content which may
be accessed through use of the Program is the
property of the respective content owner and
may be protected by applicable copyright or
other intellectual property laws and treaties. This
license grants you no rights to use such content.
WARRANTY DISCLAIMER
THE PROGRAM IS PROVIDED "AS IS" WITHOUT
WARRANTY OF ANY KIND, EITHER EXPRESSED OR
IMPLIED, INCLUDING, BUT NOT LIMITED TO THE
IMPLIED WARRANTIES OF MERCHANTABILITY,
FITNESS FOR A PARTICULAR PURPOSE, TITLE OR
NON-INFRINGEMENT. THE ENTIRE RISK AS TO THE
QUALITY AND PERFORMANCE OF THE PROGRAM
IS WITH YOU. SHOULD THE PROGRAM PROVE
DEFECTIVE, YOU (AND NOT THOMSON, ITS
SUPPLIERS, ITS AFFILIATES OR ITS DEALERS)
ASSUME THE ENTIRE COST FOR ALL NECESSARY
REPAIR OR CORRECTION.
This exclusion of warranty may not be allowed
under some applicable laws. As a result, the
above exclusion may not apply to you, and you
may have other rights depending on the law that
applies to you.
LIMITATION OF LIABILITY
a) TO THE MAXIMUM EXTENT PERMITTED BY
APPLICABLE LAW, IN NO EVENT SHALL
THOMSON, ITS AFFILIATES, OR ITS DEALERS BE
LIABLE FOR ANY SPECIAL, INCIDENTAL,
INDIRECT OR CONSEQUENTIAL DAMAGES
WHATSOEVER (INCLUDING, WITHOUT
LIMITATION, DAMAGES FOR LOSS OF PROFITS,
BUSINESS INTERRUPTION, CORRUPTION OF
FILES, LOSS OF BUSINESS INFORMATION OR
ANY OTHER PECUNIARY LOSS) REGARDLESS
OF CAUSE OR FORM OF ACTION, INCLUDING
CONTRACT, TORT OR NEGLIGENCE, ARISING
OUT OF THE USE OF OR INABILITY TO USE THE
PROGRAM, EVEN IF THOMSON HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES.
BECAUSE SOME STATES AND JURISDICTIONS
DO NOT ALLOW THE EXCLUSION OR
LIMITATION OF LIABILITY OF CONSEQUENTIAL
OR INCIDENTAL DAMAGES, THE ABOVE
LIMITATION MAY NOT APPLY TO YOU.
b) YOU ASSUME RESPONSIBILITY FOR THE
SELECTION OF THE APPROPRIATE PROGRAM
TO ACHIEVE YOUR INTENDED RESULTS, AND
FOR THE INSTALLATION, USE, AND RESULTS
OBTAINED.

EN
End User License Agreement
THIRD PARTY SOFTWARE
ANY THIRD PARTY SOFTWARE THAT MAY BE
PROVIDED WITH THE PROGRAM IS INCLUDED
FOR USE AT YOUR OPTION. IF YOU CHOOSE TO
USE SUCH THIRD PARTY SOFTWARE, THEN SUCH
USE SHALL BE GOVERNED BY SUCH THIRD
PARTY'S LICENSE AGREEMENT, AN ELECTRONIC
COPY OF WHICH WILL BE INSTALLED IN THE
APPROPRIATE FOLDER ON YOUR COMPUTER
UPON INSTALLATION OF THE SOFTWARE.
THOMSON IS NOT RESPONSIBLE FOR ANY THIRD
PARTY’S SOFTWARE AND SHALL HAVE NO
LIABILITY FOR YOUR USE OF THIRD PARTY
SOFTWARE.
GOVERNING LAW
This Agreement is governed by the laws of the
State of Indiana, U.S.A. without regard to its
conflict of laws.
GENERAL TERMS
This Agreement can only be modified by a
written agreement signed by you and Thomson,
and changes from the terms and conditions of
this Agreement made in any other manner will
be of no effect. If any portion of this Agreement
shall be held invalid, illegal, or unenforceable,
the validity, legality, and enforceability of the
remainder of the Agreement shall not in any way
be affected or impaired thereby. This Agreement
is the complete and exclusive statement of the
agreement between you and Thomson, which
supersedes all proposals or prior agreements,
oral or written, and all other communications
between you and Thomson, relating to the
subject matter of this Agreement.

