RDL RU-RA3R User manual

ACCESSORIES
Model RU-RA3R
Rack adapter for RACK-UP series
The RU-RA3R rack mounts 3 RACK-UP modules in fixed or mobile installations. Metal RACK-UP series products drop into the chassis,
slide into position and are secured by tightening two screws provided with the RACK-UP product or accessory.
Front Rear
With Product Installed
(RU-MX5ML, RU-SM16A and RU-SP1 Available Separately)
RDL •659 6th St. •Prescott, AZ., USA 86301 •[phone] •FAX [phone] •www.rdlnet.com

ACCESSORIES
Model RU-RA3R
Rack adapter for RACK-UP series
891-3152A
STEP #2
Place the RACK-UP unit onto the chassis. The screw heads
will pass through the rear position in the cutout.
STEP #3
Slide the unit forward until the screws are seated in the
forward position of the cutout. Tighten the screws to
secure the unit in the chassis.
If desired use the rectangular cut outs in the chassis to secure
wiring with hook and loop fastener or wire-ties. The small
holes can be used for ground wire attachment.
STEP #1
Start the screws into the bottom of the RACK-UP unit but
do not install them all the way.
(Bottom View)
(Bottom View)
Radio Design Labs Technical Support Centers
U.S.A. [phone], [phone]; Fax: [phone]
Europe [NH Amsterdam] (++31) 20-6238 983; Fax: (++31) 20-6225-287
NOTE: When installing a RACK UP product that is in a
plastic box start by removing the screws from the back
of the RACK UP. Bend the tabs on the mounting unit up
at a 90° angle. Secure the unit to the mounting chassis
using the screws.
Installation/Operation
Declaration of Conformity available from rdlnet.com.
Sole EMC specications provided on product package.
Specications are subject to change without notice.
