RCTimer Ares F7 Service manual

REVISED APRIL 2020
1 Copyright @ 2020, RCTIMER
Features
▸STM32F722 Cotex-M7 MCU 216MHz with 512KB Flash
▸ICM20602 6-axis Gyro & Accelerometer
▸BMP280 Barometer
▸SLC NAND SPI FLASH 128MB
▸Built-in OSD
▸Full dc-dc power rails 3.3V/0.5A, 5V/2A and 9V/1.5A
▸Core 5V & USB power rails with advanced power mux function
▸9V power on/off can be controlled by transmitter
▸Exclusive connector for Ares 60A 4IN1 ESC and DJI FPV Air Unit Module
▸4 default ESC signal channels and up to 6
▸5 UART serial ports
▸Cam control rc filter circuit compatible with most cameras
▸Dimensions 37x37mm and mounting hole 30.5x30.5mm
▸Voltage 3~4S (DJI air module used) or 3~8S
Ares F7
FPV RACE FLIGHT CONTROLLER
Quick Reference Manual

REVISED APRIL 2020
2 Copyright @ 2020, RCTIMER
Wiring Diagram
▸Receiver
TOP VIEW
S.BUS GND
R5V
RX1
TX1
GND
5V
S.BUS
Smart Port
FPORT GND
R5V
TX1
GND
5V
FPort/S.Port
CRSF GND
R5V
RX1
TX1
GND
5V
CH1
CH2
PPM GND
R5V
TX1
GND
5V
PPM DJI
Air Module
DSM 3.3V
IBUS 5V GND
3V3/R5V
RX1
GND
VCC
DSM/IBUS
TX
GND
HDL
VCC
GND
RX
RX1 TX1
GND R5V 3V3
◆Only the R5V pad can be powered via USB. To ensure easy debugging when the baery is not connected, the
5V wire of receiver must be connected to R5V instead of other 5V pads.
◆Please follow the diagram on this page to connect the desired type of receiver.
Exclusive cable in package
RX2 GND RX4 TX4 GND VCC

REVISED APRIL 2020
3 Copyright @ 2020, RCTIMER
Wiring Diagram
▸Camera & Video TX Module
TOP VIEW
CAM GND
9V
CAM
B6
GND
VCC
VIDEO
OSD
VTX
Smart Audio
IRC Tramp GND
9V
VTX
TX2/3/4/5
GND
VCC
VIDEO
VTX CTRL
GND 9V TVX
◆Most CAMs and VTXs supports a wide voltage range. For beer low-pass ltering performance, please connect
their power wires to the 9V pads.
◆The 9V remains ON in the inial state, it can be controlled ON/OFF by a PINIO funcon through the user1
mode switch.
CAM 9V GND
B6
TX2
TX3
TX4
TX5

REVISED APRIL 2020
4 Copyright @ 2020, RCTIMER
Wiring Diagram
▸ESC - Ares 4IN1 ESC
BOTTOM VIEW
◆An exclusive 10p cable for the ESC included in the package use to connect the two white connectors on the
back of them in front. In this case, It is not necessary to use the rear half-hole pads to supply power.
◆The telemetry output wire is connected to the RX5 by default.
◆You can also solder wires to the 9 half-hole pads in their front, but this is not necessary.
GND RX5 M4 M3
M2 M1 GND
GND VCC VCC
GND TLM M4 M3
M2 M1 GND
GND VCC VCC

REVISED APRIL 2020
5 Copyright @ 2020, RCTIMER
Wiring Diagram
▸ESC - other ESCs
TOP VIEW
◆Separate ESC
◇The ESC signal pads in the four corners are the same with the front half-hole pads.
◆4IN1 ESC
◇A 10p single plug cable included in the package use to connect 4IN1 ESC to the white connector on the back of
FC in front. Refer to the previous page for connector locaon.
GND
M4
GND GND M4
M1 M2
M3
GND
M2
GND
M3
GND
M1

REVISED APRIL 2020
6 Copyright @ 2020, RCTIMER
Wiring Diagram
▸LED strips , Buzzer and Compass
TOP VIEW
◆The IN pad of the LED strips needs to be connected to the LED output pad of the FC.
◆Use a 5V acve buzzer to connect to the BZ + and BZ- pads and be careful not to reverse them.
BZ + means output 5V voltage.
5V
LED
SDA
SCL
GND
BZ+
BZ-
GND
5V
+
-
IN
5V
GND
COMPASS

REVISED APRIL 2020
7 Copyright @ 2020, RCTIMER
Wiring Diagram
▸RSSI, current and voltage sensor
TOP VIEW
◆The RSSI pad mark SR compable analog signal.
◆The current sensor that needs to be used must rst know its output rao and the signal wire is connected to
the SI pad. The default rao of Ares F7 is 366.
◆Ares F7 is powered directly by the baery so it does not have a signal input pad. The onboard voltage divider is
congured to 110.
SI SR

REVISED APRIL 2020
8 Copyright @ 2020, RCTIMER
Wiring Diagram
▸Power supply
TOP VIEW
◆Ares F7 supports 8 ~ 40V direct input voltage, due to the limitaon of DJI Air module and the stability of BEC
output voltage, 3 ~ 4 cells is usually recommended.
◆Ares F7 has 3 pairs of power and ground pads onboard, In the case of using Ares 4IN1 ESC in combinaon, the
rear pads do not need to be connected.
◆Only R5V pads can provide 5V to power a receiver with only USB power supply.
BATTERY
BATTERY