EN
Table of Contents
The descriptions and characteristics given in this document are given as a general indication and not as a guarantee. In
order to provide the highest quality product possible, we reserve the right to make any improvement or modification
without prior notice. The English version serves as the final reference on all products and operational details should
any discrepancies arise in other languages.
1
FCC Information
Safety Information
Important Information
Important Safety Instruction
End User License Agreement
Table of Contents . . . . . . . . . . .1
Before You Begin . . . . . . . . . . .2
Unpacking your unit . . . . . . . . . . .2
What’s so special about this Portable
Multimedia Player? . . . . . . . . . . . .2
Computer system requirements . . .2
Inserting battery into the player . .3
Inserting a Compact Flash Card . . .3
Connecting the player to your
computer . . . . . . . . . . . . . . . . . . . .4
General Controls . . . . . . . . . . .5
Menu Settings . . . . . . . . . . . . .7
Menu operations . . . . . . . . . . . . . .7
Library . . . . . . . . . . . . . . . . . . .8
Playback audio and video files . . . .8
Music mode . . . . . . . . . . . . . . . . . .9
Browsing Images . . . . . . . . . . . . . .9
Delete Files . . . . . . . . . . . . . . . . . .10
AV Recorder . . . . . . . . . . . . . .10
Making Connections . . . . . . . . . .10
Setting Resolution . . . . . . . . . . . .10
Setting Recording Quality . . . . . .11
Recording . . . . . . . . . . . . . . . . . . .11
Timer Recording . . . . . . . . . . . . . .11
Starting Time . . . . . . . . . . . . . .11
Duration . . . . . . . . . . . . . . . . .11
Finding Recorded Files . . . . . . . . .11
Recording Display . . . . . . . . . . . . .12
Voice Recorder . . . . . . . . . . . .13
Setting Recording Quality . . . . . .13
Recording . . . . . . . . . . . . . . . . . . .13
Recording Display . . . . . . . . . . . . .13
Settings . . . . . . . . . . . . . . . . .14
Backlight . . . . . . . . . . . . . . . . . . .14
Language . . . . . . . . . . . . . . . . . . .14
TV Out . . . . . . . . . . . . . . . . . . . . .14
Built-in Speaker . . . . . . . . . . . . . .14
Powersave . . . . . . . . . . . . . . . . . .14
Beep . . . . . . . . . . . . . . . . . . . . . . .14
Format . . . . . . . . . . . . . . . . . . . . .15
Update . . . . . . . . . . . . . . . . . . . . .15
Restore Defaults . . . . . . . . . . . . . .15
Time & Date . . . . . . . . . . . . . .16
Date Format . . . . . . . . . . . . . . . . .16
Date Setting . . . . . . . . . . . . . . . . .16
Time Setting . . . . . . . . . . . . . . . . .16
Information . . . . . . . . . . . . . .17
Memory Usage . . . . . . . . . . . . . . .17
Version . . . . . . . . . . . . . . . . . . . . .17
Demo . . . . . . . . . . . . . . . . . . .17
More Information . . . . . . . . .18
Troubleshooting Tips . . . . . . . . . .18
Check for Updates . . . . . . . . . . . .18
Frequently Asked Questions . . . . .18
US Warranty . . . . . . . . . . . . . .19
Canadian Warranty . . . . . . . .21

EN
2
Before You Begin
Unpacking your unit
When you unpack your new player, be
sure you have removed all the
accessories and documentation. The
items below should have been packed in
the box.
•Portable Multimedia Player
• Video Management CD
• Win98 Driver & Instruction Manual
CD-ROM
•AC/DC adapter
•512MB Compact Flash card
•USBcable
• Audio and video cable
•Earphones
•Key ring
•Li-ion Polymer battery
What’s so special about
this Portable Multimedia
Player?
This player is meant to play MPEG4 video
and mp3 files.
To do so, you need the use of a Windows
computer with USB port , USB cable
(included) and Video management
software.
Computer system
requirements
• Pentium III 500MHz or higher
recommended
• Windows ®98SE, Me, 2000 (SP3 or
higher), or XP
•Internet Explorer 4.0 or higher
•Internet access
• 200MB free hard disk space for the
software
•128MB RAM or above
• CD-ROM drive capable of digital
audio extraction
• USB port (2.0 recommended)
• Sound card

Inserting battery into the
player
1. Remove the battery door by applying
thumb pressure. Slide the battery
door in the direction of the arrow,
then lift the battery door out and off
the cabinet.
2. Insert the Lithium polymer
rechargeable battery. Insure that the
contacts of the battery line up with
the contacts of the player. (Refer to
“Important information” for
important battery information.)
3. Close the door of the battery
compartment.
Inserting a Compact Flash
Card
1. Turn off the unit. Insert a Compact
Flash Card with the label side down
into the card slot on the right side of
the player as illustrated in the diagram
below.
2. To remove the card, push the button
beside the slot twice to eject the
compact flash card.
EN
3
Before You Begin
ON OFF / AV OUT
Compact Flash Card
(not supplied)
Note
The charging light indicator
changes from red to blue when
the battery is fully charged.
Charging light indicator

EN
4
Before You Begin
Connecting the Player to
your computer
1. Lift the cover that is covering the USB
port on the player.
2. Insert the smaller end of the USB cable
to the USB port on the player.
3. Connect the larger end of the cable to
the USB port on the computer tightly.
4. This screen will appear on the display of
the player.
AV INAVOUT
Note
Refer to the Software
Instruction manual for procedures in
setting up USB drivers and
transferring files to the player.
USB CONNECTED !
Tip
Images and video need to be
converted by the bundled video
management software before
browsing in the player.
Note
Make sure audio tracks are
encoded in the mp3 formats at
supported bitrates. Bitrates
supported by the player: mp3 – 32 to
320 kbps. WMA and DRM formats
are not supported.

