Rcom MX-BS700R User manual

Love of life begins with "Rcom"
USER'S MANUAL
Ver. 1.1
DIGITAL REPTILE BROODER
MX-BS700R / MX-BL700R
North America Sales & Service www.RcomCo.com
Rcom Reptile Brooder User Manual

North America Sales & Service www.RcomCo.com
Rcom Reptile Brooder User Manual

DIGITAL INCUBATOR 3
4. How to Clean
(1) Instructions for Disassembling and Cleaning
16 ~ 17
1. Introduction
(1) Safety precautions
4 ~ 7
(2) Identification of Parts and Composition
(4) Easy Function Operation
(3) Name & Function of Operation Parts
5. Product Information
(1) Specification
18
3. Function Settings
(1) Return to Factory Setting
11 ~ 15
(2) Temperature, Humidity Setting
(3) How to turn ON/OFF UV LAMP
(5) How to use indoor outlet
(6) How to change outlet time
(4) How to change UV lamp time
(7) How to change Cels./Fahr.
(8) How to turn ON/OFF Sound
2. Brooding
(1) Installation Environment
8 ~ 11
(2) Instructions for Installation
(3) How to Terminate Incubation
(4) Dew Condensation
Introduction
Brooding
Product Information
Function Settings
How to Clean
How to use Rcom REPTILE BROODER
The manufacturer, or the vendor does not take responsibility for any loss of animal life or property
damage caused by user’s carelessness, remodelling/painting, changing purpose of use, outage,
and etc. In order to avoid malfunctions, please use after carefully reading the user’s manual.
Caution : Caution mark against a fault that can cause damage, trouble, or failure of incubation.
Tip : References or useful suggestions in using Rcom product
Mark Explanation
Warning of actions which may be dangerous or cause damage to the incubator.
Prohibited.
Do not disassemble.
Do not touch.
It is necessary to keep.
Remove the power cord from outlet.
Ground Connection for preventing electric shock.
Contents
North America Sales & Service www.RcomCo.com
Rcom Reptile Brooder User Manual

Do not leave an animal alone
for a long time with the door
closed.
Do not use for man.
▶ Death hazard
Do not install under the direct
sunlight.
▶ Risk of fire or interference
with the incubation process.
▶ Injury or death hazard
Do not install in dusty or dirty
environment.
Do not install in excessively
cold or hot conditions,
cigarette smoke, etc.
▶ Risk of interference with
operation.
▶Risk of damage or fire
within the machine.
Do not install in moist or
humid environment.
▶ Risk of fire or electric shock.
Do not turn the machine
upside down.
▶ Water will pour out of the
machine, and view window
can be dropped or damaged.
Install away from heat
sources.
▶ Risk of damage to the
machine case and
interference with operation.
Ensure that the machine is
installed on a stable surface
away from edges.
▶ Risk of damage to machine
and eggs and user from
accidental knocks or drops.
Do not install where children
or other people can touch with
easy.
▶ Risk of electric shock or fire.
If the machine requires repair
disconnect from the power
supply and please contact to
your service center.
Please ensure that no small
objects get into
the holes on the machine.
▶ Risk of electric shock or fire.
Do not disassemble or modify
the machine in any way.
▶ Risk of electric shock or fire.
If the machine sounds
strange or emits smoke
contact your service center.
▶ Risk of electric shock or fire.
Do not use for high-priced
animals.
▶ Risk of knocking the incubator
or accidental interference with
the controls.
DIGITAL INCUBATOR
4
Electrical hazards Be careful the details below when you use.
Setting Cautions Be careful the details below when you use.
Cleaning Cautions Be sure to disconnect the electric cord from the outlet
before cleaning.
Do not pull the cord when
taking out the power cord, and
keep wet hands away from
connecting plug.
Do not use a damaged power
cord or loose outlet.
▶ Risk of electric shock or fire.
▶ Risk of electric shock or fire.
Do not insert multiple
connecting plugs in an outlet.
▶ Risk of fire or electrical
overload.
Never pull the plug out of the
outlet during the incubation
period.
▶Incubation will be interrupted.
Do not twist or crush electric
cord.
▶ Risk of electric shock or fire.
Clean the incubator by a soft
cloth with a neutral detergent.
Do not spray cleanser directly
on the incubator surface.
Do not use chemicals like wax,
benzene, alcohol, thinner,
aromatic, or lubricant, etc.
Brush away dust on the plug
with a dry cloth.
For special cleaning of inner
part per year, contact to the
service center.
▶ If you don't clean the inside of
incubator for a long time, dust
can cause some trouble or a fire.
1. Introduction (1) Safety Precautions
North America Sales & Service www.RcomCo.com
Rcom Reptile Brooder User Manual

