RCI 1012 User manual

Installation
The RCI 10 Series are for use in a controlled
environment. Installation must be in accordance with all
electrical building and fire codes. Check with the
Authority Having Jurisdiction (AHJ) prior to installation.
The RCI 1012 and 1024 supply solid state regulated DC
power.
Features
Filtered Output Voltage
Maximum AC ripple at full load .280vrms
97.5% Regulation
Short Circuit Protection
The short circuit protection relay prevents damage to
the power supply board in the event of a short circuit.
Fuse Protection
The power supply board and transformer are protected
by a 1 Amp fast blow fuse located on the Printed
Circuit Board.
LED
The green indicator lamp on the cover indicates the
presence of AC voltage.
Provisions for External Fire Panel Contacts, Reset
Contacts and Manual Override Switch.
Options:
Battery Backup, Timer Modules
Cabinet Mounting
Four keyholes are provided on the back of the power
supply cabinet for mounting.
Wiring
- AC power connection to the power supply is made to
the primary transformer leads as shown in Fig. 1 and 2.
- With NR models, the external load (ie. magnetic lock or
strike) is connected to TB1-1 (negative) and TB1-2
(positive).
- For the FPD model connection of an external reset
switch, fire panel disconnect switch, or manual override
switch refer to the separate PDD-FT installation
instruction application diagrams
2-Year Limited Warranty
We will guarantee our products to the original purchaser
against defects in workmanship, materials or operation
subject to ordinary wear and tear as it pertains to
particular installations, No unauthorized person may
attempt repair or tamper with the product.
We assume no liability for consequential or indirect loss
or damage to persons or property as a malfunction or
non function of this product.
We will not warrant against defects due to improper
installation or for uses that our products are not intended.
Our only liability under this warranty is to repair, replace
or refund the original purchase price of the product which
has been returned to us with prior authorization and proof
of purchase. No other guarantee is authorized by or on
behalf of Rutherford Controls Int’l Corp.
Troubleshooting
Problem No DC voltage
Possible Cause Absence of AC power input to supply
Solution Turn breaker on
Possible Cause PDDFT N/ON not energized
Solution Reset power supply
Possible Cause Negative side of power supply not
reaching relay
Solution Check external switch wiring
Possible Cause Blown Fuse
Solution Replace 1 Amp Fuse
Problem AC indicator light will not stay on
Possible Cause Absence of AC power input to supply
Solution Turn breaker on
Problem Low voltage at electric lock
Possible Cause Voltage drop in cabling
Solution Ensure that wire runs use appropriate
cable gauge
©2011 RUTHERFORD CONTROLS INT’L CORP. WWW.RUTHERFORDCONTROLS.COM
USA: 2517 SQUADRON COURT, SUITE 104, VIRGINIA BEACH, VA 23453 •CANADA: 210 SHEARSON CRESCENT, CAMBRIDGE, ON N1T 1J6
PHONE •1.800.265.6630 •519.621.7651 •FAX: [phone] •519.621.7939 •E-MAIL: [e-mail]
ISPS10-1A PCN110045
R07/11SH
INSTALLATION 10 Series Power Supplies
Models 1012 & 1024
®
No Relay With Fire Panel Disconnect
Model 1012NR-1A 1024NR-1A 1012FPD-1A 1024FPD-1A
Power Input 120V, 60Hz
Current Output 600 mA, 40VA 775 mA, 40VA 600 mA, 40VA 775 mA, 40VA
Voltage 12VDC 24VDC 12VDC 24VDC
* UL Tested @ 0.6 p.f.

Fig. 1 No Relay Model in
10" x 10" x 4" deep enclosure.
NOTE:
-Maintain a minimum clearance of
1/4” between power limited and
non-power limited circuits.
- We recommend that all connected
devices be UL Listed.
- Prior to using battery back-up,
check with AHJ to ensure code
compliance.
- All Class I wiring into the unit
must meet ANSI/NFPA 70.
©2011 RUTHERFORD CONTROLS INT’L CORP. WWW.RUTHERFORDCONTROLS.COM
USA: 2517 SQUADRON COURT, SUITE 104, VIRGINIA BEACH, VA 23453 •CANADA: 210 SHEARSON CRESCENT, CAMBRIDGE, ON N1T 1J6
PHONE •1.800.265.6630 •519.621.7651 •FAX: [phone] •519.621.7939 •E-MAIL: [e-mail]
10 Series Power Supply Installation Instructions (Continued)
VOLTAGE
ADJUST
HEAT SINK
WARNING
HOT TO TOUCH
TB1
Factory
Power limited
Class II wiring
AC main input
non-power limited
Class I wiring
TRANSFORMER
12 OR 24 VOLTS
L N
+
-Lock Power
Outputs are Class II
PDD-FT
TRANSFORMER
12 OR 24 VOLTS
VOLTAGE
ADJUST
HEAT SINK
WARNING
HOT TO TOUCH
Factory
Power limited
Class II wiring
AC main input
non-power limited
Class I wiring
Outputs are Class II
See separate PDD-FT
application diagrams
LN
Fig. 2 Fire Panel Disconnect Model
in 10" x 10" x 4" deep enclosure
NOTE:
-Maintain a minimum clearance of
1/4” between power limited and
non-power limited circuits.
- We recommend that all connected
devices be UL Listed.
- Lock output relays on PDD-FT
are separately energized
- Prior to using battery back-up,
check with AHJ to ensure code
compliance.
- Wiring from the Fire Panel Interface
Module to be in accoradance with
NFPA 101, Section 7.6.1.6.2.
- All Class I wiring into the unit
must meet ANSI/NFPA 70.
- Building codes require free egress.