EN
General Controls
1
2
3
4
5
6
7891011
12
13 15
14
ON OFF / AV OUT
MIC
AV INAVOUT
1. Mic - Records voice in voice recording
mode.
2. AV IN (Black)- Input audio and video
signal when the audio and video cable is
connected.
3. - Slide to lock or unlock the keys of
the player.
4. / /
•In video playback mode:
•slide down to toggle the playback
speed among 1x, 2x, 4x, 8x and 20x
•slide up to toggle the reverse
playback speed among 1x, 2x, 4x, 8x and
20x.
•press in to start and pause playback.
•In audio playback mode:
•slide down to go to the next track
and press in to start playback.
•slide up to go to previous track and
press in to start playback.
•slide down and hold to fast forward
the track.
•slide up and hold to review the
track.
•press in to start and pause playback.
• When browsing photos:
• slide down to go to the next file
•slide up to go to the previous file.
• In menu mode:
• slide down to go to the next option
• slide up to go to the previous option
• press in to select option.
• In AV recording mode:
• press in to turn off or on the speaker.
5

EN
5. - USB connector
6. AV OUT (Green)/
- Ouput audio and video signal when the
audio and video cable is connected.
- Insert the headphones here.
7. - In the main menu mode, press and
hold to turn on/off the unit.
- In playback mode, press to stop playback.
- In menu mode, press to return to previous
menu.
8. - - Press to decrease volume.
- Press to go to the previous page during file
browsing.
9. M - Press to enter menu setting mode
10. + - Press to increase volume.
- Press to go to the next page during file
browsing.
11. - Press to record in audio/video
recording mode.
• In playback mode, press to switch
between speaker and headphone
output.
• In AV recording mode, press in to
switch between speaker and headphone
output.
12. DC - Connects the power cord for battery
charging.
13. Push to eject compact flash card.
14. Compact flash card slot
15. LCD ON/AV OUT - Slide to select between
LCD output or AV output.
General Controls
6

EN
Menu Settings
Menu operations
Press and hold to turn the unit on.
Slide down or slide up to view options and press in to enter a sub-
menu. To exit menu, press .
The menu appears as illustrated below:
Information
Library
AV Recorder
Voice Recorder
Settings
Time & Date
7
Demo

EN
In menu mode, slide down or slide up
to view options. Select Library option
by pressing in .
Select this option to play video, mp3 and
wave files and browse images.
Playback audio and video
files
Selecting Files
Slide down or slide up to select
the audio or video file you want to play.
Press + to go to the next page and - to go
to the previous page.
Playback Controls
Play / pause
•Press in to begin playback.
•Press in once to pause playback,
press again to resume playback.
Stop
•Press to stop playback.
Skipping files
•In audio playback mode, slide down
to go to the next track.
•In audio playback mode, slide up to
go to the previous track.
Scanning files
•In video playback mode, slide down
to toggle the playback speed
among 1x, 2x, 4x, 8x and 20x and slide
up to toggle the reverse playback
speed among 1x, 2x, 4x, 8x and 20x
•In audio playback mode, slide down and
hold to scan forward.
•In audio playback mode, slide up and
hold to scan backward.
Adjusting the volume
•Press + / - to adjust the volume.
Library
8
Note
When video is paused, the following info bar is displayed at the bottom of the screen:
You can slide down to toggle the playback speed among 1x, 2x, 4x, 8x and 20x and slide up
to toggle the reverse playback speed among 1x, 2x, 4x, 8x and 20x.
Remaining time
Paused Elapsed time
00:00:03
00:00:45
00:00:03
00:00:45
2x
2x playback speed
00:00:03
00:00:45
2x
2x reverse playback speed

EN
Switching Audio Output
•Press to select between the
audio output to headphones or built-
in speaker.
Switching Video Output
•Connect the black end of audio and
video cable to headphones jack and
the other end (red,white and yellow
end) to TV input.
•Slide the LCD ON/AV OUT switch on
the back of the unit to “AV output.”
The LCD will turn off and the video
will switch to the TV.
Music Mode
You can change repeat mode while
playing your music.
Repeat
•Press Muntil Repeat is highlighted.
•Press in to select between One,
All or Off to repeat the current file
or repeat all files or turn off repeat
respectively.
Browsing Images
•Slide down or slide up to
select the previous and the next
image.
•Press in to browse the image.
•During image browsing, press Mto
enter “Slide Show” menu. Slide down
or slide up to select ON and
press in to start slide show. To
stop slide show, press .
Library
Tip
Images need to be converted by
the bundle video management
software before browsing in the player.
9
Note
This option can also be changed
in the Settings menu.
Note
In recording mode, press in
to switch between different
audio outputs.
Tip
Open WMA can be converted by
the bundled video management software.
Note
In each playback mode, only
files which belong to that
category will be played. Other files will be
skipped during playback. (For example, in
video playback mode, only video files will
be played. Audio files and images will be
skipped.)