Fan
Water tank
(Sold seperately)
This is the point
into which the
fresh air comes.
See the description
on how to operate
the functions.
Please use distilled
water. nomal water
or dirty water can
cause humidity unit
failure.
Ventilating
opening
Water conection
Air-filter
Operation part
Tray
Indoor Outlet
UV LAMP
DIGITAL INCUBATOR 5
Identification of Parts
Power connection (back)
This is where you connect
the power cable.
Silicon hose
Humidity unit,
Air-filter, Temp.& Humi. sensor
It is the window
you can observe
the inside.
window
1. Introduction (2) Identification of Parts
and Composition
North America Sales & Service www.RcomCo.com
Rcom Reptile Brooder User Manual

Name & Function of Operation Parts
DIGITAL INCUBATOR
6
Temperature up
Heater activation lamp
Set
Humidity Up
UV operation lamp
Humidity display
Temperature display
Humidity activation
lamp
Temperature down Humidity Down
Press ON / OFF button
at the same time to
set up UV lamp time
Conversion between
Celsius / Fahrenheit UV lamp ON/OFF
Press ON / OFF button
at the same time to
set up outlet time
1. Introduction (3) Name & Function of
Operation Parts
North America Sales & Service www.RcomCo.com
Rcom Reptile Brooder User Manual

Easy Function Operation
HOLD Set temperature
to the required figure
HOLD Set humidity
to the required figure
rst
HOLD
Keep pressing Temperature Down button until
"H.OFF" comes out.
(HEATER OFF)
H.OFF
HOLD
DIGITAL INCUBATOR 7
Press ON and OFF buttons simultaneously to be
shown "Out" on display then, starts setting mode.
Press “ON” button in once, 1 hour unit of time is
going up, Press “OFF” button to going down the time
in unit of 1 hour .
If you press “SET” button to save the setting.
[Setting range :
OFF, 1~24hours]
[Setting range :
OFF, 1~24hours]
(Outlet)
Out
(UV LAMP)
LEd
How to
change
outlet time
Press + and - buttons simultaneously to be
shown "LEd" on display then, starts setting mode.
Press “+” button in once, 1 hour unit of time is
going up, Press “-” button to going down the time
in unit of 1 hour .
If you press “SET” button to save the setting.
How to
change
UV lamp time
Humidity
setting
Temperature
setting
Factory
setting
How to turn off
heater manually
How to turn off
ventilation fan
manually
How to turn off
humidification
device
manually Keep pressing Humidity Down button until
"UOFF" comes out.
(HUMIDITY OFF)
U.OFF
Keep pressing Temperature Down button until
"H.OFF" appears. Then, press once again so that
"A.OFF" appears.
(FAN OFF)
A.OFF
HOLD
HOLD
1. Introduction (4) Easy Function Operation
North America Sales & Service www.RcomCo.com
Rcom Reptile Brooder User Manual

