READY To ASSEMBLE HEADBOARD User manual

Adult assembly
HEADBOARD
Page 1 of 3
1
2
3
A
B
B
B
A
A
A
Instructions apply for bed sizes
TWIN > FULL
PARTS LIST HARDWARE
JCB M6 X 120mm (4 3/4”) - 4 pcs
Spare - 1 pc
A
BBarrel nut - 4 pcs
Spare - 1 pc
READY
ASSEMBLE
TO
ASSEMBLY INSTRUCTIONS
Before assembling your headboard, please read through these
instructions carefully and familiarize yourself with the different parts.
Split washer - 4 pcs
Flat washer - 4 pcs
JCB M6 X 25mm (1”) - 4 pcs
HARDWARE FOR METAL BED FRAME
Spare - 1 pc
Spare - 1 pc
Spare - 1 pc
E
D
C
FAllen wrench - 1pc
Spare - 1pc
If you purchased a wood headboard to attach to metal bed frame, please refer to page 3.
NOTE: WE INCLUDE SPARE HARDWARE IN CASE DAMAGE OCCURS DURING ASSEMBLY.
BACK VIEW
A
B
Step 1 Remove packing stick (4) from headboard panel (1) and DISCARD.
HEADBOARD PANEL 1 PC
1
2
3
4
1 PC
1 PC
2 PCS
LEFT LEG
RIGHT LEG
PACKING STICK
1
4
4
Step 2 Attach the legs (2) and (3) to headboard panel (1),
using JCB (A) and barrel nut (B).
Tighten with the Allen wrench (F).
FRONT VIEW
TAPER INSIDE AND
HOLES TO THE FRONT.

WOOD BED FRAME
Your bed can be assembled using an open footrail or panel footboard. The
open footrail has a choice of tall or short legs.
Storage drawers, Trundle bed or mattress only use TALL LEGS.
Storage drawers, Trundle bed or mattress only use UPPER PINS.
The side rails can be attached to either the upper set of pins or lower set of pins.
Foundation and mattress use SHORT LEGS.
Foundation and mattress use LOWER PINS.
SHORT LEGS
LOWER
TALL LEGS
FOOTRAIL
PANEL FOOTBOARD
UPPER
Adult assembly
Page 2 of 3

Adult assembly
ASSEMBLY INSTRUCTIONS
Before assembling your bed, please read through these
Metal bed frames are sold separately from wood headboards. The hardware shown on this page
is supplied with your wood headboard for attaching the bed frame to the headboard. The metal
bed frame is supplied with its own assembly instructions and hardware.
instructions carefully and familiarize yourself with the different parts.
ATTACHING HEADBOARD TO METAL BED FRAME
Attach the headboard assembly to the metal frame using JCB (C), flat washer (D),
and split washer (E) then tighten with Allen wrench (F), as shown below.
Congratulations!
Allen wrench M4
F
C
C
E
E
D
D
Instructions apply for bed sizes
Twin > Full
JCB M6 X 1”
C
Flat washer
Split washer
D
E
Page 3 of 3
Your bed is now ready for use.
HEADBOARD
To ensure lasting safety, we recommend that you periodically check
that all screws are tight and all parts are secure.
Step 1