Rcom Brooder is designed and manufactured to provide convenient use to customers through latest
digital control technology. However, the following requirements must be followed, otherwise it may
have fatal effects on the animal. The inside environment of the Brooder is largely affected by the
installation environment and the equipment is recommended to be installed in a place where there are
minimal noise and shock. An environment with small temperature difference with the surrounding
temperature ranging from 20 to 25
℃ (68~77 ℉ ) and humidity level of 40~60% is recommended.
Careful monitoring is required as the temperature can drop rapidly during the night time. The Brooder
must not be exposed to direct sunlight.
※The equipment may not be automatically controlled by the
environment condition it was set up with if it is not in the
outside environment condition of where the product was
installed (Temperature: 20~25℃(68~77℉) / Humidity: 40~60%).
Instructions for Installation
▶Remove the vinyl cover on the front of the sight class,
then take out the tray and slowly remove the vinyl cover
on the inside.
DIGITAL INCUBATOR
8
Please operate the equipment sufficiently and check to
make sure that the equipment is functioning properly
before putting in the animal.
Installation Environment Be careful the details below when you use.
▶Please loosen a screw of right side of filter
by using a screwdriver.
▶Separte cover by bending Picture ⓐ, ⓑto the left at the
same time and using your fingers or a screwdriver, then
pulling in the direction of Picture ⓒand pulling to the front
of direction in Picture ⓓ. At this point do NOT completely
remove the silicon hose from the cover, but follow Picture
ⓔwhich will allow easier assembly (using tools will help).
2. Brooding (1) Installation Environment
(2) Instructions for Installation
North America Sales & Service www.RcomCo.com
Rcom Reptile Brooder User Manual

DIGITAL INCUBATOR 9
NOTICE
If float switch doesn’t work properly, the water may
overflow.
▶Please check end of floate switch [Fig-2] in humidity tank
[Fig-1] whether it moves to up and down by using your
fingers.
When the products are stored long time, the float switch
may not work smoothly.
▶After using Brooder, if you don’t use Brooder for about one
month, please check end of floate switch whether it moves
to up and down by using your fingers.
▶After checking float switch, please assemble a filter like
the reverse of disassemble.
[Fig-2]
Humidity
tank
[Fig-1]
Up and down
Make sure that
the moving
▶Put UV lamp into socket on the left, turn left to lock.
[ How to UV lamp assemble ]
2. Brooding (2) Instructions for Installation
North America Sales & Service www.RcomCo.com
Rcom Reptile Brooder User Manual

Water can leak onto the floor if the
height of the water container is higher
than the sticker on the side.
If you use Mineral water or Tap water for
humidification, the humidity tank can be
broken easily because of water scales.
We strongly recommend you to use only
“DISTILLED WATER” for your machine, and
Autoelex Co.,Ltd & our distributors do not
indemnify for warranty service not only if
you have any problem with using mineral water,
regular water, tab water and the like but also
if you had improper management or
handling for your machine. In this case,
Autoelex Co.,Ltd. & our distributors will
charge for your after service.
▶The equipment operates when the power
cord is connected to the back of the main body
as in [Fig-B] and the power plug is connected to
the power outlet .
Do not place the humidifying water
container on top of the Brooder when using.
▶Open the water cap on the back right side and plug
the silicon hose into the nipple as in [Fig-A],
then plug the tip into a filled humidifying water
container (sold separately). Fill the water
case after installing the product in a place
you want, since moving the product when
it is filled with water may cause product
malfunction.
[Fig-B]
Water
tank
Water
tank
DIGITAL INCUBATOR
10
[Fig-A]
O
P
E
N
Back
(2) Instructions for Installation
2. Brooding
North America Sales & Service www.RcomCo.com
Rcom Reptile Brooder User Manual

▶There is no separate power switch on this product. The equipment turns off when the power cord is unplugged.
▶To start using again, simply re-connect the power.
▶You can operate the equipment on minimal consumption power if you turn off the temperature function and
humidity function.
How to Terminate Brooding
Power Cord
HOLD
▶In case of large temperature difference between equipment interior and installation environment, water can
leak onto the window, tray or the floor. This is a natural phenomenon and may happen more severly under more
humid conditions. To minimize condensation effects, the equipment must be installed in a place where the
temperature difference between equipment interior and installation environment is small.
▶If the equipment is turned off in the middle of operation, humidity remaining inside the equipment may cause
water drops (dew) to stick on to the surface. To prevent this, the equipment should be turned off after the internal
humidity is eliminated by emptying the humidifying water container and running the equipment for about one
hour before turning it off.
▶If not using the equipment for a long period of time, open the window on equipment and dry the interior of the
equipment for about a day in a well-ventilated place.
※The electronic areas of the equipment are treated with special coatings against humidity.
DIGITAL INCUBATOR 11
Dew Condensation
▶If you unplug the power cord and re-plug while the SET
button is pushed, “rSt” will appear on the display unit and
the equipment will be initialized to a setting when it was
first released from the factory.
▶Used to initialize equipment to a setting when it was first
released from the factory in case where the input value
is changed due to mal-operation of equipment.
Return to Factory Setting
2. Brooding
3. Function Settings
(3) How to Terminate Brooding
(4)Dew Condensation
(1) Return to Factory Setting
North America Sales & Service www.RcomCo.com
Rcom Reptile Brooder User Manual

▶Set the temperature using the TEMP+/TEMP- button
while the SET button is pushed. The selected value is
automatically entered when the button is released.
[Instructions for setting ventilation function ON/OFF]
ON : Set the temperature to 20
℃ or higher by pushing the
TEMP+ button while the SET button is pushed.
OFF : Pushing the TEMP- button when the heating function
is OFF will stop the ventilation function and A.OFF
will appear on the display unit.
[Instructions for setting heating function ON/OFF]
ON : Set the temperature to 20
℃ or higher by pushing the
TEMP+ button while the SET button is pushed.
[Default : ON]
OFF : After setting the temperature to 20
℃ or higher by
pushing the TEMP+ button while the SET button is
pushed, pushing the TEMP- button once will stop the
heating function and H.OFF will appear on the display
unit.
※The display unit shows current temperature even when the heating and ventilation functions are stopped.
When the ventilation fan is stopped, there might be slight deviation between the displayed temperature and the
actual temperature as air is poorly circulated.
◀ ▶
Current temp and H.OFF
will show on display in
turn while you set “OFF”
to heating function.
◀ ▶
Current temp and A.OFF
will show on display in
turn while you set “OFF”
to Circulating function.
DIGITAL INCUBATOR
12
Temperature Setting
(2) Temperature,
Humidity Setting
3. Function Settings
North America Sales & Service www.RcomCo.com
Rcom Reptile Brooder User Manual

▶Set humidity using the HUMI+/HUMI- button while the
SET button is pushed. The selected value is automatically
entered when the button is released.
※The display unit shows current humidity level even when the humidifying function is stopped. When the
ventilation fan is stopped, there might be slight deviation between the displayed humidity and the actual
humidity as air is poorly circulated.
Please be sure
to re-fill the
water when “Et”
alarming on
the display
[Instructions for setting humidifying function ON/OFF]
ON : Set the humidity to 40% or higher by pushing the
HUMI+ button while the SET button is pushed.
[Default : ON]
OFF : After setting the humidity to 40% or higher by pushing
the HUMI+ button while the SET button is pushed,
pushing the HUMI- button once will stop the humidifying
function and U.OFF will appear on the display unit.
◀ ▶
Current temp and A.OFF will show on display in turn while
you set “OFF” to Ventilation fan function
please set “off” to heating in case you do not want to
activate the heating, Heating unit lifespan will be more
longer.
Humidity Setting
When releasing from the factory, temperature and humidiy was corrected to be optimized according to
international standard. If necessary, recorrection is possible, however, it isn’t desirable for users to correct
it directly. In case that correction is necessary, please contact Rcom homepage (www.Rcom.co.kr→data
center → Instruction manual categoty) or place where you purchased to inquire about it. As low price
thermometer and hygrometer easy to purchase in the open market have much deviation of estimate value,
it is desirable to use corrected thermometer and hygrometer for exclusive use.
[thermometer and hygrometer for exclusive use – See Rcom homepage]
DIGITAL INCUBATOR 13
(2) Temperature,
Humidity Setting
3. Function Settings
North America Sales & Service www.RcomCo.com
Rcom Reptile Brooder User Manual

How to turn ON/OFF UV LAMP
▶Press “DIMMER” button then, you can turn UV lamp on
or off.
How to use indoor outlet
▶You can put plug into socket on the right side of the product
It does not match the shape of plug and concentric plug,
an adapter must be purchased separately for use.
How to change UV lamp time
▶Press + and - buttons simultaneously to be shown "LEd"
on display then, starts setting mode.
Press “+” button in once, 1 hour unit of time is going up,
Press “-” button to going down the time in unit of 1 hour.
If you press “SET” button to save the setting.
The allowable load is 100W or lower.
The use of outlet above the allowable load can cause
the failure or fire. Be careful about that.
Outlet (indoor)
DIGITAL INCUBATOR
14
(3) How to turn ON/OFF UV LAMP
(4) How to change UV lamp time
(5) How to use indoor outlet
3. Function Settings
North America Sales & Service www.RcomCo.com
Rcom Reptile Brooder User Manual

DIGITAL INCUBATOR 15
▶If you push the ℃/℉button, the LED will blink alternatively
from "℃" ↔ "℉".
[Default setting : ℃]
◀ ▶
◀ ▶
ON : If you push the TEMP+ button for 5 seconds all sounds
are turned on and “S.ON” will appear on the display unit.
[Default : ON]
OFF : If you push the TEMP+ button again for 5 seconds all
sounds are turned off and “S.OFF” will appear on the
display unit.
How to turn ON/OFF Sound
How to change Cels./Fahr.
How to change outlet time
▶Press ON and OFF buttons simultaneously to be shown
"Out" on display then, starts setting mode.
Press “ON” button in once, 1 hour unit of time is going up,
Press “OFF” button to going down the time in unit of 1 hour.
If you press “SET” button to save the setting.
3. Function Settings (6) How to change outlet time
(7) How to change Cels./Fahr.
(8) How to turn ON/OFF Sound
North America Sales & Service www.RcomCo.com
Rcom Reptile Brooder User Manual

Instructions for Disassembling and Cleaning
The Brooder power cord must be separated from the
power outlet.
DIGITAL INCUBATOR
16
▶pull out the power cord from the connection jack on the
back and disconnect the power plug from outlet.
Power Cord
▶Unscrew with driver.
▶Separte cover by bending Picture ⓐ, ⓑto the left at the
same time and using your fingers or a screwdriver, then
pulling in the direction of Picture ⓒand pulling to the front
of direction in Picture ⓓ. At this point do NOT completely
remove the silicon hose from the cover, but follow Picture
ⓔwhich will allow easier assembly (using tools will help).
▶Brush and wash.
Take UV lamp away from socket,
keep it in safe place.
4. How to Clean (1) Instructions for
Disassembling and Cleaning
North America Sales & Service www.RcomCo.com
Rcom Reptile Brooder User Manual

▶Assemble in the reverse order of separation and store.
▶Take out the tray and wipe the inner surface of the sight
glass with a soft cloth.
▶Plug silicon tube into ⓖof humidifier in [Fig-4].
Do not clean the incubators with benzene or thinner,
it can cause modify or bleach.
DIGITAL INCUBATOR 17
Please do not touch the humidity unit. It can cause
body burn.
Cleaning cycle of air filter and humidifying container :
Air filter should be washed with water once every week
and replaced every 6 months~1 year.
(May vary according to time of usage) The humidifying
container should also be washed once every week.
It is recommended to use distilled water in order to
minimize debris (scale) from collecting around the
humidifying container. If you wish to use different
water please ask your vendor first.
(Underground water and lime water cannot be used)
Clean once every week.
Humidifier malfunction caused by debris(scale)
collected around the humidifying container from
poor cleaning is considered to be the customer’s
fault and repair will be charged even during the
warranty period.
▶Remove connector. Be careful that the connector ⓔdoes
not go into the equipment. [Fig-2]
▶Thoroughly clean the inside of the humidifier
once every week. If not cleaned well the
water level sensor (float switch) will not work
and cause malfunctions.
(Repair for humidifier malfunction due to poor
cleaning will be charged even during the warranty
period)
▶Take out float ⓕby slightly spreading using your
hand and clean the scale inside humidifying
container.
[Fig-3] (Clean once every week)
▶Take out the humidifying container in the direction of the
arrow. Take out the air filter, wash thoroughly with water
and dry. [Fig-1] NOTICE
Humidity
tank
Air-filter
[Fig-1]
[Fig-2]
[Fig-4]
[Fig-3]
4. How to Clean (1) Instructions for
Disassembling and Cleaning
North America Sales & Service www.RcomCo.com
Rcom Reptile Brooder User Manual

AC 100~120[V], 50/60[Hz] / AC 220~240[V], 50/60[Hz]
Temp. Control Range
Outside Environment Temp.
Ambient temperature ~ 38[℃] (Ambient temperature ~ 100.4[℉])
Optimal range : 20 ~ 25[℃] (68~77[℉])
Outside Environment Humi. 40 ~ 60[%]
Humidity control 40 ~ 60[%] (Subject to change depending on the ambient environment)
Power Consumption Average 60[W] Average 75[W]
Product Size
FUSE Standard 250[V] 5.0[A] (Ø6*30[mm])
(W)655×(L)470×(H)440[mm] (W)855×(L)470×(H)440[mm]
Product Weight 9.7[Kg] 10.7[Kg]
Power
Model. NO MX-BS700R MX-BL700R
1-1 Name : Rcom REPTILE BROODER
1-2 Model : MX-BS700R / MX-BL700R
Specification
We are not allowed to extend warranty therefore we ONLY provide 1 year warranty service.
If you do not register, we provide limited warranty service for 1year based on factory releasedate.
You will be asking for service charge if you are in below cases.
1. Broken or Problem caused by ‘No cleaning’ or ‘Improper handling’
2. Broken or problem caused by ‘Not using distilled water’
3. Broken or problem caused by ‘Trying Reptile hatching in incubator’
(Please don’t try Reptile hatching in incubator. Please use Hatcher during Reptile hatching.)
4. Broken or problem caused by ‘Wrong controling(Using)’
5. Broken or Problem caused by using the machine out of User’s Manual.
6. Broken or problem caused by ‘Customer’s mistake or fault’
※Product Registration Procedures
If you are a new member of Rcom, you need to log in our website at www.Rcom.co.kr
1. Click “SIGN UP” on top of the right corner.
2. Fill out the information on the blanks.
If you already registered your information on the Rcom website, please log in to
www.Rcom.co.kr.
1. Click “Login” on top of the right corner.
2. Select “Customer” and click “Register Products”.
3. Fill out the information on the blanks.
You will need below information to register on our website.
1. Your name
2. Your (home/company) address & Email address, country
3. Your product(model) name & Serial number
4. Date of purchase & Name of purchased shop you bought from
DIGITAL INCUBATOR
5. Product Information (1) Specification
18
North America Sales & Service www.RcomCo.com
Rcom Reptile Brooder User Manual

Rcom Reptile Brooder User Manual

RcomCo.com

SELLER



MANUFACTURER
● OFFICE : 218, Sangdong-ro, Sangdong-myeon,
Gimhae-si, Gyeongsangnam-do, 50805
South Korea
North America Sales & Service www.RcomCo.com
Rcom Reptile Brooder User Manual
www.RcomCo.com
